Assembly Instruction
ITEM NO. 9928BLK/DBR-2
DOUBLE GLIDER RECLINING LOVE SEAT WITH CONSOLE
NOTE: Do not use power tools for assembly. Power tools increase the risk
of over tightening which lead to splitting or cracking the wood.
PARTS LIST
NO. DRAWING QTY DESCRIPTION
A 1 LSF BACK REST
B 1 RSF BACK REST
C 1 CONSOLE BACK REST
D 1 LSF EAR
E 1 RSF EAR
F 1 SEAT
G 2 BOLT

-2-
Please follow the drawings below to assemble the item.
Step 1.Console back rest is stored in non-woven bag and put in the bottom of
Console. Please take out for assembly.
Step 2.Align the female brackets at the
back rest onto the male brackets at the
seat, insert and push to the end, make
sure the brackets are secured in
position.
Step 3.Insert the LSF ear and RSF ear
to the back rest and make sure it is
secured in position.
Step 4. .Align the back rest to the console Step 5. Completed!
Base ,insert the bolts from the top of the
base, rotate to tighten it.
A
B
F
D
E

-3-
CARE INSTRUCTION FOR PU FURNITURE
Avoid exposing furniture directly to sunlight or heating and air conditioning
Outlets. Exposure to sunlight or heating and air conditioning outlets will fade/
Damage PU.
Wipe gently with a damp soft cloth to remove dust, dirt and any grime buildup.
Wipe PU with professional cleanser
