Home Decorators Collection WSFP65SDECHD-27 User manual

THANK YOU
We appreciate the trust and confidence you have placed in Home Decorators Collection through the purchase of this fireplace
console. We strive to continually create quality products designed to enhance your home. Visit us online to see our full line of
products available for your home improvement needs. Thank you for choosing Home Decorators Collection!
OMSID # 301538222
Model # WSFP65SDECHD-27
ASSEMBLY INSTRUCTIONS
Arabian Tall 65 in. Media Console
Infrared Electric Fireplace in Antique Blue Finish
Questions, problems, missing parts? Before returning to the store,
call Home Decorators Collection Customer Service
8 a.m. - 7 p.m., EST, Monday-Friday
9 a.m. - 6 p.m., EST, Saturday
1-800-986-3460
HOMEDEPOT.COM/HOMEDECORATORS

2
Table of Contents
Table of Contents..........................................................2
Safety Information.........................................................2
Warranty.........................................................................2
Pre-Assembly ................................................................2
Planning Assembly.....................................................2
Tools required ............................................................2
Hardware Included.....................................................3
Package Contents......................................................4
Assembly....................................................................... 5
Care and Maintenance................................................ 16
Safety Information
Please read and understand these instructions before
assembling and using this console. Save these
instructions for future reference.
MAXIMUM RECOMMENDED WEIGHT
LOADS
WARNING: This unit is not intended for use with CRT
TVs. Use only with flat panel TVs and audio/video
equipment meeting recommended size and weight
limits. Never use with larger/heavier than recommended
flat panel TVs or equipment. To avoid instability, place
flat panel TV in the center of the unit; the base of the
television must be able to rest on the supporting
surface of the unit without over-hanging the edges.
Improperly positioned flat panel TVs, or flat panel TVs or
other equipment that exceeds recommended size and
weight limits could fall off or break the unit, causing
possible serious injury.
Warranty
We are confident that you will be delighted with this purchase. Should this product be defective in workmanship or
materials, or fail under normal use, we will repair or replace it for a period of up to one (1) year from date of purchase.
This warranty gives you specific rights and you may also have other rights which vary from state to state.
Contact the Customer Service Team at 1-800-986-3460 or visit www.HomeDepot.com/homedecorators.
Pre-Assembly
PLANNING ASSEMBLY
Compare all parts with the Hardware Included and Package Contents list. If any part appears missing or damaged, do not
assemble this product and contact the Customer Service Team at 1-800-986-3460.
TOOLS REQUIRED
Maximum load 22.6 kg / 50 lb MAXIMUM LOAD 50 LB (22.7 kg)
Place TV behind the stopper
Fitsup to most190.5cm / 75 in.flat panel TVs
Maximum load 61.2 kg / 135 lb
Maximum load 6.8 kg / 15 lb MAXIMUM LOAD 50 LB (22.7 kg)

3 HOMEDEPOT.COM/HOMEDECORATORS
Please contact 1-800-986-3460 for further assistance.
Phillips
screwdriver
(not provided)
Pre-Assembly (continued)
HARDWARE INCLUDED
NOTE: Hardware not shown to actual size.
Part
Description
Quantity
Part
Description
Quantity
AA
Wood dowel
36 + 1 extra
HH
Cam lock cover
8 + 1 extra
BB
Cam lock
37 + 1 extra
II
L-shaped metal brace
2
CC
Cam bolt
37 + 1 extra
JJ
Acrylic stopper
1
DD
Washer head screw
36 + 1 extra
KK
Glue
1
EE
Flat head screw
12 + 1 extra
LL
Touch-up pen
1
FF
Straight metal plate
2
MM
Tipping restraint hardware kit
2
GG
Shelf pin
8 + 1 extra
LL MAXIMUM LOAD 50 LB (22.7 kg)
KK MAXIMUM LOAD 50 LB (22.7 kg)
MM MAXIMUM LOAD 50 LB (22.7 kg)
AA MAXIMUM LOAD 50 LB (22.7 kg)
BB MAXIMUM LOAD 50 LB (22.7 kg)
CC MAXIMUM LOAD 50 LB (22.7 kg)
DD MAXIMUM LOAD 50 LB (22.7 kg)
EE MAXIMUM LOAD 50 LB (22.7 kg)
FF MAXIMUM LOAD 50 LB (22.7 kg)
GG MAXIMUM LOAD 50 LB (22.7 kg)
HH MAXIMUM LOAD 50 LB (22.7 kg)
II MAXIMUM LOAD 50 LB (22.7 kg)
JJ MAXIMUM LOAD 50 LB (22.7 kg)

4
Pre-Assembly (continued)
PACKAGE CONTENTS
Part
Description
Quantity
Part
Description
Quantity
A
Top panel
1
K
Left side panel
1
B
Base
1
L
Left partition panel
1
C
Center shelf
1
M
Right partition panel
1
D
Wood door panel
4
N
Right side panel
1
E
Middle crossbar
1
O
Left Door
2
F
Support
2
P
Right Door
2
G
Drawer
2
Q
Left side back panel
1
H
Adjustable shelf
2
R
Right side back panel
1
I
Fixed shelf
2
Fireplace insert
1
J
Middle back panel
1
Remote control with battery
1

5 HOMEDEPOT.COM/HOMEDECORATORS
Please contact 1-800-986-3460 for further assistance.
Assembly
1
Screwing the cam bolts
NOTE: Do not fully tighten all bolts until you finish assembling all parts. Once assembled, go back and fully tighten all
bolts. This will make the assembly easier.
□Unpack the unit and confirm that you have all the hardware and required parts. Assemble the unit on a
carpeted floor or the empty carton to avoid any scratches.
□Securely screw the cam bolts (CC) into the designated plastic bushings on the top panel and base (A and B)
and side panels (K and N) and center shelf molding (D). Fully tighten with a Phillips screwdriver.
2
Screwing the cam bolts
□Securely screw the cam bolts (CC) into the designated plastic bushings on the left partition panel (L). Fully
tighten with a Phillips screwdriver.
CC
A
B
KN
D
CC
LL

6
Assembly (continued)
3
Screwing the cam bolts
□Securely screw the cam bolts (CC) into the designated plastic bushings on the right partition panel (M). Fully
tighten with a Phillips screwdriver.
4
Attaching the center shelf assembling
□Align and attach the center shelf assembling (C) to the panels (L and M) by using six wood dowels (AA) and
six cam locks (BB).
GLUE
XXFINAL
1 2 43
MMCC
BB
C
L
M
BB

7 HOMEDEPOT.COM/HOMEDECORATORS
Please contact 1-800-986-3460 for further assistance.
Assembly (continued)
5
Attaching the left side panel and
fixed shelf
□Align and attach one fixed shelf (I) to the left panels (K and L) by using four wood dowels (AA) and four cam
locks (BB).
6
Attaching the right side panel and fixed shelf
□Repeat the same procedure to combine the other fixed shelf (I) and right panels (M and N) together.
BB
L
K
I
BB
M
I
N

8
Assembly (continued)
7
Attaching the top panel
□Glue eight wood dowels (AA) into the top inner holes on panels (K, L, M and N). Position the top panel (A) onto
the inserted wood dowels (AA) and fasten it in place with eight cam locks (BB).
8
Attaching the middle crossbar
□Attach the middle crossbar (E) to the base (B) by using two wood dowels (AA) and three cam locks (BB).
AA
K
L
M
N
A
B
E

9 HOMEDEPOT.COM/HOMEDECORATORS
Please contact 1-800-986-3460 for further assistance.
Assembly (continued)
9
Installing the base
□Glue eight wood dowels (AA) into the bottom inner holes on side panels (K and N) and partition panels (L and
M). Position the base (B) onto the inserted wood dowels (AA) and fasten it in place with eight cam locks (BB).
10
Installing the metal plate
□Stand the assembled unit upright.
□Fasten the middle crossbar (E) to the partition panels (L and M) by attaching two metal plates (FF) at the
joints, using two wood screws (EE) in each. As shown.
B
K
L
M
N
ML
E
EE
FF

10
Assembly (continued)
11
Installing the supports
□Align and attach the supports (F) to the base (B) with two wood dowels (CC) and two cam locks (AA) in each,
as shown.
12
Attaching the back panels
□Pick up the back panels (J, Q and R) and align the drilled holes against the upper long edge with the pilot
holes on the back stretcher of top panel (A). Attach the back panels in place using the provided washer head
screws (DD).
F
F
AA
BB
B
N
CL
AB
R
J
Q
DD

11 HOMEDEPOT.COM/HOMEDECORATORS
Please contact 1-800-986-3460 for further assistance.
Assembly (continued)
13
Installing the drawers
□Insert the drawer into the frame. Extend the ball bearing slide tracks on the panels all the way forward
(including ball bearing cart). Then align the slide runners on the drawer with the slide tracks and push the
drawer carefully inside until it stops.
NOTE: If the drawer does not go in smoothly, please take it out and repeat the step. If you need to remove the drawer, please
pull the drawer all the way out, then simultaneously push the plastic release lever of the ball bearing slides up on one side
and down on the other side, and then pull it completely out.
14
Installing the adjustable shelves
□Insert four shelf pins (GG) into the desired holes inside each side compartment. Tilt and rest the adjustable
shelves (H) onto the shelf pins (GG) and secure in place with the short wood screws (EE).
KLM
N
G
G
HH
GG
GG
EE
KLM
N
H
H

12
Assembly (continued)
15
Change wood door panels
□The doors of this unit are shipped with the glass insert. You can keep the doors as they are, or interchange the
insert panel with the wood panel (S), depending on the desired configuration.
□To change door panels, loosen the screws on the inside of the door and rotate the clips to remove the panel.
Replace with desired panel, then rotate clips to secure the panel within the door frame and tighten screws.
16
Installing the doors
□Hold the release clutch on both top guide blocks of the doors (O and P) and press all the way down.
□Install the doors (O and P) to the inner slide guide rail, then press down the release clutch and release the
guide pin into its track.
O/P
O
B
P
1
2
56
3
4
A

13 HOMEDEPOT.COM/HOMEDECORATORS
Please contact 1-800-986-3460 for further assistance.
Assembly (continued)
17
Installing the right door
□Repeat the same procedure to install the other right door (P) to the outer slide guide rail.
18
Installing the left door
□Repeat the same procedure to install the other left door (O) to the outer slide guide rail.
2
3
67
4
1
5
P
B
A
2
3
67
4
5
1
O
B
A

14
Assembly (continued)
19
Installing the fireplace insert
□Lift the fireplace insert carefully into the back of the assembled mantel and center it in the opening. DO NOT
drag the insert across the bottom panel (B) as it may scratch the unit.
20
Attaching the L-shaped metal braces
□Using the pilot holes as a guide, align and attach two L-shaped metal braces (II) to the supports (F) by screwing
two short pan head screws (DD).
F
F
Electric
Firebox
II
DD
FF

15 HOMEDEPOT.COM/HOMEDECORATORS
Please contact 1-800-986-3460 for further assistance.
Assembly (continued)
21
Installing the acrylic stopper
□Remove the paper backing of acrylic stopper (JJ), then properly align the acrylic stopper into the cut-out on the
acrylic stopper template on the front of the top panel (A). Press down on the acrylic stopper to help adhesion.
□At the back of the top panel (A), carefully pull out the thumb tacks to remove the acrylic stopper template.
NOTE: You must install the acrylic TV stopper to prevent TV from tipping when placing your flat panel television
on the top panel.
22
Installing the tipping restraint
hardware
WARNING: Young children can be seriously injured by tipping furniture. You must install the tipping restraint hardware
with the unit to prevent the unit from tipping, causing any accidents or damage. The tipping restraints are intended only
as a deterrent, they are not a substitute for proper adult supervision. The tipping restraints are not earthquake restraints.
If you wish to add the extra security of earthquake restraints, theymust be purchased and installed separately.
□With assistance, position the assembled fireplace at the desired location against a wall. In case of uneven floor,
floor levelers are provided at the bottom of the mantel. If necessary, adjust the floor levelers by hand to correct
tilting, until the unit is level.
□Follow the instructions printed on the plastic bag containing the tipping hardware to attach the tip-over restraint to
the unit and the wall.
□Connect the fireplace to the power transformer. Follow the operating manual for the electric fireplace insert to
control your fireplace.
A
A
Electric
Firebox

16
Care and Maintenance
A Touch-up Pen has been provided to repair any small nicks or scratches that may occur during assembly or shipping.
To clean and care for your furniture:
□Use a soft, clean cloth that will not scratch the surface when dusting.
□Use of furniture polishes is not necessary. Should you choose to use polishes, test first in an inconspicuous area.
□Using solvents of any kind on your furniture may damage the finish.
□Never use water to clean your furniture as it may cause damage to the finish.
□Always use coasters under beverage glasses and flowerpots.
□Liquid spills should be removed immediately. Using a soft clean cloth, blot the spill gently. Avoid rubbing.
□Always use protective pads under hot dishes and plates. Heat can cause chemical changes that may create
spotting within the furniture finish.
□Stains or marks from crayons or ink markers will be difficult to remove.
□In the event that your furniture is stained or otherwise damaged during use, we recommend that you call a
professional to repair your furniture.
□Check bolts/screws periodically and tighten them if necessary.
CARING FOR WOOD FURNITURE
It is best to keep your furniture in a climate-controlled environment. Extreme temperature and humidity changes can
cause fading, warping, shrinking and splitting of wood. It is advised to keep furniture away from direct sunlight as sun may
damage the finish.
Proper care and cleaning at home will extend the life of your purchase. Following these important and helpful tips will
enhance your furniture as it ages.
CLEANING THE FIREPLACE TRIM
Clean the metal trim using a soft cloth, slightly dampened with citrus oil based product and buff with a clean soft cloth. DO
NOT use brass polish or household cleaners as these products will damage the metal trim. Citrus oil based products can
be obtained at supermarkets or hardware stores.

Questions, problems, missing parts? Before returning to the store,
call Home Decorators Collection Customer Service
8 a.m. - 7 p.m., EST, Monday-Friday
9 a.m. - 6 p.m., EST, Saturday
1-800-986-3460
HOMEDEPOT.COM/HOMEDECORATORS
Retain this manual for future use.
