Holystone HS210 User manual

Instructions For Use
HS210
V 6.0
www.holystone.com+1(855) 888-6699
[email protected] (USA)
[email protected] (CA)
[email protected] (EU)
[email protected] (JP)

Contents
1.0 Disclaimer & Warning .........................................................................
2.0 Safety Guidelines ..................................................................................
3.0 Maintenance ..........................................................................................
4.0 Packing Contents ..................................................................................
5.0 Drone Details ......................................................................................
6.0 Low Battery Warning .........................................................................
7.0 Transmitter Functions .........................................................................
8.0 Joystick Mode .......................................................................................
9.0 Installation ..........................................................................................
10.0 Charging ..............................................................................................
11.0 Flight
Pairing ......................................................................................................
Calibrate the Gyro ................................................................................
Auto Takeoff ..........................................................................................
One Key Landing .................................................................................
12.0 Functions Details
Altitude-Hold Function........................................................................
Trimmer ....................................................................................................
Speed Switch ..........................................................................................
Emergency Stop ...................................................................................
360 ° Flip .................................................................................................
Circle Fly ..................................................................................................
Auto-Rotation ........................................................................................
Headless Mode .....................................................................................
13.0 Specification ........................................................................................
14.0 Contact Us ...........................................................................................
15.0 General Information .........................................................................
1
1
5
6
7
7
8
9
10
11
12
13
14
15
15
16
17
17
18
19
19
20
21
22
23

-1-
1. Please read this Disclaimer & Warning and Safety Guidelines carefully
before using our product. This product is not recommended for people
under the age of 14. By using this product, you hereby agree to this
disclaimer and signify that you have read it fully. You agree that you are
responsible for your own conduct and any damages caused while
using this product, and its consequences. You agree to only use this
product for it's designed purposes and in accordance with local laws,
regulations and all applicable policies and guidelines that HolyStone
may provide.
2. When using this product, please be sure to strictly abide by the
specification requirements and safety guidelines stated in this
document. Any personal injury, property damage, legal disputes and all
other adverse events caused by the violation of any of the safety
instructions or due to any other factor, WILL NOT be HolyStone’s
responsibility.
1.0 DISCLAIMER & WARNING
2.0 SAFETY GUIDELINES
① This product is a high precision drone that integrates various
electronic stability and control mechanisms. Please be sure to config-
ure this drone carefully and correctly to ensure safe, accident-free
operation.
② Ensure that the batteries of the drone and transmitter are clean,
undamaged and fully charged before every use.
③ Ensure that all the propellers are undamaged and are installed in the
correct orientation.
2.1 Check Before Use

-2-
④Ensure to do a thorough check of the product before each use.
Inspect the integrity of the parts, any signs of cracks and wear of the
propeller, battery power and effectiveness of the indicator, etc. If after
doing a complete check of the drone any problems are found, please
refrain from using it until the problem has been resolved.
2.2 Flight Environment
Fly in Open Areas Maintain Line
of Sight
- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -
Avoid flying over or near obstacles, crowds, high voltage power lines,
trees, airports or bodies of water.
DO NOT fly near strong electromagnetic sources such as power lines
and base stations as it may affect the onboard compass.
- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -
DO NOT use this drone in adverse weather conditions such as rain,
snow, fog, and wind.
Fly Below
164 feet (50 m)

-3-
2.3 Operation Requirements
①DO NOT use this product to follow any moving vehicles.
②During the flight, turn off the motors only in case of an emergency.
③Fly the drone back to you as soon as you are notified that the battery
is running low.
④This product should not be used while drinking alcohol or consum-
ing drugs, if you are feeling fatigued, taking medicine, or feeling any
physical discomfort.
⑤Be aware of the volume of noise that the drone produces. Please
ensure to keep your distance to avoid ear damage.
2.4 Use of Battery
①Please ensure batteries are fitted in the correct orientation as shown
in the instruction manual.
②Avoid short circuits by fitting the batteries correctly, and do not crush
or squeeze the batteries as this could cause the risk of a fire or explosion.
③DO NOT mix new and old batteries as this can lead to a poor
performance of the product.
④Please dispose of used batteries carefully, do not litter and recycle
where ever possible.
⑤DO NOT expose dead batteries to heat or fire or they may explode.
⑥If the device is not going to be used for an extended period of time,
⑥Stay away from the rotating
propellers and motors.
⑦ DO NOT fly in any spaces
where drones are prohibited.
Please respect people's right to
privacy by not flying your drone
close to others.

-4-
please remove batteries to prevent potential damage from to the drone
battery leakage.
⑦Only use the USB charging cable that comes with the drone to
charge the battery.
⑧DO NOT connect the battery directly to wall outlets or car cigarette
-lighter sockets as this will damage your battery as they are a different
voltage.
⑨DO NOT attempt to disassemble or modify the battery in any way
⑩DO NOT use the battery if it gives off an odor, generates heat,
becomes discolored, deformed or appears abnormal in any way. If any
of these situations occur while the battery is in use or being charged,
remove it from the device or charger immediately and discontinue use.
DO NOT pierce the battery casing with a nail or any other sharp
object, break it open with a hammer, or step on it! Dispose or recycle
this battery as it may cause personal injury or damage to your drone.
Always charge the batteries on a fireproof surface and away from
combustible materials. DO NOT charge on surfaces that can catch fire.
This includes: wood, cloth, carpet, or on the application's device.
DO NOT immerse the battery in water or get it wet.
DO NOT solder battery terminal in any way.
Keep batteries out of reach of children or pets.
DO NOT short-circuit the battery by connecting wires or any other
metal object to the positive(+) and negative(-) terminals.
11
12
13
14
15
16
Li-Po Battery Disposal & Recycling
Waste Lithium-polymer batteries must not be placed with household trash.
Please contact local environmental or waste agency or the waste agency
or the supplier of your model or your nearest Li-Po battery recycling center.

-5-
3.0 MAINTENANCE
①Clean the product after each use with a clean, soft cloth.
②Avoid prolonged exposure to direct sunlight and avoid buildup of
heat on the drone or batteries.
③This device is not waterproof and must not be submerged or
subjected in water under any circumstance. Failure to keep the device
completely dry will result in the failure and permanent damage to the
unit. Be aware that although it might be dry where you are, droplets of
rain or mist from a river or waterfall could be damaging your drone
where it is flying.
④Frequently Check the charging plug and other accessories for signs
of damage. If any part of the device or cables are damaged, avoid use
or charging until the device can be serviced.

4.0 PACKAGE CONTENTS
Instructions For Use
HS210
V 6.0
www.holystone.com+1(855)888-6699
[email protected](USA)
[email protected](CA)
[email protected](EU)
[email protected](JP)
Drone Transmitter Drone Battery
USB Charger Screwdriver
Instructions For
Use
-6-
Propellers
Spanner
Spare Propellers

5.0 DRONE DETAILS
Propeller B
Propeller A
Propeller A
HEAD
TAIL
Propeller B
6.0 LOW BATTERY WARNING
①When the drone battery runs low, the indicator lights on the drone
will blink continuously. About 1 minute or so the drone will automati-
cally land on low electricity.
②When the transmitter battery runs low, the power indicator of the
transmitter will blink continuously and the transmitter will keep
beeping. When this happens, the pilot should change the new battery
for the transmitter.
-7-

7.0 TRANSMITTER FUNCTIONS
Turn ON/OFF
Headless Mode
One Key Start/
Landing
Indicator Light
Left Joystick Right Joystick
Speed Switch
(Short press) /
Circle Fly
(Long press)
360°Flip
(Short press)/
Auto-Rotation
(Long press)
If you want to install the batteries, please always pay close attention
to battery polarity to make sure they are inserted correctly.
AAA Batteries
(NOT included)
Battery
Compartment
Battery Cover
-8-

8.0 JOYSTICK MODE
8.1 MODE 2 (Default Setting)
Left Joystick Right Joystick
Ascend
Descend
Rotate
Left Rotate Right
Forward
Backward
Up
Left
Up
Down
Down
Left Right Fly to
Right
Fly to
Left
Right
8.2 MODE 1
To enter MODE 1, turn on the transmitter while holding the “Speed
Switch” button. (Please do not release the “Speed Switch” button until
the transmitter is powered on.)
Left Joystick Right Joystick
Ascend
Descend
Forward
Backward
Up
Left
Up
DownDown
Left Right Fly to
Right
Fly to
Left
Right
-9-
Rotate
Left Rotate Right

-10-
9.1 Propeller
Attention:The drone will not fly unless the correct propeller is installed
on the correct motor shaft.
See illustration above. An “A” or “B” is printed on each propeller. Install
the propeller to the motor shaft and press into place.
HEAD
Removal: Insert the propeller spanner between the propeller and the
motor. Be sure to hold the motor while detaching the propeller.
A
B
AB
9.0 INSTALLATION

10.0 CHARGING
USB Adapter
(5V/2A)
Power Bank
① Connect the battery with the charger.
② Plug the charger into a USB charging port on power bank or USB
adapter (5V/2A).
③ Charging time: about 40-60 minutes.
④
a. While the battery is charging, the charging indicator light is
Red.
b. When the battery is full charged, the charging indicator
light will turn Green.
Before charging, please check the contents of the “ Use of Battery”
section of the “ Safety Guidelines” carefully!
Charging Indicator
Charging Port
USB Charger
-11-

11.0 OPEARATION GUIDE
11.1 Pairing
①Connect the battery port access
to the fuselage power port.
③Turn on the transmitter. ④ Push the throttle joystick up
then down to pair the drone with
the transmitter. The LED indicator
lights on the drone will turn solid if
the drone is paired successfully.
②Place the drone on a flat and
level surface with the head
forward and the tail towards the
pilot.
- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -
- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -
All of the operations shown in this manual are demonstrated using
MODE 2.
HEAD
TAIL
-12-

11.2 Calibrate the Gyro
Tip: To ensure a stable flight, we suggest that the pilot calibrates
the gyro every time after pairing the drone and after a crash.
As shown in the diagram above, push the left and right joystick
simultaneously to the lower left corner
to calibrate the gyro. The
indicator lights on the drone will blink quickly and turn solid. When you
hear 2 beeps from the transmitter that indicates the calibration is
completed.
-13-

There are two methods to take off the drone.
Method 1: Press the One Key Start button, the propellers will start
spinning, indicating this drone is ready to fly. Then push the left joystick
up slowly to take off. The more the joystick is pushed away from the
center position, the faster the drone will change elevation. Always push
the joystick gently to prevent sudden and unexpected elevation
changes.
Method 2: After pairing, pick up the drone and lay it flat on your palm.
Gently toss the drone into air, and it will hover in place.
Takeoff
11.3 Auto Takeoff
- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -
-14-

11.4 One Key Landing
When in flight, you can press the One Key Landing button, the drone
will lands automatically.
Landing
12.0 FUNCTIONS DETAILS
12.1 Altitude-Hold FunctionN
The drone is designed with altitude-hold function so the drone can
maintain its altitude after you release the left joystick ( the left joystick will
automatically spring back to the middle ).
-15-

12.2 Trimmer
F/B Sideward Fly Trim
L/R Sideward Fly Trim
- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -
(When you hear one long beep from the transmitter that indicates the
drone is adjusted to balance.)
If the drone drifts forward, hold down the throttle joystick and do not
release it while pushing the direction joystick down to balance the
drone; If the drone drifts backwards, hold down the throttle joystick and
do not release it while pushing the direction joystick up to balance the
drone.
If the drone drifts left, hold down the throttle joystick and do not release
it while pushing the direction joystick right to balance the drone; If the
drone drifts right, hold down the throttle joystick and do not release it
while pushing the direction joystick left to balance the drone.
-16-

12.3 Speed Switch
This drone comes with 3 speed modes (Low/ Medium/ High). Press the
Speed Switch button on the upper left of the transmitter to switch the
speed. Increase or decrease one speed at a time.
“Di” indicates Low speed, “DiDi” indicates Medium speed and “DiDiDi”
indicates High speed. (The Low Speed is default speed mode.)
12.4 Emergency Stop
The Emergency Stop function can be only used in case of
emergency during the flight to avoid any of damage or injury.
Press the upper left and upper right button of the transmitter at the
same time, the motors will stop immediately.
-17-
