Holmes Hap9242 User manual

WARRANTY INFORMATION

3 YEAR LIMITED WARRANTY

Sunbeam Products, Inc. doing business as Jarden Consumer Solutions or if in Canada, Sunbeam Corporation (Canada)

Limited doing business as Jarden Consumer Solutions (collectively “JCS”) warrants that for a period of three years

from the date of purchase, this product will be free from defects in material and workmanship. JCS, at its option, will

repair or replace this product or any component of the product found to be defective during the warranty period.

Replacement will be made with a new or remanufactured product or component. If the product is no longer available,

replacement may be made with a similar product of equal or greater value. This is your exclusive warranty. Do NOT

attempt to repair or adjust any electrical or mechanical functions on this product. Doing so will void this warranty.

This warranty is valid for the original retail purchaser from the date of initial retail purchase and is not transferable.

Keep the original sales receipt. Proof of purchase is required to obtain warranty performance. JCS dealers, service centers,

or retail stores selling JCS products do not have the right to alter, modify or any way change the terms and conditions of this

warranty.

This warranty does not cover normal wear of parts or damage resulting from any of the following: negligent use or

misuse of the product, use on improper voltage or current, use contrary to the operating instructions, disassembly, repair

or alteration by anyone other than JCS or an authorized JCS service center. Further, the warranty does not cover: Acts

of God, such as fire, flood, hurricanes and tornadoes.

What are the limits on JCS’s Liability?

JCS shall not be liable for any incidental or consequential damages caused by the breach of any express, implied or

statutory warranty or condition.

Except to the extent prohibited by applicable law, any implied warranty or condition of merchantability or fitness for a

particular purpose is limited in duration to the duration of the above warranty.

JCS disclaims all other warranties, conditions or representations, express, implied, statutory or otherwise.

JCS shall not be liable for any damages of any kind resulting from the purchase, use or misuse of, or inability to use

the product including incidental, special, consequential or similar damages or loss of profits, or for any breach of

contract, fundamental or otherwise, or for any claim brought against purchaser by any other party.

Some provinces, states or jurisdictions do not allow the exclusion or limitation of incidental or consequential damages or

limitations on how long an implied warranty lasts, so the above limitations or exclusion may not apply to you.

This warranty gives you specific legal rights, and you may also have other rights that vary from province to province,

state to state or jurisdiction to jurisdiction.

How to Obtain Warranty Service

In the U.S.A.

If you have any questions regarding this warranty or would like to obtain warranty service, please call

1-800-546-5637 and a convenient service center address will be provided to you.

In Canada

If you have any questions regarding this warranty or would like to obtain warranty service, please call

1-800-546-5637 and a convenient service center address will be provided to you.

In the U.S.A., this warranty is offered by Sunbeam Products, Inc. doing business as Jarden Consumer Solutions located

in Boca Raton, Florida 33431. In Canada, this warranty is offered by Sunbeam Corporation (Canada) Limited doing

business as Jarden Consumer Solutions, located at 20 B Hereford Street, Brampton, Ontario L6Y OM1. If you have any

other problem or claim in connection with this product, please write our Consumer Service Department. PLEASE DO

NOT RETURN THIS PRODUCT TO ANY OF THESE ADDRESSES OR TO THE PLACE OF PURCHASE.

TROUBLESHOOTING

PLEASE READ AND SAVE THESE IMPORTANT INSTRUCTIONS

Owner’s Guide

HAP9242, HAP9414, HAP9422

138378/9100040004570 HOL B HAP9242/HAP9414/HAP9422 MANUAL 10EM2 Printed In China

GCDS-HOL19954-PH

HEPA-Type

Air Purifier with Optional Ionizer

Distributed by Sunbeam Products, Inc. doing business as Jarden Consumer Solutions, Boca Raton, Florida 33431.

The ARM & HAMMER®name, logo and associated marks are trademarks of Church & Dwight Co., Inc. and are used

under license by Sunbeam Products, Inc.

LEARNING MORE

For a wealth of information about your air purifier and other Holmes®products, visit our website at

www.holmesproducts.com or call 1-800-546-5637.

TROUBLESHOOTING

Problem Solution

•Unit will not operate. 4Check if unit is properly plugged in and outlet is energized.

4Make sure unit turned ON.

4Make sure filters are properly installed and rear grill is seated correctly.

•Decreased air flow. 4Make sure nothing is blocking air inlet and filtered air outlets.

4Check condition of the filter and replace if necessary.

•Excessive Noise. 4Make sure parts are firmly positioned in place.

4Open the air inlet grill and make sure that any plastic packaging was

removed from the filters, if applicable.

•The filter check indicator

will not reset.

4Check condition of the filter and replace it if necessary.

4Press and hold the Filter Reset Button for 3 seconds under power on

condition. The indicator light will blink three times and turn off.

HOL B HAP9242_HAP9414_HAP9422 MANUAL_10EM2.indd 1 11/24/10 11:47 AM

IMPORTANT SAFEGUARDS FEATURES

HIGH, MEDIUM AND LOW SPEED SETTINGS

For optimum air filtration, operate your Holmes®air

purifier continuously on the MEDIUM (2) setting. Its

rugged motor has been designed to give many years of

use. For quieter operation (such as in a bedroom), select

the LOW (1) setting. When high levels of air pollution are

present, select the HIGH (3) setting to quickly circulate

and filter the room air.

FILTER CHECK INDICATOR

The filter indicator light eliminates guesswork by letting

you know when it is time to replace the filters. To reset

the Filter Check Indicator, press and hold the button for 3

seconds only under working mode. The Indicator light will

blink three times and turn off.

BEFORE USE

1. Carefully unpack your Air Purifier. Select a firm level

place where there are no obstructions to the air inlet

or filtered air outlet.

2. Remove the air inlet grill and check if the filter is

covered by a plastic bag. If it is, remove plastic bag

before use and place filters into unit. Reinstall the air

inlet grill.

3. DO NOT POINT FILTERED AIR OUTLET TOWARDS WALL.

OPERATING INSTRUCTIONS

1. Plug into a 120V AC electrical outlet.

2. Select the desired operating speed; HI (3), MEDIUM

(2), LOW (1), by turning Speed Control Knob to the

appropriate setting. For optimum air filtration, it is

recommended to operate the air purifier continuously.

Its rugged motor has been designed to give many

years of use.

NOTE: The Filter Check Indicator light will blink three

times to indicate that the feature has been activated.

3. To release negative ions into the filtered air, press the

ionizer button ( ) to ON and the outer ring of the

button will illuminate in blue.

NOTE: The ionizer will not work unless the unit is

running.

CLEANING/MAINTENANCE

INSTRUCTIONS

1. Turn the air purifier off and unplug it before

cleaning.

2. The outside of the air purifier can be cleaned with a

soft, clean dampened cloth.

3. The air inlet grill (reference Fig. 1) can be removed

and washed in warm soapy water (not dishwasher

safe). Dry before replacing in the unit.

4. The filtered air outlet can be cleaned of dust with a

small, soft brush.

CORD SAFETY

• The length of cord used on this appliance was

selected to reduce tangling or tripping hazards.

• If a longer cord is necessary, an approved extension

cord may be used. The electrical rating of the

extension cord must be equal to or greater than the

electrical rating of the air purifier (see rating label

marked on bottom of the product).

• Care must be taken to arrange the extension cord so

that it will not drape over the countertop or tabletop

where it can be pulled on by children or accidentally

tripped over.

GET TO KNOW YOUR AIR PURIFIER

•

Your Holmes®air purifier features a HEPA-Type filter that

removes up to 99% of airborne dust and pollen as small

as 2 microns, and helps reduce smoke, mold spores and

pet dander from air passing through the filter.

• Arm & Hammer®baking soda and carbon help

absorb and eliminate household odors.

• Optional ionizer naturally improves performance and

helps freshen the air.

IONIZER

This appliance has an optional ionizer feature which,

when turned on, releases negative ions into outgoing

filtered air to help the air purification process.

What Are Ions?

Ions are tiny particles that carry a positive or negative

charge. They exist naturally around us: in the air, water,

and ground. Both positive and negative ions are colorless,

odorless, and harmless.

How Does The Ionizer Work?

Negative ions help air purification by attaching

themselves to very small airborne particles in the room.

These particles take on a negative charge and may join

with positively charged particles such as dust, pollen,

smoke, and pet dander to form larger particles. These

larger particles are then more easily captured by the

filter system.

Important Notes:

Your ionizer may produce an occasional popping or

cracking sound. This is normal and occurs when a small

buildup of ions is discharged.

After extended use, you may notice dust around the grills

or front panel. This is caused by negative ions exiting the

air outlet, evidence of the ionizer’s air cleaning

effectiveness. You can remove the dust with a soft brush

or clean, damp cloth.

Larger particles may be attracted to positively charged

surfaces throughout the home, like walls or floors.

• This may occur more frequently when the filter is

nearing the end of its useful product life and unable

to capture as many charged particles.

• Excessive amounts of pet dander, dust, or smoke may

decrease the life expectancy of the filter and

interfere with the ionization process.

To help prevent particles from attracting to surfaces

throughout your home:

• You may want to run the ionizer less often.

• Check the condition of the filter more frequently.

CAUTION: The ionizer in this appliance produces less

ozone than the UL established limits of 50ppb. However,

in high concentrations, ozone can be harmful to birds and

small pets. To prevent ozone buildup, we suggest using

the ionizer in well ventilated areas with the air purifier

fan on.

HEPA-TYPE FILTER

HEPA-Type (High Efficiency Particulate Air) filters are

designed to remove up to 99% of airborne pollutants, at

2 microns or larger, from the air that passes through

them. These include tobacco smoke, household dust, pet

dander and pollen.

When using electrical appliances, basic safety precautions

should always be followed to reduce the risk of fire, electric

shock, and injury to persons. These precautions include:

1. Read all instructions before using the appliance.

2. To avoid fire or shock hazard, plug the appliance

directly into a 120V AC electrical outlet.

3. If the filter is covered by a bag when shipped,

remove plastic bag before use.

4. Keep the cord out of heavy traffic areas. To avoid

fire hazard, NEVER put the cord under rugs, near

heat registers, radiators, stoves, or heaters.

5. To protect against electrical hazards, DO NOT

immerse the appliance in water or other liquids. Do

not use near water.

6. Close supervision is necessary when any appliance is

used by or near children, or disabled persons.

7. Always unplug the air purifier before moving or

cleaning the unit, opening the grill, changing the

filters and whenever the unit is not in use. To

disconnect the unit, be sure to pull the plug and not

the cord.

8. NEVER drop or insert any objects into the openings of

the unit.

9. DO NOT operate any appliance with a damaged cord

or plug. If the motor fan fails to operate or the unit

has been dropped or damaged in any manner, return

appliance to manufacturer for examination and/or

repair.

10. Use appliance only for intended household use as

described in this manual. Any other use not

recommended by the manufacturer may cause fire,

electric shock, or injury to persons. The use of

attachments not recommended or sold by Jarden

Consumer Solutions may cause hazards.

11. DO NOT use outdoors.

12. NEVER place on a soft surface such as a bed or sofa

as this could cause the unit to tip over and block the

air inlet or outlet grills.

13.

Keep unit away from heated surfaces and open flames.

14. DO NOT attempt to repair or adjust any electrical or

mechanical functions on this unit. Doing so will void

your warranty. The inside of the unit contains no user

serviceable parts. All servicing should be performed

by Jarden Consumer Solutions or an authorized

Jarden Consumer Solutions Center.

15. DO NOT place anything on top of unit.

16. NEVER use detergents, gasoline, glass purifier,

furniture polish, paint thinner, or other household

solvents to clean any part of the appliance.

17. Always turn the appliance off before unplugging it.

18.

The ionizer in this appliance produces less ozone than

the UL established limits of 50ppb (parts per billion).

However, in high concentrations, ozone can be harmful

to birds and small pets. To prevent ozone buildup, we

suggest using the ionizer in well ventilated areas with

the fan on.

19. This appliance should only be used in a room with

temperatures between 40° F and 110° F.

20. WARNING: To reduce the risk of fire or electric

shock, DO NOT use this appliance with any solid-state

speed control device.

PLEASE READ AND SAVE

THESE IMPORTANT

SAFETY INSTRUCTIONS

FEATURES - OPERATIONS CLEANING/MAINTENANCE

FILTER REPLACEMENT

THIS APPLIANCE HAS A POLARIZED PLUG (one blade is wider than the

other). To reduce the risk of electric shock, this plug is intended to fit in a

polarized outlet only one way. If the plug does not fit fully in the outlet,

reverse the plug. If it still does not fit, contact a qualified electrician to

install the proper outlet.

DO NOT ATTEMPT TO MODIFY THIS PLUG OR DEFEAT THIS

SAFETY FEATURE IN ANY WAY.

5. If you wish to clean the inside of the air purifier,

please only use a dry, soft cloth to wipe it down.

WARNING: Do not allow moisture to come in

contact with the main housing of the air purifier.

FILTER REPLACEMENT INSTRUCTIONS

IMPORTANT:

• DO NOT attempt to wash and re-use the HEPA-type

filter.

• If the filters are enclosed in plastic bags, remove

them before use.

NOTE:

Every few weeks, check the condition of filters. Filter life

will vary, depending on air quality and usage. Under

normal conditions of continuous use, the HEPA-type filter

will operate efficiently for 3-4 months.

After approximately 4 months of operation, the Filter

Check Indicator will light up to alert you to replace filters

before further use.

To replace your filter:

1. Turn off and unplug the air purifier.

2. Open the air inlet grill and examine the black foam

prefilter. Remove any dust or lint, and wash in warm

soapy water. Rinse, drip dry, and place back into grill

inlet.

3. Remove HEPA-type filter from the unit by pulling it

gently towards you and discard it. DO NOT attempt to

clean the old HEPA-type filter.

4. Install the new HAPF30 HEPA-type filter into the unit.

This model utilizes a hang tab and filter clips to

insure that the filter is properly in place. Before

replacing the filter, make sure that the hang tab is

securely in place. The

clip can only be

attached to the tabs on

the filter one way. The

filter clip should easily

slide onto the filter

hang tab with only a

small amount of

pressure. DO NOT use force while attaching the clip to

the filter. (Fig. 2)

5. Align the clip on the

side of HEPA-type filter

with rails on the inside

of the purifier unit.

Gently slide the filter

onto the rail. (Fig. 3)

6. Replace air inlet grill.

7. To reset the Filter Check Indicator, press and hold the

button for 3 seconds only under working mode. The

Indicator light will blink three times and turn off.

NOTE: Every time you power on the air cleaner by

selecting any speed setting, the Filter Check Indicator light

will blink 3 times. This routine test checks the current

condition of the filters. If filters are in good condition, the

icon will disappear. If not, the indicator will remain lit

until filters have been replaced and Filter Check Indicator

() has been reset (see instructions above).

Filters can be purchased at a retailer near you, online at www.holmesproducts.com, or by calling 1-800-546-5637.

Air Purifier

Model Number

Filter Quantity

Needed

Filter Model

Number

Filter

Description

HAP9242/HAP9414 1HAPF30

A Filter HEPA-type Filter

HAP9422 2HAPF30

A Filter HEPA-type Filter

Fig. 3

Fig. 2

Fig. 1

A. Control Panel

B. Speed Control Knob

C. Filter Reset Button

D. Filter Check

Indicator Light

E. Ionizer Button

F. Filtered Air Outlet

G. HEPA-Type Filter(s)

H. Washable Foam

Pre-Filter

I. Air Inlet Grill

HAP9422-U

F G HI

HAP9414-U

HAP9240-U

HOL B HAP9242_HAP9414_HAP9422 MANUAL_10EM2.indd 2 11/24/10 11:47 AM

IMPORTANT SAFEGUARDS FEATURES

HIGH, MEDIUM AND LOW SPEED SETTINGS

For optimum air filtration, operate your Holmes®air

purifier continuously on the MEDIUM (2) setting. Its

rugged motor has been designed to give many years of

use. For quieter operation (such as in a bedroom), select

the LOW (1) setting. When high levels of air pollution are

present, select the HIGH (3) setting to quickly circulate

and filter the room air.

FILTER CHECK INDICATOR

The filter indicator light eliminates guesswork by letting

you know when it is time to replace the filters. To reset

the Filter Check Indicator, press and hold the button for 3

seconds only under working mode. The Indicator light will

blink three times and turn off.

BEFORE USE

1. Carefully unpack your Air Purifier. Select a firm level

place where there are no obstructions to the air inlet

or filtered air outlet.

2. Remove the air inlet grill and check if the filter is

covered by a plastic bag. If it is, remove plastic bag

before use and place filters into unit. Reinstall the air

inlet grill.

3. DO NOT POINT FILTERED AIR OUTLET TOWARDS WALL.

OPERATING INSTRUCTIONS

1. Plug into a 120V AC electrical outlet.

2. Select the desired operating speed; HI (3), MEDIUM

(2), LOW (1), by turning Speed Control Knob to the

appropriate setting. For optimum air filtration, it is

recommended to operate the air purifier continuously.

Its rugged motor has been designed to give many

years of use.

NOTE: The Filter Check Indicator light will blink three

times to indicate that the feature has been activated.

3. To release negative ions into the filtered air, press the

ionizer button ( ) to ON and the outer ring of the

button will illuminate in blue.

NOTE: The ionizer will not work unless the unit is

running.

CLEANING/MAINTENANCE

INSTRUCTIONS

1. Turn the air purifier off and unplug it before

cleaning.

2. The outside of the air purifier can be cleaned with a

soft, clean dampened cloth.

3. The air inlet grill (reference Fig. 1) can be removed

and washed in warm soapy water (not dishwasher

safe). Dry before replacing in the unit.

4. The filtered air outlet can be cleaned of dust with a

small, soft brush.

CORD SAFETY

• The length of cord used on this appliance was

selected to reduce tangling or tripping hazards.

• If a longer cord is necessary, an approved extension

cord may be used. The electrical rating of the

extension cord must be equal to or greater than the

electrical rating of the air purifier (see rating label

marked on bottom of the product).

• Care must be taken to arrange the extension cord so

that it will not drape over the countertop or tabletop

where it can be pulled on by children or accidentally

tripped over.

GET TO KNOW YOUR AIR PURIFIER

•

Your Holmes®air purifier features a HEPA-Type filter that

removes up to 99% of airborne dust and pollen as small

as 2 microns, and helps reduce smoke, mold spores and

pet dander from air passing through the filter.

• Arm & Hammer®baking soda and carbon help

absorb and eliminate household odors.

• Optional ionizer naturally improves performance and

helps freshen the air.

IONIZER

This appliance has an optional ionizer feature which,

when turned on, releases negative ions into outgoing

filtered air to help the air purification process.

What Are Ions?

Ions are tiny particles that carry a positive or negative

charge. They exist naturally around us: in the air, water,

and ground. Both positive and negative ions are colorless,

odorless, and harmless.

How Does The Ionizer Work?

Negative ions help air purification by attaching

themselves to very small airborne particles in the room.

These particles take on a negative charge and may join

with positively charged particles such as dust, pollen,

smoke, and pet dander to form larger particles. These

larger particles are then more easily captured by the

filter system.

Important Notes:

Your ionizer may produce an occasional popping or

cracking sound. This is normal and occurs when a small

buildup of ions is discharged.

After extended use, you may notice dust around the grills

or front panel. This is caused by negative ions exiting the

air outlet, evidence of the ionizer’s air cleaning

effectiveness. You can remove the dust with a soft brush

or clean, damp cloth.

Larger particles may be attracted to positively charged

surfaces throughout the home, like walls or floors.

• This may occur more frequently when the filter is

nearing the end of its useful product life and unable

to capture as many charged particles.

• Excessive amounts of pet dander, dust, or smoke may

decrease the life expectancy of the filter and

interfere with the ionization process.

To help prevent particles from attracting to surfaces

throughout your home:

• You may want to run the ionizer less often.

• Check the condition of the filter more frequently.

CAUTION: The ionizer in this appliance produces less

ozone than the UL established limits of 50ppb. However,

in high concentrations, ozone can be harmful to birds and

small pets. To prevent ozone buildup, we suggest using

the ionizer in well ventilated areas with the air purifier

fan on.

HEPA-TYPE FILTER

HEPA-Type (High Efficiency Particulate Air) filters are

designed to remove up to 99% of airborne pollutants, at

2 microns or larger, from the air that passes through

them. These include tobacco smoke, household dust, pet

dander and pollen.

When using electrical appliances, basic safety precautions

should always be followed to reduce the risk of fire, electric

shock, and injury to persons. These precautions include:

1. Read all instructions before using the appliance.

2. To avoid fire or shock hazard, plug the appliance

directly into a 120V AC electrical outlet.

3. If the filter is covered by a bag when shipped,

remove plastic bag before use.

4. Keep the cord out of heavy traffic areas. To avoid

fire hazard, NEVER put the cord under rugs, near

heat registers, radiators, stoves, or heaters.

5. To protect against electrical hazards, DO NOT

immerse the appliance in water or other liquids. Do

not use near water.

6. Close supervision is necessary when any appliance is

used by or near children, or disabled persons.

7. Always unplug the air purifier before moving or

cleaning the unit, opening the grill, changing the

filters and whenever the unit is not in use. To

disconnect the unit, be sure to pull the plug and not

the cord.

8. NEVER drop or insert any objects into the openings of

the unit.

9. DO NOT operate any appliance with a damaged cord

or plug. If the motor fan fails to operate or the unit

has been dropped or damaged in any manner, return

appliance to manufacturer for examination and/or

repair.

10. Use appliance only for intended household use as

described in this manual. Any other use not

recommended by the manufacturer may cause fire,

electric shock, or injury to persons. The use of

attachments not recommended or sold by Jarden

Consumer Solutions may cause hazards.

11. DO NOT use outdoors.

12. NEVER place on a soft surface such as a bed or sofa

as this could cause the unit to tip over and block the

air inlet or outlet grills.

13.

Keep unit away from heated surfaces and open flames.

14. DO NOT attempt to repair or adjust any electrical or

mechanical functions on this unit. Doing so will void

your warranty. The inside of the unit contains no user

serviceable parts. All servicing should be performed

by Jarden Consumer Solutions or an authorized

Jarden Consumer Solutions Center.

15. DO NOT place anything on top of unit.

16. NEVER use detergents, gasoline, glass purifier,

furniture polish, paint thinner, or other household

solvents to clean any part of the appliance.

17. Always turn the appliance off before unplugging it.

18.

The ionizer in this appliance produces less ozone than

the UL established limits of 50ppb (parts per billion).

However, in high concentrations, ozone can be harmful

to birds and small pets. To prevent ozone buildup, we

suggest using the ionizer in well ventilated areas with

the fan on.

19. This appliance should only be used in a room with

temperatures between 40° F and 110° F.

20. WARNING: To reduce the risk of fire or electric

shock, DO NOT use this appliance with any solid-state

speed control device.

PLEASE READ AND SAVE

THESE IMPORTANT

SAFETY INSTRUCTIONS

FEATURES - OPERATIONS CLEANING/MAINTENANCE

FILTER REPLACEMENT

THIS APPLIANCE HAS A POLARIZED PLUG (one blade is wider than the

other). To reduce the risk of electric shock, this plug is intended to fit in a

polarized outlet only one way. If the plug does not fit fully in the outlet,

reverse the plug. If it still does not fit, contact a qualified electrician to

install the proper outlet.

DO NOT ATTEMPT TO MODIFY THIS PLUG OR DEFEAT THIS

SAFETY FEATURE IN ANY WAY.

5. If you wish to clean the inside of the air purifier,

please only use a dry, soft cloth to wipe it down.

WARNING: Do not allow moisture to come in

contact with the main housing of the air purifier.

FILTER REPLACEMENT INSTRUCTIONS

IMPORTANT:

• DO NOT attempt to wash and re-use the HEPA-type

filter.

• If the filters are enclosed in plastic bags, remove

them before use.

NOTE:

Every few weeks, check the condition of filters. Filter life

will vary, depending on air quality and usage. Under

normal conditions of continuous use, the HEPA-type filter

will operate efficiently for 3-4 months.

After approximately 4 months of operation, the Filter

Check Indicator will light up to alert you to replace filters

before further use.

To replace your filter:

1. Turn off and unplug the air purifier.

2. Open the air inlet grill and examine the black foam

prefilter. Remove any dust or lint, and wash in warm

soapy water. Rinse, drip dry, and place back into grill

inlet.

3. Remove HEPA-type filter from the unit by pulling it

gently towards you and discard it. DO NOT attempt to

clean the old HEPA-type filter.

4. Install the new HAPF30 HEPA-type filter into the unit.

This model utilizes a hang tab and filter clips to

insure that the filter is properly in place. Before

replacing the filter, make sure that the hang tab is

securely in place. The

clip can only be

attached to the tabs on

the filter one way. The

filter clip should easily

slide onto the filter

hang tab with only a

small amount of

pressure. DO NOT use force while attaching the clip to

the filter. (Fig. 2)

5. Align the clip on the

side of HEPA-type filter

with rails on the inside

of the purifier unit.

Gently slide the filter

onto the rail. (Fig. 3)

6. Replace air inlet grill.

7. To reset the Filter Check Indicator, press and hold the

button for 3 seconds only under working mode. The

Indicator light will blink three times and turn off.

NOTE: Every time you power on the air cleaner by

selecting any speed setting, the Filter Check Indicator light

will blink 3 times. This routine test checks the current

condition of the filters. If filters are in good condition, the

icon will disappear. If not, the indicator will remain lit

until filters have been replaced and Filter Check Indicator

() has been reset (see instructions above).

Filters can be purchased at a retailer near you, online at www.holmesproducts.com, or by calling 1-800-546-5637.

Air Purifier

Model Number

Filter Quantity

Needed

Filter Model

Number

Filter

Description

HAP9242/HAP9414 1HAPF30

A Filter HEPA-type Filter

HAP9422 2HAPF30

A Filter HEPA-type Filter

Fig. 3

Fig. 2

Fig. 1

A. Control Panel

B. Speed Control Knob

C. Filter Reset Button

D. Filter Check

Indicator Light

E. Ionizer Button

F. Filtered Air Outlet

G. HEPA-Type Filter(s)

H. Washable Foam

Pre-Filter

I. Air Inlet Grill

HAP9422-U

F G HI

HAP9414-U

HAP9240-U

HOL B HAP9242_HAP9414_HAP9422 MANUAL_10EM2.indd 2 11/24/10 11:47 AM

IMPORTANT SAFEGUARDS FEATURES

HIGH, MEDIUM AND LOW SPEED SETTINGS

For optimum air filtration, operate your Holmes®air

purifier continuously on the MEDIUM (2) setting. Its

rugged motor has been designed to give many years of

use. For quieter operation (such as in a bedroom), select

the LOW (1) setting. When high levels of air pollution are

present, select the HIGH (3) setting to quickly circulate

and filter the room air.

FILTER CHECK INDICATOR

The filter indicator light eliminates guesswork by letting

you know when it is time to replace the filters. To reset

the Filter Check Indicator, press and hold the button for 3

seconds only under working mode. The Indicator light will

blink three times and turn off.

BEFORE USE

1. Carefully unpack your Air Purifier. Select a firm level

place where there are no obstructions to the air inlet

or filtered air outlet.

2. Remove the air inlet grill and check if the filter is

covered by a plastic bag. If it is, remove plastic bag

before use and place filters into unit. Reinstall the air

inlet grill.

3. DO NOT POINT FILTERED AIR OUTLET TOWARDS WALL.

OPERATING INSTRUCTIONS

1. Plug into a 120V AC electrical outlet.

2. Select the desired operating speed; HI (3), MEDIUM

(2), LOW (1), by turning Speed Control Knob to the

appropriate setting. For optimum air filtration, it is

recommended to operate the air purifier continuously.

Its rugged motor has been designed to give many

years of use.

NOTE: The Filter Check Indicator light will blink three

times to indicate that the feature has been activated.

3. To release negative ions into the filtered air, press the

ionizer button ( ) to ON and the outer ring of the

button will illuminate in blue.

NOTE: The ionizer will not work unless the unit is

running.

CLEANING/MAINTENANCE

INSTRUCTIONS

1. Turn the air purifier off and unplug it before

cleaning.

2. The outside of the air purifier can be cleaned with a

soft, clean dampened cloth.

3. The air inlet grill (reference Fig. 1) can be removed

and washed in warm soapy water (not dishwasher

safe). Dry before replacing in the unit.

4. The filtered air outlet can be cleaned of dust with a

small, soft brush.

CORD SAFETY

• The length of cord used on this appliance was

selected to reduce tangling or tripping hazards.

• If a longer cord is necessary, an approved extension

cord may be used. The electrical rating of the

extension cord must be equal to or greater than the

electrical rating of the air purifier (see rating label

marked on bottom of the product).

• Care must be taken to arrange the extension cord so

that it will not drape over the countertop or tabletop

where it can be pulled on by children or accidentally

tripped over.

GET TO KNOW YOUR AIR PURIFIER

•

Your Holmes®air purifier features a HEPA-Type filter that

removes up to 99% of airborne dust and pollen as small

as 2 microns, and helps reduce smoke, mold spores and

pet dander from air passing through the filter.

• Arm & Hammer®baking soda and carbon help

absorb and eliminate household odors.

• Optional ionizer naturally improves performance and

helps freshen the air.

IONIZER

This appliance has an optional ionizer feature which,

when turned on, releases negative ions into outgoing

filtered air to help the air purification process.

What Are Ions?

Ions are tiny particles that carry a positive or negative

charge. They exist naturally around us: in the air, water,

and ground. Both positive and negative ions are colorless,

odorless, and harmless.

How Does The Ionizer Work?

Negative ions help air purification by attaching

themselves to very small airborne particles in the room.

These particles take on a negative charge and may join

with positively charged particles such as dust, pollen,

smoke, and pet dander to form larger particles. These

larger particles are then more easily captured by the

filter system.

Important Notes:

Your ionizer may produce an occasional popping or

cracking sound. This is normal and occurs when a small

buildup of ions is discharged.

After extended use, you may notice dust around the grills

or front panel. This is caused by negative ions exiting the

air outlet, evidence of the ionizer’s air cleaning

effectiveness. You can remove the dust with a soft brush

or clean, damp cloth.

Larger particles may be attracted to positively charged

surfaces throughout the home, like walls or floors.

• This may occur more frequently when the filter is

nearing the end of its useful product life and unable

to capture as many charged particles.

• Excessive amounts of pet dander, dust, or smoke may

decrease the life expectancy of the filter and

interfere with the ionization process.

To help prevent particles from attracting to surfaces

throughout your home:

• You may want to run the ionizer less often.

• Check the condition of the filter more frequently.

CAUTION: The ionizer in this appliance produces less

ozone than the UL established limits of 50ppb. However,

in high concentrations, ozone can be harmful to birds and

small pets. To prevent ozone buildup, we suggest using

the ionizer in well ventilated areas with the air purifier

fan on.

HEPA-TYPE FILTER

HEPA-Type (High Efficiency Particulate Air) filters are

designed to remove up to 99% of airborne pollutants, at

2 microns or larger, from the air that passes through

them. These include tobacco smoke, household dust, pet

dander and pollen.

When using electrical appliances, basic safety precautions

should always be followed to reduce the risk of fire, electric

shock, and injury to persons. These precautions include:

1. Read all instructions before using the appliance.

2. To avoid fire or shock hazard, plug the appliance

directly into a 120V AC electrical outlet.

3. If the filter is covered by a bag when shipped,

remove plastic bag before use.

4. Keep the cord out of heavy traffic areas. To avoid

fire hazard, NEVER put the cord under rugs, near

heat registers, radiators, stoves, or heaters.

5. To protect against electrical hazards, DO NOT

immerse the appliance in water or other liquids. Do

not use near water.

6. Close supervision is necessary when any appliance is

used by or near children, or disabled persons.

7. Always unplug the air purifier before moving or

cleaning the unit, opening the grill, changing the

filters and whenever the unit is not in use. To

disconnect the unit, be sure to pull the plug and not

the cord.

8. NEVER drop or insert any objects into the openings of

the unit.

9. DO NOT operate any appliance with a damaged cord

or plug. If the motor fan fails to operate or the unit

has been dropped or damaged in any manner, return

appliance to manufacturer for examination and/or

repair.

10. Use appliance only for intended household use as

described in this manual. Any other use not

recommended by the manufacturer may cause fire,

electric shock, or injury to persons. The use of

attachments not recommended or sold by Jarden

Consumer Solutions may cause hazards.

11. DO NOT use outdoors.

12. NEVER place on a soft surface such as a bed or sofa

as this could cause the unit to tip over and block the

air inlet or outlet grills.

13.

Keep unit away from heated surfaces and open flames.

14. DO NOT attempt to repair or adjust any electrical or

mechanical functions on this unit. Doing so will void

your warranty. The inside of the unit contains no user

serviceable parts. All servicing should be performed

by Jarden Consumer Solutions or an authorized

Jarden Consumer Solutions Center.

15. DO NOT place anything on top of unit.

16. NEVER use detergents, gasoline, glass purifier,

furniture polish, paint thinner, or other household

solvents to clean any part of the appliance.

17. Always turn the appliance off before unplugging it.

18.

The ionizer in this appliance produces less ozone than

the UL established limits of 50ppb (parts per billion).

However, in high concentrations, ozone can be harmful

to birds and small pets. To prevent ozone buildup, we

suggest using the ionizer in well ventilated areas with

the fan on.

19. This appliance should only be used in a room with

temperatures between 40° F and 110° F.

20. WARNING: To reduce the risk of fire or electric

shock, DO NOT use this appliance with any solid-state

speed control device.

PLEASE READ AND SAVE

THESE IMPORTANT

SAFETY INSTRUCTIONS

FEATURES - OPERATIONS CLEANING/MAINTENANCE

FILTER REPLACEMENT

THIS APPLIANCE HAS A POLARIZED PLUG (one blade is wider than the

other). To reduce the risk of electric shock, this plug is intended to fit in a

polarized outlet only one way. If the plug does not fit fully in the outlet,

reverse the plug. If it still does not fit, contact a qualified electrician to

install the proper outlet.

DO NOT ATTEMPT TO MODIFY THIS PLUG OR DEFEAT THIS

SAFETY FEATURE IN ANY WAY.

5. If you wish to clean the inside of the air purifier,

please only use a dry, soft cloth to wipe it down.

WARNING: Do not allow moisture to come in

contact with the main housing of the air purifier.

FILTER REPLACEMENT INSTRUCTIONS

IMPORTANT:

• DO NOT attempt to wash and re-use the HEPA-type

filter.

• If the filters are enclosed in plastic bags, remove

them before use.

NOTE:

Every few weeks, check the condition of filters. Filter life

will vary, depending on air quality and usage. Under

normal conditions of continuous use, the HEPA-type filter

will operate efficiently for 3-4 months.

After approximately 4 months of operation, the Filter

Check Indicator will light up to alert you to replace filters

before further use.

To replace your filter:

1. Turn off and unplug the air purifier.

2. Open the air inlet grill and examine the black foam

prefilter. Remove any dust or lint, and wash in warm

soapy water. Rinse, drip dry, and place back into grill

inlet.

3. Remove HEPA-type filter from the unit by pulling it

gently towards you and discard it. DO NOT attempt to

clean the old HEPA-type filter.

4. Install the new HAPF30 HEPA-type filter into the unit.

This model utilizes a hang tab and filter clips to

insure that the filter is properly in place. Before

replacing the filter, make sure that the hang tab is

securely in place. The

clip can only be

attached to the tabs on

the filter one way. The

filter clip should easily

slide onto the filter

hang tab with only a

small amount of

pressure. DO NOT use force while attaching the clip to

the filter. (Fig. 2)

5. Align the clip on the

side of HEPA-type filter

with rails on the inside

of the purifier unit.

Gently slide the filter

onto the rail. (Fig. 3)

6. Replace air inlet grill.

7. To reset the Filter Check Indicator, press and hold the

button for 3 seconds only under working mode. The

Indicator light will blink three times and turn off.

NOTE: Every time you power on the air cleaner by

selecting any speed setting, the Filter Check Indicator light

will blink 3 times. This routine test checks the current

condition of the filters. If filters are in good condition, the

icon will disappear. If not, the indicator will remain lit

until filters have been replaced and Filter Check Indicator

() has been reset (see instructions above).

Filters can be purchased at a retailer near you, online at www.holmesproducts.com, or by calling 1-800-546-5637.

Air Purifier

Model Number

Filter Quantity

Needed

Filter Model

Number

Filter

Description

HAP9242/HAP9414 1HAPF30

A Filter HEPA-type Filter

HAP9422 2HAPF30

A Filter HEPA-type Filter

Fig. 3

Fig. 2

Fig. 1

A. Control Panel

B. Speed Control Knob

C. Filter Reset Button

D. Filter Check

Indicator Light

E. Ionizer Button

F. Filtered Air Outlet

G. HEPA-Type Filter(s)

H. Washable Foam

Pre-Filter

I. Air Inlet Grill

HAP9422-U

F G HI

HAP9414-U

HAP9240-U

HOL B HAP9242_HAP9414_HAP9422 MANUAL_10EM2.indd 2 11/24/10 11:47 AM

IMPORTANT SAFEGUARDS FEATURES

HIGH, MEDIUM AND LOW SPEED SETTINGS

For optimum air filtration, operate your Holmes®air

purifier continuously on the MEDIUM (2) setting. Its

rugged motor has been designed to give many years of

use. For quieter operation (such as in a bedroom), select

the LOW (1) setting. When high levels of air pollution are

present, select the HIGH (3) setting to quickly circulate

and filter the room air.

FILTER CHECK INDICATOR

The filter indicator light eliminates guesswork by letting

you know when it is time to replace the filters. To reset

the Filter Check Indicator, press and hold the button for 3

seconds only under working mode. The Indicator light will

blink three times and turn off.

BEFORE USE

1. Carefully unpack your Air Purifier. Select a firm level

place where there are no obstructions to the air inlet

or filtered air outlet.

2. Remove the air inlet grill and check if the filter is

covered by a plastic bag. If it is, remove plastic bag

before use and place filters into unit. Reinstall the air

inlet grill.

3. DO NOT POINT FILTERED AIR OUTLET TOWARDS WALL.

OPERATING INSTRUCTIONS

1. Plug into a 120V AC electrical outlet.

2. Select the desired operating speed; HI (3), MEDIUM

(2), LOW (1), by turning Speed Control Knob to the

appropriate setting. For optimum air filtration, it is

recommended to operate the air purifier continuously.

Its rugged motor has been designed to give many

years of use.

NOTE: The Filter Check Indicator light will blink three

times to indicate that the feature has been activated.

3. To release negative ions into the filtered air, press the

ionizer button ( ) to ON and the outer ring of the

button will illuminate in blue.

NOTE: The ionizer will not work unless the unit is

running.

CLEANING/MAINTENANCE

INSTRUCTIONS

1. Turn the air purifier off and unplug it before

cleaning.

2. The outside of the air purifier can be cleaned with a

soft, clean dampened cloth.

3. The air inlet grill (reference Fig. 1) can be removed

and washed in warm soapy water (not dishwasher

safe). Dry before replacing in the unit.

4. The filtered air outlet can be cleaned of dust with a

small, soft brush.

CORD SAFETY

• The length of cord used on this appliance was

selected to reduce tangling or tripping hazards.

• If a longer cord is necessary, an approved extension

cord may be used. The electrical rating of the

extension cord must be equal to or greater than the

electrical rating of the air purifier (see rating label

marked on bottom of the product).

• Care must be taken to arrange the extension cord so

that it will not drape over the countertop or tabletop

where it can be pulled on by children or accidentally

tripped over.

GET TO KNOW YOUR AIR PURIFIER

•

Your Holmes®air purifier features a HEPA-Type filter that

removes up to 99% of airborne dust and pollen as small

as 2 microns, and helps reduce smoke, mold spores and

pet dander from air passing through the filter.

• Arm & Hammer®baking soda and carbon help

absorb and eliminate household odors.

• Optional ionizer naturally improves performance and

helps freshen the air.

IONIZER

This appliance has an optional ionizer feature which,

when turned on, releases negative ions into outgoing

filtered air to help the air purification process.

What Are Ions?

Ions are tiny particles that carry a positive or negative

charge. They exist naturally around us: in the air, water,

and ground. Both positive and negative ions are colorless,

odorless, and harmless.

How Does The Ionizer Work?

Negative ions help air purification by attaching

themselves to very small airborne particles in the room.

These particles take on a negative charge and may join

with positively charged particles such as dust, pollen,

smoke, and pet dander to form larger particles. These

larger particles are then more easily captured by the

filter system.

Important Notes:

Your ionizer may produce an occasional popping or

cracking sound. This is normal and occurs when a small

buildup of ions is discharged.

After extended use, you may notice dust around the grills

or front panel. This is caused by negative ions exiting the

air outlet, evidence of the ionizer’s air cleaning

effectiveness. You can remove the dust with a soft brush

or clean, damp cloth.

Larger particles may be attracted to positively charged

surfaces throughout the home, like walls or floors.

• This may occur more frequently when the filter is

nearing the end of its useful product life and unable

to capture as many charged particles.

• Excessive amounts of pet dander, dust, or smoke may

decrease the life expectancy of the filter and

interfere with the ionization process.

To help prevent particles from attracting to surfaces

throughout your home:

• You may want to run the ionizer less often.

• Check the condition of the filter more frequently.

CAUTION: The ionizer in this appliance produces less

ozone than the UL established limits of 50ppb. However,

in high concentrations, ozone can be harmful to birds and

small pets. To prevent ozone buildup, we suggest using

the ionizer in well ventilated areas with the air purifier

fan on.

HEPA-TYPE FILTER

HEPA-Type (High Efficiency Particulate Air) filters are

designed to remove up to 99% of airborne pollutants, at

2 microns or larger, from the air that passes through

them. These include tobacco smoke, household dust, pet

dander and pollen.

When using electrical appliances, basic safety precautions

should always be followed to reduce the risk of fire, electric

shock, and injury to persons. These precautions include:

1. Read all instructions before using the appliance.

2. To avoid fire or shock hazard, plug the appliance

directly into a 120V AC electrical outlet.

3. If the filter is covered by a bag when shipped,

remove plastic bag before use.

4. Keep the cord out of heavy traffic areas. To avoid

fire hazard, NEVER put the cord under rugs, near

heat registers, radiators, stoves, or heaters.

5. To protect against electrical hazards, DO NOT

immerse the appliance in water or other liquids. Do

not use near water.

6. Close supervision is necessary when any appliance is

used by or near children, or disabled persons.

7. Always unplug the air purifier before moving or

cleaning the unit, opening the grill, changing the

filters and whenever the unit is not in use. To

disconnect the unit, be sure to pull the plug and not

the cord.

8. NEVER drop or insert any objects into the openings of

the unit.

9. DO NOT operate any appliance with a damaged cord

or plug. If the motor fan fails to operate or the unit

has been dropped or damaged in any manner, return

appliance to manufacturer for examination and/or

repair.

10. Use appliance only for intended household use as

described in this manual. Any other use not

recommended by the manufacturer may cause fire,

electric shock, or injury to persons. The use of

attachments not recommended or sold by Jarden

Consumer Solutions may cause hazards.

11. DO NOT use outdoors.

12. NEVER place on a soft surface such as a bed or sofa

as this could cause the unit to tip over and block the

air inlet or outlet grills.

13.

Keep unit away from heated surfaces and open flames.

14. DO NOT attempt to repair or adjust any electrical or

mechanical functions on this unit. Doing so will void

your warranty. The inside of the unit contains no user

serviceable parts. All servicing should be performed

by Jarden Consumer Solutions or an authorized

Jarden Consumer Solutions Center.

15. DO NOT place anything on top of unit.

16. NEVER use detergents, gasoline, glass purifier,

furniture polish, paint thinner, or other household

solvents to clean any part of the appliance.

17. Always turn the appliance off before unplugging it.

18.

The ionizer in this appliance produces less ozone than

the UL established limits of 50ppb (parts per billion).

However, in high concentrations, ozone can be harmful

to birds and small pets. To prevent ozone buildup, we

suggest using the ionizer in well ventilated areas with

the fan on.

19. This appliance should only be used in a room with

temperatures between 40° F and 110° F.

20. WARNING: To reduce the risk of fire or electric

shock, DO NOT use this appliance with any solid-state

speed control device.

PLEASE READ AND SAVE

THESE IMPORTANT

SAFETY INSTRUCTIONS

FEATURES - OPERATIONS CLEANING/MAINTENANCE

FILTER REPLACEMENT

THIS APPLIANCE HAS A POLARIZED PLUG (one blade is wider than the

other). To reduce the risk of electric shock, this plug is intended to fit in a

polarized outlet only one way. If the plug does not fit fully in the outlet,

reverse the plug. If it still does not fit, contact a qualified electrician to

install the proper outlet.

DO NOT ATTEMPT TO MODIFY THIS PLUG OR DEFEAT THIS

SAFETY FEATURE IN ANY WAY.

5. If you wish to clean the inside of the air purifier,

please only use a dry, soft cloth to wipe it down.

WARNING: Do not allow moisture to come in

contact with the main housing of the air purifier.

FILTER REPLACEMENT INSTRUCTIONS

IMPORTANT:

• DO NOT attempt to wash and re-use the HEPA-type

filter.

• If the filters are enclosed in plastic bags, remove

them before use.

NOTE:

Every few weeks, check the condition of filters. Filter life

will vary, depending on air quality and usage. Under

normal conditions of continuous use, the HEPA-type filter

will operate efficiently for 3-4 months.

After approximately 4 months of operation, the Filter

Check Indicator will light up to alert you to replace filters

before further use.

To replace your filter:

1. Turn off and unplug the air purifier.

2. Open the air inlet grill and examine the black foam

prefilter. Remove any dust or lint, and wash in warm

soapy water. Rinse, drip dry, and place back into grill

inlet.

3. Remove HEPA-type filter from the unit by pulling it

gently towards you and discard it. DO NOT attempt to

clean the old HEPA-type filter.

4. Install the new HAPF30 HEPA-type filter into the unit.

This model utilizes a hang tab and filter clips to

insure that the filter is properly in place. Before

replacing the filter, make sure that the hang tab is

securely in place. The

clip can only be

attached to the tabs on

the filter one way. The

filter clip should easily

slide onto the filter

hang tab with only a

small amount of

pressure. DO NOT use force while attaching the clip to

the filter. (Fig. 2)

5. Align the clip on the

side of HEPA-type filter

with rails on the inside

of the purifier unit.

Gently slide the filter

onto the rail. (Fig. 3)

6. Replace air inlet grill.

7. To reset the Filter Check Indicator, press and hold the

button for 3 seconds only under working mode. The

Indicator light will blink three times and turn off.

NOTE: Every time you power on the air cleaner by

selecting any speed setting, the Filter Check Indicator light

will blink 3 times. This routine test checks the current

condition of the filters. If filters are in good condition, the

icon will disappear. If not, the indicator will remain lit

until filters have been replaced and Filter Check Indicator

() has been reset (see instructions above).

Filters can be purchased at a retailer near you, online at www.holmesproducts.com, or by calling 1-800-546-5637.

Air Purifier

Model Number

Filter Quantity

Needed

Filter Model

Number

Filter

Description

HAP9242/HAP9414 1HAPF30

A Filter HEPA-type Filter

HAP9422 2HAPF30

A Filter HEPA-type Filter

Fig. 3

Fig. 2

Fig. 1

A. Control Panel

B. Speed Control Knob

C. Filter Reset Button

D. Filter Check

Indicator Light

E. Ionizer Button

F. Filtered Air Outlet

G. HEPA-Type Filter(s)

H. Washable Foam

Pre-Filter

I. Air Inlet Grill

HAP9422-U

F G HI

HAP9414-U

HAP9240-U

HOL B HAP9242_HAP9414_HAP9422 MANUAL_10EM2.indd 2 11/24/10 11:47 AM
