Honeywell SmartLine SLG 700 User manual

Honeywell Process Solutions
SLG 700
SmartLine Level Transmitter
Guided Wave Radar
User’s Manual
34-SL-25-11
Revision 7.0
February 2017

Page ii SLG 700 SmartLine Level Transmitter User’s Manual Revision 7
Copyrights, Notices and Trademarks
© Copyright 2017 by Honeywell International
Revision 7.0, February 2017
While the information in this document is presented in good faith and believed to be
accurate, Honeywell disclaims any implied warranties of merchantability and fitness for a
particular purpose and makes no express warranties except as may be stated in the written
agreement with and for its customers. In no event is Honeywell liable to anyone for any
indirect, special, or consequential damages. The information and specifications in this
document are subject to change without notice.
Honeywell, TDC3000, SFC, SmartLine, PlantScape, Experion PKS, and TotalPlant are
registered trademarks of Honeywell International Inc. Other brand or product names are
trademarks of their respective owners. While the information in this document is presented
in good faith and believed to be accurate, Honeywell disclaims any implied warranties of
merchantability and fitness for a particular purpose and makes no express warranties except
as may be stated in the written agreement with and for its customers. In no event is
Honeywell liable to anyone for any indirect, special, or consequential damages. The
information and specifications in this document are subject to change without notice.
Honeywell, TDC3000, SFC, SmartLine, PlantScape, Experion PKS, and TotalPlant are
registered trademarks of Honeywell International Inc. Other brand or product names are
trademarks of their respective owners.
Honeywell Process Solutions
1250 W Sam Houston Pkwy S
Houston, TX 77042

Revision 7 SLG 700 SmartLine Level Transmitter User’s Manual Page iii
About This Manual
This manual is a detailed how to reference for installing, wiring, configuring, starting up,
operating, maintaining, calibrating, and servicing Honeywell’s family of SLG 700 SmartLine
Guided Wave Radar Level Transmitters. Users who have a Honeywell SLG 700 SmartLine
Guided Wave Radar Level Transmitter configured for HARTprotocol are referred to the
SLG 700 Series HARTOption User’s Manual, Document #34-SL-25-06. Users who have a
Honeywell SLG 700 SmartLine Guided Wave Radar Level Transmitter configured for
Fieldbus operation are referred to the SLG 700 Series FoundationTM Fieldbus Option User’s
Manual, Document #34-SL-25-07.
The configuration of your Transmitter depends on the mode of operation and the options
selected for it with respect to operating controls, displays and mechanical installation. This
manual provides detailed procedures to assist first-time users, and it further includes
keystroke summaries, where appropriate, as quick reference or refreshers for experienced
personnel.
To digitally integrate a Transmitter with one of the following systems:
For the Experion PKS, you will need to supplement the information in this document
with the data and procedures in the Experion Knowledge Builder.
For Honeywell’s TotalPlant Solutions (TPS), you will need to supplement the
information in this document with the data in the PM/APM SmartLine Transmitter
Integration Manual, which is supplied with the TDC 3000 book set. (TPS is the evolution
of the TDC 3000).
Revision History
SLG 700 SmartLine Level Guided Wave Radar Transmitter User’s Manual,
Document #34-SL-25-11
Rev. 1.0 March 2015 First release
Rev. 2.0 April 2015 Updates to troubleshooting and Display menus
Rev. 3.0 June 2015 Security Considerations and Vulnerability added.
Rev. 4.0 June 2016 Updates for the R101 release. Including SLG726.
Rev. 5.0 July 2016 Display menus updated.
Rev. 6.0 December 2016 False Echo suppression, improved interface thickness
Rev. 7.0 February 2017 Troubleshooting section and Fieldbus updates

Page iv SLG 700 SmartLine Level Transmitter User’s Manual Revision 7
References
The following list identifies publications that may contain information relevant to the information
in this document.
SLG 700 SmartLine Guided Wave Radar Level Transmitter Quick Start Guide,
Document #34-SL-25-04
SLG 700 SmartLine Guided Wave Radar Level Transmitter Safety Manual,
Document #34-SL-25-05
SLG 700 SmartLine Guided Wave Radar Level Transmitter HART Option Manual,
Document #34-SL-25-06
SLG 700 SmartLine Level Transmitter Guided Wave Radar FOUNDATION Fieldbus Option
Manual, Document #34- SL-25-07
SLG 700 SmartLine Level Transmitter Product Specification Document #34-SL-03-03
Patents
The Honeywell SLG 700 SmartLine Guided Wave Radar Level Transmitter family is covered by
U.S. Patents 6055633, 9329072, 9329073, 9476753 and 9329074 their foreign equivalents and
other patents pending.
Support and Contact Information
For Europe, Asia Pacific, North and South America contact details, refer to the back page of this
manual or the appropriate Honeywell Support web site:
Honeywell Corporate www.honeywell.com
Honeywell Process Solutions https://www.honeywellprocess.com/*
Honeywell SmartLine Level https://www.honeywellprocess.com/smartline-level-transmitter.aspx
Telephone and Email Contacts
Area
Organization
Phone Number
United States and
Canada
Honeywell Inc.
1-800-343-0228 Customer Service
1-800-423-9883 Global Technical Support
Global Email
Support
Honeywell Process
Solutions
[e-mail]

Revision 7 SLG 700 SmartLine Level Transmitter User’s Manual Page v
Symbols Descriptions and Definitions
The following symbols may appear in this document.
Symbol
Definition
ATTENTION: Identifies information that requires special consideration.
TIP: Identifies advice or hints for the user, often in terms of performing a
task.
CAUTION
Indicates a situation which, if not avoided, may result in equipment or
work (data) on the system being damaged or lost, or may result in the
inability to properly operate the process.
CAUTION: Indicates a potentially hazardous situation which, if not
avoided, may result in minor or moderate injury. It may also be used to
alert against unsafe practices.
CAUTION symbol on the equipment refers the user to the product manual
for additional information. The symbol appears next to required
information in the manual.
WARNING: Indicates a potentially hazardous situation, which, if not
avoided, could result in serious injury or death.
WARNING symbol on the equipment refers the user to the product
manual for additional information. The symbol appears next to required
information in the manual.
WARNING, Risk of electrical shock: Potential shock hazard where
HAZARDOUS LIVE voltages greater than 30 Vrms, 42.4 Vpeak, or 60
VDC may be accessible.
ESD HAZARD: Danger of an electro-static discharge to which equipment
may be sensitive. Observe precautions for handling electrostatic sensitive
devices.
Protective Earth (PE) terminal: Provided for connection of the protective
earth (green or green/yellow) supply system conductor.
Functional earth terminal: Used for non-safety purposes such as noise
immunity improvement. Note: This connection shall be bonded to
Protective Earth at the source of supply in accordance with national local
electrical code requirements.
Earth Ground: Functional earth connection. Note: This connection shall
be bonded to Protective Earth at the source of supply in accordance with
national and local electrical code requirements.
Chassis Ground: Identifies a connection to the chassis or frame of the
equipment shall be bonded to Protective Earth at the source of supply in
accordance with national and local electrical code requirements.

Page vi SLG 700 SmartLine Level Transmitter User’s Manual Revision 7
Symbol
Definition
The Factory Mutual®Approval mark means the equipment has been
rigorously tested and certified to be reliable.
The Canadian Standards mark means the equipment has been tested
and meets applicable standards for safety and/or performance.
The Ex mark means the equipment complies with the requirements of the
European standards that are harmonized with the 2014/68/EU Directive
(ATEX Directive, named after the French "ATmosphere EXplosible").

Revision 7 SLG 700 SmartLine Level Transmitter User’s Manual Page vii
Contents
