Honeywell Home T6R User manual

Needed during installation:
Cable with 2 wires from the boiler to Receiver Box.
The Receiver Box requires 230V power
Before installation of the
Receiver Box
Find a suitable location near to
the boiler. Leave at least 30cm
distance from any metal objects
including wallboxes and boiler
housing.
Install the
T6 thermostat
Turn OFF the power
and remove the old thermostat
1
4Complete
installation
5
Prepare Receiver Box
for installation
2Install the
Receiver Box
3
min 0.25mm2
max 1.5mm2
To ensure your safety, always make sure mains power is switched OFF before
accessing wiring.
In case of removing the old thermostat be aware that the existing wiring will
no longer be used.
The T6 thermostat should not be placed near draughts, in direct sunlight or near heat
sources.
Loosen the front
screw to remove
cover or tighten it
when the cover is
back in place.
Max 6 mm
Please refer to the wiring
diagrams over the page
A) Wall box or Rear Wiring
Hinge open the terminal block flap
to access the cables and wall box
screw holes.
B) Surface wiring
Use the cable clamps to secure the
surface wiring.
C) Replace the cover
Locate the
hinges at the top
of the cover and
wall plate, close
the cover and
secure with the
screw.
WEEE Directive 2012/19/EC
Waste Electrical and Electronic Equipment directive
At the end of the product life dispose of the packaging and product in a
corresponding recycling centre. Do not dispose of the unit with the
usual domestic refuse. Do not burn the product.
Compatible with 24-230V on/off and OpenTherm®
appliances such as gas boilers, combi-boilers and heat
pump. Also works with zone valve applications but not with
electric heating (240V).
T6R
SMART THERMOSTAT
32308181-025 C
Choose the appropriate plug.
Place the thermostat on an even, horizontal surface and plug it in.
1.70 m
After
powering up both
devices the green
LED is on.
Turn ON mains power to the Heating Appliance and Receiver Box.
Push the button to
check if the boiler
switches on.
Button lights green.
After power up,
SETUP is displayed
on the thermostat’s
screen.
Reset
To rebind the units, reset the Receiver box, then press the button for 3 seconds.
The LED on the receiver box will blink yellow to indicate the box is in binding
mode. On the thermostat press for 5 seconds to enter the advanced menu.
Navigate to Binding, clear the current binding then bind the device again.
Must be installed by a competent person!
Read these instructions carefully. Failure to follow these instructions
can damage the product or cause a hazardous condition.
Need help? For assistance please visit: getconnected.honeywellhome.com
Resideo, 200 Berkshire Place, Winnersh Triangle, Berkshire RG41 5R
Phone: [phone]
Approvals
Hereby, Pittway Sarl declares that the radio equipment type T6R is in compliance with
Directive 2014/53/EU. The full text of the EU declaration of conformity is available at
the following internet address: https://hwllhome.co/DoC
RF (868MHz): Receiver Category 2, Max RF Power 25mW, 868–868.6MHz (868.3MHz)
Wi-Fi (2.4GHz): Max Power 100mW, 2.4–2.458GHz
ErP: Class V (+3%), (EU) 811/2013

Once setup is completed, if you need to
change more settings go to the advanced
menu. To access the advanced menu
press for 5 seconds.
Set Up and
configuratio
6
Wiring Diagrams
In the advanced menu the following
settings can be adjusted:
1) Touch to begin
setting up the thermostat.
2) Select your language.
3) Set the clock format,
time and date.
4) Touch to finalise setup.
( to setup using the App is
currently unsupported)
https://hwllhome.co/uk-wiring
For other wiring
diagrams visit:
* See boiler specifications for correct terminals
A) Basic 230V boiler
Boiler
Receiver Box
B) Combi boiler
Receiver Box
T1 T2
Boiler*
C) OpenTherm boiler D) Two-port zone valve or S-plan
Receiver Box
V4043
LANGUAGE
OPENTHERM
CYCLE RATE
MINIMUM ON TIME
HEAT RANGE
SCHEDULE OPTIONS
OPTIMISE
CLOCK
LOW LOAD CONTROL
TEMPERATURE OFFSET
BINDING
RESET
FAILSAFE
English
6
ON 0 = off, 1 = on
OFF
-
-
-
0 = off, 1 = on
0.0ºC 1.5 ºC to 1.5ºC
Bind , check RF and clear bind.
Factory, schedule, WiFi and HomeKit reset
Clock format: 1 = 12h, 2 = 24h
Setup time and date
1 minute
3, 6, 9 or 12
Daily
Opt. start OFF
Opt. stop OFF
Opt. start: 0 = off, 1 = on, 2 = Delayed start
Opt. stop: 0 = off, 1 = on
Format: 24h
Time: --:--
Date: 01/09/16
1, 2, 3, 4 or 5 minutes
Min = 5.0ºC
Max = 35.0ºC
1 = Daily schedule, 2 = 5+2 days schedule
Min: 5ºC to 21ºC, Max: 21ºC to 35ºC
Menu Item Default Options
0 = English, 1 = Français, 2 = Español
3 = Deutsch, 4 = Nederlands, 5 = Italiano
OpenTherm boiler data when available
© 2020 Resideo Technologies, Inc. All rights reserved.
The Honeywell Home trademark is used under license from Honeywell International Inc.
This product is manufactured by Resideo Technologies, Inc. and its affiliates.
Pittway Sarl, Z.A. La Pièce 4,
1180 Rolle, Switzerland
Country of origin : UK
***SETUP****
SETUP
**LANGUAGE**
*CLOCK
SETUP SETUP
CONFIGURE W
AM
PM
AM
PM
AM
PM
*1234
1 2 3 4 5 6
*****230****
5 sec
Receiver Box
Boiler*
T1 T2
For security reasons:
Route this wiring
through conduit or
in the wall so it is not
accessible.
