Hollyland Mars 4K User manual

QuickGuide
V1.0.0
Mars4K

WELCOME
ThankyouforpurchasingtheMars4Kwirelessvideotransmissionsystem.Please
readthequickguidecarefullybeforeusingtheproduct.

KEYFEATURES
1
• 4K 3 0fp s HDMI input and output
• Color LCD
• Smart channel selection upon power-on
• 66ms transmission latency
• 450ft (150m) wireless transmission distance (LOS range) for the receiver
• 260ft (80m) wireless transmission distance (LOS range) for the app
• SDI input and HDMI input for the transmitter
• SDI output and HDMI output for the receiver
• DC, NP-F battery, and USB-C power supply

Note:Thequantitydependsontheconfigurationandissubjecttotheactuallistof
equipmentpurchased.
PACKINGLIST
2
⑤
① ② ③
⑥
⑦⑧⑨
④
SK U 1 TX 1 RX1 TX t o 1 R X
① Transmitter
② Receiver
③ Antenna
④ Cold Shoe
⑤ Type-C OTG Converter
⑥ Self-locking DC Adapter
⑦ User Guide
⑧ Warranty Card
⑨ Expansion Accessory
1
1
5
1
1
1
1
1
1
1
0
2
0
0
1
1
1
0
1
2
0
0
1
1
1
0
1

PRODUCTCONNECTION
DUALMONITORSETUP
3
TYPICALSETUP

PRODUCTINTERFACE
4
①①
①①

PRODUCT INTRODUCTION
①AntennaInterface
② HDMI Input
④DCPowerInput
③SDIInput
⑤ExpansionAccessoryMountingHole
⑥ColorLCD
⑦MenuButton
⑧ Pow e r B u t ton
⑨ USB-C Interface

⑩1/4ThreadedHole
5
Transmitter:
A Receiver: B
①AntennaInterface
② HDMI Output
④DCPowerInput
③SDIOutput
⑤ExpansionAccessoryMountingHole
⑥ColorLCD
⑦MenuButton
⑧PowerButton
⑨USB-CInterface

⑩1/4ThreadedHole

⑪Outlet

⑪Outlet

6
①Installtheantennashowninthepicture.
② Install the transmitter on the camera with the cold shoe.
④ Install the battery (compatible with NP-F970, or o t h e r batter i e s of the same series).
③ Connect the transmitter to the corresponding interface of the camera with an HDMI cable or SDI cable.
⑤Pushthepowerbuttonuptoturnonthedevice.
INSTALLATION
INSTALLATIONOFTRANSMITTER

7
①Installtheantennashowninthepicture.
② Install the receiver on the stand through the 1/4 threaded hole on the buttom of the device.
③ Install the battery (compatible with NP-F970, or o t h e r batter i e s of the same series).
④ Push the po w e r b u tton up to turn on the device.
INSTALLATION
INSTALLATIONOFRECEIVER

OLEDDISPLAY
① Receiver Number
② Signal Strength
Transmitter:
A
8
③ Indicator of Power Supply
④ USB Plugged In
⑤ Video Format
⑥ Channel Display
⑦ Device Wi-Fi ID
⑧ Application Mode
① Signal Strength
Receiver:
B
② Indicator of Power Supply
③ USB Plugged In
④ Video Format
⑤ Channel Display
⑥ Device Wi-Fi ID
⑦ Application Mode

QUICKGUIDE
9
CH A N N E L SELECTI O N
Pu s h t h e r ocker-s t y l e d button up o r d o w n o n the trans m i t t er or recei v e r a n d press the
bu t t o n t o select a ch a n n e l. The chan n e l s o f the recei v e r a n d transmi t t e r a re
sy n c h r onized au t o m a tically .
ME N U O P T IONS

Af t e r a c h annel is se l e c t ed, press a n d h o l d the butto n f o r 3 s t o enter the m e n u o p tions.
Yo u c a n p u sh the butt o n u p o r d own to chan g e t h e m enu optio n s .
AP P I N S T ALLATIO N AND CONNECTION
1. D o w n l oad the Hol l y V i ew app.
2.Connectthedevicetoamobilephone.
Find the WiFi named "HLD+DEVICE ID" on the mobile phone and enter the WiFi password (the
default password is 12345678) to connect the deviceto the mobile phone. After the connection is
successful, you can use the apponthemobile phone for monitoring.

PARAMETERS
Interface
Transmitter Receiver
Powersupply
Powerconsumption
<8.5W (typical) <5W(typical)
Dimension
Weight
223g (7.9oz)
(excluding the antennas)
223g (7.9oz)
(excluding the antennas)
(LxWxH): 115x65x32mm (4.5"x2.5"x1.3") (LxWxH): 115x65x32mm (4.5"x2.5"x1.3")
Antenna (RP-SMA male)
HDMI 1.4 b input (Type-A female)
3G-SDI input
DC input (2.0mm core socket)
USB Type-C (USB 2.0 OTG)
Antenna (RP-SMA male)
HDMI 1.4 b output (Type-A female)
3G-SDI output
DC input (2.0mm core socket)
USB Type-C (USB 2.0 OTG)
DC input: 6V–16V
USB Type-C: 5V/2.5A
(not supporting the QC and PD
protocols)
NP-F battery: 6.8V–8.4V
DC input: 6V–16V
USB Type-C: 5V/2.5A
(not supporting the QC and PD
protocols)
NP-F battery: 6.8V–8.4V
Operating frequency
5.1GHz–5.8GHz 5.1GHz–5.8GHz
Modulation mode
802.11n 802.11n
TX power
21dBm (max.) 21dBm (max.)
RX sensitivity
N/A –90dBm
Bit rate
8Mbps–20Mbps
Latency
0.06s (test data when 1080p60 signals are transmitted in a laboratory)
Range
450ft (150m) (test data in an open, interference-free outdoor environment)
Bandwidth
20MHz
Audio format
2 audio channels for the 3G-SDI and 8 audio channels for the HDMI 1.4b
Operating temperature
‒10 ℃ to 60 ℃
Storage temperature
‒40 ℃ to 60 ℃
ESD protection
Contact discharge: ±6kV; air discharge: ±8kV (test data)

720p50/59.94/60 720p50/60 720p50/60
1080i50/59.94/60
1080i50/60
1080i50/60
1080p23.98/24/25/29.97/30 1080p24/25/30
1080p50/59.94/60 1080p50/60 1080p50/60
1080p24/25/30
3840*216024/25/30 3840*216024/25/30 1080P24/25/30
1080p50/59.94/60(LevelA) 1080p50/59.94/60
1080p50/59.94/60(LevelB)
1080i50/59.94/60
1080p23.98/24/25/29.97/30
1080psf25/29.97/30
720p50/59.94/60
1080p50/59.94/60(LevelA)
1080i50/59.94/601080i50/59.94/60
720p50/59.94/60720p50/59.94/60
1080p23.98/24/25/29.97/301080p23.98/24/25/29.97/30
1080psf23.98/24 1080p23.98/241080p23.98/24
1080i50/59.94/601080i50/59.94/60
HDMI Input Format SDIOutputFormat
SDI Input Format SDI Output Format HDMI Output Format
PARAMETERS
HDMI Output Format

SUPPORT
Ifyouhaveanyproblemsinusingtheproductorneedanyhelp,pleasevisitthe
followingtogetmoretechnicalsupport.

Note: The frequency range and wireless TXpower of the device vary based on the
regulations of different countries and regions.
Safety Precautions
Do not place the product near or inside heating devices (including but not limited to
microwave ovens, induction cookers, electric ovens, electric heaters, pressure cookers,
water heaters, and gas stoves) to prevent the battery from overheating and exploding.
Donot use non-original charging cases, cables, and batteries with the product.
The use of non-original spare parts may cause electric shock, fire, explosion, or other
dangers.

FCC Requirement
Any changes or modifications not expressly approved by the party responsible for compliance
could void the user’s authority to operate the equipment.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two
conditions:
(1) This device may not cause harmful interference.
(2) This device must accept any interference received, including interference that may cause
undesired operation.
Note:
This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment generates,
uses, and can radiate radio frequency energy, andifitisnotinstalledandusedinaccordance
withtheinstructions,itmaycauseinterferencetoradiocommunications. However, there is no
guarantee that interference will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be determined by turning the
equipment off and on, y o u are encouraged to try to correct the interference by one or more of
the following measures:
– Reorient or relocate the receiving antenna.
– Increase the distance between the equipment and receiver.
– Connect the equipment to an outlet on a circuit different from that to which the receiver is
connected.
– Consult the dealer or an experienced radio/TV technician for help.
