HOMELITE
EXTENDED REACH HEDGE TRIMMER
MODEL NUMBER UT44180
REPAIR SHEET

2
HOMELITE HEDGE TRIMMER – MODEL NUMBER UT44180
Note: The assembly shown represents an important part of the double insulated system. To avoid the possibility of alteration or damage to the
system, service should be performed by your nearest Homelite authorized service dealer.
1 32201162G Screw (M4 x 23)................................. 2
2 3290675G Lock Washer ...................................... 2
3 3290186G Washer............................................... 2
4 31307445G Front Handle ...................................... 1
PARTS LIST
Figure A
5 31103445G Debris Deflector................................. 1
6 34201162G Deflector Retainer.............................. 1
7 34111171G Scabbard ........................................... 1
Key Part
No. Number Description Qty
Key Part
No. Number Description Qty
1
2
3
41
2
3
5
6
7

3
HOMELITE HEDGE TRIMMER – MODEL NUMBER UT44180
Figure B
15
29
22
22
21
21
1
11 26
15
27
1
25
2
10
11
12
9
13
14
14
6
5
16
18
17
19
20
10
21
23
22
21
22
3
4
7
38
30
9
24
28
See Page 2, Key 5

4
HOMELITE HEDGE TRIMMER – MODEL NUMBER UT44180
1 31302152BG Handle Assembly.................................. 1
2 34114152CG Collar ....................................................1
3 31102445G Pivot Housing Assembly ............................ 1
4 31306171G Spring Cord Assembly.......................... 1
5 34103171AG Pivot Button .......................................... 1
6 31305445G Motor w/Blade Assembly ..................... 1
7 32907152G Lock Nut (M6) .......................................1
8 099999499051 Icon Label ............................................. 1
9 3220203G Screw (M2.9 x 12 mm).......................... 2
10 31101445G Motor Housing Assembly .....................1
11 3220313G Screw (M4 x 14 mm)........................... 14
12 099941002900 Data Label............................................. 1
13 099941002902 Left Danger Label .................................1
14 099999499054 Deflector Warning Label .......................2
15 36504161G Wire Nut ................................................ 3
16 34104171AG Pivot Lock ............................................. 1
The model number will be found on a label attached to the motor housing. Always mention the model number in all correspondence regarding
your HEDGE TRIMMER or when ordering repair parts.
17 33903171G Compression Spring ............................. 1
18 099941002903 Right Danger Label............................... 1
19 099941002901 Logo Label ............................................ 1
20 099941002904 Pivot Label ............................................ 1
21 3410801G Cord Clamp .......................................... 4
22 3220345G Screw (M3.5 x 12 mm).......................... 8
23 32901163G Screw (M6 x 41 mm)............................. 1
24 34110445G Tube ...................................................... 1
25 36303152G Switch ................................................... 1
26 34118152G Switch Trigger ....................................... 1
27 34110152G Lock Off Button ....................................1
28 33402161G Compression Spring ............................. 2
29 31305163G Power Cord Assembly .......................... 1
30 099941002910 Cord Warning Label.............................. 1
987000834 Operator’s Manual ................................ 1
11-19-09
(REV:02)
PARTS LIST
KEY PART
NO. NUMBER DESCRIPTION QTY.
KEY PART
NO. NUMBER DESCRIPTION QTY.
WARNING: Improper repair of a double insulated tool can result in damage to the double insulation system possibly causing electrical shock or
electrocution. Any repairs requiring disassembly of your tool requires safety testing and should be performed by your nearest Homelite autho-
rized service dealer.

5
HOMELITE HEDGE TRIMMER – MODEL NUMBER UT44180
WIRING DIAGRAM
SLEEVE
BLACK
BLACK
WHITE
POWER CORD
JUMPER CORD
WHITE
BLACK
CONNECTOR
CONNECTOR
BLACK
WHITE
RED
BRUSH LEAD
RED
BRUSH LEAD
MOTOR
