HOLLICY SX1628 User manual
Products should be assembled by an adult. Protective equipment should be worn. Not
to be used in traffic. Not suitable for children under 3 years. Choking hazard- small
parts. In unassembled state, contains potentially hazardous small parts. Please keep
out of the reach of small children. Pay attention to the potential hazards of using the toy
in areas other than private grounds.
WARNING
Please read the manual before using the product. The manual and carton contain
important information, please keep them properly for later references. If failure to
following the instruction in the manual, it might be dangerous for your child.
In order to improve the product and quality, we may change the parts of structure,
appearance, packing method, assembly method and function of the product
without any notice. When there is any difference between the manual and the
product, please subject to the actual product. We are sorry for any inconvenience.
Model:SX1628
The assembly manual of
battery operated car
Executive standard：
EN71-1
EN71-2
EN71-3
EN62115
ASTM F963
Training wheel
LED LIGHT WHEELS
LED light wheel
PRODUCT SPECIFICATIONS
PARTS LIST
PARTS NAME
PICTURE QTY
Main body
Rear mirror
PARTS NAME
PICTURE QTY
1PC
1PC
1PC
2PC 1PC
2PC
Front wheel
LED light wheel
Tool bag
Battery charger
12V-7AH
PP
36-95 Months
30kg
102x64x45.5cm
3-5KM/Hour
1-2 hours after full charge, based on ride on conditions
input AC 6V-1000mA out DC 12V-1000mA
Auto-reset fuse
Battery
Main material
Suitable age
Weight limit
Product size
Speed
Runtime
Charger
Fuse
DISCLAIMER:
The pictures in this manual are for reference only,
please kindly refer the actual product.
3.Training wheel assembling
aim the traning wheel to the hole
beside the motorcycle, fix with 4
screws. (The traning wheel can
be adjusted up and down)
Front axle
Nut
Nut
Front wheel set
Motorcycle body set
2.Rear mirror assembling
Position the rear mirror on
the steering wheel , insert
it with strength.
Rear mirror
1.Front wheel assembling
Connect the front wheel and
the front fork, (first, press
down the conductive pin on
the front wheel, then align it
with the hole on the front fork),
insert the front axle and fix
with nuts.
ASSEMBLY INSTRUCTION
The car should be assembled by the adults.
Choking hazard, keep children away while assembling.
Children under 3 years are prohibited to use.
Please count all the parts carefully before assembling.
And dispose the plastic bag properly.
Receiver:
The receiver is located
under the seat.
FUSE
This car has the auto-reset fuse, if the car stops
suddenly during driving, it is mainly caused by
instantaneous current exceeds ,and make the
fuse to trip. Then just stop operating for about 8
seconds, and this fuse can be reset.
In order to avoid the fuse tripping and cut off power
supply, please pay attention to the following matters:
This product can't overload, the maximum load is 30kgs.
Don't drag anything behind products.
Don't let the water or other liquid into the batteries and other electrical
components.
Do not change the circuit system and the structure of the product.
WARNING:
This product is not the vehicle for transportation, it should
be used under adult guidance.
Parents should ensure that children have taken the safety
measures before use.
4: Connect the power
The power supply is under the oil tank, take out the screw on the
battery box panel with the tool, open the battery box panel from
one end, expose the battery box, connect with the red plug, you
can connect the power.
Screw
SECURITY WARNING
1.The installation and charging of vehicle should be under adult
supervision at all times.
2.This product is limited to the children from 3 to 8 years, 66 pounds
weight limit, please do not overload.
3.This product is ideal for driving on a hard flat surface.
4.It is strictly prohibited in the streets or the road, pot holes, and slopes.
5.Avoid driving in the sand or grass or uneven ground.
6.Children should be given full instructions on operation of the car.
Improper operation can cause damage or accidents.
7.While children are driving, it is parents' duty to supervise at all time to
avoid accidents.
8.Avoid driving in rains or flooded pathways. By doing so it can damage
the motor, circuit and other electrical equipments.
9.Battery charger should be regularly inspected by parents to insure
whether the wires, plugs, crusts and other components are damaged.
Please stop using if any damage is found, until it is completely
restored.
10.In order to ensure product life and safety, avoid damage to the
charger, battery or electric circuit, the car must use the default
configuration of a dedicated charger and power supply.
11.Rechargeable batteries should be removed from the toy before
charging.
12.When no use of product, please cut off the product power, and keep
all the switch to "stop" or "off" position.
13.The charge provided is not a toy. To be kept away from children.
14.Strictly prohibit using the non-manufacturer provided parts.
15.This product is made of PP material mainly, the safe using time is
two years.
USAGE DIRECTION
1. Before using it, make sure that all the following works are done.
● Step described in accordance with the instructions to complete the
installation of the car, the battery plug-in has been connected, the
power supply has been switched on.
● Make sure that all the positions which need the screws are fixed tightly.
● Parents or guardian should ensure that children have taken the safety
measures before use.
● To reduce the risk during using:
①. When driving the car ,child should sit on the car seat.
②. Only one kid is allowed to use every time.
③. Adults should always supervise their child when the child driving.
④. Adult or parents should take more care and guidance when child
driving and can't leave away.
⑤. Pay attention to the driving environment and driving on the hard flat
surface, not the unsafe environment:
a. The trenches, the riverside, slope or uneven ground;
b. Road or other place for driving and walk;
c. The obstruction which is easily hitting and causing injury;
d. Other unsafely zone.
⑥. Pay attention to the road, trenches, the riverside, slope or uneven
ground.
⑦. Not to be used in public roads.
⑧. The car should be used only in daytime or bright place, avoid using
under low visibility.
⑨. Children can not deal with unexpected obstacles and events.
Fast/Slow:speed
Horn
Lamp on/ off Forward/Backward
Horn
One-start Button
Pedal
MP3 Screen
2. Operating(function reference diagram)
Audio input
Battery indicator
light
Mode
Horn
Short press : music /
Long press: volume up Short press : story /
Long press: Volume
down
Big memory
CHARGING WAY
MP3（optional）
Audio input
Battery indicator
light
Mode
Horn
Short press : music /
Long press: volume up
Short press : story /
Long press: Volume
down
Big memory
·For Safety purpose, battery charging by adults only.
·Fully charged is necessary for first time to use.
.Power OFF before charging,then put the charger into the rear
charging hole.
.Put the power plug into correct voltage of power supply (120V).
·Charge the battery when the motorcycle runs slow, normal
charging
time is 8 -12 hours. Do not exceeded.
.Charge the battery fully before you store away for a long period
of time.
·Do not use incorrect battery or charger.
·Do not mix old and new or different types of batteries.
·The battery terminal should not be short circuit.
·Do not open the battery or charger.
·Do not leave battery up side down when charging.
·Check the charger, battery and the plug before charging.
If there is any broken parts, stop using it immediately.
.Do not use it until it is fully repaired.
·The battery will be little warm when being charged, it is normal. If not,
it may be caused from the short circuit of charger or circuit board.
·Must use the pressing plate to fix the battery.
·Run out of battery must be handled by adults, remove the batteries
which is run out, from toys to recycle properly and shall not be arbitrarily
discarded.
·To extend the lifetime of the battery, fully charge once in every 3 months.
·Charger and Battery are not a toys. Keep it away from children.
1.First insert the plug of the charger into the charging port.
2.Then insert the charger to the power socket. (The car cannot be
started when it is being charged)
Attention:
MAINTENANCE AND SERVICE
1.Parents should check whether all the parts are perfect before
using, like battery, charger, wire, plug, out body and other parts
are broken ,whether the screw is loose. whether there is potential
safety hazard, if found then it has to repair.
2.Use a small amount of lubricating oil for moving parts, to prevent
wear and tear of rust after using the toys for some time.
3.The car should be far away from the fire and avoid sunlight,
store flat, not upside down the car shall be stored indoors or cover
outdoors.
4.The car should be far away from the hot things, like the stove or
heater, the plastic part may melt. When charging ,the car should
be far away from the inflammable material to prevent it from fire.
5.Charging in time after using, and charging work must be done
by adults, if the product is going to unused for long time it must be
fully charged, and charge it every months ,so that to extend the
battery lifespan.
6.Must use the soft cloth to clean the car, do not use chemical
solvents to wipe the toy plastic parts, do not use soap and water
to clean the car, driving in rainy or snowy weather, water will
damage the motor, the vehicle's battery and circuit system.
7.When stop or storage the car, please cut the power and make all
the switch to “STOP” or “OFF” position.
8.Do not use the fuse which is not same with this product
specifications.
9.Do not change the product structure and circuit system,
maintenance and repair work must be under the guidance of the
professional or technical personnel in place.
TROUBLESHOOTING
If the battery is not fully charged. Need to be charged in time
If there is an issue with the wheels
If the wheels stuck and cannot move
If the pedal switch is not functioning properly
If “power” switch is in OFF position
If the fuse is not functioning properly
If the battery is not connected, check the red and black wires.
If the charger is plugged in, car will not power on. Unplug charger.
If rider weight exceeds specifications
If the charger is malfunctioning
If the battery lost its capacity
If the charger and battery connection is charged
Battery does
not charge
Car moves slow
Car does not
move or power on
10.Don't put toys for other purposes. Put the battery in the right
polarity.
11.It is forbidden to battery is negative short circuit. Non
rechargeable batteries, can't charge.
12.Chargeable batteries can only be charged adult the
guardianship of adults.
13.Don’t mix the old or new batteries or different type of
batteries.
14.Run out of battery should be removed from the toy properly
and prevent children from playing.
15.Disconnect the battery completely if not in use and prevent
children from playing.
PINGHU SHUANGXI BABY CARRIER MANUFACTURE CO.,LTD.
PINGHU BABY CARRIER INDUSTRY CITY, ZHEJIANG, CHINA
Table of contents
