Honeywell Home ADEMCO 5811 System manual

ADEMCO 5811
One Zone Door/Window Transmitter
Installation and Setup Guide
GENERAL INFORMATION
The 5811 is a single zone Door/Window Transmitter, compatible with alarm systems that support 5800 series wireless
devices. 5811 has a unique serial number permanently assigned during manufacture, which must be entered into the control
panel upon installation.
NOTES
•Refer to the panel’s installation instructions for programming details.
•During programming of the control unit, 5811 transmitters should be treated as “RF” (i.e. supervised RF) Type.
MOUNTING
Choose a mounting location for the 5811 where the device is stationary and the magnet is mounted to the moving part of the
door or window. To verify adequate signal strength, conduct the Go/No Go test (see control’s instructions) on the 5811 before
mounting permanently.
1. Install the Battery by inserting one edge of the battery under one of the two plastic battery retainer clips, then pressing
down firmly to snap it beneath both clips; see figure 1.
2. Mount the 5811 using double-faced tape (supplied) by affixing it to the back of the unit and mounting the unit in place.
Use screws (optional) if desired; see figure 2. Mount the magnet (supplied) near the alignment marks on the case (see
Diagram).
Replacing an existing unit: The back-mounting plate must be replaced when replacing the 5811. Use
standard installation practices when removing the unit to avoid any damage to the mounting surface.
3. Engage the case tabs (see figure 2), then rotate the housing to close. Engage the latch with firm pressure to close and
lock.
BATTERY REMOVAL
1. Open the housing by inserting a flat blade screwdriver into latch and twisting gently.
2. Remove the old battery cell using a small flat screwdriver into the latch and gently twisting it until the cover becomes
removable (see figure 3).
5811-005-V1
BATTERY
(+ SIDE UP)
REED
SWITCH
PRESS DOWN FIRMLY TO
SNAP BATTERY UNDER
BOTH CLIPS
MAGNET
ALIGNMENT
MARKS
INSERT BATTERY
EDGE UNDER ONE CLIP
A
B
BATTERY
RETAINER
CLIPS
5811-003-V2
REED
LATCH
R
O
T
A
T
E
T
O
C
L
O
S
E
MAGNET
MOUNTING
HOLES
MAX GAP
3/4"
CASE 
TABS
SCREWDRIVER
(NO)
5811-006-V1
SCREWDRIVER
(CORRECT) PLACE TIP OF FLAT SCREW
DRIVER BETWEEN EDGE OF
BATTERY AND PLASTIC CASE
AS SHOWN. POSITIONING
SCREWDRIVER AT ANY OTHER
CORNER MAY CAUSE DAMAGE
TO DEVICE.
CAREFULLY PRY UP WHILE
TWISTING TO REMOVE BATTERY.
A
B
X
X
IC: #
FCC ID: #
IC: xxxx-xxxx
FCC ID: xxxxxxxxxx
Figure 1. Battery Installation Figure 2. Mounting Figure 3. Battery Removal
SPECIFICATIONS
Dimensions: 2-1/8” (55mm) x 1-3/16" (30mm) x 1/4” (7mm)
Operating Conditions: 23°F (-5°C) to 120°F (50°C)
Relative Humidity 95%, (non-condensing)
Replacement Battery:
Panasonic/Sener CR2032 and Duracell DL2032
1
3
2

NOTE: The FCC ID and IC Certification number is on the back of the plastic case, or see the diagram in the “Figure 3: Battery
Removal” section for the alternate location.
FEDERAL COMMUNICATIONS COMMISSION (FCC) & ISED
The user shall not make any changes or modifications to the equipment unless authorized by the Installation Instructions or User's Manual.
Unauthorized changes or modifications could void the user's authority to operate the equipment.
FCC / ISED STATEMENT
This device complies with Part 15 of the FCC Rules, and ISED’s license-exempt RSSs. Operation is subject to the following two conditions: (1)
This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may
cause undesired operation.
Cet appareil est conforme à la partie 15 des règles de la FCC et exempt de licence RSS d’ISED. Son fonctionnement est soumis aux
conditions suivantes: (1) Cet appareil ne doit pas causer d’interférences nuisibles. (2) Cet appareil doit accepter toute interférence reçue y
compris les interférences causant une réception indésirable.
Responsible Party / Issuer of Supplier’s Declaration of Conformity: Ademco Inc., a subsidiary of Resideo Technologies, Inc., 2 Corporate Center Drive., Melville,
NY 11747, Ph: 516-577-2000
TO THE INSTALLER: Regular maintenance and inspection (at least annually) by the installer and frequent testing by the user are vital to continuous satisfactory
operation of any alarm system. The installer should assume the responsibility of developing and offering a regular maintenance program to the user, as well as
acquainting the user with the proper operation and limitations of the alarm system and its component parts. Recommendations must be included for a specific
program of frequent testing (at least weekly) to insure the system’s operation at all times.
REFER TO THE INSTALLATION INSTRUCTIONS FOR THE CONTROL WITH WHICH THIS DEVICE IS USED, FOR DETAILS REGARDING
LIMITATIONS OF THE ENTIRE ALARM SYSTEM.
The product should not be disposed of with other household waste. Check for the nearest authorized collection centers or authorized
recyclers. The correct disposal of end-of-life equipment will help prevent potential negative consequences for the environment and human
health.
Any attempt to reverse-engineer this device by decoding proprietary protocols, de-compiling firmware, or any similar actions is strictly
prohibited.
SUPPORT & WARRANTY INFORMATION
For the latest documentation, online support and, patent information, please go to:
www.resideo.com
For the latest warranty information, please go to:
www.security.honeywellhome.com/warranty
.
The Honeywell Home Trademark is used under license from Honeywell International Inc.
This product manufactured by Resideo Technologies and its affiliates
2 Corporate Center Drive, Suite 100
P.O. Box 9040, Melville, NY 11747
2020 Resideo Technologies, Inc.
www.resideo.com
Ê800-03928V2DÇŠ
800-03928V2D 4/15 Rev. D
