Honeywell TP30WKN User manual

Dehumidifier
User Manual
Read and save these instructions before use
EN
Déshumidificateur
Mode d’emploi
Lire ces consignes avant l’utilisation de l’appareil et les conserver
FR
Deshumidificador
Manual Del Propietario
Lea y guarde estas instrucciones antes de usar la unidad
ES
www.jmatek.com
Email: [email protected]
Model / Modèle / Modelo:
TP30WKN / TP50WKN /
TP70WKN / TP70PWKN
ENERGY STAR® qualified units remove
moisture with less energy than
conventional dehumidifiers.
Unités ENERGY STAR® pour éliminer
l'humidité avec moins d'énergie que les
déshumidificateurs conventionnels.
Unidades con calificación ENERGY
STAR® eliminan la humedad con menos
energía que los deshumidificadores
convencionales.

1
THANK YOU
SAFETY RULES
Thank you for purchasing a Honeywell Dehumidifier. This User Manual is intended to provide you
with important information needed to set up, operate, maintain and troubleshoot this product.
WARNING -- READ AND SAVE THESE INSTRUCTIONS BEFORE USING THIS PRODUCT.
The use of electrical products may create hazards that include, but are not limited to injury, fire,
electrical shock. Failure to follow these instructions may damage and/ or impair its operation and
void the warranty. In case there is any inconsistency or conflict between the English version and any
other language version of the content of this material, the English version shall prevail.
When using electrical appliances, basic safety precautions should always be followed:
EN
DO NOT touch the dehumidifier or the electrical plug with wet hands.
Check the household voltage to ensure it matches the appliance's specification.
Before operating, remove all packaging material and check for any damage that may have
occurred during shipping.
DO NOT operate any product with a damaged cord or plug.
DO NOT use an extension cord with this appliance.
DO NOT run power cord under carpeting, or cover it with rugs or runners. Keep the cord away from
areas where it may be tripped over.
Always unplug the dehumidifier before emptying the water tank.
The water collected in the tank must be discarded. The water should never be used for drinking.
Always unplug the dehumidifier and remove the water from the water tank before cleaning,
servicing or relocating the unit.
Remove the power cord from the electrical receptacle by grasping and pulling on the power cord
plug-end only, never pull the cord.
This appliance has been manufactured for use in domestic environments and must not be used
for other purposes.
DO NOT use the product in areas where gasoline, paint or other flammable goods and objects are
used or stored.
This dehumidifier is designed for indoor residential applications only. It should not be used for
commercial or industrial applications.
DO NOT attempt to repair or adjust any electrical or mechanical functions of the dehumidifier,
as this may cause danger and void the warranty.
DO NOT cover the air inlet or outlet on the appliance as this may cause the unit to fail.
DO NOT insert or allow objects to enter any ventilation or exhaust opening as this may damage
the product and could cause electrical shock or fire.
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•

2
DO NOT let children play with this appliance, packaging or included plastic bag.
If the unit is damaged or it malfunctions, do not continue to operate it. Unplug the product from
the electrical outlet. Refer to the troubleshooting section and contact the customer support
center.
Always place the dehumidifier on a leveled floor.
Never install the product near a bathtub or any water container.
Store in a dry area, away from direct sunlight, when not in use.
This appliance and its packaging materials are not intended for use by persons (including
children or elderly) with reduced physical, sensory or mental capabilities, or lack of experience
and knowledge, unless they have been given supervision or instructions concerning the use of
the appliance by a person responsible for their safety.
Always grip the top handle and keep the unit upright when transporting from room to room –
DO NOT tilt the product on its side or upside-down.
If the dehumidifier was transported tilted on its side, you must position it upright again and wait
at least 4 hours before using it.
WARNING: To reduce the risk of fire or electric shock, do not use this appliance with any solid
state speed control device.
•
•
•
•
•
•
•
•
•
SAFETY RULES (CONTINUED)
EN

3
HOW A DEHUMIDIFIER WORKS
When the dehumidifier is switched ON, a fan pulls moisture-laden air into the dehumidifier where it
passes through dehumidifying coils inside the unit. These coils condense moisture from the air
and collect it in the water tank. The dry air is then exhausted from the dehumidifier. The air flows
through the air vents of the dehumidifier into the room as dry, warm air.
IMPORTANT: The dehumidifier is designed to operate between 41°F (5°C) and 89°F (32°C).
The dehumidifier’s performance may be greatly reduced if room temperature is beyond this
temperature range.
EN
Before using the dehumidifier, place the unit UPRIGHT for at least 1 hour before use to allow the
refrigerant to stabilize. If the unit was tilted on its side or upside-down during transportation, set
the unit upright for 4 hours before use.
For optimal efficiency, the dehumidifier must be operated in an enclosed area. Keep all doors,
windows and other outside entrances to the room closed.
•
•
SELECTING A LOCATION - IMPORTANT

4
Place the dehumidifier in an area where the temperature will not drop below 41°F (5°C)
Place the dehumidifier at least 17.7 inches (45 cm) away from other objects (e.g. curtains or
furniture) that may restrict airflow from the back or through the air vents of the unit.
The dehumidifier must be positioned on a level floor.
•
•
•
SELECTING A LOCATION - IMPORTANT (CONTINUED)
17.7 inches (45 cm) 17.7 inches (45 cm)
IMPORTANT: The effectiveness of the dehumidifier can be influenced by different factors. One
factor is the rate at which new, moisture-laden air enters the room and the amount of air circulating
in and out of the area to be dehumidified. For example, if a door to a basement is constantly
opened, letting new, moisture-laden air into the room, dehumidification will take longer than
if the door was kept closed. If the dehumidifier is in a room with a storage closet or cabinets, it
will have little or no effect in drying the inside of the storage closet or cabinets unless there
is adequate circulation of air in and out of these spaces. To dehumidify these spaces, open the
storage door or cabinet doors to allow air circulation. You may find that installing a second
dehumidifier may be required for larger enclosed areas.
EN

5EN
UNPACKAGING THE DEHUMIDIFIER
There is a Foam Float inside the water tank that senses the water
level to automatically stop dehumidification when the water
tank is full. Make sure the Foam Float is positioned correctly
inside the water tank by ensuring it lies level with the top edge
of the water tank.
DO NOT REMOVE THIS FOAM FLOAT.
This Dehumidifier is packaged with a colored or transparent tape to secure some parts during
transportation. Remove the colored or transparent packaging tape from the unit.
1. Gently pull the water tank from out of the dehumidifier
2. Remove the splash guard from the top part of the
water tank
3. Take out the power plug, drain hose and other accessories,
which is placed inside the tank of the dehumidifier.
4. Once all accessories have been removed, replace
the splash guard onto the top part of the water tank.
Make sure that the tank is properly positioned.
Splash
Guard
Foam
Float
•
•

6
PARTS DESCRIPTION
11
10
7
8
12
3
9
6
16
15
12
13
17 18 19 20
5
4
1) Control Panel 10) Dehumidified Air Exhaust Vent
2) Handle 11) Washable Dust Filter
3) LED Display 12) Direct Drain Outlet
4) Splash Guard 13) Direct Drain Cap
5) Water Tank Handle 14) Mounting Holes for Cord Winders
6) Foam Float 15) Power Cord & Plug
7) Water Tank 16) Cord Winders
8) Water Level Indicator 17) Continuous Water Drain Tube
9) Casters 18) Continuous Water Drain Cap
19) Auto Drain Pump Tube 20) Auto Drain Pump Cap
* THIS IS ONLY FOR MODEL TP55PN / TP70P / TP70PN WITH BUILTIN DRAIN PUMP
14
EN
x2
**

7
Once you have removed the cord winder accessories from the water tank - follow the steps below.
EN
INSTALL THE CORD WINDER
EN
Step 2: Rotate 45-degrees clock-wise.
Step 1: Line up the cord winder pieces to the mounting holes.
Step 3: Once you hear “click”, then you know the cord winder is ready for use.
NOTE: Once the installation of the cord winder has been completed. The cord winder cannot be
removed. The installation is permanent.

8EN
USE & OPERATION
1) Display Screen 6) Filter Alert
2) Power Control 7) Sleep Mode
3) Humidity / Timer Set Controls 8) Water Full Indicator Light
4) Fan Speed Control 9) Continuous Operation Light
5) Timer Control
11) Auto Drain Pump Mode
10) PTC Mode
*THIS IS ONLY FOR MODEL TP55PN / TP70P / TP70PN WITH BUILTIN DRAIN PUMP
#THIS IS ONLY FOR MODEL TP50H / TP50HN WITH PTC TECHNOLOGY
CONTROL PANEL
(1)(8) (9)
(6) (4) (3) (2) (3) (5) (7)
(10#) (11*)

9
HUMIDITY CONTROL SETTING
When the unit is switched ON, the Display Screen shows the current humidity percentage.
Press or to select your preferred humidity level. The humidity is adjusted in increments of 5%
by pressing or . The adjustable Relative Humidity (RH) range is between 30% RH to
90% RH. Ten seconds after setting the preferred humidity setting, the display will revert back
to displaying the current humidity.
Recommended Settings: It is recommended to leave the unit running at 30% humidity at
High Fan Speed during the first 2 to 3 days until damp odors are removed. After a few days when
the Relative Humidity has been reduced to a more comfortable level, press or to choose a
higher RH% that maintains a comfortable humidity level thereafter. A recommended healthy
humidity level is between 40% and 50%.
NOTE: The humidity sensor senses current humidity in the surrounding area. It is normal for a few
degrees of variance to the humidity sensitivity from the sensor.
CONTINUOUS MODE
To activate the Continuous Mode, press the button on the Display Screen until appears.
The indicator light will be illuminated. The unit will run continuously.
FUNCTION BUTTONS
USE & OPERATION (CONTINUED)
EN
WATER TANK FULL ALERT
When the Water Tank is full, the indicator will be illuminated. The unit will beep for 3 seconds.
The compressor will shut off, and the fan will stop for a few minutes. To switch off the indicator
light, empty the water tank and when replacing it ensure the tank is secured properly in place.
IMPORTANT: Do not place the Water Tank on the floor when full. In case of an uneven base which may
cause the tank to spillover.
POWER CONTROL
Press to switch the dehumidifier ON or OFF.
CO

10
Auto-On Timer:
When unit is in Standby Mode, press , the timer indicator light will flash, press or to
select the number of hours (0.5-24 hours) until you want the unit to automatically start
running. In 5 seconds without the operation, the Timer start function, the timer indicator
light is illuminated. The previous fan speed and humidity setting will be maintained. The unit
will turn on and continue running until the water tank is full (unless the unit is set up for continuous
draining) or until you switch it off manually. Timer must be set again after each use.
NOTE: To cancel any Timer settings, simply press again, and the timer indicator light will
disappear.
NOTE: The solid red Power light indicates the unit is on Standby Mode.
Auto-Off Timer:
While the unit is running, press , the timer indicator light will flash, press or to select
the number of hours (0.5-24 hours) you want the unit to run before it switches off. In 5 seconds
without the operation, the Timer start function, the timer indicator light is illuminated. Timer
must be set again after each use.
TIMER CONTROL
The dehumidifier can be set to automatically switch ON or OFF for a selected period of time (between
0.5-24 hour intervals). The Timer hours selection is displayed on the Display Screen.
NOTE: Before setting the Timer control, make sure there is power to the unit.
FAN SPEED CONTROL
There are two fan speeds - High and Low. When, the indicator light is illuminated, the
unit is operating on High speed. When the indicator light is off, and the unit is on -
the unit is operating on Low speed.
FUNCTION BUTTONS (CONTINUED)
USE & OPERATION (CONTINUED)
EN
FILTER ALERT
When the Filter Alert Light is ON, it is time to clean the filter. Switch the unit OFF and carefully remove
the filter from the unit and clean. Replace the filter and switch ON the unit.
The Filter Alert Light should not be illuminated until the filter requires cleaning again. The frequency
of filter cleaning depends on room environment conditions. Some rooms may require changing more
frequently than others.

11
SLEEP MODE
The LED display brightness will be reduced when the unit is in Sleep Mode. Press the to activate
the Sleep Mode. When Sleep Mode is activated the indicator light will be illuminated. There
is a one-minute window period in which you can adjust the settings such as humidity and fan speed.
After one minute has lapsed, the top display will shut off, except the indicator light. Press any
button to deactivate Sleep Mode.
PTC HEATER MODE#
Press the to activate PTC Heater Mode, the indicator light is illuminated. The PTC Heater
function is suitable for environments with a temperature of 0°F to 41°F (0°C to 5°C). This
technology helps to add heat to the dehumidifying process which helps to improve the
efficiency, and increases the dehumidifying capacity of the unit.
AUTO DRAIN PUMP MODE*
The Auto Drain Pump function helps to remove condensation vertically and horizontally. Press the
to activate the Pump function, the indicator light will be illuminated.
*THIS IS ONLY FOR MODEL TP55PN / TP70P / TP70PN WITH BUILTIN DRAIN PUMP
#THIS IS ONLY FOR MODEL TP50H / TP50HN WITH PTC TECHNOLOGY
FUNCTION BUTTONS (CONTINUED)
USE & OPERATION (CONTINUED)
EN
AUTO RESTART FUNCTION
AUTOMATIC DEFROST
This unit is equipped with an Auto Restart feature. When there is a power outage, the dehumidifier
will automatically resume all its previous settings upon regaining power.
Frost may build up on the internal coils of the unit. When there is frost build up, the internal
compressor will turn off and the fan will continue to run until the frost has melted. Once the internal
coils have defrosted and dried, the compressor or fan will automatically restart and dehumidifying
will resume.

12
The condensed water can be collected directly into the water tank. When the water tank is full, the
dehumidifier will automatically shut OFF and the indicator will illuminate on the control
panel followed by a beeping sound.
IMPORTANT: Do not move the dehumidifier when the Water Tank is full as it will be heavy and can
cause water spillage.
USE & OPERATION (CONTINUED)
EN
DRAINING THE WATER
WARNING: Always drain and discard water collected from dehumidification.
The water is not clean and cannot be used for drinking.
IMPORTANT: Improper alignment or positioning of the
water tank will cause the unit to pause operation, the
warning light on top of the dehumidifier will illuminate
followed by a beeping sound, until the water tank is fitted
properly.
NOTE: There is a Foam Float inside the water tank
that senses the water level to automatically stop
dehumidification when the water tank is full. Make sure the
Foam Float is positioned correctly inside the water tank by
ensuring it lies level with the top edge of the water tank.
DO NOT REMOVE THIS FOAM FLOAT.
Locate the water tank at the front of the dehumidifier.
Gently pull the water tank out.
Grip the handle inside the water tank and carry the
water tank to a sink to empty.
Replace the empty water tank back into the front of
the dehumidifier. Please make sure that the tank is
properly positioned. The safety feature ensures that
any misalignment of the tank and the unit will prevent
the unit from turning back on.
1. Draining water collected in the Water Tank
1.1
1.2
1.3
Foam Float
1.1
1.2

13
DRAINING THE WATER (CONTINUED)
USE & OPERATION (CONTINUED)
EN
Locate the drain outlet at the back of the unit. Unscrew and remove the Direct Drain Cap.
Insert and screw the Continuous Water Drain Tube into the Direct Drain Outlet.
2.1
A continuous water drain tube is included with this unit. To activate the continuous water draining
function, you will require a suitable water drain (e.g. sink or drain hole at floor level) near the
dehumidifier.
NOTE: The Continuous Drain Tube and Continuous Drain Cap come pre-installed.
2. Continuous Water Drainage – Using a Continuous Water Drain Tube
Direct Drain Cap
Continuous
Water Drain Tube
Continuous Water
Drain Tube
3.28 ft. (1 m) Continuous Water Drain Cap

14
If there are leaks, the Continuous Water Drain Tube and Cap may have loosened and may not be
connected properly. Disconnect, replace and tighten again.
Position the other end of the Continuous Water Drain Tube in the sink or drain. Make sure the
tube is not bent or kinked which might stop the water flow. Make sure the tube is secured over
the drain and will not fall out of place causing unwanted water spillage.
2.2
2.3
IMPORTANT: Make sure water can flow down the Continuous Water Drain Tube by keeping the tube
angled down and free of bends or kinks.
IMPORTANT: If the unit is placed on uneven ground, or the Drain Tube is installed incorrectly, the
water may fill the water tank and stop running. Please check whether the ground is uneven and
reinstall the Drain Tube.
EN
DRAINING THE WATER (CONTINUED)
USE & OPERATION (CONTINUED)

15
DRAINING THE WATER (CONTINUED)
USE & OPERATION (CONTINUED)
EN
The Auto Drain Pump is available if you want to use the continuous drain function, but the drain is
further away, or located above the dehumidifier. The Auto Drain Pump Tube can be attached to the
Direct Drain Outlet located on the back side of the dehumidifier. When the water level in the water
tank reaches a certain level, the drain pump will automatically pump the water out of the tank to
the drain. This allows you to drain water condensation vertically or horizontally, even if the drain is
located above the dehumidifier.
Auto Drain Pump Tube
16.4 ft. (5 m)
Auto Drain Pump Cap
3. Continuous Water Drainage – Using the Auto Drain Pump option
*THIS IS ONLY FOR MODEL TP55PN / TP70P / TP70PN WITH BUILTIN DRAIN PUMP
Locate the drain outlet at the back of the unit. Unscrew and remove the Direct Drain Cap.
Insert and screw the Auto Drain Pump Tube into the Direct Drain Outlet.
3.1
Direct Drain Cap
Auto Drain Pump Tube
NOTE: The Auto Drain Pump Tube and Auto Drain Pump Cap come pre-installed.

16
EN
DRAINING THE WATER (CONTINUED)
USE & OPERATION (CONTINUED)
If there are leaks, the Auto Drain Pump Tube and Auto Drain Pump Cap may have loosened and
may not be connected properly. Disconnect, replace and tighten again.
Place the other end of the tube into the sink or drain. The water can be pumped up to 16.4 ft (5 m)
vertically or horizontally.
NOTE: DO NOT use an alternative drain tube that is longer than the one provided with
the unit.
To activate the Pump function, press the indicator. Once on, the indicator light will
be illuminated.
3.2
3.5
3.3
*Auto Drain Pump Tube is included in Dehumidifier models with Auto Drain Pump feature only.

17
EN
CLEANING & MAINTENANCE
USE & OPERATION (CONTINUED)
Switch off and unplug the dehumidifier from the
electrical outlet.
Carefully pull out the dust filter from the
dehumidifier.
Rinse the dust filter under running water, or
vacuum away the dust with a vacuum cleaner.
After cleaning the dust filter, dry in a cool, shaded
place, then carefully reinstall into the unit.
1.
2.
3.
4.
WARNING: Always switch OFF the dehumidifier and unplug it from the electrical outlet before
attempting any cleaning or maintenance of this product.
Appliance Maintenance:
• Switch OFF the appliance before disconnecting the power supply.
• Only use a soft cloth to clean the appliance.
Dust Filter Maintenance:
The Dust Filter located at the back of the unit helps to remove dust particles from the air. A dirty filter
clogged by dust particles can reduce the efficiency of the dehumidifier. For optimum
dehumidification, it is recommended to clean the dust filter every 2 weeks:
End of Season Storage & Maintenance:
Switch OFF the unit and unplug from the electrical power outlet.
Empty the water tank and let it dry. If your dehumidifier is connected to the continuous drain
hose, you must disconnect the hose, dry and then replace the drain cap back into the drain outlet.
Remove the air filter and clean with water. Let the air filter dry and reinstall back into the unit.
Make sure all parts of the dehumidifier and accessories are dry before storage.
Cover the dehumidifier with a cloth/ plastic bag before storage, to protect the surface from dust
and scratches.
It is recommended to coil the power cord and store it off the floor to ensure it is protected from
bends and kinks.
Store the unit upright in a dry location, away from direct sunlight.
•
•
•
•
•
•
•
If the appliance will not be used for an extended period of time:

18
EN
TROUBLESHOOTING GUIDE
The following troubleshooting guide addresses the most common problems. If problems persist, call
customer service.
PROBLEM POSSIBLE CAUSE SOLUTION
Dehumidifier
does not start
No electricity. Check for power.
The power cord is not
properly plugged in. Remove and reconnect the power cord.
The safety switch
activated on the
electrical plug.
Reset the safety switch and wait for 3 minutes to
pass. Contact customer service if problem persists.
The water tank is not in
the correct position. Position the water tank correctly into the unit. Unit will not operate until the water tank is secure in place.
Unit runs but
the humidity
level does
not decrease
The humidity level setting
is too high. Decrease the humidity level setting.
A door or window is open,
letting in new moisture. Make sure all windows or doors to the outside are closed and tightly sealed.
There are other sources
of humidity in the room
(e.g. boiling water in pot).
Switch on the dehumidifier when these
sources are not present.
The temperature in the
room is too low.
The dehumidifier is designed to operate between
41°F (5°C) and 89°F (32°C). Moisture removal is
greatly reduced if room temperatures exceed this
temperature range.
The dust filter is dirty/
blocked. Clean the dust filter.
Air outlet or intake is
blocked. Remove blockage.

19
TROUBLESHOOTING GUIDE (CONTINUED)
EN
PROBLEM POSSIBLE CAUSE SOLUTION
Unit runs but
the humidity
level does
not decrease
Insufficient time for the
dehumidifier to remove
moisture.
After initial installation, allow 24 hours to maintain
desired dryness.
Dehumidifier
runs constantly/
does not stop
Area to be dehumidified
is too large.
The capacity of your dehumidifier may not be
adequate for the room it is used in. It is recommended
to add an extra dehumidifier for large areas.
A door or window is open,
letting in new moisture. Make sure all windows or doors to the outside are closed and tightly sealed.
Water Tank
Full is
illuminated
and the unit is
beeping
The water tank is full. Empty the water tank.
The water tank is not in
the correct position. Position the water tank correctly into the unit. Unit will not operate until the water tank is secure in place.
The unit is
blowing cold air
out of the top
vent
The purpose of the top
air vent is to distribute air
into the room.
The temperature of the air from the vent depends
on the room environment and other factors. It can
fluctuate and this is normal. No action required.
Frost appears
on the coils
Dehumidifier has been
recently turned on in low
room temperatures
(usually below 41°F
(5°C)).
This is normal. Frost will disappear in an hour
or so after the dehumidifier is switched OFF.
Connected
the continuous
drain but
the water
condensation is
not draining out
the tube
Some floors may have
an uneven surface
which may affect the
continuous drainage
function
Raise the front of the Dehumidifier ½ to 1 inch
(1.27 cm to 2.54 cm) from the floor. The water
condensation will drain out the back hose and not
into the bucket.
