4850DR
Document Reader
Quick Start Guide
4850DR-QS Rev C
8/14
Aller à www.honeywellaidc.com pour le français. FR
Vai a www.honeywellaidc.com per l'italiano. IT
Gehe zu www.honeywellaidc.com für Deutsch. DE
Ir a www.honeywellaidc.com para español. ES
ዴせ฿୰ᅜ www.honeywellaidc.com㸦䬨ỻ炸ࠋSC
㞍䚳䷩ỻ䇰実䘣旮 www.honeywellaidc.com TC

Note: Refer to your Bar Code Manual for information about cleaning
your device.
Assembling the 4850DR
Place the arm on the tray.

Attach the arm to the underside of the tray with the 3 screws from
the bag marked 50121545-001.
Place the scanner in the stand.

3
.

Press the cable firmly into the wire run along the back of the arm.
(You must use the USB cable that’s supplied with the 4850DR or a
compatible 5 volt powered cable.)

Connecting to the Host
Turn off computer’s power before connecting the document reader,
then power up the computer once the document reader is fully con-
nected.
USB Connection

Interface
Scan the bar code that describes the PC or interface you are using.
If you scan the USB COM Port Emulation code and are using a
Microsoft® Windows® PC, you will need to download a USB Serial
driver from the Honeywell website (www.honeywellaidc.com). The
driver will use the next available COM Port number. Apple® Macin-
tosh computers recognize the scanner as a USB CDC class device
and automatically use a class driver.
USB Keyboard (PC)
USB HID Bar Code Reader
USB COM Port Emulation

Aligning the Document Reader Tray
Proper cable placement is important for accurate alignment of the
device. Place the cable in the wire channel if the scanner will remain
in the base most of the time. If you plan to frequently lift out the
scanner to scan items, then set the cable in the location where it will
rest while the scanner is in the stand.
Note: The 4850DR will not capture any images until it has been
properly aligned using the following procedure.
1. Loosen the screw in the base tray with a coin.
2. Place the alignment page on the tray. Align the upper left corner
of the alignment page to the upper left corner of the tray.
3. Make sure the serial number on the alignment page matches the
serial number on your document reader.
4850DR serial number
4. Press the button on the scanner to display the illuminated aimer
crosshairs. You will hear a single beep that indicates you are
using the correct page.
(If you hear an error razz and the aimer turns off, then you have
the wrong alignment page for your document reader.)
5. Move the tray until the illuminated aimer crosshairs line up with
the printed crosshairs on the alignment page. (Be sure to wait
until the crosshairs go off before removing power or attempting to
capture an image.)

6. Remove the alignment page and tighten the screw. Save the
alignment page in the event that the tray needs to be realigned in
the future.
Note: If you need to print a new copy of the alignment page, make
sure to print the page in landscape mode.
Scanning Technique
Center a document in the document reader tray. (Smaller docu-
ments should be centered in the pocket in the tray.) Press the button
on the scanner. The view finder projects an aiming beam to indicate
the image capture area.
EZConfig-Scanning
To access additional features for the scanner use EZConfig-Scan-
ning, an online configuration software tool, available from our web-
site at www.honeywellaidc.com.
Technical Assistance
Contact information for technical support, product service, and
repair can be found at www.honeywellaidc.com.
Limited Warranty
Refer to www.honeywellaidc.com/warranty_information for your
product’s warranty information.
Patents
For patent information, refer to www.honeywellaidc.com/patents.

User Documentation
For localized versions of this document, and to download the User’s
Guides, go to www.honeywellaidc.com.
