Honeywell TC-RPFM01 User manual

Experion PKS
ControlNet Fiber Optic
Implemenation Guide
EP-DCX293
R210
10/04

ii Experion PKS ControlNet Fiber Optic Implemenation Guide R210
Honeywell 10/04
Notices and Trademarks
Copyright 2004 by Honeywell International Inc.
Release R210 October 25, 2004
While this information is presented in good faith and believed to be accurate, Honeywell disclaims
the implied warranties of merchantability and fitness for a particular purpose and makes no
express warranties except as may be stated in its written agreement with and for its customers.
In no event is Honeywell liable to anyone for any indirect, special or consequential damages. The
information and specifications in this document are subject to change without notice.
Honeywell, TotalPlant, and Experion PKS are registered trademarks of Honeywell International
Inc.
Other brand or product names are trademarks of their respective owners.
Honeywell
Industry Solutions
2500 West Union Hills
Phoenix, AZ 85027
1-800 343-0228

R210 Experion PKS ControlNet Fiber Optic Implemenation Guide iii
10/04 Honeywell
About This Document
Revision Notes
The following list provides notes concerning all revisions of this document.
Doc ID Rel ID Date Notes
EP-DCX293 R210 10/25/04 Initial Release
References
The following list identifies all documents that may be sources of reference for material
discussed in this publication.
Document Title Doc ID
ControlNet Installation Guide EP-DCXX43

About This Document
iv Experion PKS ControlNet Fiber Optic Implemenation Guide R210
Honeywell 10/04
Contacts
World Wide Web
The following lists Honeywell’s World Wide Web sites that will be of interest to our
industrial automation and control customers.
Honeywell Organization WWW Address (URL)
Corporate http://www.honeywell.com
Automation & Control Solutions http://www.acs.honeywell.com
International http://www.honeywell.com/Business/global.asp
Telephone
Contact us by telephone at the numbers listed below.
Organization Phone Number
United States
and Canada Honeywell International Inc. Automation & Control Solutions 1-800-223-8947 Sales 416-502-5200 Canada
1-800-822-7673 Tech.
Support
Asia Pacific Honeywell Ltd.
Hong Kong 852-2331-9133
Europe Honeywell Ltd.
Brussels, Belgium 32 2-728-2704
Latin America Honeywell International Inc.
Sunrise, Florida U.S.A. 954-845-2600

About This Document
R210 Experion PKS ControlNet Fiber Optic Implemenation Guide v
10/04 Honeywell
Symbol Definitions
The following table lists those symbols used in this document to denote certain
conditions.
Symbol Definition
ATTENTION: Identifies information that requires special
consideration.
TIP: Identifies advice or hints for the user, often in terms of
performing a task.
REFERENCE -EXTERNAL: Identifies an additional source of
information outside of the bookset.
REFERENCE - INTERNAL: Identifies an additional source of
information within the bookset.
Indicates a situation which, if not avoided, may result in equipment
or work (data) on the system being damaged or lost, or may result in
the inability to properly operate the process.
CAUTION: Indicates a potentially hazardous situation which, if not
avoided, may result in minor or moderate injury. It may also be used
to alert against unsafe practices.
CAUTION symbol on the equipment refers the user to the product
manual for additional information. The symbol appears next to
required information in the manual.
WARNING: Indicates a potentially hazardous situation which, if not
avoided, could result in serious injury or death.
WARNING symbol on the equipment refers the user to the product
manual for additional information. The symbol appears next to
required information in the manual.
WARNING, Risk of electrical shock: Potential shock hazard where
HAZARDOUS LIVE voltages greater than 30 Vrms, 42.4 Vpeak, or
60 VDC may be accessible.

About This Document
vi Experion PKS ControlNet Fiber Optic Implemenation Guide R210
Honeywell 10/04
Symbol Definition
ESD HAZARD: Danger of an electro-static discharge to which
equipment may be sensitive. Observe precautions for handling
electrostatic sensitive devices
Protective Earth (PE) terminal:. Provided for connection of the
protective earth (green or green/yellow) supply system conductor.
Functional earth terminal: Used for non-safety purposes such as
noise immunity improvement. NOTE: This connection shall be
bonded to Protective Earth at the source of supply in accordance
with national local electrical code requirements.
Earth Ground. Functional earth connection. NOTE: This
connection shall be bonded to Protective Earth at the source of
supply in accordance with national and local electrical code
requirements.
Chassis Ground: Identifies a connection to the chassis or frame of
the equipment shall be bonded to Protective Earth at the source of
supply in accordance with national and local electrical code
requirements.

R210 Experion PKS ControlNet Fiber Optic Implemenation Guide vii
10/04 Honeywell
Contents
ControlNet Fiber Media............................................................................1
Fiber Optic Coupling Scheme......................................................................................1
Coax to Fiber Optic Links.......................................................................................................1
Repeater/Fiber Hub................................................................................................................2
Fiber optic cable considerations.............................................................................................2
Fiber Optic Cable Handling Guidelines ..................................................................................4
Segment and link planning considerations.............................................................................5
Network Update Time (NUT) considerations..........................................................................6
About the optical power budget..............................................................................................7
Installation declaration ...........................................................................................................7
Installing ControlNet Repeater Adapter.......................................................................8
Front View..............................................................................................................................8
Mounting on a DIN rail............................................................................................................8
Wiring...................................................................................................................................10
Installing ControlNet Fiber Module.............................................................................14
Front View............................................................................................................................14
Mounting on a DIN rail..........................................................................................................14
Wiring...................................................................................................................................16
Interpreting Component LED Indications...................................................................20
Repeater Adapter LEDs.......................................................................................................20
Fiber Module LEDs ..............................................................................................................21
Checking fiber optic cable measurements.................................................................22
Measuring power loss ..........................................................................................................22
Measuring OTDR.................................................................................................................22
Dimensions ................................................................................................................23
ControlNet Repeater Adapter...............................................................................................23
Short-Distance Fiber Module................................................................................................24
Medium-Distance Fiber Module ...........................................................................................25
Specifications.............................................................................................................26
ControlNet Repeater Adapter TC-RPA002...........................................................................26
Short-Distance Fiber Module TC-RPFS01...........................................................................27
Medium-Distance Fiber Module TC-RPFM01 ......................................................................28
Appendix A ............................................................................................25
CSA Hazardous Location Approval ...........................................................................25
About CSA ...........................................................................................................................25

Contents
viii Experion PKS ControlNet Fiber Optic Implemenation Guide R210
Honeywell 10/04
CSA Certification................................................................................................................. 25
Temperature Ratings........................................................................................................... 26
Notices................................................................................................................................ 26
Approbation d’utilisation dans des environments dangereux par la CSA..................27
La CSA................................................................................................................................ 27
La certification CSA............................................................................................................. 27
Autour de temperature ........................................................................................................ 27
Discerner............................................................................................................................. 28

Tables
R210 Experion PKS ControlNet Fiber Optic Implemenation Guide ix
10/04 Honeywell
Tables
Figures
Figure 1 ControlNet Repeater/Fiber Hub for extending ControlNet coax segments......1
Figure 2 Front view ControlNet Repeater Adapter model TC-RPA002..........................8
Figure 3 Example of redundant ControlNet cabling using fiber media.........................13
Figure 4 Front view ControlNet Fiber Module model TC-RPFM01 or TC-RPFS01. ....14
Figure 5 Typical Repeater/Fiber hub cabling for non-redundant ControlNet media. ...18
Figure 6 Typical Repeater/Fiber hub cabling for non-redundant ControlNet media using a
second hub in series to extend cable distance. .....................................................18
Figure 7 Typical Repeater/Fiber hub cabling for non-redundant ControlNet media in
support of two coax segments................................................................................19

Figures
x Experion PKS ControlNet Fiber Optic Implemenation Guide R210
Honeywell 10/04

R210 Experion PKS ControlNet Fiber Optic Implemenation Guide 1
10/04 Honeywell
ControlNet Fiber Media
Fiber Optic Coupling Scheme
Coax to Fiber Optic Links
The ControlNet Repeater Adapter and ControlNet Fiber Module quickly connect to form
a Repeater/Fiber hub that lets you extend the length of a coax segment through fiber optic
links – See Figure 1. This is similar to using a coax repeater, but fiber optic cable
provides a more secure transmission over a greater distance.
The ControlNet Repeater Adapter (or the fiber optic repeater) connects to a coax trunk
cable using a standard tap and drop cable. Each Repeater Adapter supports up to four
Fiber Modules. Each Fiber Module has a pair of Receive and Transmit ports for fiber
optic cable connections.
BNC
Connector
Terminals for
Power Supply
ControlNet
Repeater
TM
Adapter
TC-RPA001
ControlNet TM
Fiber Module
TC-RPFM01
CH 1
MODULE
STATUS
N
I
RX RXTX
TX
CH 2
Receive
Channel 2
Transmit
Channel 2
Receive
Channel 1
Transmit
Channel 1
+V COM
Figure 1 ControlNet Repeater/Fiber Hub for extending ControlNet coax
segments.

ControlNet Fiber Media
Fiber Optic Coupling Scheme
2 Experion PKS ControlNet Fiber Optic Implemenation Guide R210
Honeywell 10/04
Repeater/Fiber Hub
The Repeater Adapter and Fiber Module are designed to plug together on a user supplied
35 x 7.5 mm metal, top hat rails (DIN EN50022). The Repeater Adapter model TC-
RPA002 requires a 24 Vdc power supply and it supplies the power to the Fiber Module.
The Fiber Module is available in a short distance model TC-RPFS01 and a medium
distance model TC-RPFM01. The TC-RPFS01 short-distance, Fiber Module supports
fiber optic trunk segments up to 300 meters (984 feet) in length. The TC-RPFM01
medium-distance, Fiber Module supports fiber optic trunk segments up to 3 kilometers
(9,842 feet) or more in length. The actual distance supported depends upon the quality of
the fiber cable and the quantity and quality of cable splices and connectors, including
patch panels
Fiber optic cable considerations
Since cable routes can vary from using plenum air returns to being buried underground,
we suggest that you work with a cable manufacturer to select the wiring that meets your
particular installation requirements. If you have access to the internet, you can visit the
Belden Wire and Cable Company web site at www.belden.com for helpful technical data
on a wide variety of wire and cable types.
The following table summarizes the general cable specifications for the given Fiber
Module.
Item Short-Distance Fiber
Module Medium-Distance Fiber Module
Compatible Fiber Type 200/230 micron HCS
(Hard-Clad Silica) 62.5/125 micron multimode fiber
Termination Type Versalink V-System ST-type connector
(ceramic recommended,
plastic allowed)
Operating Wavelength 650 nm (red) 1300 nm
Optical Power Budget 4.2 dB (including losses in
all connectors, splices,
and fiber)
9.3 dB

ControlNet Fiber Media
Fiber Optic Coupling Scheme
R210 Experion PKS ControlNet Fiber Optic Implemenation Guide 3
10/04 Honeywell
You can purchase prefabricated cable with Versalink fiber termination or a termination
kit and bulk cable from the Allen-Bradley Company, Inc. as noted below. This is 200/230
micron HCS cable for use with the short-distance Fiber Module only.
Cable Length Allen-Bradley Part Number
10 meters 1786-FS10
20 meters 1786-FS20
60 meters 1786-FS60
100 meters 1786-FS100
200 meters 1786-FS200
300 meters 1786-FS300
Cable Making Accessories Allen-Bradley Part Number
Bulk Cable (500 meters) 1786-FSB500
Connector Kit (10 blue v-pins, 10 black v-
pins, and 10 clamshells) 1786-FSKIT
Termination Kit 1403-NTOL

ControlNet Fiber Media
Fiber Optic Coupling Scheme
4 Experion PKS ControlNet Fiber Optic Implemenation Guide R210
Honeywell 10/04
Fiber Optic Cable Handling Guidelines
WARNING
•Never look directly into the fiber ports or the end of a cable
connected to an active transmitter. The light levels may damage
your eyesight.
•Never use a microscope to view an active cable system. The
concentration of the light from the microscope could permanently
damage your eye.
Please observe the following general guidelines when handling fiber optic cable, as well
as all manufacturer recommendations.
•Do not bend the cable beyond the minimum radius specified.
•Do not touch the end of the fiber optic strands.
•Always protect the ends of a fiber optic strand from coming in contact with dust, dirt,
or other contaminants.
•Always put protective caps on disconnected fiber cable connectors.
•Clean any contaminated ends with a soft, clean, lintless cloth and alcohol.
•Observe all local regulations for installation, including the use of personal safety
equipment.
•Always dispose of any fiber waste. This prevents the contamination of clothes, fingers,
or eyes by glass fragments.
•Review all cable parameters and specifications before installation. Be sure you have
the proper amount of connectors and installation equipment. Never attempt to use non-
compatible connectors and installation tools.

ControlNet Fiber Media
Fiber Optic Coupling Scheme
R210 Experion PKS ControlNet Fiber Optic Implemenation Guide 5
10/04 Honeywell
Segment and link planning considerations
ATTENTION
The segment and link planning considerations covered in the Experion PKS
Planning Guide in Knowledge Builder also apply for ControlNet fiber media.
The following considerations are specifically related to using fiber media in a ControlNet
system. They are intended to supplement the ControlNet coax system considerations.
•The total number of coax Repeaters and/or fiber optic Repeaters that can be connected
in series between two nodes is five (5) or less. The total number of repeaters includes:
−Each coax Repeater used to connect one coax segment to another in the path.
−Each Repeater/Fiber hub used to connect a coax segment to a fiber optic segment in
the path.
−Each Fiber Module used to connect one fiber optic segment to another in the path.
•The total length of ControlNet coax and fiber optic cable between any two nodes can
not be more than 10 km (32,808 ft).

ControlNet Fiber Media
Fiber Optic Coupling Scheme
6 Experion PKS ControlNet Fiber Optic Implemenation Guide R210
Honeywell 10/04
Network Update Time (NUT) considerations
The default NUT settings for every ControlNet Interface (CNI) module are as follows:
•NUT Time = 10000 microseconds
•Smax = 1
•UMax = 20 (w/KTC card) or 24 (w/PCIC card)
•Number of Repeaters = 0
•Cable Length = 1000 Meters
•Cable Usage = A+B
•My System uses Fiber Optics = No Checkmark
Since the Number of Repeaters and Cable Length settings affect the maximum
communications delay time in the network, you may need to adjust these settings to
match your network configuration. Set the Number of Repeaters to equal the number of
repeaters (fiber and/or coax) used in series in the longest cable (fiber and/or coax) path
between two nodes in the link. Set the Cable Length to equal the longest communications
distance (fiber and/or coax cable) between two nodes in the link, if greater than 1000
meters (3,280 feet). Also, if you use fiber optic cable in your network, you must check
the checkbox for the My System uses Fiber Optics selection.
You can use the Network Tools (NTools) utility supplied with the Experion PKS
Engineering Tools to change the network parameters (Keeper Values) in a CNI with an
address of one. Please refer to the NTools online Help for more information.

ControlNet Fiber Media
Fiber Optic Coupling Scheme
R210 Experion PKS ControlNet Fiber Optic Implemenation Guide 7
10/04 Honeywell
About the optical power budget
The maximum allowable attenuation for a system using a medium distance Fiber Module
is 9.3 dB. The connectors, splices, and fiber cable all contribute to the attenuation of a
system. You can use the following formula to determine the length of cable you can use.
Maximum cable length (km) = (Rx - Tx) (total attenuation of connectors, splices, etc.
)
cable attenuation (dB/km @ 1300nm)
For example, a fiber optic trunk segment could have the following attenuation
characteristics:
•A cable with an attenuation of 1 dB/km @ 1300 nm.
•Two cable connectors with an attenuation of 0.5 dB each.
•A splice with an attenuation of 0.3 dB.
•Repeater/Fiber hubs with maximum attenuation of 9.3 dB
Maximum cable length = (9.3 dB) (2 0.5 dB + 0.3 dB
)
1 dB/km
For this example, the maximum cable length is 8 km.
Installation declaration
ATTENTION
This equipment shall be installed in accordance with the requirements of the
National Electrical Code (NEC), ANSI/NFPA 70, or the Canadian Electrical
Code (CEC), C22.1. It is supplied as “open equipment” that is intended to be
mounted on a sub-panel within an enclosure. The suitability of the enclosure
and installed system shall be acceptable to the local “authority having
jurisdiction,” as defined in the NEC, or “authorized person” as defined in the
CEC.

ControlNet Fiber Media
Installing ControlNet Repeater Adapter
8 Experion PKS ControlNet Fiber Optic Implemenation Guide R210
Honeywell 10/04
Installing ControlNet Repeater Adapter
Front View
BNC Connector
(Remove cover
before connection)
Terminals for
Power Supply DIN Rail
Locking Tab
Cover for
Bus Connector
Fiber Channels
Status
Coax
Status
ControlNet
Repeater
TM
Adapter
TC-RPA001
+V COM
MODULE
STATUS
IN
Figure 2 Front view ControlNet Repeater Adapter model TC-RPA002.
Mounting on a DIN rail
ATTENTION
•You are responsible for obtaining and mounting the 35 x 7.5 mm
metal, top hat rails (DIN EN50022) to be used for mounting the
Repeater Adapter.
•The Repeater Adapter supports non-redundant ControlNet media
communications. For redundant ControlNet media support, a
second Repeater Adapter is required.
•Be sure you install the ControlNet Repeater Adapter at the left end
of a Repeater Adapter and Fiber Module hub.

ControlNet Fiber Media
Installing ControlNet Repeater Adapter
R210 Experion PKS ControlNet Fiber Optic Implemenation Guide 9
10/04 Honeywell
Step Action
1Orient the Repeater Adapter so the top of the unit is over the top of the DIN
rail.
2Slightly rotate the module to slip its top mounting flange on the top of the DIN
rail.
3Press the module down flush with the DIN rail so its locking tab snaps into
place, securing the module to the rail. If necessary, you can use a
screwdriver to manually retract the lock while pressing the module firmly
against the rail and then releasing it when in position.
4Leave the protective covers on the connectors until you are ready to make
the connections.
5For redundant ControlNet media, repeat this procedure to mount a second
Repeater Adapter on a separate DIN rail.

ControlNet Fiber Media
Installing ControlNet Repeater Adapter
10 Experion PKS ControlNet Fiber Optic Implemenation Guide R210
Honeywell 10/04
Wiring
ATTENTION
•To comply with CE Low Voltage Directives, you must use a Safety Extra
Low Voltage (SELV) or Protected Extra Low Voltage (PELV) power supply
(24 Vdc) to power the Repeater Adapter. To comply with the requirements
of the National Electrical Code (NEC) ANSI/NFPA 70 and the UL Listing of
this equipment, you must use a UL Listed Class 2 power supply. To
comply with the requirements of the Canadian Electrical Code (CEC)
C22.1 and the CSA Certification of this equipment, you must use a CSA
Certified Class 2 power supply.
•Be sure the Repeater Adapter is attached and secured before applying
power to it. Failure to do so may cause damage to the Repeater.
•Do not connect more that four Fiber Modules or exceed the power limit
(1.6 A @ 5 Vdc) to avoid damaging the Repeater and Fiber Modules.
