ASSEMBLY INSTRUCTIONS
5pcs Pack Counter Height Set
Ant Oak Finish
This page lists all the contents included in the box. Please take the time to identify
the hardware as well as the individual components to this product. As you unpack
and prepare for assembly, place the contents on a carpeted or padded area to
protect them from damage.
c l e a n i n g & c a r e Treat surface with care. Clean surfaces with a dry or
damp soft cloth. Do not use abrasive cleaners. Hardware may loosen over time.
Periodically check that all connections are tight.
A Phillips head screwdriver is necessary for assembly.

2
4 PCS
CHAIR RIGHT SIDE CROSSBAR
R

TOP
61
2
3
D
C
C
D
TOP
5
5
5
5
Place center post (C) upside down on a clean, smooth surface. Attach table legs (D) to the
center post (C) using nuts (1), spring washers (2) and flat washers (3).Fasten nuts (1) with
wrench (6).
REQUIRED HARDWARE IN THIS STEP
NO. DESCRIPTION SKETCH QTY
2.
8 PCS
SPRING WASHER
1.
8 PCS
3.
8 PCS
OPEN WRENCH
6. 1 PC
FLAT WASHER
NUT
STEP 1
3
REQUIRED HARDWARE IN THIS STEP
NO. DESCRIPTION SKETCH QTY
4 PCS
5. LEVELER
Attach levelers (5) into the pre-drilled holes on the bottom of the
legs (D).
STEP 2

BOTTOM
7
4
C
B
4
REQUIRED HARDWARE IN THIS STEP
NO. DESCRIPTION SKETCH QTY
4 PCS
4.
LONG ALLEN BOLT
Turn the assembled pedestal upright. Attach table base panel (B) to the
center post (C) using long allen bolts (4). Tighten the allen bolts (4) with
allen key (7).
1 PC
7.
ALLEN KEY
REQUIRED HARDWARE IN THIS STEP
NO. DESCRIPTION SKETCH QTY
4 PCS
8.
SHORT BOLT
Gently place the table top (A) upside down on a clean smooth surface.
Attach the assembled table base to the table top (A) using short bolts
(with spring and flat washers) (8). Tighten bolts (8) with allen key (7).
1 PC
7.
ALLEN KEY
STEP 3
STEP 4
8
8
8
A
B
7

5
STEP5
Turn the table upright.
The table is now ready for use

Attach seat frame (G) to chair back frame (E) using short bolts (10), long
bolts (9), spring washers (2) and flat washers (3) as shown. do not tighten
the bolts in this step.
6
REQUIRED HARDWARE IN THIS STEP
NO. DESCRIPTION SKETCH QTY
2.
7 PCS
SPRING WASHER
7 PCS
3.
OPEN WRENCH
6. 1 PC
FLAT WASHER
LONG BOLT
9. 4 PCS
SHORT BOLT
10. 3 PCS
Note: Seat frame (G) has holes on each side. These holes are to attach
the seat board (F) in the next step. Ensure that the wider end of the holes
face down towards the ground.
Place seat board (F) upside down on a clean smooth surface. Attach
assembled chair frame to the seat board (F) with wood screw (11) using
a Phillips head screw driver (not included).
REQUIRED HARDWARE IN THIS STEP
NO. DESCRIPTION SKETCH QTY
11. WOOD SCREW
6 PCS
STEP 6
STEP 7

STEP 8
7
Attach chair left and right front legs (H & I) to seat frame (G) with flat
washers (3), spring washers (2), and nuts (1) as shown. Do not fully tighten
nuts (1). Insert chair left side crossbar and chair right side crossbar (K & L)
into the front left and right chair legs (H & I) and chair back frame (E).
Note: The small holes on all the crossbars must face towards the ground
(when chair in the normal use position).
Tighten all nuts previously installed with wrench (6). Secure the front
crossbar (J), chair left side crossbar (K) and chair right side crossbar (L) to
the chair legs using wood screws(11) and a Phillips head screw driver
(not included) as shown below.
REQUIRED HARDWARE IN THIS STEP
NO. DESCRIPTION SKETCH QTY
2.
4 PCS
SPRING WASHER
1.
4 PCS
3.
4 PCS
OPEN WRENCH
6. 1 PC
FLAT WASHER
NUT
11. WOOD SCREW
6 PCS

Repeat Step 6-8 to assemble the remaining chairs.
STEP 9
8
Turn the chair upright.
The chair is now ready for use
