Honeywell H2W4PER3 User manual

PERFORMANCE SERIES IP
H2W4PER3* WDR 4MP IR Micro-Dome Camera
Quick Installation Guide
(The last “*” represents V orL,and other numbers orletters)
Thank you for purchasing a Honeywell Performance Series IP
camera. Follow the instructions in this guide to install and log in to
your camera. For instructions on configuring the camera, refer to the
user guide on the DVD that came with your camera. If you require
additional assistance, call the number listed for your region on the
back cover.
Cautions and Warnings
WARNING
To ensure compliance with electrical safety standards, this product is
intended for use with a Listed Power Adapter marked “Limited Power
Source” or “LPS” on the unit, output rated to 12 VDC, minimum 0.33 A,
TMA=60 deg C, or from Power over Ethernet (PoE) provided by Listed
Information Technology Equipment meeting IEEE 802.3af PoE standard.
CAUTION
The Ethernet connection is not intended to be connected to exposed
(outside plant) networks. Do not connect two power sources to the camera
at the same time.
CAUTION
Invisible LED radiation (850 nm). Avoid exposure to beam.
Important Safeguards
•Read and keep these instructions.
•Do not aim the camera toward a bright light source for extended periods to prevent damage to
the imager. Avoid operating the unit under or close to unstable light sources (may cause
flickering), or close to fluorescent lamps or objects reflecting light.
•Do not touch the camera lens.
•Do not drop the camera or subject it to physical shock.
•Do not use a strong or abrasive detergent when cleaning the camera.
•Avoid operating or storing the unit in extremely humid, dusty, hot/cold environments, where
the operating temperature is outside the recommended range of -22°F to 140°F (–30°C to
60°C).
•Do not apply power to the camera before completing installation.
•Ensure that the installation surface can support at least three times the weight of the camera.
Before You Begin
Before you begin, check that you have received all the parts listed below. If any parts are missing or
damaged, contact your dealer immediately.
•Camera
•Installation DVD
•Quick Installation Guide
•Allen Key (L-wrench)
•Self-tapping Screws (×5)
•Plastic Wall Anchors (×5)
•Mounting Template
CAUTION Installation and servicing should be performed only by qualified and experienced
technicians to conform to all local codes and to maintain your warranty.
Preparing the Mounting Surface
1. Inspect the site where you want to install the camera. The mounting
surface must be flat and capable of supporting at least three times
the weight of the camera.
2. Remove the backing from the mounting template sticker and affix
the sticker to the mounting surface.
Note If you are using the side exit for the cable, note the orientation of
the cable exit notch. In outdoor installations, the notch should point
downwards to prevent water from entering the camera housing.
3. Drill screw holes at the locations indicated on the mounting
template sticker and insert the supplied plastic anchors in the holes.
4. If you are flush mounting the camera and want to store the cables
inside the wall or ceiling, drill a hole at the cable exit position on the
mounting template and then pull the cables through the hole.
Mounting the Camera
1. Use the supplied Allen key to remove the dome cover from the camera assembly and set it
aside.
2. If you are using a Micro SD card with the camera, insert the SD card into the SD card slot
before continuing. See figure below for details:
CAUTION
THIS SYMBOL INDIC ATES THAT
DANGEROUS VOLTAGE
CONSTITUTING A RISK OF
ELECTRIC SHOCK IS PRESENT
WITHIN THE UNIT.
CAUTION: TO REDUCE THE RISK OF ELECTRIC
SHOCK, DO NOT REMOVE THE COVER.
NO USER-SERVICEABLE PARTS INSIDE.
REFER SERVICING TO QUALIFIED SERVICE
PERSONNEL.
THIS SYMBOL INDIC ATES THAT
IMPORTANT OPERATING AND
MAINTENANCE INSTRUCTIONS
ACCOMPANY THIS UNIT.
RISK OF ELECTRIC
SHOCK
DO NOT OPEN

© 2021 Honeywell International Inc. All rights reserved. No part of this publication may be reproduced by any means without written permission from Honeywell. The information in this publication is believed to be accurate in all respects. However, Honeywell
cannot assume responsibility for any consequences resulting from the use thereof. The information contained herein is subject to change without notice. Revisions or new additions to this publication may be issued to incorporate such changes.
3. Connect one end of the Ethernet cable to the RJ-45 port on the camera.
4. If the other end of the Ethernet cable is NOT connected to a PoE switch or NVR, connect the
power connector of the camera to a 12 VDC power source.
5. Attach the camera assembly to the mounting surface using the supplied screws.
Aiming the Camera and Logging on to the Camera
1. Aim the camera lens in the desired direction as shown in below:
Note Lens adjustment can be divided into left/right and up/down adjustment. Left/right
adjustment can be done manually as shown in Figure 1. For up/down adjustment, you must insert
the L-wrench into the hole on the lens and turn it as shown in Figure 2.
2. Tighten the adjustment screws to secure the camera lens in place.
3. Reattach the dome cover.
4. If the camera is connected to the PoE port of a Honeywell Embedded NVR, you can log on to
the camera directly from the NVR. To log on from a PC:
a. Install the Unified Tool from the installation DVD.
b. Use the Tool to discover the camera and open the camera’s webpage.
c. Log on to the camera as the admin user. The default user name is admin (case-sensitive)
and the default password is 1234.
Note

Only Internet Explorer 11 (or later) is supported.
IP address of the device is assigned automatically by DHCP server. If the DHCP server is not
available, the device will acquire 192.168.1.108 as the default IP address.
Recommended Recorders
HEN*4 8/16/32/64-channel Focus 4K NVRs (H.264 and H.265)
HEN*3 4/8/16/32-channel Performance Series NVRs (H.264 and H.265)
Regulatory Statements
FCC Compliance
This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This equipment generates, uses, and can
radiate radio frequency energy and, if not installed and used in accordance with the instructions,
may cause harmful interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the interference by one or more of the following
measures:
•Reorient or relocate the receiving antenna.
•Increase the separation between the equipment and receiver.
•Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
•Consult the dealer or an experienced radio/TV technician for help.
Note Changes or modifications not expressly approved by the party responsible for compliance
could void the user's authority to operate the equipment.
This Class B digital apparatus complies with Canadian ICES-003.
Manufacturer’s Declaration of Conformance
North America The equipment supplied with this guide conforms to UL 60950-1 and CSA C22.2
No. 60950-1.
Europe The manufacturer declares that the equipment supplied is compliant with the European
Parliament and Council Directive on the restriction of the use of certain hazardous substances in
electrical and electronic equipment (2015/863/EU), the Low Voltage Directive (2014/35/EU) and
the essential requirements of the EMC directive (2014/30/EU), conforming to the requirements of
standards EN 55032 for emissions, EN 50130-4 for immunity, and EN 62368-1 for electrical
equipment safety.
WEEE (Waste Electrical and Electronic Equipment)
Correct disposal of this product (applicable in the European Union and other
European countries with separate collection systems). This product should be
disposed of, at the end of its useful life, as per applicable local laws, regulations,
and procedures.
North America
Europe
Middle East
715 Peachtree St. NE Atlanta,
GA 30308
Newhouse Industrial Estate
Motherwell Lanarkshire ML1 5SB
United Kingdom
Emaar Business Park, Building No. 2,
Sheikh Zayed Road
P.O. Box 232362
Dubai, United Arab Emirates
www.security.honeywell.com
Tel: [phone]
www.security.honeywell.com/uk
Tel: [phone]
www.security.honeywell.com/me
Tel: [phone]
Document 800-26633-A, 03/2021
Figure 1 Figure 2
