Honeywell HMC14 User manual

The Honeywell HMC14 is a high quality 14-inch color monitor. The monitor
features a sturdy housing, and delivers sharp color images with 400 TV lines of
resolution. Unlike conventional monitors, the HMC14 features convenient
recessed front panel controls that make setup and adjustment quick and easy,
while restricting movement caused by accidental contact.
Installers can easily switch between NTSC and PAL video formats to comply with
worldwide standards. An illuminated green LED beside the power button confirms
that power is being supplied to the monitor. The monitor also features a latching
power switch which remains in its set position – either On or Off – eliminating the
need to turn the monitor back on in the event of a power loss.
The HMC14 has both composite BNC connectors and Y/C mini DIN connectors
for S-video. Since the BNC connectors are auto terminating, there is no need for
users to set termination switches when using the BNC connectors for loop-
through video. Additionally, the HMC14 has audio input and output connectors,
allowing users to listen-in as well as view the monitored area. This is especially
convenient for secured entry areas.
Market Opportunities
The HMC14 is ideal for an optimal viewing distance of six feet or less and is
designed for commercial security or surveillance applications. The monitor is ideal
for single camera viewing, or multiple camera displays when using a quad or
multiplexer.
The HMC14 can be either rack mounted using an optional rack mount kit
(HMC14RK1) or placed on a desktop.
Features
www.honeywellvideo.com
HMC14
• 400 TVL (at center)
• Convenient recessed front panel
controls
• Heavy duty metal cabinet
• Supports two composite and one
Y/C video input (looping)
• NTSC or PAL compatible
• Video loop-through with automatic
termination
• Audio Input/Output
• Rack mountable
14-INCH COLOR CRT MONITOR

NOTE: Honeywell reserves the right, without notification, to make changes in product design or specifications.
HMC14
L/HMC14D/D
July 2007
© 2007 Honeywell International Inc.
Honeywell Security
Honeywell Video Systems
2700 Blankenbaker Pkwy, Suite 150
Louisville, KY 40299
1.800.796.CCTV
www.honeywell.com
www.honeywellvideo.com
SPECIFICATIONS
Video
Video Standard NTSC or PAL
Input Signal Video
1.0 Vp-p @ 75 Ohms composite
S-Video (Y/C)
Y sig.= 0.7 V p-p
C sig.= 0.3 Vp-p @ 75 Ohms
Deflection 90° angle
Bandwidth 5 Mhz
Resolution 400 TV lines (at center)
Linearity Horizontal: 10% maximum
Vertical: 10% maximum
Front Panel Controls
•Volume •Sharpness •Contrast
•Brightness •Color •Tint CVBS or Y/C
Selector •A/B Selector •Power
Back Panel Controls Y/C Impedance
Electrical
Operating Voltage 90 to 264 VAC, 60 Hz/50 Hz
Power Consumption 70 W (Maximum)
Power Cable NEMA 5-15P, UL
Accessories
HMC14RK1 14” rack mount kit, black
Regulatory
Emissions FCC: Part 15, Class B, Canada ICES-003
Immunity CE: EN 50130-4
Safety UL: UL1950, cUL: CSA C22.2 No. 950
DHHS Rules 21
Ordering
HMC14 14 inch Color Monitor (black cabinet)
8.29’’ (210.6 mm)
12.6’’ (320 mm)
.39’’
(
10 mm)
10.79’’ (274 mm)
13.78’’ (350 mm)
1.81’’ (46 mm)
13.92’’ (353.5 mm)
12.11’’ (307.5 mm)
9.8’’ (249 mm)
2.05’’
(52 mm)
11.06’’ (280.8 mm)
AUDIO
Y/C
AC/IN
IMPEDANCE
HIGH
IN
Y/C
75
VIDEO B
OUT
IN
VIDEO A
IN
OUT OUT
IN
OUT
Environmental
Temperature
Operating: 32° F to 104° F
0° C to 40° C
Storage: 14° F to 122° F
-10° C to 50° C
Relative
Humidity 10% to 90% (non-condensing)
Mechanical
Dimensions
(W x H x D)
13.78" x 12.99" x 13.94"
(350 mm x 330 mm x 354 mm)
Viewable
Picture Area
88.97 sq. in
574 sq. cm
Weight 29.10 lb (13.2 kg)
Construction Housing: Steel
Finish: Black
Video Inputs 2 x BNC (auto terminating)
1 x Y/C Mini DIN 4-pin connectors
Video Outputs 2 x BNC (auto terminating)
1 x Y/C Mini DIN 4-pin connectors
Audio Input 1 x RCA connectors
300 mVrms
Audio Output 1 x RCA connectors
300 mVrms
