Honeywell Home T6R User manual

32308181-028 B
Needed during installation:
Cable with 2 wires from the boiler to Receiver Box.
The Receiver Box requires 230V power.
Before installation of the
Receiver Box.
Find a suitable location near to
the boiler. Leave at least 30cm
distance from any metal objects
including wallboxes and boiler
housing.
Install the
T6 thermostat
Turn OFF the power
and remove the old thermostat
1
4Complete
installation
5
Prepare Receiver Box
for installation
2Install the
Receiver Box
3
min 0.25mm2
max 1.5mm2
To ensure your safety, always make sure mains power is switched OFF before
accessing wiring.
In case of removing the old thermostat be aware that the existing wiring will
no longer be used
The T6R thermostat should not be placed near draughts, in direct sunlight or near
heat sources. It should be at least 1.2 - 1.5 meters from the floor.
Loosen the front
screw to remove
cover or tighten it
when the cover is
back in place.
Max 6 mm
Please refer to the wiring
diagrams over the page
Turn ON mains power to the Heating Appliance and Receiver Box.
No binding needed, Receiver Box and Thermostat are pre-bound.
After power up,
SETUP is displayed on
the thermostat’s screen.
A) Wall box or Rear Wiring
Hinge open the terminal block flap
to access the cables and wall box
screw holes.
B) Surface wiring
Use the cable clamps to secure the
surface wiring.
C) Replace the cover
Locate the
hinges at the top
of the cover and
wall plate, close
the cover and
secure with the
screw.
WEEE Directive 2012/19/EC
Waste Electrical and Electronic Equipment directive
At the end of the product life dispose of the packaging and product in
a corresponding recycling centre. Do not dispose of the unit with the
usual domestic refuse. Do not burn the product.
T6R Smart Thermostat
Wall Mount
After powering
up both devices
the green LED is
on.
Push one of the buttons
to check if the valves are
switching.
Buttons light green.
Reset
To rebind the units, reset the Receiver box, then press the button for 3 seconds.
The LED on the receiver box will blink yellow to indicate the box is in binding
mode. On the thermostat press for 5 seconds to enter the advanced menu.
Navigate to Binding, clear the current binding then bind the device again.
Compatible with 24-230V on/off and OpenTherm®
appliances such as gas boilers, combi-boilers and heat
pump. Also compatible with Sundial Y- and S-plan stored
hot water systems with zone valves.
Must be installed by a competent person!
Read these instructions carefully. Failure to follow these instructions
can damage the product or cause a hazardous condition.
Need help? For assistance please visit: getconnected.honeywellhome.com
Resideo, 200 Berkshire Place, Winnersh Triangle, Berkshire RG41 5R
Phone: [phone]
Approvals
Hereby, Pittway Sarl declares that the radio equipment type T6H700RW is in
compliance with Directive 2014/53/EU. The full text of the EU declaration of conformity
is available at the following internet address: https://hwllhome.co/DoC
RF (868MHz): Receiver Category 2, Max RF Power 25mW, 868–868.6MHz (868.3MHz)
Wi-Fi (2.4GHz): Max Power 100mW, 2.4–2.458GHz
ErP: Class V (+3%), (EU) 811/2013
+
--
+
N L
The wall mounted power supply requires 230V power. Minimum wall box depth is 40mm.
A) Connect the 230V power wires to
the power supply. C) Connect thermostat wires to the
terminals: Red to + and Black
to
- and close cover.
B) Using a screwdriver open wallplate
terminal cover to connect
wires
D) Attach the thermostat to
the wallplate when finished.

Once setup is completed, if you need to
change more settings go to the advanced
menu. To access the advanced menu
press for 5 seconds.
Set Up and
configuration
6
Wiring Diagrams
In the advanced menu the following
settings can be adjusted:
https://homecomfort.resideo.com/sites/UK/
For other wiring
diagrams visit:
* See boiler specifications for
correct terminals
A) Sundial S-plan
Boiler
Receiver Box
V4043 V4043
Cylinder thermostat
1
2
B) Sundial Y-plan
Mid-Position
zone valve
Boiler
Receiver Box
V4073A
Cylinder thermostat
1
2
C) Combi boiler
Receiver Box
T1 T2
Boiler*
D) OpenTherm boiler
Receiver Box
Boiler*
T1 T2
Menu Item Default Options
LANGUAGE
OPENTHERM
SYSTEM TYPE
CYCLE RATE
MINIMUM ON TIME
HEAT RANGE
SCHEDULE OPTIONS
OPTIMISE
CLOCK
LOW LOAD CONTROL
TEMPERATURE OFFSET
BINDING
RESET
FAILSAFE
English
Heat only
6
ON 0 = off, 1 = on
OFF
-
-
-
0 = off, 1 = on
0.0ºC 1.5 ºC to 1.5ºC
Bind , check RF and clear bind.
Factory, schedule, WiFi and HomeKit reset
Clock format: 1 = 12h, 2 = 24h
Setup time and date
1 minute
3, 6, 9 or 12
Daily
Opt. start OFF
Opt. stop OFF
Opt. start: 0 = off, 1 = on, 2 = Delayed start
Opt. stop: 0 = off, 1 = on
Format: 24h
Time: --:--
Date: 01/09/16
1, 2, 3, 4 or 5 minutes
Min = 5.0ºC
Max = 35.0ºC
1 = Daily schedule, 2 = 5+2 days schedule
Min: 5ºC to 21ºC, Max: 21ºC to 35ºC
0 = English, 1 = Français, 2 = Español
3 = Deutsch, 4 = Nederlands, 5 = Italiano
Heating only or Heating + Hot Water
OpenTherm boiler data when available
*****230****
AM
PM
AM
PM
AM
PM
*12 34
1 2 3 4 5 6
5 sec
For security reasons:
Route this wiring
through conduit or
in the wall so it is not
accessible.
Pittway Sarl, Z.A. La Pièce 4,
1180 Rolle, Switzerland
Country of origin : UK
© 2021Resideo Technologies, Inc. All rights reserved.
The Honeywell Home trademark is used under license from Honeywell International Inc.
This product is manufactured by Resideo Technologies, Inc. and its affiliates.
1) Touch to begin
setting up the thermostat.
2) Select your language. 3) Set the clock format,
time and date.
5) Touch to finalise setup.
( to setup using the App is
currently unsupported)
***SETUP****
SETUP
**LANGUAGE** CLOCK
SETUP
SETUP
CONFIGURE W
*SYSTEM
SETUP
4) Select system type:
Heating only or
Heating + Hot Water.
