Home Decorators Collection HDVB4801 User manual

Model# HDVB4801
ASSEMBLY INSTRUCTIONS
HDVB4801 48 IN. VANITY
Questions, problems, missing parts? Before returning to the store,
call Home Decorators Collection Customer Service
8 a.m. - 7 p.m., EST, Monday - Friday, 9 a.m. - 6 p.m., EST, Saturday
1-800-986-3460
HOMEDEPOT.COM/HOMEDEPOT.CA/HOMEDECORATORS
THANK YOU
We appreciate the trust and condence you have placed in Home Decorators Collection through the purchase of this vanity. We strive to continually
create quality products designed to enhance your home. Visit us online to see our full line of products available for your home improvement needs.
Thank you for choosing Home Decorators Collection!

HOMEDEPOT.COM/HOMEDEPOT.CA/HOMEDECORATORS
Please contact 1-800-986-3460 for further assistance.
2
Table of Contents ......................................................... 2
Safety information ........................................................ 2
Warranty ........................................................................ 3
Limited Lifetime Warranty .......................................................3
What is Covered.......................................................................3
What is Not Covered ................................................................3
Pre-assembly ................................................................ 4
Planning Assembly .................................................................4
Tools Required .........................................................................4
Installation guidelines..............................................................4
Package Contents ...................................................................5
Assembly ...................................................................... 6
Maintenance .............................................................. 18
Care and cleaning ...................................................... 18
Troubleshooting.......................................................... 18
Safety Information
Table of Contents
DANGER
□Keep small parts away from children during assembly.
□Failure to follow warnings and cautions could result in
serious injury.
□DO NOT use harsh bathroom cleaners or grout
cleaners on any natural stone.
WARNING
□Read these instructions carefully and keep in a safe place.
□Adult assembly required.
□Do not over tighten connectors (screws, bolts, etc.)
Overtightening can lead to product damage.
□Small parts may present choking hazard prior to assembly.
□Do not stand, step or climb on unit.
Caution
□USE preventative cleaning mesures to keep your stone
pristine.
□USE sealers according to the product specic directions.
□Blot spills quickly, and wash with mild soap and warm water.
□Stone countertops (Granite, Marble, etc.) are suprisingly
resiliant to stains and scratches. However, as a preventative
measure, any spills on the stone surfaces should be wiped
up within a reasonable amount of time. Do not let liquid sit
on the stone overnight. Stones are most prone to staining by
oil and acid, so be sure to blot these spills as soon as they
happen. Follow up by cleaning the stone with a mild non-
abrasive soap and water.
□Be sure to check all packing materials carefully for small
parts that may have come loose inside the carton during
shipment. If parts are missing, contact THE HOME DEPOT to
obtain any missing parts.
□Using abrasive cleansers will damage the surface.

HOMEDEPOT.COM/HOMEDEPOT.CA/HOMEDECORATORS
Please contact 1-800-986-3460 for further assistance.
3
Warranty
LIMITED LIFETIME WARRANTY
WHAT IS COVERED
Home Decorators Collection products are manufactured with superior quality standards and workmanship and are backed by our limited
lifetime warranty. Home Decorators Collection products are warranted to the original consumer purchaser to be free of defects in materials
or workmanship. We will replace FREE OF CHARGE any product or parts that proves defective.
Simply, return the product / part to any of The Home Depot retail locations or call 1-800-986-3460 to receive the replacement item.
Proof of purchase (original sales receipt) from the original consumer purchaser must be made available for all Home Decorators Collection
warranty claims.
WHAT IS NOT COVERED
This warranty excludes incidental/consequential damages and failures due to misuse, abuse or normal wear and tear.
This warranty excludes all industrial, commercial & business usage, whose purchasers are hereby extended a ve-year limited warranty
from the date of purchase, with all other terms of this warranty applying except the duration of warranty. Some states and provinces do
not allow the exclusion or limitation of incidental or consequential damages, so the above limitations may not apply to you. This warranty
gives you specic legal rights and you may also have other rights that vary from state to state and province to province. Please see a store
or contact 1-800-986-3460 for more details.

HOMEDEPOT.COM/HOMEDEPOT.CA/HOMEDECORATORS
Please contact 1-800-986-3460 for further assistance.
4
When installing this product, the screws should reach the wood studs
behind the plasterboard wall. It is not recommended to install on a
plasterboard wall if the screws and anchors are not secured in the
wood studs.
INSTALLATION GUIDELINES
Pre-assembly
PLANNING ASSEMBLY
Check the vanity for damage before installation. If any part of the vanity is missing or damaged, contact the Customer Service Team at
1-800-986-3460.
Ensure that the vanity location is accessible to water supply and drain lines. It is suggested that you rough-in the water lines and drain
before installing the vanity.
NOTE: A drain pipe and trap are not included with this vanity.
TOOLS REQUIRED
Safety
goggles
Philips
screwdriver Level
Silicone Clean
rag

HOMEDEPOT.COM/HOMEDEPOT.CA/HOMEDECORATORS
Please contact 1-800-986-3460 for further assistance.
5
Pre-assembly (continued)
PACKAGE CONTENTS
A
C
B
Part Description Quantity
A Countertop 1
B Vanity 1
C Backsplash 1
D Leg 2
E Support bar 2
FWall Anchor 12
G Screw 12
H Bolt 10
I Spring washer 10
J Washer 12
K Screw 12
L Allen key 1
E
D
FG
J
H
KL
I

HOMEDEPOT.COM/HOMEDEPOT.CA/HOMEDECORATORS
Please contact 1-800-986-3460 for further assistance.
6
Unpaking the countertop
1
□Unpack the countertop (A) from its vanity (B)
and place it on a throw rug or other protective
oor covering material to prevent damage to the
countertop (A) or oor.
□Tear off the protective foam above the vanity (B).
CAUTION: During the unpacking and the handling of this
vanity, note that the countertop is not pre-glued to the
frame.
DANGER: You will need at least two people to assemble
this product properly.
Assembly (Option#1)
A
B
2
□Using Allen key (L), install the legs (D) to the vanity (B)
with the spring washers (I), washers (J) and bolts (H).
Installing the legs
L
H
J
D
B
I

HOMEDEPOT.COM/HOMEDEPOT.CA/HOMEDECORATORS
Please contact 1-800-986-3460 for further assistance.
7
□Secure the legs (D) with the screws (K) using screw
driver.
3Installing the legs
D
B
K
Assembly (Option#1) (continued)
A
B
4
□Apply lines of silicone onto the top of the vanity (B).
□Place the countertop (A) on top of the vanity (B).
CAUTION: Wear a pair of rubber gloves to protect your
hands.
Attaching the countertop

HOMEDEPOT.COM/HOMEDEPOT.CA/HOMEDECORATORS
Please contact 1-800-986-3460 for further assistance.
8
B
A
C
C
Attaching the backsplash
5
□Wipe off the area on the top of the countertop (A)
where the backsplash (C) will sit using a clean rag.
□Apply a line of silicone onto the bottom of the
backsplash (C).
□Align the backsplash (C) with the back edge. Slowly
lower it onto the countertop (A) and gently press to
adhere.
Assembly (Option#1) (continued)
6
□Wipe away any seeping silicone from underneath
the backsplash (C) with a clean rag.
Completing the assembly

HOMEDEPOT.COM/HOMEDEPOT.CA/HOMEDECORATORS
Please contact 1-800-986-3460 for further assistance.
9
Drying
7
□Allow the vanity to dry for 24 hours before use.
24H!
Assembly (Option#1) (continued)

HOMEDEPOT.COM/HOMEDEPOT.CA/HOMEDECORATORS
Please contact 1-800-986-3460 for further assistance.
10
Assembly (Option#2)
A
B
2
CAUTION: During the unpacking and the handling of this
vanity, note that the countertop is not pre-glued to the
frame.
DANGER: You will need at least two people to assemble
this product properly.
Unpaking the countertop
1
□Unpack the countertop (A) from its vanity (B)
and place it on a throw rug or other protective
oor covering material to prevent damage to the
countertop (A) or oor.
□Tear off the protective foam above the vanity (B).
Installing support bars
□Measure the height (d) at where the vanity will be
located, as illustrated.
□Add 19-3/4” (502mm) to the height (H1), this
calculated measure is the distance of the bottom of
the 2 support bars to the oor, as illustrated below.
Mark the bottom position of the 2 support bar (E) on
the wall.
H = H1 + 19-3/4” [502]
Support
bar
E
H1

HOMEDEPOT.COM/HOMEDEPOT.CA/HOMEDECORATORS
Please contact 1-800-986-3460 for further assistance.
11
Installing support bars
3Installing support bars 4
□Keep the support bars in the position, then drill pilot
holes on the wall through the support bar at the
marked positions using ø1/8” (2.5mm) drill bit.
□Using a stud nder or equivalent tool, locate at
least 1 wall stud and mark its positions on the wall
for each support bar (E). While holding the support
bar (E) in its position against the wall, check that it
is level, then mark 2 positions for 2 holes for each
support bar (E) as indicated. One of the holes must
be right over the wall stud.
□Note: make sure the distance between the 2 bar is
smaller than 1-3/16’’ [30mm].
E
E
0”~1-3/16” [0~30]
1-3/8’’ [35]
Proper height of the
holes to be drilled on
the Support Bar.
Assembly (Option#2) (continued)
ø1/8”
2.5mm

HOMEDEPOT.COM/HOMEDEPOT.CA/HOMEDECORATORS
Please contact 1-800-986-3460 for further assistance.
12
Installing support bars
5Installing support bars 6
□Replace and secure the support bars (E) with
screws (G).
□Except for the holes that are over the stud, drill in
the exisiting holes on the wall using ø5/16” (8mm)
drill bit and insert the wall anchors (F) into the holes
using a rubber mallet until the wall anchors are
ush with the wall.
F
ø5/16”
8mm
Assembly (Option#2) (continued)
G
E

HOMEDEPOT.COM/HOMEDEPOT.CA/HOMEDECORATORS
Please contact 1-800-986-3460 for further assistance.
13
Hang on the vanity
7Securing the vanity 8
□Mark the positions of the holes through the vanity
(B) onto the wall.
□Gently hang the vanity (B) on the support bars (E).
E
B
B
Assembly (Option#2) (continued)

HOMEDEPOT.COM/HOMEDEPOT.CA/HOMEDECORATORS
Please contact 1-800-986-3460 for further assistance.
14
Securing the vanity
9Securing the vanity 10
□Drill pilot holes on the wall at the marked positions
using ø5/16” (8mm) drill bit and insert the wall
anchors (E) into the holes using a rubber mallet
until the wall anchors (E) are ush with the wall.
□Gently unhang the vanity (B) from the support bars
(E).
Assembly (Option#2) (continued)
E
BF
E
ø5/16”
8mm

HOMEDEPOT.COM/HOMEDEPOT.CA/HOMEDECORATORS
Please contact 1-800-986-3460 for further assistance.
15
Securing the vanity
11 12
□Replace and secure the vanity (B) with screws (G).
G
B
Assembly (Option#2) (continued)
A
B
□Apply lines of silicone onto the top of the vanity (B).
□Place the countertop (A) on top of the vanity (B).
CAUTION: Wear a pair of rubber gloves to protect your
hands.
Attaching the countertop

HOMEDEPOT.COM/HOMEDEPOT.CA/HOMEDECORATORS
Please contact 1-800-986-3460 for further assistance.
16
A
C
B
14
□Wipe away any seeping silicone from underneath the
backsplash (C) with a clean rag.
Completing the assembly
Attaching the backsplash
13
□Wipe off the area on the top of the countertop (A)
where the backsplash (C) will sit using a clean rag.
□Apply a line of silicone onto the bottom of the
backsplash (C).
□Align the backsplash (C) with the back edge.
Slowly lower it onto the countertop (A) and gently
press to adhere.
Assembly (Option#2) (continued)

HOMEDEPOT.COM/HOMEDEPOT.CA/HOMEDECORATORS
Please contact 1-800-986-3460 for further assistance.
17
Drying
15
□Allow the vanity to dry for 24 hours before use.
Assembly (Option#2) (continued)
24H!

HOMEDEPOT.COM/HOMEDEPOT.CA/HOMEDECORATORS
Please contact 1-800-986-3460 for further assistance.
18
Maintenance
□Stone countertops (Granite, Marble, etc.) are surprisingly resilient to stains and scratches. However, as a preventative measure, any spills
on the stone surfaces should be wiped up within a reasonable amount of time. Do not let liquid sit on the stone overnight. Stones are most
prone to staining by oil and acid, so be sure to blot these spills up as soon as they happen. Follow up by cleaning the stone with a mild non-
abrasive soap and water.
□In bathrooms specically, stone tends to attract soap scum, just like man-made tile. Rinse vanity top with clean, hot water frequently.
□The use of sealers is also a powerful preventative measure. Your stone was sealed at the factory, but reapplication is necessary over time.
How often is determined by the quality of the sealer used, and the frequency of use. We recommend using a penetrating non-toxic sealer for
bath areas, but a food-safe sealer is typically not necessary.
□If stains and scratches do occur, there are many things you can do as a consumer to remove them. Remove oil based stains with acetone,
mineral spirits, or ammonia. Organic stains like coffee, tea, or juice can be removed with hydrogen peroxide, mixed with a few drops of
ammonia.
□Water spots or rings are the most common problem with bath vanities, and are caused by minerals left behind when water evaporates.
These can be removed by bufng the spots gently with 00 gauge steel wool. Likewise, small nicks and scratches can often be removed the
same way. Larger scratches, chips, and resilient stains may require professional help. Please contact your local stonemason for details.
Care and Cleaning
□Liquid spills, such as alcohol, medications, etc should be cleaned up promptly. Some liquids with high-acid content can etch marble
surfaces if left for any length of time. Popular products that should be promptly cleaned up are: shaving cream, toothpaste, perfume,
cologne, nail polish remover, hair coloring and perm products, shampoo, drain opener, and toilet bowl cleaner.
□Place protective pads on the bottoms of any heavy objects, such as pottery, appliances, or other objects that may scratch the marble
surface.
□Avoid abrasive cleaners or rough cleaning pads. If necessary, you can use a soft bufng pad.
□Use coasters under drinking glasses to prevent glass rings on the surface.
□Do not stand on the marble top to x overhead lights or other items. Do not place extremely heavy items on the top.
Troubleshooting
Problem Possible Cause Correction
Surface or product is not level. Floor is not level. If this product has adjustable legs,
adjust the legs until the surface
is level.
Doors are not properly aligned. Door hinges not adjusted properly. Adjust the door hinges.

Questions, problems, missing parts? Before returning to the store, call
Home Decorators Collection Customer Service.
8 a.m. - 7 p.m., EST, Monday - Friday, 9a.m. - 6 p.m., EST, Saturday
1-800-986-3460
HOMEDEPOT.COM/HOMEDEPOT.CA/HOMEDECORATORS
Retain this manual for future use.
