WARRANTY INFORMATION
PLEASE READ AND SAVE THESE IMPORTANT INSTRUCTIONS
Owner’s Guide
HAP222
Odor Grabber PlusTM
Air Purifier
FILTER REPLACEMENT
TIPS AND TROUBLESHOOTING
3 YEAR LIMITED WARRANTY
Sunbeam Products, Inc. doing business as Jarden Consumer Solutions or if in Canada, Sunbeam Corporation (Canada)
Limited doing business as Jarden Consumer Solutions (collectively “JCS”) warrants that for a period of three years
from the date of purchase, this product will be free from defects in material and workmanship. JCS, at its option, will
repair or replace this product or any component of the product found to be defective during the warranty period.
Replacement will be made with a new or remanufactured product or component. If the product is no longer available,
replacement may be made with a similar product of equal or greater value. This is your exclusive warranty. Do NOT
attempt to repair or adjust any electrical or mechanical functions on this product. Doing so will void this warranty.
This warranty is valid for the original retail purchaser from the date of initial retail purchase and is not transferable.
Keep the original sales receipt. Proof of purchase is required to obtain warranty performance. JCS dealers, service
centers, or retail stores selling JCS products do not have the right to alter, modify or any way change the terms and
conditions of this warranty.
This warranty does not cover normal wear of parts or damage resulting from any of the following: negligent use or
misuse of the product, use on improper voltage or current, use contrary to the operating instructions, disassembly,
repair or alteration by anyone other than JCS or an authorized JCS service center. Further, the warranty does not
cover: Acts of God, such as fire, flood, hurricanes and tornadoes.
What are the limits on JCS’s Liability?
JCS shall not be liable for any incidental or consequential damages caused by the breach of any express, implied or
statutory warranty or condition.
Except to the extent prohibited by applicable law, any implied warranty or condition of merchantability or fitness for a
particular purpose is limited in duration to the duration of the above warranty.
JCS disclaims all other warranties, conditions or representations, express, implied, statutory or otherwise.
JCS shall not be liable for any damages of any kind resulting from the purchase, use or misuse of, or inability to use
the product including incidental, special, consequential or similar damages or loss of profits, or for any breach of
contract, fundamental or otherwise, or for any claim brought against purchaser by any other party.
Some provinces, states or jurisdictions do not allow the exclusion or limitation of incidental or consequential damages
or limitations on how long an implied warranty lasts, so the above limitations or exclusion may not apply to you.
This warranty gives you specific legal rights, and you may also have other rights that vary from province to province,
state to state or jurisdiction to jurisdiction.
How to Obtain Warranty Service
In the U.S.A.
If you have any question regarding this warranty or would like to obtain warranty service, please call
1-800-546-5637 and a convenient service center address will be provided to you.
In Canada
If you have any question regarding this warranty or would like to obtain warranty service, please call
1-800-546-5637 and a convenient service center address will be provided to you.
In the U.S.A., this warranty is offered by Sunbeam Products, Inc. doing business as Jarden Consumer Solutions located
in Boca Raton, Florida 33431. In Canada, this warranty is offered by Sunbeam Corporation (Canada) Limited doing
business as Jarden Consumer Solutions, located at 20 B Hereford Street, Brampton, Ontario L6Y 0M1. If you have any
other problem or claim in connection with this product, please write our Consumer Service Department. PLEASE DO
NOT RETURN THIS PRODUCT TO ANY OF THESE ADDRESSES OR TO THE PLACE OF PURCHASE.
© 2008 Sunbeam Products, Inc. doing business as Jarden Consumer Solutions. All Rights Reserved.
Distributed by Sunbeam Products, Inc. doing business as Jarden Consumer Solutions, Boca Raton,
Florida 33431 .
9100040003493 HAP222UC08EM1 Printed in China
TIPS AND TROUBLESHOOTING
LEARNING MORE
For a wealth of information about your air purifier and other Holmes®products, visit our website at
www.holmesproducts.com or call 1-800-546-5637.
ISSUE SOLUTION
UNIT WILL NOT OPERATE
DECREASED
AIR FLOW
EXCESSIVE NOISE
• Make sure unit is properly plugged in and outlet is energized.
• Make sure unit turned ON.
• Make sure filters are properly installed and front grill is seated correctly.
• Make sure nothing is blocking air inlet and filtered air outlets.
• Check condition of the filter and replace if necessary.
• Make sure parts are firmly positioned in place.
• Remove plastic bag from the filter.
FILTER REPLACEMENT INSTRUCTIONS
Note: Use Filter Reminder Dial to keep track on how long a filter has been in use.
1. Turn off and unplug the unit before replacing filter.
2. Remove the air inlet grill and check the condition of your carbon pre-filter and the main filter. If the carbon
pre-filter and main filter are dirty, remove the used filters and properly dispose of them. Do NOT try to wash and
re-use the filters. Replace with a new carbon pre-filter and a new main filter, removing the protective polybag from
each before inserting into the air purifier. (Both of these filters should be replaced every 1-2 months depending on
usage.)
3. Re-set the filter reminder dial by selecting the current month.
4. Filter Life – Under normal conditions of continuous use, the main filter will operate efficiently for 1-2 months.
Filters can be purchased at a retailer near you, online at www.holmesproducts.com, or by calling 1-800-546-5637.
Air Purifier Model #
HAP222
HAP222
Filter Quantity Needed
1
1
Filter Model #
HAPF21 / G Filter
HAPF220
Filter Description
General Purpose/Carbon
Carbon Pre-Filter
HAP222UC08EM1.qxd:9100040003493 8/8/08 3:19 PM Page 1

5. Remove main filter by gripping on both sides and
pulling forward.
6. Remove protective plastic bag from the main filter
cartridge.
7. Fold the tabs up on the main filter cartridge and hang
onto the plastic tabs of the air purifier with the carbon
(black) filter side facing you. (Figure 1).
8. Replace the carbon pre-filter.
9. Replace air inlet grill back onto unit securely.
10. Select current month on the filter reminder dial. This
will serve as reference for when filter replacement is
needed.
11. DO NOT POINT FILTERED AIR OUTLET TOWARDS
WALL.
OPERATING INSTRUCTIONS
1. Plug into a 120V AC electrical outlet.
2. Select the desired operating speed from HIGH (II), or LOW
(I) by sliding the switch to the desired setting. The power
light will illuminate letting you know the power is on.
3. To release negative ions into the filtered air, slide the
Ionizer switch to ON ( ) and the light will illuminate.
For optimum air filtration, it is recommended to operate the
air purifier continuously. Its rugged motor has been designed
to give many years of use. For continuous use, operate the
air purifier at the HIGH (II) setting; for quieter operation or
use in a bedroom, select the LOW (I) setting.
CLEANING/MAINTENANCE INSTRUCTIONS
Turn off and unplug the unit before cleaning.
1. The outside of the air purifier can be cleaned with a
soft, clean dampened cloth.
2. The air inlet grill can be removed and washed in warm
soapy water (not dishwasher safe). Dry before replacing
in the unit.
3. The air outlet grill can be cleaned of dust with a small
soft brush.
WARNING: Do not allow moisture to come in contact with
the main housing of the air purifier.
cord must be equal to or greater than the electrical
rating of the air purifier (see rating label marked on
product).
• Care must be taken to arrange the extension cord so
that it will not drape over the countertop or tabletop
where it can be pulled on by children or accidentally
tripped over.
GET TO KNOW YOUR AIR PURIFIER
• Your Holmes®Odor Grabber PlusTM Purifier features an
Arm & Hammer®enhanced HEPA-type filter that helps
fight common household odors and remove particles such
as dust, pollen, mold spores and pet dander from the air
passing through the filter.
• Optional ionizer naturally improves performance and
helps freshen the air.
IONIZER
This appliance has an optional ionizer feature which, when
turned on, releases negative ions into outgoing filtered air to
help the air purification process.
What Are Ions?
Ions are tiny particles that carry a positive or negative
charge. They exist naturally around us: in the air, water, and
ground. Both positive and negative ions are colorless,
odorless, and harmless.
How Does The Ionizer Work?
Negative ions help air purification by attaching themselves
to very small airborne particles in the room. These particles
take on a negative charge and may join with positively
charged particles such as dust, pollen, smoke, and pet
dander to form larger particles. These larger particles are
then more easily captured by the filter system.
Important Notes:
Your ionizer may produce an occasional popping or cracking
sound. This is normal and occurs when a small buildup of
ions is discharged.
After extended use, you may notice dust around the grills or
front panel. This is caused by negative ions exiting the air
outlet, evidence of the ionizer’s air cleaning effectiveness. You
can remove the dust with a soft brush or clean, damp cloth.
Larger particles may be attracted to positively charged surfaces
throughout the home, like walls or floors.
• This may occur more frequently when the filter is
nearing the end of its useful product life and unable to
capture as many charged particles.
• Excessive amounts of pet dander, dust, or smoke may
decrease the life expectancy of the filter and interfere
with the ionization process.
To help prevent particles from attracting to surfaces throughout
your home:
• You may want to run the ionizer less often.
• Check the condition of the filter more frequently.
CAUTION: The ionizer in this appliance produces less
ozone than the UL* established limits of 50ppb. However,
in high concentrations, ozone can be harmful to birds and
small pets. To prevent ozone buildup, we suggest using the
ionizer in well ventilated areas with the fan on.
TWO SPEED SETTINGS
Select from HIGH (II) or LOW (I) speed settings depending
on the room air quality.
FILTER REMINDER DIAL
This convenient feature helps you keep track of when to
change the filter.
BEFORE USE
1. Carefully unpack your Air Purifier. Select a firm level
place where there are no obstructions to the air inlet
or filtered air outlet.
2. Pull air inlet grill towards you by grasping the finger
tabs on both sides.
3. Remove carbon pre-filter by pulling off prongs.
4. Remove plastic bag from carbon pre-filter.
IMPORTANT SAFEGUARDS OPERATIONS
CLEANING/MAINTENANCE
When using electrical appliances, basic safety precautions
should always be followed to reduce the risk of fire, electric
shock, and injury to persons. These precautions include:
1. Read all instructions before using the appliance.
2. To avoid fire or shock hazard, plug the appliance directly
into a 120V AC electrical outlet.
3. If the filter is covered by a bag when shipped, remove plastic
bag before use.
4. Keep the cord out of heavy traffic areas. To avoid fire
hazards, NEVER put the cord under rugs, near heat registers,
radiators, stoves, or heaters.
5. To protect against electrical hazards, DO NOT immerse the
appliance in water or other liquids. Do not use near water.
6. Close supervision is necessary when any appliance is used by
or near children, or disabled persons.
7. Always unplug the air purifier before moving or cleaning the
unit, opening the grill, changing the filters and whenever the
unit is not in use. To disconnect the unit, be sure to pull the
plug and not the cord.
8. NEVER drop or insert any objects into the openings of the
unit.
9. DO NOT operate any appliance with a damaged cord or
plug. If the motor fan fails to operate or the unit has been
dropped or damaged in any manner, return appliance to
manufacturer for examination and/or repair.
10.Use appliance only for intended household use as described
in this manual. Any other use not recommended by the
manufacturer may cause fire, electric shock, or injury to
persons. The use of attachments not recommended or sold
by Jarden Consumer Solutions may cause hazards.
11.DO NOT use outdoors.
12.NEVER place on a soft surface such as a bed or sofa as this
could cause the unit to tip over and block the air inlet or
outlet grills.
13.Keep unit away from heated surfaces and open flames.
14.DO NOT attempt to repair or adjust any electrical or
mechanical functions on this unit. Doing so will void your
warranty. The inside of the unit contains no user serviceable
parts. All servicing should be performed by Jarden Consumer
Solutions or an authorized Jarden Consumer Solutions Center.
15. DO NOT place anything on top of unit.
16. NEVER use detergents, gasoline, glass purifier, furniture
polish, paint thinner, or other household solvents to
clean any part of the appliance.
17. Always turn the appliance off before unplugging it.
18. The ionizer in this appliance produces less ozone than
the UL established limits of 50ppb. However, in high
concentrations, ozone can be harmful to birds and
small pets. To prevent ozone buildup, we suggest using
the ionizer in well ventilated areas with the fan on.
19. This appliance should only be used in a room with
temperatures between 40° F and 110° F.
20. WARNING: To reduce the risk of fire or electric shock,
DO NOT use this appliance with any solid-state speed
control device.
PLEASE SAVE THESE
IMPORTANT SAFETY
INSTRUCTIONS
PLUG SAFETY
CAUTION: To reduce the risk of
electric shock, THIS PRODUCT
HAS A POLARIZED PLUG (one
blade is wider than the other).
This plug will fit into a polarized
outlet only one way. If the plug
does not fit fully into the outlet, reverse the plug. If it still
does not fit, contact qualified personnel to install the proper
outlet. DO NOT ALTER THE PLUG IN ANY WAY.
CORD SAFETY
• The length of cord used on this appliance was selected
to reduce tangling or tripping hazards.
• If a longer cord is necessary, an approved extension
cord may be used. The electrical rating of the extension
FEATURES - OPERATIONS
Figure 1
*Tested and listed by the Underwriters Laboratories, Inc.
HAP222UC08EM1.qxd:9100040003493 8/8/08 3:19 PM Page 2
