STRAIGHT SHAFT TRIMMER
MODEL NO. UT70129
REPAIR SHEET

HOMELITE STRAIGHT SHAFT TRIMMER – MODEL NO. UT70129
2
FIGURE A
26
4
3
1
5
9
10
8
7
14
19
20
18
13
26
27
29
12
821
24
23
22
25
28
11
17
16
30 31
15
32

HOMELITE STRAIGHT SHAFT TRIMMER – MODEL NO. UT70129
3
The model number will be found on a plate attached to the engine housing. Always mention the model number in all correspondence regarding your
STRING TRIMMER or when ordering repair parts.
17 PA01613 DRUM & CONNECTOR ...........................1
18 PS04300 SPACER ...................................................1
19 00242 CLUTCH DISK ( ST185 & ST385 ) ..........2
20 98929A WASHER..................................................1
21 82538 SCREW....................................................4
22 06976 DECAL, CE ..............................................1
23 984287001 DECAL, 110 POWER SOUND.................1
24 PS06261 DECAL, ZIP START .................................1
25 PS06297 DECAL, MODEL ......................................1
26 A98773A SPRING & CONTAINER ..........................1
27 98770A STARTER PULLEY ..................................1
28 PS06339 AIR BAFFEL PLATE.................................1
29 82543 SCREW....................................................3
30 PS00218 MUFFLER GUARD ..................................1
31 82541 SCREW....................................................2
32 PA00385 STARTER HOUSING & EYELET .............1
33 03646 TORX WRENCH (NOT SHOWN).............1
KEY PART
NO. NUMBER DESCRIPTION QTY.
PARTS LIST FOR FIGURE A
1 984520001 IGNITION KIT........................................1
2 A06963 ELECTRICAL LEAD..............................1
3 82540 SCREW.................................................2
4 A06964 ELECTRICAL LEAD..............................1
5 PS02227 SPARK PLUG........................................1
6 984633001 REAR COVER ASSEMBLY...................1
7 PS00156 DECAL, HOMELITE..............................1
8 82563 SCREW ................................................6
9 984521001 ROTOR AND PAWL ASSEMBLY...........1
10 95479A WASHER, FLAT ....................................1
11 9789902 STARTER ROPE (42 in.).......................1
12 984576001 STARTER ASSEMBLY ..........................1
13 5946702 STARTER GRIP ....................................1
14 82556 SCREW.................................................2
15 81208 NUT.......................................................2
16 PS03542 NOSE CONE ADAPTER.......................1
KEY PART
NO. NUMBER DESCRIPTION QTY.

HOMELITE STRAIGHT SHAFT TRIMMER – MODEL NO. UT70129
4
FIGURE B
2
1
FIGURE C
1
26
9
10
11
12
8
4
17
16
3
3
4
5
7
6
8
13
14
7
5
15
20
21
22
23
18 19
10
25
24

HOMELITE STRAIGHT SHAFT TRIMMER – MODEL NO. UT70129
5
The model number will be found on a plate attached to the motor housing. Always mention the model number in all correspondence regarding your
STRING TRIMMER or when ordering repair parts.
1 984559001 CONTROL HANDLE ASSEMBLY................1
2 81162 NUT .............................................................1
3 PS05028 PLASTIC KNOB...........................................1
4 PS03545 HANDLE BAR CLAMP ................................1
5 PS05035 BOLT............................................................1
6 PS03631 HANDLEBAR...............................................1
7 PS03543 ASSIST GRIP L/H........................................1
8 984557001 BIKE HANDLE ASSEMBLY .........................1
9 983989001 STRAP W/HIP PAD (NOT SHOWN) ............1
10 82260 THUMB SCREW..........................................1
KEY PART
NO. NUMBER DESCRIPTION QTY.
1 PS01255 SCREW .......................................................4
2 PS02293 FLEXIBLE SHAFT ......................................1
3 PA01364 GEAR CASE ASSEMBLY............................1
4 041681A FLANGED WASHER ...................................1
5 08572 STRING SHIELD CCW................................1
6 82531 SCREW (10 - 24 x 7/8)................................2
7 08573 BLADE GUARD CCW .................................1
8 9855141 ADAPTER SHAFT/1986 ..............................1
9 A98231A HOUSING AND EYELETS ..........................1
10 06713 COMPRESSION SPRING ...........................1
11 PA01347A SPOOL AND STRING (.95).........................1
12 PA01271 SPOOL RETAINER (L/H THREAD).............1
13 A08139 MOUNTING PLATE .....................................2
14 07076 CUT OFF BLADE .......................................1
15 81261 HEX NUT .....................................................2
16 984662001 D.S. HOUSING FOR BIKE HANDLE ...........1
17 PS06337 WARNING DECAL.......................................1
18 PS04673 SCREW (10-24 x .625 TAPTIT) ...................1
19 PS04680 SCREW (1/4 - 20 x 1.25 TAP)......................1
20 984227001 TRI-ARC BLADE ........................................1
21 04409 CUPPED WASHER .....................................1
22 04277 LOCK NUT...................................................1
23 00063 HOLDING PIN .............................................1
24 09197 WARNING LABEL .......................................1
25 984554001 STRING SHIELD ASSEMBLY .....................1
KEY PART
NO. NUMBER DESCRIPTION QTY.
PARTS LIST FOR FIGURE B PARTS LIST FOR FIGURE C

HOMELITE STRAIGHT SHAFT TRIMMER – MODEL NO. UT70129
6
FIGURE D FIGURE E
1
3
2
5
4
2
7
6
4
2
1
6
5
7
4
3
9
10
11
8
12
8
9

HOMELITE STRAIGHT SHAFT TRIMMER – MODEL NO. UT70129
7
The model number will be found on a plate attached to the motor housing. Always mention the model number in all correspondence regarding your
STRING TRIMMER or when ordering repair parts.
1 06900A HEAT DAM GASKET ...................................1
2 04474 CARBURETOR BOLT..................................2
3 98768A HEAT DAM...................................................1
4 093221 PAN HEAD SEMS SCREW .........................2
5 98766A CARBURETOR GASKET ............................1
6 A09115 FUEL CAP ...................................................1
7 98792 BUMPER .....................................................3
8 984550001 * FUEL TANK ASSEMBLY..............................1
9 984549001 CARBURETOR ASSEMBLY KIT .................1
KEY PART
NO. NUMBER DESCRIPTION QTY.
1 06900A HEAT DAM GASKET ...................................1
2 PS02128 CYLINDER ..................................................1
3 PS04000 MUFFLER GASKET ....................................1
4 98766A CARBURETOR GASKET ............................1
5 04388B CYLINDER GASKET...................................1
6 PS03498 PISTON RING ( 1-5/16 in.) .........................2
7 984543001 PISTON ASSEMBLY KIT .............................1
8 PS02807 SCREW (12-24 x .660 PAN TORX) .............3
9 06443A GASKET COVER, C/C ................................1
10 PS02130 CRANKCASE COVER.................................1
11 PS01565 PAN HEAD SCREW ....................................4
12 984546001 SHORT BLOCK ASSEMBLY .......................1
KEY PART
NO. NUMBER DESCRIPTION QTY.
PARTS LIST FOR FIGURE D PARTS LIST FOR FIGURE E
* WHEN ORDERING FUEL TANK ASSEMBLY (ITEM NUMBER 8), ALSO ORDER BUMPERS (ITEM NUMBER 7)

HOMELITE STRAIGHT SHAFT TRIMMER – MODEL NO. UT70129
8
PARTS LIST
4
67
5
3
1
3
2
1 PA01073 MUFFLER ASSEMBLY....................................................................................................................... 1
2 PS02788 PRIMER DECAL................................................................................................................................. 1
3 81208 LOCK NUT (10-24)............................................................................................................................. 2
4 PS02113 BOX AIR FILTER (CONEHEAD) ........................................................................................................ 1
5 98760 AIR FILTER......................................................................................................................................... 1
6 PS02523 CHOKE DECAL.................................................................................................................................. 1
7 PS02309 AIR BOX COVER................................................................................................................................ 1
8 06502 SPARK SCREEN (NOT SHOWN) ...................................................................................................... 1
983000207 OPERATOR'S MANUAL ..................................................................................................................... 1
KEY PART
NO. NUMBER DESCRIPTION QTY.
5-03
