HobbyZone J-7 commando User manual

INSTRUCTIONS
Get ready to rumble with your J-7 Commando Cross Country Assault Vehicle. But before the fun begins,
it’s very important that you read these instuctions completely and follow the directions carefully.
STEP 1. Charge battery
• Insert 6V battery into charger.
• Plug charger into 110V AC wall outlet.
• The battery should be charged for 3 hours prior to first use.
Subsequent charges should also be 3 hours.
• When the battery becomes warm, it is fully charged.
Stop charging immediately.
NOTE: For best battery
performance, deplete each
charge before re-charging.
When the battery is low,
run your vehicle until the
motor stops completely.
Your battery is now
depleted and can
be recharged.
STEP 2. Install battery in transmitter
• Open the battery cover on the back of the transmitter.
• Check for positive and negative poles, then install 9V battery pack.
• Close cover.
NOTE: You'll get about 8 hours of operation with this battery—
it is not rechargeable.
Antenna
Right Stick
(control right wheels)
Left Stick
(controls left wheels)
®Wall Charger
Wall Charger
110V AC
Wall Outlet
Transmitter
6V Rechargeable Ni-Cd Battery
6V Rechargeable
Ni-Cd Battery
9V
Transmitter
Battery
9V Transmitter
Battery
Back of Transmitter

4600
HBZ5000 J-7 Commando RTR, 27MHz (Green) $59.99
HBZ5005 J-7 Commando RTR, 49MHz (Tan) $59.99
HBZ5010 6V 600mAh Ni-Cd Battery $9.99
HBZ5011 3-Hour Wall Charger $6.99
HBZ5012 6V Battery/Wall Charger Combo $14.99
HBZ5015 TX Only: 27MHz $9.99
HBZ5016 TX Only: 49MHz $9.99
HBZ5017 TX Antenna $2.99
HBZ5020 Machine Gun $1.19
HBZ5021 Wheel/Tire (1): Green $2.99
HBZ5022 Wheel/Tire (1): Tan $2.99
HBZ5023 Electric Motor $8.99
HBZ5024 Vehicle Battery Door $1.19
The J-7 Commando and accessory parts can be easily purchased at most
hobby shops. For the location of the hobby shop nearest you, please go to
www.horizonhobby.com
© 2002 Horizon Hobby, Inc.
HobbyZone products are distributed exclusively by Horizon Hobby, Inc.
4105 Fieldstone Road, Champaign, IL 61822 www.horizonhobby.com
HBZC5000
Parts & Accessories Retail
Warnings and Safety
• Use only the charger and battery pack supplied for this vehicle.
Do not over charge–when the battery pack becomes warm, remove
from charger. Do not leave charger unattended while charging.
Unplug charger immediately after charging battery.
• Improper use of battery may lead to dangers such as heat, breakage
or leakage which can cause skin and eye irritation or injury. Do not
cut or puncture the battery. Do not charge or store the battery close
to fire, heat or moisture.
• Choose a safe place for operation. Do not run your vehicle on streets
or in traffic areas.
• Do not operate on rainy days, in water or on wet surfaces.
Avoid operation on fine soil or sand. Do not store vehicle near heat
sources or fire.
STEP 3. Install battery in vehicle
• Make sure switch is off.
• Open the battery cover on the underside of vehicle.
• Check for positive and negative poles, then place charged 6V battery
in compartment. Close cover.
NOTE: You'll get about 20 minutes of operation with each charge—
depending on speed and terrain.
STEP 4. You're ready to roll!
Your J-7 Commando operates like a real tank. That means the front and
back wheels on each side work together to drive and steer.
• To move forward, push both left and right sticks forward (1).
• To reverse, push both sticks back (2).
• To turn left, push the right stick forward (3).
• To turn right, push the left stick forward (4).
• For tighter turns and spins, push one stick forward while pulling
the other stick back.
Forward (1)
Right Turn (4) Left Turn (3)
Reverse (2)
