Holux GPSmile62 Operational manual

i
GPSmile6
2
NAV Slim
Portable Automobile Navigation System
Product User Manual
Version: 1.0
September 2008
Registered info
HOLUX and GPSmile are trademarks of HOLUX Technolog , Inc.
All other trademarks belong to registered companies.
Note
 The contents of this manual will be modified without further notice.
 The operation temperature for the product is between 0℃~40℃.
 Operating or recharging in an environment with a temperature over 45
℃ might cause the s stem to malfunction. However, this should be
considered a normal phenomenon. Please do not operate under
extreme temperatures.

ii
GPSmile62
Safety Precautions
• Use the power adapter included with the package. Using other power
adapters than the one provided will result to malfunction and could
prove to be dangerous.
• The device should onl be used with the supplied batteries.
• About the power adapter:
1. Do not use the power adapter in a wet environment. When hands
and feet are wet, do not touch the power adapter.
2. While using the power adaptor, ensure that the area is well
ventilated. Do not let paper or other material cover the power
adaptor, as this will interfere with cooling. Do not use the power
adaptor whilst it is in a bag.
3. Do not attempt to repair the device. If device is damaged or is in a
wet environment, replace the device immediatel .
4. It is not recommended to charge from a PC because the PC power
voltage is not enough to suppl the device.
• About the batter
1. Use onl the original factor approved charger.
2. A Lithium batter is built into the device. To prevent fire or skin
burns, do not disassemble, pierce, impact, or expose the batter to
fire. The batter will crack, explode, or release dangerous
chemicals if placed in a fire.
• Important instructions
1. Note: Replacing with an incorrect batter ma result in an explosion.
When disposing of the batter , follow the instructions. The
replacement batter must be a factor approved original.
2. Regulations must be observed when rec cling or disposing of
batteries.
3. The batter should onl be used in this device.

iii
GPSmile6
2
Warranty Statement
• This warrant applies to parts and services of GPSmile 62 that are
manufactured and sold through Holux Technolog Inc. The local area
covered is Taiwan; the warrant length is one ear from date of
purchase (starting from the date on the sales receipt). Under normal
user operation, Holux Technolog provides free repair services.
 After repair, the replaced parts are the properties of Holux
Technolog Inc.
• Holux Technolog is not responsible for providing repairs or
replacements of an software; Holux Technolog does not provide an
warrant service for third part software/hardware.
• Important instructions
Note: This warrant does not cover damage or malfunction from the
below causes: unauthorized disassembl /modification of unit, abuse or
incorrect usage, accidental and other unpreventable causes, operation
under variables mentioned that are different from those in this product
user manual, using parts not made or sold b Holux Technolog , or
repairs done b an one other than Holux Technolog and authorized
retail/service providers.
 Expendable parts are not covered in the warrant .
 Holux Technolog is not responsible for an program, data, or
portable storage media damages or loss. Please contact our local
Holux Technolog authorized service provider to learn more about
geographical limitations, proof of purchase requests, response time
agreements, and other specific maintenance service requests.

iv
GPSmile62
Technical Support
• If there are an questions regarding the use of this product, please
log on to the website www.holux.com and see the FAQ.
• If answers cannot be found on the website, please send us an e-mail
at [email protected], stating our quer and location.
Maintenance Service
HO UX Technology, Inc.
[phone]
Web Site: www.holux.com
E-mail: [e-mail]
or
Contact your nearest dealer, for further support.
HO UX Technology, Inc.
www.holux.com

GPSmile62
Table of Contents
Warranty Statement ............................................................. iii
Technical Support................................................................ iv
Maintenance Service............................................................ iv
Preface................................................................................... 1
Symbols ................................................................................. 1
Important Notice ................................................................... 1
Other Functions .................................................................... 2
First time use......................................................................... 3
Copyright ........................................................................... 3
Important Notice................................................................ 3
Package Contents................................................................. 4
Basic Operation .................................................................... 5
Introduction ....................................................................... 5
Getting Started ...................................................................... 8
Micro SD memory card installation.................................. 8
Charging........................................................................... 10
Using Home / Travel adapter: ..................................... 10
Using the In-Vehicle Bracket .......................................... 13
Operating Methods ............................................................. 17
Startup.............................................................................. 17
Shutdown ......................................................................... 17
Using Functions.................................................................. 18
Function Menu Image Browsing Function ................... 19
Setting .............................................................................. 21
Volume & ight ............................................................ 21

GPSmile62
Time .............................................................................. 23
Panel Adjustment ........................................................ 24
Reset GPS .................................................................... 26
Version.......................................................................... 28
anguage...................................................................... 29
Startup Message .......................................................... 29
Hot Key ......................................................................... 30
Bluetooth (Optional function) ............................................ 31
Make a call ....................................................................... 31
Phonebook....................................................................... 33
Call History ...................................................................... 35
Device ist ....................................................................... 36
Device Manager ............................................................... 37
Settings......................................................................... 37
Search Device .............................................................. 38
Disconnect ................................................................... 41
Information ................................................................... 41
Troubleshooting.................................................................. 42
System reset .................................................................... 42
Normal Care and Maintenance ....................................... 43
Storage ............................................................................. 44
Appendix.............................................................................. 45
Specifications .................................................................. 45
Federal regulations............................................................. 47

1
GPSmile62
Preface
We appreciate our purchase of the GPSmile 62.
Please read all instructions thoroughl for a full understanding of the
products’ features.
Symbols
For fast reference of the data ou wish to find, this manual uses the
following s mbols.
 This icon means ou should take note of the message and read
during use.
 This icon means warning and ou should take care not to damage
the unit.
 This icon means useful tips for extra information while using.
Important Notice
• This s stem onl provides a navigational reference. Do not use this
s stem for an directional, distance, and geographic precise
measurements.
• The first GPS positioning should be performed at a single set point in
a wide-open area without building shelters. The length of time it takes
to position will depend on the satellite signal strength, and cloud
levels. It will possibl taking up to 10 minutes.
• GPS (Global Positioning S stem) is the satellite s stem used b the
United States of America Department of Defense. All maintenance
and operations are also managed b the United States of America
Department of Defense. Should the s stem be modified and adjusted,
the precision and operation of the GPS related s stems might be
affected.
• An wireless communication products (mobile phone, radio, speed
detection unit etc) might affect the GPS signal and result in a poor
signal.
• For safet reasons, do not operate this s stem while driving a vehicle.

2
GPSmile62
• Do not leave this unit under our front windshield after ou leave the
vehicle. Exposure to high temperatures might be dangerous and
cause the batter to overheat, resulting in malfunction of the device.
• Window tinting might interfere with the reception of satellite signals.
We recommend that ou install a vehicle antenna to strengthen and
stabilize the signal.
• The planned navigational route is for reference onl ; changes in
roadside conditions (one wa streets, no right turns) ma happen so
please respond according to the situation and decide whether or not
to follow the planned course.
• When placing this s stem in the vehicle, please secure it on the car
with brackets to ensure safet . The recommended installation
location is illustrated below.
• Differences between manufactured and shipped versions ma be
present; this software ma be updated frequentl . If the descriptions
in this manual are different from our software version, please follow
the software version currentl on hand.
Other Functions
• Image displa : displa s photographs or image files
X
Do not block
driver’s view
X
Do not secure in
front of airbag
X Do not secure in
front of airbag
X Do not place on
unstable dashboard

3
GPSmile62
First time use
Copyright
Without the written consent of HOLUX Technolog , Inc, this manual,
including the product and the software, ma not be duplicated, transmitted,
recorded or saved on storage devices. Furthermore, it shall not be
translated under an circumstances into an other languages.
Cop right ©2008 HOLUX Technolog , Inc. All rights reserved.
Important Notice
Please thoroughl read this manual of operating instructions and
explanations. Onl use original factor approved batteries and accessories
to prevent unexpected damage. If the correct procedures were not followed
for operation or incompatible accessories were connected, this is a
violation of the warrantee agreement and will automaticall void the
warrantee. This ma also cause personal safet issues.

4
GPSmile62
Package Contents
Your product should include the following accessories:
NAV-62 Unit In-vehicle Bracket fixing
Car Adapter Home / Travel Adapter
(Optional)
Micro SD Card
(Optional)
CD-ROM Quick Guide

5
GPSmile62
Basic Operation
Introduction
Front View
Rear View
5
” TFT
CD with
touch
screen
External Antenna port

6
GPSmile62
Left ide
Right ide
USB port
Micro SD card
slot
Power button
Earphone port
Battery

7
GPSmile62
Top View
Bottom View
Hot key

8
GPSmile62
Getting Started
If ou are a first-time s stem user, the following explanations will help ou
quickl understand the s stem operations, and experience the s stem’s
powerful and convenient functions.
Micro SD memory card installation
This unit is equipped with a Micro SD memor card slot. You can purchase
Micro SD Cards to expand the memor capacit .
To insert the memory card:
With the metal contacts of the memor card facing back, insert the card into
the slot on the right side of the unit.
To remove the memory card:
1. Gentl press the top of the memor card, and the card will eject
automaticall .
2. Then, pull to remove the memor card.
 The included memor card contains the digital map files that are
required for the GPS navigational data. Please do not delete.
 When removing the memor card, please make sure the card is not
reading data, or it will cause a s stem crash.

9
GPSmile62
 Do not set the Micro SD memor card as write protected, or the
s stem will not operate properl .
 When operating, accidental removal of the memor card will
result in showing an error message. Please reinsert the
memor card and the s stem ma need to be reset before
further use.

10
GPSmile62
Charging
Using Home / Travel adapter:
Before using the device for the first time, we strongl suggest ou use a
full charged batter .
1. Insert the USB connector into the unit.
2. Plug the adapter into a power outlet.
 Please do not use USB cable to connect with PC/Laptop when
batter low or without batter , it will be causing device can not
boot.

11
GPSmile62
Using the car charger:
While using the device in a vehicle, use the included car charger for long
periods of usage.
1. Plug the small plug into the power jack on the  rear 1-1 side of the
device bracket is optional.
2. Insert the other end into the cigarette lighter.
*1-1 Optional in basic version.
1-1
Optional

12
GPSmile62
 This device uses a built-in rechargeable batter . Please note the
following:
• Please do not charge in a hot environment, such as on a balcon
or an area exposed to direct sunlight.
• Do not wait until the batter is depleted to recharge.
• When the unit is not in use for a long time, please remove the
batter pack from the device.
• When charging a completel depleted batter , wait at least one
minute before starting up the s stem. This will prevent excessive
batter discharge.

13
GPSmile62
Using the In-Vehicle Bracket
The included in-vehicle bracket set can be securel suctioned on the front
windshield, or secured on top of the glove compartment using the adhesive
plate. This device will effectivel secure the GPS unit in the vehicle. Follow
the procedures below to secure the bracket:
1. Follow the arrows and secure the unit into the in-vehicle bracket
fitting holes.
2. Gentl push the unit until the unit is tightl fixed with the bracket.

14
GPSmile62
Note: Please note the directions of the arrows. When secured, the
assembl should be tight. If these directions are not followed, a loose fit will
result, and components must be reassembled.
3. Suction the vehicle bracket securel to the windshield, ensuring its
base is resting firml on the dashboard . Bend the bracket support
to a proper angle (＆).
