Holux GPSmile51B Operational manual

Portable Automobile
Navigation System
Product User Manual
Version: V.01
July 2005
Registered info
HOLUX and GPSmile are trademarks of HOLUX Technology, Inc.
All other trademarks belong to each registered companies.
Note
Contents of this manual will be modified without further notice.

-ii-
GPSmile51

-iii- GPSmile51

-iv-
GPSmile51
Safety Precautions
About charging
zUse the power adapter included with the package, using power
adapters other than the one provided will result in malfunction and
could prove dangerous.
zThe device should only be used with the supplied batteries.
About the power adapter
zDo not use the power adapter in a wet environment. When hands and
feet are wet, do not touch the power adapter.
zWhile using the power adaptor ensure that the area is well ventilated.
Do not let paper or other material cover the power adaptor, as this will
interfere with cooling. Do not use the power adaptor whilst it is in a
bag.
zDo not attempt to repair the device. If device is damaged or is in a wet
environment, replace the device immediately.
About the battery
zUse only the original factory approved charger.
zA Lithium battery is built in to the device. To prevent fire or skin burns,
do not disassemble, pierce, impact, or expose the battery to fire. The
battery will crack, explode, or release dangerous chemicals if placed in
a fire.
zImportant instructions
Note: Replacing with an incorrect battery may result in an
explosion. When disposing of the battery, follow the
instructions. The replacement battery must be original factory
approved.
Regulations must be observed when recycling or disposing of
batteries.
The battery should only be used in this device.

-v- GPSmile51
Warranty Statement
zThis warranty applies to parts and services of GPSmile51 manufactured
and sold through Holux Technology Inc. The local area covered is
Taiwan; the warrantee length is one year from date of purchase
(counting from the date on the sales receipt). Under normal user
operation, Holux Technology provides free repair services.
The replaceable battery warranty is six months.
The replaced parts after repair are properties of Holux
Technology Inc.
zHolux Technology is not responsible for providing repairs or
replacements of any software; Holux Technology does not provide any
warranty service for third party software/hardware.
zImportant instructions
Note: This warranty does not cover damage or malfunction
from the below causes: unauthorized disassembly/modification
of unit, abuse or incorrect usage, accidental and other
unpreventable causes, operation under variables mentioned
other than in this product user manual, using parts not made
or sold by Holux Technology, or repairs done by anyone other
than Holux Technology and authorized retail/service provider.
Expendable parts are not covered in the warranty.
Any program, data, or portable storage media damages or loss
are not responsible. Please contact your local Holux Technology
authorized service provider to learn more about geographical
limitations, proof of purchase requests, response time
agreements, and other specific maintenance service requests.

-vi-
GPSmile51
Technical Support
zIf there are any questions regarding the use of this product, please
logon to the website www.holux.com and see the FAQ.
zIf answers cannot be found on the website, please send us an e-mail at
[email protected], stating your query and location.
Maintenance Service
HOLUX Technology, Inc.
[phone]
Web Site: www.holux.com.tw
E-mail: [email protected]
HOLUX Technology, Inc.
www.holux.com

-vii- GPSmile51
Contents
Preface..................................................................... 1
Symbols .................................................................................1
Important Notice.....................................................................1
Functions and Features ...........................................................3
Other Functions ......................................................................3
First Time Use ........................................................................4
Copyright .......................................................................4
Important Notice.............................................................4
Package Contents ...................................................................5
Basic Operation ....................................................... 6
Introduction ...........................................................................6
Front View......................................................................6
Rear View.......................................................................7
Left Side.........................................................................8
Right Side.......................................................................8
Top View........................................................................9
Bottom View...................................................................9
Getting Started...................................................... 10
Preparing for Use .................................................. 11
Installing Battery ..................................................................11
Connecting to AC Adapter and Charging.................................12
Using the In Vehicle Bracket ..................................................13
Using the Car Charger ...........................................................16
Operating Methods................................................................17
Startup.........................................................................17
Shutdown.....................................................................17
Using the Function Buttons............................................18
Using the Stylus............................................................19
Using the SD Memory Card....................................................20
Function Menu......................................................................21

-viii-
GPSmile51
Setting ................................................................... 22
System Settings ....................................................................22
[Time]..........................................................................22
[Volume] ......................................................................23
[Startup Message].........................................................23
[Stylus Adjustment] ......................................................24
Backlight Settings .................................................................25
Help.....................................................................................27
Music Playback Function ....................................... 28
Storing MP3 files onto SD memory cards ................................28
Starting music playback.........................................................28
Create custom playlist ...........................................................30
Image Browsing Function ..................................... 31
Using the CD.......................................................... 33
Appendix................................................................ 33
Troubleshooting....................................................................33
System reset ................................................................33
Quick Troubleshooting...................................................34
Normal Care and Maintenance .......................................35
Storage ................................................................................36
Specifications........................................................................37

-1- GPSmile51
Preface
We appreciate your purchase of the GPSmile 51.
Please read all instructions thoroughly for a full understanding of the
products’ features.
Symbols
For fast reference to the data you wish to find, this manual uses the
following symbols.
9This icon means to take note to messages and to read for while
during use.
0This icon means a warning and should take care not to damage the
unit.
)This icon means useful tips for extra information while using.
Important Notice
zThis system only provides a navigational reference. Do not use this
system for any directional, distance, and geographic etc precise
measurements.
zThe first GPS positioning should be performed at a single set point,
wide-open area without building shelters. Positioning time length will
depend on the satellite signal strength, cloud levels; possibly taking up
to 10 minutes.
zGPS (Global Positioning System) is the satellite system used by the
United States of America Department of Defense. All maintenance and
operations are also managed by the United States of America
Department of Defense. Should the system be modified and adjusted,
the precision and operation of GPS related systems might be affected.
zAny wireless communication products (mobile phone, radio, speed
detection unit etc) might affect the GPS signal, resulting in a poor
signal.
zFor safety reasons, do not operate this system while driving a vehicle.

-2-
GPSmile51
zDo not leave this unit under your front windshield after you leave the
vehicle. Exposure to high temperatures might be dangerous and cause
overheating to the battery, resulting in malfunction of the device.
zWindow tinting might interfere with the reception of satellite signals. We
recommend you install a vehicle antenna to strengthen and stabilize
the signal.
zThe planned navigational route is for reference only; changes in
roadside conditions (one way streets, no right turns) may happen so
please respond accordingly to the situation and decide whether or not
to follow the planned course.
zWhen placing this system in the vehicle, please secure with brackets on
the car to ensure safety. The recommended installation location is
illustrated below.
9Differences between manufactured and shipped versions may be
present; this software may be updated frequently. If the
descriptions in this manual are different from your software version,
please follow the software version currently on hand.
X Do not block
driver’s view
XDo not secure in front
of airbag
XDo not secure in
front of airbag
XDo not place on
unstable dashboard

-3- GPSmile51
Functions and Features
zRealistic full scene 3D view, ‘go where you see’.
zSmart road travel display, zoom-in on cross roads.
zGPS speed limit warning setting (city and highway speed limit settings).
zVoice cue for information such as turning, u-turn, distance etc.
zHighway info display and voice cueing function, including for next
interchange, rest stop, tollbooth.
zGPS map rotation.
zGPS street traveled, administrative divisions, map direction information
displays.
zCustom “speeding camera location”. Under GPS, voice cueing from a
distance of 300m before contact.
Other Functions
zMusic playback: plays MP3 music files.
zImage display: displays photographs or image files.

-4-
GPSmile51
First Time Use
Copyright
Without the written consent of HOLUX Technology, Inc, this manual
including the product and the software may not be duplicated,
transmitted, recorded or saved on storage devices; nor shall it be
translated under any circumstances into any other languages.
Copyright ©2005 HOLUX Technology, Inc. All rights reserved.
Important Notice
Please read thoroughly this manual of operating instructions and
explanations. Use only original factory approved batteries and
accessories to prevent unexpected damage. If the correct procedures
were not followed for operation or incompatible accessories were
connected, this violates the warrantee agreement and will automatically
void the warrantee; even causing personal safety issues.

-5- GPSmile51
Package Contents
Your product should include the following accessories:
1 NAV-51 Unit 6 Battery
2 In Vehicle Bracket 7 USB Charging Cable
3 Base Unit for Bracket 8 128 MB SD Memory Card
(Option)
4 Travel Adapter 9 CD-ROM
5 Car Adapter 10 Quick Guide
1
6
4
7
5
8
2
3
10
(option)
9

-6-
GPSmile51
Basic Operation
Introduction
Front View
1 Charge
Indicator
Displays the battery charging status
2 Find-Target
Hotkey
Press to quickly enter the destination
window
3 Zoom-Out Zooms out of the map
4 Zoom-In Zooms in on the map
5 Directional Pad Press up/down/left/right keys to move
around onscreen or press on the center to
select items
6 ESC Key Exits current operation
7 Menu Directory Returns to the main menu window
8 Power Button Switches on/off the power
9 Touch Screen Displays system status/use stylus to directly
input data or select items on the screen

-7- GPSmile51
Rear View
1 Retractable
Antenna
Receives satellite signals
2 External
Antenna
Connector
For connection of an external antenna
3 In Vehicle
Securing
Bracket Base
Fast secure to the in vehicle securing
bracket
4 Stylus Use stylus to directly input data or select
items on the screen
5 Speaker Increase audio output

-8-
GPSmile51
Left Side
1 Battery Lid Open the battery lid to replace the
rechargeable battery
Right Side
1 Headphone Jack Connection to external headphones
2 SD Memory
Card Slot
SD memory card slot, the required
programs and maps are saved on this
memory card, please do not remove
memory card while in use.

-9- GPSmile51
Top View
1 Reset System reset switch
2 Volume
Adjustment Key
Adjusts volume level
Bottom View
1 USB/Power
Connection Port
Dual function port for USB connector and
charger

-10-
GPSmile51
Getting Started
If you are a first-time system user, the following explanations will help
you quickly understand the system operations, and experience the
system’s powerful and convenient functions.
1. Battery installation
This system uses a proprietary Lithium battery, charge after
installation. For details please refer to page 12 in this manual.
2. SD memory card installation
The system included memory card contains the digital map files
and important data for GPS navigation. Install first and refer to
page 20 in this manual.
3. Using the stylus
The stylus is the main tool for operating this unit and is concealed
in a pen slot at the rear. Pull out to use. For details please refer to
page 19 in this manual.
4. Initial GPS positioning
Perform GPS positioning at an outdoor open location. Press the
power switch and select [GPS] to enter the navigational screen.
Select [Menu] for the control menus and then select [GPS status]
to enter the GPS positioning screen. The system will automatically
search for a satellite signal and begin the positioning procedure.
After GPS positioning is complete, a GPS satellite status icon will
appear onscreen and related data will be displayed. For details
please refer to page 5 “Navigation software manual”.
5. Voice settings
Sets the language type. Startup > select [GPS] > press [Menu] key
> enter the control menu > select [Navigation setting] > at
[Language selection] select the arrows on both sides to switch
between Chinese and English. For details please refer to page 58
“Navigation software manual”.

-11- GPSmile51
6. Experience the GPS navigation
Startup > select [GPS] > press [Find] key > enter the destination
screen > select [Area] > select city > zoom in/out or scroll map to
find destination > select [Find nearest location] > select [Sort] >
select a type > select an entry > select [Set destination] > select
[Simulate navigation] > system will begin to plan a route and then
start simulation of navigation. For details please refer to page 13
“Navigation software manual”.
Preparing for Use
Installing Battery
Follow these procedures to install the
proprietary rechargeable battery:
1. Follow these directions to open the
battery compartment.
2. Insert the rechargeable battery
observing the correct polarity.
3. Close the battery compartment as shown.

-12-
GPSmile51
Connecting to AC Adapter and Charging
Before using the device for the first time, we strongly suggest you use
a fully charged battery.
1. Insert the USB connector into the adapter.
2. Insert the other end into the power port under the unit.
3. Plug the adapter into a power outlet.
4. When charging starts, the charging indicator light will be red,
please wait for the charging to complete (this might take several
hours). After charging is completed the indicator light will be green.
9This device uses a Lithium battery, please note the following:
zPlease do not charge in a hot environment, such as on a balcony or
expose to direct sunlight.
