CAHBC720PI60V
720P AHD Weather-proof IR Bullet Camera
Honeywell BlackTM
www.black.honeywell.com
Featuring the advanced Analog High Definition (AHD) video technology, the
Honeywell Black™ CAHBC720PI60V is a multi-megapixel HD analog camera
which produces 720P (1280H x 960V) sharp, high-definition image. The AHD
technology ensures real-time and non compressed signal transmission of up to
500 meters via coaxial cable, which significantly reduces installation cost and
provides much sharper images without quality loss.
Advanced Features
Featuring hybrid output definitions in CVBS (960H) and AHD (720P), the
CAHBC720PI60V is compatible with existing analog cameras, and is capable of
transmitting HD image via existing cable layout.
Market Opportunities
Featuring 2.8-12mm 2 megapixel lens, 720P high resolution, TDN function and
60 meters IR night vision, the CAHBC720PI60V is designed for small-to-medium
HD surveillance application including hotels, chain stores, commercial offices,
hospitals, residential areas, warehouses, and education facilities and so on. It is
also ideal for easy and cost-eective upgrade of existing analog system to realize
HD application.
FEATURES
● Ultra high denition: 720P (1280H x 960V)
● Hybrid output denitions in CVBS (960H) and AHD (720P) via OSD setup
● Minimum illumination: 0Lux (IR on)
● TDN (IR-Cut), AWB, AGC
● 1/2.8" Sony Exmor 960P Sensor
● 2.8-12mm 2 megapixel lens
● IR distance: 60 meters
● Power: 12VDC
● IP66 weather-proof
TDN
720P
IR
60m
weatherproof


CAHBC720PI60V
720P AHD Weather-proof IR Bullet Camera
Honeywell BlackTM
www.black.honeywell.com
SPECIFICATIONS
Model CAHBC720PI60V
Sensor 1/2.8" Sony Exmor 238 CMOS sensor
Processor NVP2430H
Scanning System Progressive scan method
Sensor Resolution 960P
Eective Pixels 1.3 Megapixel (1280H x 960V)
Output Pixels 1.3 Megapixel (1280H x 960V)
Shutter Speed 1/50- 1/100,000 sec
Minimum Illumination Color: 0.001Lux
B/W: 0 (IR-on)
Video Output CVBS and AHD output
S/N More than 50dB (AGC o)
Picture adjustments ON/OFF
Gamma Correction 0.45
Lens
Focus Length 2.8-12mm 2 Megapixel lens
Auto Iris Support N/A
Night Vision
Infrared LED 4 Array Leds
IR Beam Distance 60m
ICR ON/OFF
Camera Feature
Day & Night TDN, IR cut removable
Day / Night Mode Auto (ICR) / Color / Black & White
Auto (ICR) / Color / Black & White
Language 11 Languages (English /Chinese / Germany / French / Italian / Spanish / Polish / Romania /
Russian / Portuguese / Dutch / Turkish)
White Balance Auto / Manual
Auto Gain Control ON/OFF
WDR ON/OFF
Digital Noise Reduction 3D NR
Picture Adjustment ON/OFF
OSD DWDR / 3D / 2DNR / AGC / AWB / BLC / Anti-foggy / Privacy Mask / Mirror / DPC
Privacy Masking 4 zones
Electrical Protection Video protections voltage: 8K V
Surge protections voltage: 1.8K V
Operating Temperature -10°C~50°C
Storage Temperature -30°C~60°C
Operating Humidity 20%~90%
Power Supply 12VDC
IP Rating IP66
Dimensions 300 (D) x 110 (W) x 110 (H) mm
Weight 0.8kg
Certicate CE, FCC, C-tick
Note: Honeywell reserves the right, without notication, to make changes in product design and/or specications.

CAHBC720PI60V
720P AHD Weather-proof IR Bullet Camera
Honeywell BlackTM
www.black.honeywell.com
ORDERING
CAHBC720PI60V Weather-proof IR Bullet Camera, 720P, 1/2.8" Sony Exmor 238 CMOS sensor, TDN,2.8-12mm
2 megapixel lens, IR distance: 60m, 12VDC, PAL or NTSC
For more information:
Security East Asia
Security Pacic
Security India
Security Middle East & N.Africa
Security Russia
Security China
Security Korea
Tel: [phone]
Tel: [phone]
Tel: [phone]
Tel: [phone]
Tel: [phone]
Tel: [phone]
Tel: [phone]
www.black.honeywell.com
security[email protected]
Honeywell Security Group
Automation & Control Solutions
Honeywell International Inc.
www.security.honeywell.com
Jan 2015
© 2015 Honeywell International Inc.
DIMENSION

Unit: mm
