Home Decorators Collection Elmhurst WSFP60ECHD-20 User manual

THANK YOU
We appreciate the trust and confidence you have placed in Home Decorators Collection through the purchase of this fireplace console
We strive to continually create quality products designed to enhance your home Visit us online to see our full line of products available
for your home improvement needs Thank you for choosing Home Decorators Collection!
OMSID # 207000465
Model # WSFP60ECHD-20
ASSEMBLY INSTRUCTIONS
Elmhurst 60 in Media Console with Infrared Electric Fireplace
in Brown Twilight Grey Finish
Questions, problems, missing parts? Before returning to the store,
call Home Decorators Collection Customer Service
8 a m - 7 p m , EST, Monday-Friday
9 a m - 6 p m , EST, Saturday
1-800-986-3460
HOMEDEPOT COM/HOMEDECORATORS

2
Table of Contents
Table of Contents 2
Safety Information 2
Warranty 2
Pre-Assembly 2
Planning Assembly 2
Tools required 2
Hardware Included 3
Package Contents 4
Assembly 5
Care and Maintenance 18
Safety Information
Please read and understand these instructions before
assembling and using this console Save these instructions
for future reference
MAXIMUM RECOMMENDED WEIGHT LOADS
WARNING: This unit is not intended for use with CRT TVs
Use only with flat panel TVs and audio/video equipment
meeting recommended size and weight limits Never use
with larger/heavier than recommended flat panel TVs or
equipment To avoid instability, place flat panel TV in the
center of the unit; the base of the television must be able
to rest on the supporting surface of the unit without
over-hanging the edges Improperly positioned flat panel
TVs, or flat panel TVs or other equipment that exceed
recommended size and weight limits could fall off or break
the unit, causing possible serious injury
Warranty
We are confident that you will be delighted with this purchase Should this product be defective in workmanship or materials, or
fail under normal use, we will repair or replace it for a period of up to one (1) year from date of purchase
This warranty gives you specific rights and you may also have other rights which vary from state to state
Contact the Customer Service Team at 1-800-986-3460 or visit www HomeDepot com/homedecorators
Pre-Assembly
PLANNING ASSEMBLY
Compare all parts with the Hardware Included and Package Contents list If any part appears missing or damaged, do not
assemble this product and contact the Customer Service Team at 1-800-986-3460
TOOLS REQUIRED
Phillips
screwdriver
(not provided)
Maximum load 22 6 kg / 50 lb
P
lace
TV
behind
the
stopper
F
its
up
to
most
1
77
8
cm /
70
in
flat
panel
TVs
M
aximum
load
61
2
kg
/
1
3
5
lb

3 HOMEDEPOT COM/HOMEDECORATORS
Please contact 1-800-986-3460 for further assistance
Pre-Assembly (continued)
HARDWARE INCLUDED
NOTE: Hardware not shown to actual size
Part
Description
Quantity
Part
Description
Quantity
AA
Cam
l
ock
35
+ 1 extra
LL
Straight
m
etal plate
2
BB
Cam
b
olt
35
+ 1 extra
MM
L
-
shaped metal brace
2
CC
Long
w
ood dowel
34
+
1
extra
NN
Door stopper
2
DD
Short
w
ood dowel
4
+
1
extra
OO
Knob
4
EE
Long
wood
s
crew
4
+ 1 extra
PP
Knob bolt
4
FF
Medium wood
s
crew
17
+ 1 extra
QQ
Tri
angle metal plate
2
GG
Short wood screw
16
+ 1 extra
RR
Floor leveler
2
HH
Washer head screw
38
+
1
extra
SS
Acrylic stopper
1
II
Pan head screw
2
+ 1 extra
TT
Glue
1
JJ
Cam
l
ock
c
over
16
+ 1 extra
UU
Touch
-
up
p
en
1
KK
Shelf
pin
8 + 1 extra
VV
Tipping
r
estraint
h
ardware
k
it
2
MM
LL NN
OO
PP
QQ
RR SS
VV UU
TT
AA BB CC DD EE FF GG HH II JJ
KK

4
Pre-Assembly (continued)
PACKAGE CONTENTS
Part
Description
Quantity
Part
Description
Quantity
A
Top panel
1
L
Right lower partition panel
1
B
Center shelf
1
M
Upper partition
panel
1
C
Bottom panel
1
N
Fireplace insert cover
1
D
Upper back panel
1
O
Center crossbar
1
E
Top crossbar
1
P
Adjustable shelf
2
F
Bottom back stretcher
1
Q
Lower back panel
2
G
Bottom front stretcher
1
R
Side door
2
H
Bottom front molding
1
S
Middle
stile
2
I
Left side panel
1
Fireplace insert
1
J
Right side panel
1
Remote control with battery
1
K
Left lower partition panel
1
A
B
C
D
E
F
G
H
I J K L
M
OP
QRSN

5 HOMEDEPOT COM/HOMEDECORATORS
Please contact 1-800-986-3460 for further assistance
Assembly
1
Attaching the top crossbar
NOTE: Do not fully tighten all bolts until you finish assembling all parts Once assembled, go back and fully tighten all bolts This
will make the assembly easier
□Unpack the unit and confirm that you have all the hardware and required parts Assemble the unit on a carpeted floor or
the empty carton to avoid any scratches
□Attach the top crossbar (E) to the top panel (A) with five medium wood screws (FF)
2
Screwing the cam bolts
□
Securely screw the cam bolts (BB) into the designated small holes on the
t
op
p
anel
(A),
the
bottom panel (C)
,
side panels
(I and J) and the lower partition panels (K and L) using a Phillips screwdriver
A
I
J
C
K
L
BB
FF
E
A

6
Assembly (continued)
3
Attaching the cam bolts and door stoppers
□
Securely screw the cam bolts (BB) into the designated small holes on the center shelf (B)
on
both s
id
es Tighten with
a
Phillips screwdriver
□Using the pilot holes as a guide, fasten two door stoppers (NN) to the center shelf (B) with four short wood screws (GG)
Make sure that the right angle edge faces the finished edge
4
Installing the center crossbar
NOTE: Refer to the dowel and cam lock assembling guide drawings in this step for further clarification on how to properly glue
in the wooden dowels and install cam locks Apply this method whenever instructed to install wood dowels and cam locks
□Align and attach the center crossbar (O) to the center shelf (B) with two long wood dowels (CC) and three cam locks
(AA)
AA
CC
O
B
BB
B
B
NN
GG
GLUE
XX
FINAL
1 2 43

7 HOMEDEPOT COM/HOMEDECORATORS
Please contact 1-800-986-3460 for further assistance
Assembly (continued)
5
Attaching the middle stiles
□
Fasten one
m
iddle
stile
(S) to the left lower partition panel (K)
with
two long wood dowels (CC) and two cam locks (AA)
□Repeat the same procedure to combine the other middle stile (S) and right lower partition panel (L) together
6
Installing the lower partition panels
□
Glue
four long wood dowels (CC) into the top inner holes of
the
lower partition panels (
K
and
L
)
□Align the large holes on the center shelf (B) with the inserted wood dowels (CC) and press them together Attach the
lower partition panels (K and L) in place by engaging four cam locks (AA)
CC
AA
B
K
L
K
S
S
L
CC
AA

8
Assembly (continued)
7
Attaching the bottom stretchers
□
Glue
two
long wood dowels (CC) into the inner holes of
the
bottom front stretcher
(
G
) and attach
i
t to the
bottom panel
(C) with three cam locks (AA)
□Repeat the same procedure to attach the bottom back stretcher (F) at the opposite end
8
Attaching the bottom panel
□
Glue
four wood dowels (
CC
) into the inner holes of the partition panels (K and L)
□Align the large holes on the bottom panel (C) with the inserted wood dowels (CC) and press them together Attach the
bottom panel (C) into place with four long wood screws (EE)
CC
EE
EE
C
K
L
F
G
C
F
G
CC
AA

9 HOMEDEPOT COM/HOMEDECORATORS
Please contact 1-800-986-3460 for further assistance
Assembly (continued)
9
Installing the side panels
□
Glue
ten long wood dowels (CC) into the inner
holes of
the
center shelf (B)
and
the
bottom panel assembly at both ends
□Align the large holes on both side panels (I and J) with the inserted wood dowels (CC) and press them together Attach
the side panels (I and J) in place by engaging ten cam locks (AA)
10
Securing the bottom front stretcher
□
Fasten the bottom front stretcher
(G)
to the side panels (I and J)
with
four
medium wood
screws (FF)
C
B
I
J
CC
AA
I
J
G
FF

10
Assembly (continued)
11
Attaching the bottom front molding
□
Align and attach the bottom
front molding (H) to the bottom front stretcher (G)
with
four short wood dowels (DD) and
eight medium wood screws (FF)
12
Installing the triangle metal plates
□
Using
the pilot holes as a guide, fasten
two
triangle metal plates (
QQ
) at the
bottom joints between
the
bottom front
stretcher (G) and side panels (I and J) using four short wood screws (GG) per plate
C
FF
FF
DD
H
G
GG
QQ
I
J
G

11 HOMEDEPOT COM/HOMEDECORATORS
Please contact 1-800-986-3460 for further assistance
Assembly (continued)
13
Screwing the floor levelers
□
Screw two floor levelers (RR) into the
installed t
riangle metal plates
(QQ)
14
Attaching the upper partition panel
□
Insert one long wood dowel (CC
) into the middle hole of
the
upper partition panel (M) and attach it to the center shelf (B)
by engaging two cam locks (AA)
CC
AA
B
M
RR
RR
I
J
G
QQ
QQ

12
Assembly (continued)
15
Attaching the top panel
□
Insert
five long
wood dowels (
CC
) into
the
top inner
holes
on upper
side panels (I and J) and
p
artition
p
anel
(M)
Position
the top panel (A) onto the inserted wood dowels (CC) and fasten it in place with six cam locks (AA)
16
Installing the metal plate
□
Flip the assembled unit around at its front edges
Fasten the middle crossbar (
O
) to the
middle
stile
s
(
S
) by attaching
two metal plates (LL) at the joints, using two short wood screws (GG) in each, as shown
AA
CC
I
J
AM
B
S
O
S
GG
LL

13 HOMEDEPOT COM/HOMEDECORATORS
Please contact 1-800-986-3460 for further assistance
Assembly (continued)
17
Attaching the back panels
□
Pick up the upper back panel (D
) and align the
drilled holes against the upper long edge with the pilot holes on the back
stretcher of the top panel (A) Attach the back panel (D) in place using the provided washer head screws (HH)
□Align and attach two lower back panels (Q) to the lower side panels and partition panels (I, J, K and L) with the provided
washer head screws (HH), using the pilot holes as a guide
18
Attaching the knobs
□
Attach
the
knob
s
(
OO
) to the front side of
the
door
s
(
R
)
and
fireplace insert cover (
T
)
with
the
knob
b
olt
s
(
PP
)
UP
UP
HH
D
Q
Q
J
K
C
B
PP PP
OO
OO
X2
R
T

14
Assembly (continued)
19
Installing the doors
□
Stand the assembled unit upright
□Pick up one door (R) and attach the extended hinge arms to the hinge bases installed on the left side panel (I) Loosen
the bolt on the back of the hinge base for an easy fit Align and insert the “U” slot on the hinge arm under the bolt head
on the back of the hinge base Make sure that both door hinges engage and function properly Tighten the bolt on the
hinge base to lock the hinges in place
□Repeat the procedure to attach the other door (R) at the opposite side
□Open and close the doors to make sure they are aligned and shut correctly If necessary, adjust the screws for a good
fit Refer to the hinge sticker on the door for adjustment
20
Attaching the adjustable shelves and cam lock covers
□Open the doors (R) and insert 4 shelf pins (KK) into the desired holes inside each side compartment Make sure you
place the 4 shelf pins in the same level so the shelf is not tilted Rest the adjustable shelves (P) onto the shelf pins (KK)
□Plug the cam lock covers (JJ) onto the visible cam locks to conceal the cams
I
J
R
R
1
I
J
K
L
KK
KK
JJ

15 HOMEDEPOT COM/HOMEDECORATORS
Please contact 1-800-986-3460 for further assistance
Assembly (continued)
21
Installing the fireplace insert
□
Lift the fireplace insert carefully into the back of the assembled mantel and center it in the opening DO NOT drag the
insert across the bottom panel (C) as it may scratch the unit
22
Attaching the L-shaped metal braces
□Using the pilot holes as a guide, align and attach two L-shaped metal braces (MM) to the bottom panel (C) by screwing
one pan head screw (II) in each
C
C
II
MM

16
Assembly (continued)
23
Attaching the acrylic stopper
□Remove the paper backing of the acrylic stopper (SS) Then properly align the acrylic stopper into the cut-out on the
acrylic stopper template on the front of the top panel (A) Press down on the acrylic stopper to help adhesion
□At the back of the top panel (A), carefully pull out the thumb tacks to remove the acrylic stopper template
NOTE
: You must install the acrylic TV stopper to prevent TV from tipping when placing your flat panel television
on the top panel
24
Installing the fireplace insert cover
□Pick up the fireplace insert cover (N) and insert the bottom pins into the pre-attached plastic bushings on the bottom
panel (C) Push the top rail of the fireplace insert cover (N) until snap the top ball spring catch
NOTE: Please ensure the fireplace insert has been properly turned off, and allow the fireplace insert to cool before placing
this insert cover panel over the insert
C
N
N
B
AA

17 HOMEDEPOT COM/HOMEDECORATORS
Please contact 1-800-986-3460 for further assistance
Assembly (continued)
25
Installing the tipping restraint hardware
WARNING: Young children can be seriously injured by tipping furniture You must install the tipping restraint hardware with
the unit to prevent the unit from tipping, causing any accidents or damage The tipping restraints are intended only as a
deterrent, they are not a substitute for proper adult supervision The tipping restraints are not earthquake restraints If you wish
to add the extra security of earthquake restraints, they must be purchased and installed separately
□With assistance, position the assembled fireplace at the desired location against a wall In case of uneven floor, floor
levelers are provided at the bottom of the mantel If necessary, adjust the floor levelers by hand to correct tilting, until
the unit is level
□Follow the instructions printed on the plastic bag containing the tipping hardware to attach the tip-over restraint to the
unit and the wall
□Connect the fireplace to the power transformer Follow the operating manual for the electric fireplace insert to control
your fireplace

18
Care and Maintenance
A Touch-up Pen has been provided to repair any small nicks or scratches that may occur during assembly or shipping
To clean and care for your furniture:
□Use a soft, clean cloth that will not scratch the surface when dusting
□Use of furniture polishes is not necessary Should you choose to use polishes, test first in an inconspicuous area
□Using solvents of any kind on your furniture may damage the finish
□Never use water to clean your furniture as it may cause damage to the finish
□Always use coasters under beverage glasses and flowerpots
□Liquid spills should be removed immediately Using a soft clean cloth, blot the spill gently Avoid rubbing
□Always use protective pads under hot dishes and plates Heat can cause chemical changes that may create spotting
within the furniture finish
□Stains or marks from crayons or ink markers will be difficult to remove
□In the event that your furniture is stained or otherwise damaged during use, we recommend that you call a professional
to repair your furniture
□Check bolts/screws periodically and tighten them if necessary
CARING FOR WOOD FURNITURE
It is best to keep your furniture in a climate-controlled environment Extreme temperature and humidity changes can cause
fading, warping, shrinking and splitting of wood It is advised to keep furniture away from direct sunlight as sun may damage
the finish
Proper care and cleaning at home will extend the life of your purchase Following these important and helpful tips will enhance
your furniture as it ages
CLEANING THE FIREPLACE TRIM
Clean the metal trim using a soft cloth, slightly dampened with citrus oil based product and buff with a clean soft cloth DO NOT
use brass polish or household cleaners as these products will damage the metal trim Citrus oil based products can be obtained
at supermarkets or hardware stores

Questions, problems, missing parts? Before returning to the store,
call Home Decorators Collection Customer Service
8 a m - 7 p m , EST, Monday-Friday
9 a m - 6 p m , EST, Saturday
1-800-986-3460
HOMEDEPOT COM/HOMEDECORATORS
Retain this manual for future use
