Homeglow B-Warm HGH001 User manual

B-Warm
Instructions
Patent No: GB2514123
Model No: HGH001
Homeglow Products Ltd., Mayeld, Usk, Monmouthshire NP15 1SY
Tel: [phone] www.homeglowproducts.co.uk
To nd out more about the B-warm heated seat cover please
visit our website at www.homeglowproducts.co.uk.
Technical Specication:
l 220v-240v 50Hz AC
l Output 10W/45W
l Precision temperature control
l One button control 4 settings
l CE certied to EN60335-2-17 and EN62233
l Auto shutdown in event of any failure
l Machine washable cover for hygiene
l 1 year warranty
Maintenance:
Seat cover is low maintenance and can be wiped with a dampened cloth to
remove marks. It can be washed in a washing machine at 30C (synthetics);
remove the loose plastic items and disconnect power cable with controller from
cover by pressing retaining clips and withdrawing. DO NOT WASH CONTROLLER.
Do not tumble dry. It should be left to dry on a rack or on a at surface.
Re-assemble when dry.
Warranty:
1 year warranty subject to there being no evidence of misuse.
When disposing of this product please separate it from other household waste to ensure that it
can be recycled in an environmentally sound manner. For more details on collection and proper
disposal, please contact your local government ofce or the retailer where you purchased this
product. Proper disposal will prevent possible harm to the environment or to human health.

1. Slot loose Velcro belt (5) through L shaped part (3) and
position with equal lengths either side, with tails’ hooks
at each end on lower side (on top of cushion – see next
instruction).
2. Lift seat cushion and place L shaped part (3) behind cushion
with belt straps wrapped over rear of seat cushion with tail
Velcro hooks uppermost. Tension lightly and close.
3. Attach second attached Velcro belt (6) around cushion near
front – lightly tension and close. Replace cushion.
4. Place main cover (1) on chair with patterned side up with
connector position in angle of chair cushion and back. Press
rmly down in angle of seat and lumbar to ensure Velcro
has engaged between cover and chair.
5. Slot top of main cover (1) through slotted plastic part (4) and
close Velcro. Locate over top of chair .
6. Take back section (2). Attach by looping Velcro straps
around chair legs, tension so that back section is central and
close loops.
7. Take top of back section (2) and loop through slot in plastic
part (4), tension back section lightly and close Velcro.
8. Position front of cover either under cushion or leave over
end of chair.
Operating:
1. Ensure cable with controller is connected firmly to
heated seat cover socket before you plug into the
mains supply.
2. Insert plug to mains power supply and switch on.
2. Ensure cables are positioned safely to avoid hazards.
3. Press controller button to select one of the four settings
indicated by coloured LEDs. Lowest setting is green, highest
red. To switch off or set another setting repeatedly press
button to select. Heat setting will be fast to respond and will
hold temperature selected very accurately.
4. Unit will switch off automatically after 4 hours and can be
reset for further 4 hour period.
Assembly:
The Homeglow Heated Seat Cover will t on most armchairs
and some sofas. Unpack and check following items:
• Main seat cover with controller already connected
• Adjustable back section
• L shaped plastic part
• Slotted plastic part
• 1 loose Velcro belt
• 1 attached Velcro belt
