HOLDEN Monaro V2 II 2003 Series User guide

V2 Series II Owner's Handbook.
V2 II Monaro
MONARO
MONARO
www.holden.com.au

Part No. 92158982
May 2003 (V2 series II, Print 1)
Holden Ltd, ABN 84 006 893 232 (hereinafter Holden).
Change of name, address or ownership
In the event of a Safety Recall, or for various reasons, Holden may need to
contact you as the owner of this vehicle. Also, if less than three years old, this
vehicle will qualify for Roadside Assistance, refer to Chapter 9. If you have
recently changed your address, or name, or purchased this vehicle second hand,
please help us to help you by taking a few minutes to fill in and mail the form on
the third page of this handbook. For information about Holden's privacy policy,
please visit Holden's website at www.holden.com.au.
Note: Please refer to the inside front cover of the service
booklet for the Vehicle Identification Certificate.
© 2003 Holden Ltd. Re roduction in whole or art is rohibited without written
a roval from Holden Ltd, ABN 84 006 893 232.
Printed in Australia

Engine starting, running in, use of transmission, anti-lock
braking, traction control, driving precautions and notes
about add on equipment.
Exhaust warning, petrol filling, fuel tank capacity, emission
control, reducing fuel consumption.
Dashboard 1
Locks 2
Know your vehicle 3
Driving 4
Fuel 5
Emergencies 6
Weekly checks 7
Specifications 8
After Sales 9
ow and load 10
Cleaning 11
Index
Instruments, switches, heating, clock, radio,
exterior lights, wipers and washers.
Seats, seat belts, child restraints,
mirrors, windows, park brake,
interior lighting, glovebox, storage
compartments, cup holders.
hecking: oil, coolant, automatic
transmission fluid, power steering fluid,
brake fluid, clutch fluid, washer fluid,
battery, tyre pressure.
Engine and general specifications,
capacities, identification plates,
dimensions.
Warranty, Holden Retailers, Holden Roadside
Assistance, ustomer Assistance.
Interior cleaning, washing, list of maintenance
materials.
CONTENTS
Loading information, towing equipment,
towing precautions.
Keys, locks, doors, alarm, anti-theft, deadlock, bonnet lock.
Accidents, first aid, airbag, towing the
vehicle, flat tyre, engine overheating, flat
battery, fuses, bulb replacement.

We thank you for choosing Holden and want to assure you of
our continuing interest in your driving pleasure and
satisfaction.
This handbook applies to the current Monaro model.
Therefore, due to different models and options, you may find
reference in this Handbook to some equipment not fitted to
your own vehicle.
Please note that all information, illustrations and specifications
in this Handbook are based on the latest production
information available at the time of printing. Holden reserves
the right to make changes at any time without notice and
without incurring any obligation.
eference is made throughout this Handbook to different
engines:
• V6 supercharged engine (labelled
'SUPE CHA GED V6' on the engine)
• V8 engine (labelled '5.7 ALLOY V8' on the engine)
If unsure of which engine is fitted to your vehicle, please lift
the bonnet and check the identification on the top of the
engine.

Original Owner Subsequent Owner
Title: (Mr, Mrs, Miss, Ms, etc.) First name in full or initials
Street / box
City / Town
State Postcode
Address
Surname or Name of ompany / Institution / Government Department
Vehicle registration number
ISOVIN Number (refer to hapter 8)
Please tick the appropriate box:
1st contact phone no
Email address
2nd contact phone no
CHANGE OF ADDRESS OR OWNERSHIP
Please fill in the form below if you have changed your name,
address, bought the vehicle second-hand, or have become the
new driver.
Holden requires these details in order to contact the operator in the
event of a safety recall and to keep the initial 3 year oadside
Assistance details up to date (refer to Chapter 9). For information
about Holden's privacy policy, please visit Holden's website at
www.holden.com.au.
Please mail to the address on the back of this page.
If Holden Assist is fitted, please also press the Assist button on the rear
view mirror to advise of change of address / ownership.
$$ $$
$

Place in an envelope and mail to:
The Manager – Warranty Administration
Service Department
Holden Ltd
Box 548D, G.P.O.
Melbourne
Victoria, 3001

Original Owner Subsequent Owner
Title: (Mr, Mrs, Miss, Ms, etc.) First name in full or initials
Street / box
City / Town
State Postcode
Address
Surname or Name of ompany / Institution / Government Department
Vehicle registration number
ISOVIN Number (refer to hapter 8)
Please tick the appropriate box:
1st contact phone no
Email address
2nd contact phone no
CHANGE OF ADDRESS OR OWNERSHIP
Please fill in the form below if you have changed your name,
address, bought the vehicle second-hand, or have become the
new driver.
Holden requires these details in order to contact the operator in the
event of a safety recall and to keep the initial 3 year oadside
Assistance details up to date (refer to Chapter 9). For information
about Holden's privacy policy, please visit Holden's website at
www.holden.com.au.
Please mail to the address on the back of this page.
If Holden Assist is fitted, please also press the Assist button on the rear
view mirror to advise of change of address / ownership.
$$ $$
$

Place in an envelope and mail to:
The Manager – Warranty Administration
Service Department
Holden Ltd
Box 548D, G.P.O.
Melbourne
Victoria, 3001

Original Owner Subsequent Owner
Title: (Mr, Mrs, Miss, Ms, etc.) First name in full or initials
Street / box
City / Town
State Postcode
Address
Surname or Name of ompany / Institution / Government Department
Vehicle registration number
ISOVIN Number (refer to hapter 8)
Please tick the appropriate box:
1st contact phone no
Email address
2nd contact phone no
CHANGE OF ADDRESS OR OWNERSHIP
Please fill in the form below if you have changed your name,
address, bought the vehicle second-hand, or have become the
new driver.
Holden requires these details in order to contact the operator in the
event of a safety recall and to keep the initial 3 year oadside
Assistance details up to date (refer to Chapter 9). For information
about Holden's privacy policy, please visit Holden's website at
www.holden.com.au.
Please mail to the address on the back of this page.
If Holden Assist is fitted, please also press the Assist button on the rear
view mirror to advise of change of address / ownership.
$$ $$
$

Place in an envelope and mail to:
The Manager – Warranty Administration
Service Department
Holden Limited
Box 548D, G.P.O.
Melbourne
Victoria, 3001

CHAPTER
Dashboard
The following page illustrates the
dashboard, identifying and locating each
function; page numbers refer to each
item.
Page
1-2 Layout
1-4 auges
1-5 Warning / reminder indications
1-14 Turn signals, Horn, Tilt / reach
steering
1-15 Trip computer – single-window
1-20 Trip computer – triple-window
1-27 Customisation mode
1-35 Wipers and washers
1-36 Lights
1-39 Radio / CD and clock
1-41 Remote radio / CD controls
1-42 Antenna
1-43 Phone
1-44 Heater and air conditioner
1-47 Ventilation system
1-48 Climate control
1-55 Cruise control
1-58 Reverse parking aid
1-61 Navigation system
1

1-2
Chapter 1
DASHBOARD
LAYOUT
Page
Alovebox ....................................................................... 3-14
BCup holders (if fitted) ..................................................... 3-18
CVents.............................................................................. 1-47
DSunlight sensor .............................................................. 1-36
EHazard warning switch .................................................. 1-38
FSwitches for (depending on model)
• Air conditioner and heater controls ......................... 1-44
• Climate controls ....................................................... 1-48
GTrip computer switches
• with single-window type........................................... 1-15
• with triple-window type ............................................ 1-20
HLever for wipers and washers ....................................... 1-35
IIn-car temperature sensor ............................................. 1-54
Jauges ............................................................................ 1-4
KLever for:
• turn signal ................................................................ 1-14
• high / low beam ....................................................... 1-38
• cruise control ........................................................... 1-55
LHeadlights dial switch
(incl. front fog lights and dimmer) ........................... 1-36
MRemote radio / CD controls ........................................... 1-41
NIgnition switch / lock ........................................................ 2-9
OHorn pad ........................................................................ 1-14
PTilt steering .................................................................... 1-14
QStorage compartment .................................................... 3-15
RRadio / CD ..................................................................... 1-39

1-3
Chapter 1
DASHBOARD

1-4
Chapter 1
DASHBOARD
GAUGES
Speedometer
The speedometer shows vehicle speed
in kilometres per hour (km/h .
Tachometer
The tachometer shows engine speed
in revolutions per minute (r.p.m. .
Sustained operation in the RED zone
may cause serious engine damage.
Automatic transmission: Under wide
open throttle acceleration (accelerator
pedal pushed flat to the floor it is
possible that the tachometer needle
may briefly touch / enter the lower end
of the tachometer's red zone just prior
to automatically upshifting into a higher
gear. This is normal during wide open
throttle and will not harm the engine.
Fuel gauge
The fuel gauge shows the level of fuel
in the fuel tank when the ignition is
switched on. E = empty F = full
Note: Small additions of fuel (less than
15 litres may take up to 10 minutes to
register on the fuel gauge; larger
amounts will show up almost
immediately. This is designed so that
fuel movement, when cornering, will
not register on the gauge. Also refer to
Chapter 5, FUEL.
Temperature gauge
The temperature gauge indicates the engine coolant temperature when the ignition is
switched on. Stop / start driving in heavy traffic, driving at high speed in warm weather, hill
climbing or towing may cause the needle to move toward the 'H'. This is normal and is not
cause for concern. However, if the needle should move all the way to 'H' and remain there
for more than 30 seconds, you should stop the vehicle as soon as it is safe to do so. Also refer
to ENGINE OVERHEATING in Chapter 6.
Centre display
The instrument panel centre display provides visual information to the driver for a number
of vehicle functions, such as – trip computer, radio, warnings and reminders, etc. Two
types of display are available. Depending on your luxury level, your vehicle is fitted with a
single-window display or a triple-window display. The various functions and their associated
displays are explained later in this chapter and in the following chapters.
Note: Illumination of the gauges is adjusted by moving the tab on the side of the headlights
dial, refer to LIGHTS later in this chapter.

1-5
Chapter 1
DASHBOARD
WARNING / REMINDER INDICATIONS
Trip Computer Switch Centre Display
Warning / Reminder Lights
Warning / reminder indications are provided to the driver via the instrument panel as
illuminated icons, animated symbols or a combination of both. The illuminated icons
appear along the bottom of the instrument panel, below the Temperature and Fuel
gauges. The animated symbols appear on the instrument panel centre display. Most
warning / reminder indications are accompanied by a chime.
Control of the instrument panel display is provided through the trip computer switch. The
switch is located left of the instrument panel.
The trip computer switch has four buttons – MODE, SET,  and .
Display – Ignition on
System Check: When the ignition is turned
on, a vehicle System Check is performed
and the status is shown on the display. If
there are no warnings or service reminders,
the display will show a series of Holden
welcome screens displaying the Holden
logo and finishing with the 'OK!' screen.
Note: Pressing the MODE button any time during the System Check will cause the display
to jump ahead to the last trip computer screen displayed on the last ignition key off. The
System Check will continue to run in the background.

1-6
Chapter 1
DASHBOARD
PRND321
Check
Alternator
WARNING / REMINDER INDICATIONS cont.
If a service reminder is active, it displays for
10 seconds or until the MODE button is
pressed, refer to the service booklet in your
glovebox for details on service displays. Once
the service reminder screen times-out or the
MODE button has been pressed, the display
advances to the system check and welcome
screens.
If the system check detects a problem, it displays the appropriate warning immediately. If
a warning displays, press the MODE button to acknowledge it (once for each warning , the
display jumps ahead to the last trip computer screen displayed before the ignition key was
last switched off.
Options Menu: After the 'System Check' is
completed, the Options Menu displays for
3 seconds if the vehicle speed is under 10 km/
h and no active warnings exist. For details on
the Options Menu, refer to CUSTOMISATION
MODE further on in this chapter.
Trip Display: If the MODE button is pressed
or the screen times-out (3 seconds , the
Options Menu disappears and the trip
computer displays the same functions as
when the ignition was last turned off.
Note: To display the Odometer screen, if not already displayed, tap the MODE button until
the screen displays.
Display – Ignition off
When the ignition is turned off, the Odometer displays on the screen unless a service reminder
is active. Active service reminders display for 10 seconds before the Odometer displays.
WARNINGS AND REMINDERS
The following warning and reminder indications may appear on your instrument panel centre
display (depending on the luxury level of your vehicle .
Alternator
To check that the alternator warning light is working, the p icon illuminates when the ignition is
turned on and remains illuminated until the engine is started.
If the p warning light and 'Check Alternator'
animation illuminate while driving, it indicates
that the alternator is not charging properly and
that you should see your Holden Retailer.
The 'Check Alternator' animation displays until
the MODE button on the trip computer switch is
pressed, whereas the p warning light remains
illuminated until the problem is rectified.
Options Menu
Press or to enter
RND321
P
PRND321
1,500 km
Service

1-7
Chapter 1
DASHBOARD
WARNING / REMINDER INDICATIONS cont.
ABS fault / off
To check that the Anti-lock Brake System (ABS) warning light is working the u icon
displays for a short time when the ignition is turned on.
If the u warning light and 'ABS Fault'
animation illuminate when driving a
malfunction of the Anti-lock Brake System
is indicated and you should see your Holden
Retailer. The vehicle's brake system will still
operate conventionally only the anti-lock
operation is disabled refer to Chapter 4.
The 'ABS Fault' animation displays until the MODE button on the trip computer switch is
pressed whereas the u warning light remains illuminated until the problem is rectified.
Brake fail and park brake warning (if fitted)
To check that the light is working the R icon displays when the ignition is first turned on
and the park brake is applied.
If the R warning light and 'Brake' animation
illuminate while driving and the park brake
is released a fault with the brakes is
indicated. You should immediately stop the
vehicle on the side of the road as carefully
as possible. Do not proceed until satisfied
that braking is possible or that the cause of
the problem has been fixed.
A warning chime sounds if you attempt to drive off without releasing the park brake fully.
The 'Brake' animation displays until the MODE button on the trip computer switch is
pressed whereas the R warning light remains illuminated until the problem is rectified.
Rear brake bulb failure (if fitted)
If the 'Rear Brake Bulb Fail' animation
illuminates while driving a fault in the rear
brake lamps or high mounted brake lamp is
indicated.
The 'Rear Brake Bulb Fail' animation
displays until the MODE button on the trip
computer switch is pressed. The animated
symbol then reverts to the original trip
computer display with a small bulb failure
icon on the left. The icon remains illuminated
until the problem is rectified.
RND321P
ABS
Fault
ABS
RND321P
Brake
Rear Brake
Bulb Fail
RND321P
RND321P
Odometer
012,689 km
B

1-8
Chapter 1
DASHBOARD
WARNING / REMINDER INDICATIONS cont.
Rear lamp bulb failure (if fitted)
If the 'Rear Lamp Bulb Fail' animation
illuminates while dri ing, a fault in the rear
park lamps or the licence plate lamps is
indicated.
The 'Rear Lamp Bulb Fail' animation displays
until the MODE button on the trip computer
switch is pressed. The animated symbol
then re erts to the original trip computer
display with a small lamp failure icon on the
left. The icon remains illuminated until the
problem is rectified.
Rear lamp fuse failure (if fitted)
If the 'Rear Lamp Fuse Fail' animation
illuminates while dri ing, a fault in the rear
stop lamps fuse or park lamps fuse is
indicated.
The 'Rear Lamp Fuse Fail' animation
displays until the MODE button on the trip
computer switch is pressed. The animated
symbol then re erts to the original trip
computer display with a small fuse failure
icon on the left. The icon remains illuminated
until the problem is rectified.
Airbag and seat belt pretensioners
To check that the warning light is working, the SRS icon displays for a short time when
the ignition is first turned on.
If the SRS warning light and 'SRS Airbag
Fault' animation illuminate while dri ing, it
indicates that the airbag system or seat belt
pretensioner system may not function
correctly, especially in an accident. You
should see your Holden Retailer
immediately.
The warning light illuminates after an accident where the pretensioners, or pretensioners
and airbag(s), ha e acti ated.
The 'SRS Airbag Fault' animation displays until the MODE button on the trip computer
switch is pressed, whereas the SRS warning light remains illuminated until the problem
is rectified.
For more information, refer to Chapter 6 for airbags or Chapter 3 for seat belt
pretensioners.
RND321P
SRS Airbag
Fault
RND321P
Odometer
012,689 km
F
PRND321
RearLamp
Fuse Fail
PRND321
RearLamp
Bulb Fail
RND321P
Odometer
012,689 km
L

1-9
Chapter 1
DASHBOARD
WARNING / REMINDER INDICATIONS cont.
Low traction
If the 'Low Traction' animation illuminates
while dri ing, it indicates that the traction
control system has sensed that your ehicle
requires help with road grip and that the
system is acti ely working to stop any wheel
spin.
The 'Low Traction' animation displays until
the MODE button on the trip computer switch
is pressed. The animated symbol then re erts
to the original trip computer display with a
small low traction icon on the left. The icon
remains illuminated as long as the low traction
situation exists. Refer to Chapter 4 for more
information on the traction control system.
Traction control off
If the 'Traction Ctrl Off' animation illuminates
while dri ing, without the traction control
being turned off by the dri er, it indicates the
traction control system is not working and
you should see your Holden Retailer.
The 'Traction Ctrl Off' animation displays for
2 seconds. The animated symbol then re erts
to the original trip computer display with a
small TRAC OFF icon on the right. The icon
remains illuminated until the problem is
rectified. Refer to Chapter 4 for more
information on the traction control system.
Low oil pressure
If the 'Check Oil' animation illuminates when
dri ing, it indicates that the oil pressure is
dangerously low. Stop immediately, turn off
the engine and check the engine oil le el
(refer to Chapter 7 for engine oil le el checking
information). Do not run the engine with this
symbol illuminated. If the oil le el is normal,
ha e the system checked at your nearest
Holden Retailer.
The 'Check Oil' animation displays until the
MODE button on the trip computer switch is
pressed. The animated symbol then re erts
to the original trip computer display with a
small oil can icon on the left. The icon remains
until the problem is rectified.
Low
Traction
RND321P
RND321P
Odometer
012,689 km
Traction
Ctrl Off
OFF
TRAC
RND321P
OFF
TRAC
RND321P
Odometer
012,689 km
Check
Oil
RND321P
RND321P
Odometer
012,689 km

1-10
Chapter 1
DASHBOARD
WARNING / REMINDER INDICATIONS cont.
Over temperature
If the 'Engine Temp Hot' animation
illuminates while dri ing, it indicates that
the engine coolant temperature is
dangerously hot. You should stop the ehicle
as soon as it is safe to do so.
The 'Engine Temp Hot' animation displays
until the MODE button on the trip computer
switch is pressed. The animated symbol
then re erts to the original trip computer
display with a small o er temperature icon
on the left. The icon remains illuminated
until the problem is rectified.
Refer to 'Engine o erheating' in Chapter 6.
Low coolant (with V8 engine)
If the 'Low Coolant' animation illuminates
while dri ing, it indicates that the engine
coolant le el is dangerously low. You should
check the le el as soon as possible, refer to
Chapter 7 for engine coolant le el check
instructions.
The 'Low Coolant' animation displays until
the MODE button on the trip computer
switch is pressed. The animated symbol
then re erts to the original trip computer
display with a small low coolant icon on the
left. The icon remains illuminated until the
problem is rectified.
Low fuel
If the 'Low Fuel' animation illuminates when
dri ing, it indicates that the fuel le el is low.
The 'Low Fuel' animation displays until the
MODE button on the trip computer switch is
pressed. The trip computer then displays
its calculation of kilometres to empty for
10 seconds before re erting to the original
trip computer display with a small low fuel
icon on the left. The icon remains illuminated
until the fuel tank is filled abo e the low fuel
le el.
PRND321
Engine
Temp Hot
RND321P
Odometer
012,689 km
PRND321
Low
Coolant
PRND321
Odometer
012,689 km
RND321P
Low
Fuel
PRND321
Odometer
012,689 km
