Honeywell ScanDome II HSDN-251NS/PS Owner's manual

ScanDomellTM Dome
Camera
HSDN-251NS/PS , HSDN-230NS/PS
Please read this manual thoroughly before use and keep it handyfor future reference.
Rev.040602
Operation & Programming Manual

2
Warnings and Cautions
TO REDUCE THE RISK OFFIRE ORELECTRIC SHOCK,DONOTEXPOSE THIS PRODUCT TO RAIN
OR MOISTURE. DONOTINSERT ANYMETALLIC OBJECTSTHROUGHTHE VENTILATIONGRILLSOR
OTHER OPENINGS ON THE EQUIPMENT.
EXPLANATION OFGRAPHICAL SYMBOLS
Thelightningflash witharrowheadsymbol,within anequilateral triangle,isintended to
alerttheusertothepresenceofuninsulated"dangerous voltage"withintheproduct's
enclosurethatmaybeof sufficient magnitudetoconstitute ariskofelectricshockto
persons.
Theexclamationpointwithinanequilateraltriangleisintendedtoalerttheusertothe
presence ofimportantoperatingandmaintenance (servicing)instructioninthe literature
WARNING
CAUTION
accompanying theproduct.

3
FCC COMPLIANCE STATEMENT
FCC INFORMATION: THIS EQUIPMENT HAS BEEN TESTED AND FOUND TO
COMPLY WITHTHELIMITS FOR ACLASS ADIGITAL DEVICE,PURSUANT TO
PART 15 OF THE FCC RULES. THESE LIMITS ARE DESIGNED TO PROVIDE
REASONABLE PROTECTION AGAINST HARMFUL INTERFERENCE WHEN
THE EQUIPMENT IS OPERATED IN ACOMMERCIAL ENVIRONMENT. THIS
EQUIPMENT GENERATES, USES, AND CAN RADIATERADIO FREQUENCY
ENERGY AND IF NOT INSTALLED AND USEDIN ACCORDANCE WITH THE
INSTRUCTION MANUAL, MAY CAUSE HARMFUL INTERFERENCE TO RADIO
COMMUNICATIONS. OPERATIONOFTHIS EQUIPMENT IN ARESIDENTIAL
AREA IS LIKELY TO CAUSE HARMFUL INTERFERENCE IN WHICH CASE THE
USER WILL BEREQUIRED TO CORRECT THE INTERFERENCE AT HIS OWN
EXPENSE.
CAUTION: CHANGES OR MODIFICATIONSNOT EXPRESSLY APPROVED BY
THE PARTY RESPONSIBLE FOR COMPLIANCE COULD VOID THEUSER'S
AUTHORITYTO OPERATE THE EQUIPMENT.
THISCLASS A DIGITALAPPARATUS COMPLIES WITHCANADIAN ICES-003.
CET APPAREIL NUM RIQUEDE LACLASSE A EST CONFORME ALA NORME
NMB-003 DU CANADA.
CE COMPLIANCE STATEMENT
WARNING
THISISACLASSAPRODUCT. INADOMESTIC ENVIRONMENT THIS
PRODUCT MAY CAUSE RADIO INTERFERENCE IN WHICH CASE THE USER
MAY BE REQUIRED TO TAKE ADEQUATEMEASURES.

4
IMPORTANT SAFEGUARDS
1.
2.
3.
4.
5.
6.
6A.
7.
8.
9.
10.
11.
12.
13.
14.
15.
16.
17.
18.
19.
READ INSTRUCTIONS-- Allthesafetyandoperating
instructionsshouldbereadbeforetheapplianceisoperated.
RETAININSTRUCTIONS-- Thesafetyandoperating
instructionsshouldberetainedforfuturereference.
CLEANING--Unplug videomonitor orequipmentfromthe
walloutletbeforecleaning.Do notuseliquid cleaners or
aerosolcleaners.Useadampclothforcleaning.
ATTACHMENTS--Donot useattachmentsnot
recommendedbythevideomonitoror equipment
manufacturer asthey may resultinthe riskoffire,electric
shockorinjurytopersons.
WATERANDMOISTURE--Do notusevideomonitoror
equipmentnear water--forexample,nearabathtub,
washbowl, kitchensink, laundrytub, in a wetbasement, or
nearaswimmingpool,orthelike.
ACCESSORIES--Do notplace videomonitororequipment
onanunstable cart, standor table.Thevideomonitoror
equipmentmayfall,causingseriousinjurytoachildoradult,
andseriousdamagetotheequipment.Wallorshelfmounting
shouldfollowthemanufacturer'sinstructions,andshould
useamountingkitapprovedbythemanufacturer.
Videomonitororequipmentandcart
combinationsshouldbemovedwith
care.Quickstops,excessiveforce,
andunevensurfacesmaycausethe
equipmentandcartcombinationtooverturn.
VENTILATION --Slotsandopenings inthe cabinetand the
backorbottom are providedforventilation,andtoensure
reliable operation ofthe video monitororequipmentand to
protectitfrom overheating.Theseopeningsmustnotbe
blockedorcovered. Theopeningsshould neverbe blocked
byplacingthevideomonitororequipmentonabed,sofa,
rug,orothersimilarsurface.Videomonitororequipment
shouldneverbeplacednearoroveraradiatororheat
register.Videomonitoror equipmentreceiver shouldnotbe
placedin abuilt-ininstallationsuchasabookcase unless
properventilationisprovided.
POWERSOURCES-- Videomonitororequipmentshould
beoperatedonly fromthetype ofpower source indicatedon
themarkinglabel.If youarenotsure of thetypeofpower
suppliedtoyourhome,consult yourvideomonitor or
equipmentdealerorlocalpowercompany.For videomonitor
orequipmentdesignedtooperatefrombatterypowerrefer to
theoperatinginstructions.
GROUNDINGORPOLARIZATION-- Thisvideomonitor
may be equippedwithapolarizedalternating-currentline
plug(aplughavingonebladewider thantheother).This plug
willfitintothepoweroutletonlyoneway.Thisisasafety
feature.If youareunabletoinserttheplugfullyintotheoutlet,
try reversing theplug.Iftheplugshouldstillfail tofit, contact
yourelectriciantoreplaceyourobsoleteoutlet.Donotdefeat
thesafetypurposeofthepolarizedplug.
AlternateWarnings -This video monitorisequippedwith a
three-wire grounding-typeplug,aplughaving athird
(grounding)pin.Thisplug willonlyfit intoagrounding-type
poweroutlet.Thisisasafetyfeature.Ifyouareunableto
inserttheplugintotheoutlet,contactyourelectricianto
replaceyourobsoleteoutlet.Donotdefeatthe safety
purposeofthegrounding-typeplug.
POWERCORDS--Do notallowanythingtorestonthe
powercord. Do notlocate videomonitor or equipmentwhere
thecordwillbeabusedbypersonswalkingonit.
HEED WARNINGS --Follow allinstructionsmarked onthe
videomonitororequipment.
LIGHTNING--Foraddedprotectionforvideomonitoror
equipmentduringalightningstorm,orwhenit isleft
unattendedandunusedforlongperiodsof time,unplug it
from thewalloutletanddisconnecttheantennaorcable
system.This willpreventdamage to thevideoproductdueto
lightningandpower-linesurges.
OVERLOADING--Do notoverloadwalloutletsand
extensioncordsas this canresult in a risk offire orelectric
shock.
OBJECTAND LIQUIDENTRY --Never pushobjectsof any
kindintovideomonitor or equipmentthroughopeningsas
theymaytouch dangerous voltagepointsor short-outparts
thatcouldresultinafire orelectricshock.Never spillliquidof
anykindontheproduct.
SERVICING-- Do notattempttoservicevideomonitoror
equipmentyourself as openingorremovingcoversmay
exposeyouto dangerousvoltageor other hazards. Refer all
servicingtoqualifiedservicepersonnel.
DAMAGEREQUIRINGSERVICE--Unplugvideomonitor or
equipmentfromthe walloutletandreferservicingtoqualified
servicepersonnelunderthefollowingconditions:
A.Whenthepower-supplycordor theplughasbeen
damaged.
B.If liquidhasspilled,orobjectshavefallen into the video
product.
C.Ifthevideoproducthasbeenexposedtorainor water.
D.Ifthe videoproductdoesnotoperatenormallyby
followingtheoperatinginstructions,adjustonly those
controlsthat arecoveredby the operating instructionsasan
improperadjustmentof other controls mayresultindamage
andwilloftenrequireextensiveworkbyaqualifiedtechnician
torestorethevideoproducttoitsnormaloperation.
E.Ifthevideoproducthasbeendropped,orthecabinet
damaged.
F.Whenthevideoproductexhibitsadistinctchangein
performance--thisindicatesaneedforservice.
REPLACEMENTPARTS-- Whenreplacementpartsare
required, besuretheservice technicianhasused
replacementpartsspecifiedbythemanufacturerorthathave
the same characteristics astheoriginal part. Unauthorized
substitutionsmayresultinfire, electricshockor other
hazards.
SAFETYCHECK--Uponcompletionofanyserviceor
repairs tothisvideoproduct, asktheservicetechnician to
perform safetychecks to determinethatthevideoproductis
inproperoperatingcondition.
FIELDINSTALLATION--Thisinstallationshouldbemadeby
aqualifiedservice personandshouldconformtoalllocal
codes.

5
Table of Contents
Chapter 1 …Introduction ..............................................................1
1.1 Features............................................................................................ 1
Chapter 2 …Installation And Configuration..................................3
2.1 PackageContents.............................................................................3
2.2 Basic Configuration Of Scandome IITM Dome Camera System .........4
2.3 SettingUnit For Termination.............................................................. 5
2.4 SettingAddress(Id)Of Dome Camera .............................................. 6
2.5 SettingProtocolOf Dome Camera ................................................... 7
2.6 ConnectingWiring ............................................................................8
Connecting ToThe RS-485...................................................................................... 8
Connecting ToThe Monitor...................................................................................... 8
Connecting Alarms................................................................................................... 8
Connecting The Power ............................................................................................ 8
2.7 GettingStarted.................................................................................. 8
Chapter 3 …Program And Operation .........................................10
3.1 Selecting DomeCamera.................................................................10
3.2AccessingOn-ScreenMenuUtility .................................................. 10
3.3 How To ControlOn-Screen Menu Utility.......................................... 11
3.4Auto Scan........................................................................................ 11
3.5 Preset ............................................................................................. 12
3.6 Shortcut Preset Program.................................................................14
3.7 Tour ................................................................................................ 14
3.8 Pattern ............................................................................................ 16

6
3.9Alarm............................................................................................... 17
3.10AreaTitle....................................................................................... 17
3.11 PrivacyZone ................................................................................. 18
3.12Camera ........................................................................................ 20
Focus Control ........................................................................................................ 20
WB(White Balance) Control................................................................................... 21
AE(Auto Exposure) Control.................................................................................... 21
Line Lock Control................................................................................................... 22
Night Shot Menu.................................................................................................... 22
3.13Dome Setup.................................................................................. 22
Home Function Setup............................................................................................ 23
OSD DisplaySetup................................................................................................ 24
ViewDirection........................................................................................................ 24
Initialize Data......................................................................................................... 26
Origin Offset........................................................................................................... 26
Dome Reset........................................................................................................... 26
System Information................................................................................................ 26
Appendix A …Specifications.......................................................27
Appendix B …Troubleshooting...................................................29
Appendix C …Glossary..............................................................30

7
Chapter 1 Introduction
1.1 Features
TheScanDomeIITM Keyboard Controller andtheScanDome IITM domecameramake upthe
buildingblocks for anysurveillance/securitysystem. Using multiple Keyboard Controllers and
multiple domecameras, no place is too large for monitoring. Extensible and flexible architecture
facilitates remotecontrol functionsfor avarietyofexternal switchingdevices suchas
multiplexers and DVRs.
•Built-in 25 timesopticalpower zoom camerawith TrueNight Shot function.(HSDN-251 Series)
•240 Preset positions.
•8 Tours consist of Preset, Pattern, Auto-Scanand Tour itself can beprogrammed over 300
functionsand Preset location. While moving, each Preset scan canbewatched insmooth
Vector Scan mode.
•8 AutoScan includingvector scan
•4 Pattern(240second)
•8 Privacyzone
•8 Alarm input / 4 Auxout (NC & NO)
•Variable speed from 0.1°/secto90°/sec.
Turbo speedis Max360°/sec with Ctrl keypressed.
Maximum speed is inversely proportional to the zoom ratio.
•Programmable user preferences(alarm, preset, title, etc.).
•Up to 999 selectable cameraaddresses (Option 3999)
•Built-in RS-485/422 receiver driver.
•Built-in power-line surge protectionand lightning protection
•Clear bubble with black liner (shelter) for concealingthecamera.
•Optional Tinted Bubble, Indoor(HSGN-502) & Outdoor (HSGN-502SH) pendant housing with
heater & blower, Indoor Flush Mount(HSG-502F), Parapet mount &Roof Top mount.

2
UPTO 32 CAMERA
UPTO 255 MULTIPLEXER
UPTO 99 DVR
<Master Keyboard>
Alarm Input
UPTO 8
Alarm
Output
UP TO 4
<Sensor>
<Siren>
<Flashing Light>
UPTO 3 SlaveKeyboard
Figure 1 •Typical System Configuration

3
Chapter 2 Installation and Configuration
2.1 Package Contents
Thepackagecontainsthe following.
ScanDome IITM (Dome Camera) “““““““““1
Bubble Ring “““““““““1
InstructionManual (This Document) “““““““““1
AssemblyScrews for AttachingScanDomeIITM “““““““““3
Plastic Anchor “““““““““3
10Pin Connector “““““““““1
12Pin Connector “““““““““2
CAUTION: Be suretohave caution labels(Eversion only) on both bodyand base of the
camera. Different version will not support alarm input and output.
Figure 2 •Installation

4
2.2 BasicConfiguration ofScanDome IITM DomeCamera System.
3~4
5~8
1~2
1~4
ALARMOUTPUT
UPTO 4
ALARMOUTPUT ALARMOUTPUT
ALARMINPUT
HALFDUPLEXMODE:TX+,TX-
RS-485
ALARMINPUT
UPTO8
ALARMINPUT
LIGHT
SIREN
SENSOR
D O M E1 +
D O ME 1 -
UTPAWG#24
BNC
BNC
MONITOR
AC24V
POWER
R X - ( T X - )
R X + ( T X + )
( R X - )
( R X + )
(RS-422)
RS- 485
GND
(RX +)
AC-
AC+
FGND
(RX -)
AC-
RX+(TX +)
RX-(TX-)
AC+
NC2
NO2
NC1
NO1
COM2
COM1
AL4
GND
AL3
AL2
GND
AL1
NO4
NC4
COM4
NO3
NC3
COM3
GND
AL8
AL7
GND
AL6
AL5
AC24V
POWER
RS-422
SIMPLEXMODE:(RX+),(RX-)
DUPLEXMODE:(TX+),(TX-),(RX+),(RX-)
Figure 3•Basic installation diagram

5
Thedomecameramust be installed byqualifiedservice personnel in accordance with all local
and federal electrical and buildingcodes. The system should beinstalled accordingto Figures2
through 8.
1
2
3
4
5
6
7
8
9
0
1
2
3
4
5
6
7
8
9
0
1
2
3
4
5
6
7
8
9
0
1
2 3
4
5
6
7 8
9
0
81
1
2
3
4
5
6
7
8
9
0
81
1
2
3
4
5
6
7
8
9
0
81
S1
S2
S3
ONKSD02H
12
9A
SW1
ononon
12 3 412 3 4
S4
S5
S6
Figure 4•Layout of Switches
2.3 Setting Unit for Termination
Thedevice which is connected at endof line, whether it bea dome camera or keyboard
controller, must have the cable for communication terminatedbysettingthe appropriate DIP
switch. Without proper termination, there is potential for control signal errors. Total length of the
cable for communication should not exceed 1.2Km.
ON KSD02H
12
9A
SW1
Figure 5•Setting Unit for Termination
SW1 1 2
Terminated ON ON
Not terminated OFF OFF
Address(ID) selection
Switches
Termination Switches
Protocol selection
Switches

6
Figure 6 Termination Diagram
2.4 Setting Address (ID) of DomeCamera
Toprevent damage, each dome camera must have a uniqueaddress(ID). Wheninstalling
multiple domecamerasusingamultiplexer, it is suggestedthat the domecamera addressmatch
the multiplexer port number.
Example: Port 1= Dome 1, Port 2= Dome2 “Port 16= Dome16. If more than 16dome
cameras are installed using two or more multiplexers, IDof thedomecamera should be ID of
MUX xNo. of camera IN. (e.g. multiplexer ID= n, CameraIN= m then ID of Dome=16x(n-1)+m )
Refer to Figures 3-4 for settingthe domecamera address (ID) and protocol selection.
Figure 7•Setting Address (ID) of Dome Camera
EnableTermination (On) EnableTermination (On)
Cable for communication
Cable for communication
3
rd
Branch Not allowed
Without spliter /repeater
1
2
3
4
5
6
7
8
9
0
8
1
S
W
3
1
2
3
4
5
6
7
8
9
0
8
S
W
2
1
1
2
3
4
5
6
7
8
9
0
8
1
S
W
1
DOME ID SW1 SW2 SW3
1 0 0 1
2 0 0 2
. . . .
999 9 9 9

7
2.5 Setting Protocol of DomeCamera
If a dome camera is tobe installed with a Scandome IITM keyboard controller, select F2 protocol.
Consult service personnel if a dome camerais installed with device other than akeyboard
controller.
S/W On Off FUNCTION
D1 S4-1 Enable Disable Alarm
D2 S4-2 PAL NTSC NTSC/PAL
D3 S4-3 Reserved
D4 S4-4 RS-422 RS-485 RS-422/RS-485
D5 D6 D7
S5-1 S5-2 S5-3
PROTOCOL
Off Off Off F2,F2E,P,D,E & PhProtocol
Off Off On Reserved
Off On Off S 422
Off On On Reserved
On Off Off V Protocol
On Off On Reserved
On On Off D Color
On On On Reserved
D8 D9 D10
S5-4 S6-1 S6-2
BAUD RATE
Off Off Off 2400 bps
Off Off On 4800 bps
Off On Off 9600 bps
Off On On 19200 bps
On Off Off 38400 bps
On Off On 57600 bps
On On Off 115200 bps
On On On 230400 bps
D11 D12
S6-3 S6-4 CAMERA
Off Off Default cameras
Off On Reserved
On Off Reserved
On On Reserved
Figure 8•Protocol Selection Switches
Camera
Protocol
Alarm
1 2 3 4
S6
S5
S4
Baudrate
NTSC/PAL
RS-485
1 2 3 4 1 2 3 4
RS-422/
D1 D2 D3 D4 D5 D6 D7 D8 D9 D12D10D11
Reserved

8
2.6 Connecting Wiring
㿱Connecting to the RS-485/ 422
The dome cameracan be controlled remotelybyan external device or control system, suchasa
control keyboard, using RS485 half-duplex , RS422 duplex or simplex serial communications
signals. Connect Marked Rx+, Rx- to Tx+ and Tx- ofthe RS485 control system.
If control system is RS422, connect Rx+(Tx+), Rx+(Tx-) and (Rx+), (Rx-) of the dome camera to
Tx+, Tx- and (Rx+), (Rx-) of the control device respectively.
Connecting Video out connector
Connect the video out(BNC) connector tothemonitor or video input.
㿱Connecting Alarms
AL1 to 8 (Alarm In)
You can useexternal devices to signal the dome camera toreact toevents. Mechanical or
electrical switches canbe wired to the AL (Alarm In) and GND (Ground) connectors.. See
Chapter 3 …Program and Operation for configuringalarm input.
GND (Ground)
NOTE: All the connectors marked GND are common.
Connect the ground side of theAlarm input and/or alarm output to the GND connector.
NC(NO)1 TO 4 (Normal Close or Normal Open : Alarm Out)
The domecamera can activate external devices such asbuzzers or lights. Connect the device to
the NC(NO) (Alarm Out) and COM (Common) connectors. SeeChapter 3 …Program and
Operation for configuring alarm output.
㿱Connecting the Power
Connect the power of AC 24V 850mA tothe dome camera.
2.7 Getting Started
Once installed apply power to the dome camera. Thedomecamerawill start a configuration
sequence.Whenconfiguration isdone, thefollowing informationis displayed:

9
RAMTEST
CHECK NO. : OK!
CHECK AAAA : OK!
CHECK 5555 : OK!
SCANDOME II Vx.xxx
CAMERA TYPE xxxx
WAIT DOME SETTING.
INIT TILT ORGIN SET OK
INIT PAN ORGIN SET OK
INIT CAMERA SET OK

10
Chapter 3 Program and Operation
3.1 Selecting Dome Camera
Before you program or operatea dome camera, you must select the domecamera by pressing
the dome camera No. + CAM
Example:Pressing 1, 0and CAM keysequentiallywill select dome camera 10. The selected
dome camera ID will be displayed on the LCD monitor of the keyboard controller.
3.2 Accessing On-Screen Menu Utility
You can call uptheOn-screen menu utilityon your monitor bypressing MENU keyon the
keyboard controller, thefollowing On-screenmenu utility will appear:
MAIN MENU
AUTO SCAN
PRESET
TOUR
PATTERN
ALARM
AREA TITLE
PRIVACY ZONE
CAMERA
DOME SETUP
EXIT(ESC TO EXIT)

11
3.3 Howto control On-Screen Menu Utility
Action Function
MENU Call on On-screenmenu utility
Joystick left or right
Go intothe sub-menuitems.
Execute the command(exit)
Change value.
Navigate through themenu items.
Joystick up or down Navigate through themenu items.
Joystick down Finish editingtitle.
Zoom handle twist Change value.
Enter editing title mode.
CTRL + Joystick Change value of angle
ESC Escape (EXIT)
3.4 Auto Scan (First Item of theMain menu / Shortcut: Scan)
The Autoscan supports up to8 programmed angles at user-programmable speeds. Follow
these stepstoprogram Auto Scan:
1. Press the Scan keytoenter Auto Scanmenudirectly. Or pressthe Menu keyto displaythe
main menu onthe monitor. Scroll toAutoScan and push the Joystick to the right.
2. Select an Auto Scannumber bypushing the Joystick left or right.
AUTO SCAN SETUP
SCAN 01 : AUTOSCAN01
SPEED(MODE) : FAST VECTOR
START ANGLE : 127.1, 027.7 X7
END ANGLE : 157.7, 080.7 X3
SCAN DIR. : CCW
SWAP: OFF
SAVE AND EXIT (ESC TO CANCEL)
HOLD DOWNCTRL KEY
WHILE SELECT POSITION.

12
3. Twist the Joystick to enter thetitle by scrolling through the alphanumeric characters and
pushing thehandle tothe right or left to move tothe next space. Press Enter keyor pushthe
Joystick down to finishtitle mode
4. Pushthehandle downward to select ”SPEED’and set thespeedby movingthe Joystick left
and right to select theauto scanspeed.
5. When finishentering the speed, select ”START ANGLE’with the Joystick. Hold down the
Ctrl/PGM keywhile selecting thestart position usingthe Joystick. Current panningposition
will be displayed. Release Ctrl/PGM keytocomplete the selection of the start position.
6. Pushthe Joystick downward to select ”END ANGLE.’Hold down the Ctrl/PGM keywhile
movingthe joystickto select the endposition. Theend position angle should be larger than
start position. Releasethe Ctrl/PGM keytocomplete the selection of the end position.
7. Pushthe Joystick downward to select ”SCAN DIR’andset the scandirection by moving the
Joystick left and right toselect theautoscan direction.(CWor CCW)
8. Pushthe Joystick downward to select ”SWAP’andset the swap by movingthe Joystick left
and right toselect the swap ON or OFF.
9. Select Save and Exit bypushingthe Joystick to the right. Press ESC to exit theprogram
without saving.
Pressing the Home keycauses the camera to gotothe000.0 angle immediately.
NOTE: Using the Tour mode in conjunction with preset and Auto Scan,you can make the camera
travel from one preset position to another preset position at a specificspeed. (Pan only)
a. Beforeentering the Auto Scanmenu, select apreset positionas astarting point forAuto Scan.
Example:2+ Prst anddo step1 to 4. Instead of step 5, just pressthe Ctrl/PGM keyat thestart
angle position, thecurrent positionwill be displayed as astart position.
b. Save and exit from themenu.
c. In normalmode, call a preset to betheendpoint of scan. Press 3+ Prst thenpress Scan
keytoenter the AutoScan menu. Move the cursor positiontoEND ANGLE. Just press
Ctrl/PGM keyat theendangle position. Dostep 7 to 9.
Example:Preset 001>002>003>004>005>006, Auto Scan01 starts at 002, endsat 003,
Auto Scan02 starts at 005, endsat 006. Tour 001, 002, A01, 004, A02.
1 è2 2~3 è4è5~6 è1 è22~3 ““
Whereè: Quick move, ~ : Programmedspeed byAuto Scan.
3.5 Preset (SecondItem of the Main menu / Shortcut: Prst)

13
If you need toviewspecificplaces routinely, you should program presets. A preset is a
programmedvideo scene with automatic pan, tilt, zoom, focusand iris settings. Once
programmed, entering the number andpressing apreset buttononyour controller automatically
calls up thepreset. In addition, presetsmaybe assigned toalarm actions or asthe ”home’
position for the dome camera. Asmanyas240 presets, whose positionsare saved in the
dome█s firmware, maybe programmed.
There are threepagesof preset menu, eachpagecan hold80 presets. Pagescan be scrolled
bypushingthe Joystick to the Left or Right onthe first or last No. of Preset.
x: 16 digitsof title for preset label
= : blankpreset position
* : position hasthepreset
º: Current cursor position
Followsteps below to store the Preset positions:
1. Press Menu to display themain menu. Select the Preset option byusing the Joystick to the
right. (Press Prst togodirectlytothePreset menuwithout going throughthe main menu.)
2. Select theblankpreset positiontobe stored bypushing the Joystick up, down, right, or left.
3. Theposition, which is markedwith , alreadyhas thepreset viewassigned. Toreviewthe
storedpreset, press Prst keyon the 竡 The camera will showthe storedpreset view.
4. After selecting a blank position, press andhold Ctrl/PGM, usethe Joystick to controlthe
direction of the camera and lens.
5. After aiming thecamera (viewdirection and lens control), release Ctrl/PGM. Thentwist the
Joystick handle or Press Tele or Wide Key tostore the selected view. The position number will
be displayed and theuser will be prompted to enter apreset title.
PRESET SETUP
NO. 001 : xxxxxxxxxxxxxxxx
FOCUS : AUTO/ MANUAL
IRIS : AUTO/ MANUAL
DWELL: 03~99 (Sec)
1234567890 1234567890
00º* * * ===== 01==========
02========== 03==========
04========== 05==========
06========== 07==========
JOY-LEFT TO PREV. PAGE
SAVE AND EXIT(ESC TO CANCEL)

14
6. Enter thetitle for the preset position using the Joystick. (Rotate handle clockwise and
counterclockwise or press Tele or Wide Key toscroll throughthe alphanumeric characters,
push thehandle to right or left to select next or previous digit.)
7. When you arefinishedentering thetitle, push the Joystick downward. Set thefocus by
pushingthe Joystick to the right or left. Set the IRIS value in the samemanner asthefocus.
8. Move to theDWELL settingbypushingthe Joystick down. Twist the Joystick clockwise or
counterclockwise toincrease or decrease dwell time of the preset position.
9. Toselect thenext page of presets, scroll thepagebypushing the Joystick totheLeft onthe
first and last columnsof the menu.
10. Repeat steps 2 through7 for each additional preset position.
11. Toedit the title of astoredpreset, usethe Joystick toposition the cursor onthedesired
preset position. Press the Prst keytorecall thestored preset. Twist the zoom handle
clockwise to enter the preset title, focus andIRIS. Preset titles are useful with short cut preset
programming. Refer toShortcut programming below.
12. Select Save and Exit bypushing thejoystick to theright. PressESC toexit the Preset menu
without saving.
NOTE: Pressthe Home keyat programmed position to delete a programmedpreset view.
3.6 Shortcut of Preset Program.
Select a viewto be stored (direction of the camera, zoom and focus), thenpressNo. (1to 240),
and thenpress Pgm, Prst subsequently. The current viewwill be stored to theselectedpreset
number ifposition is empty. If selected preset number is not empty, ”PRESET EXISTING’
messagewill be displayed on the monitor andask tooverwrite.
Example: 1 , 0 , 1 + Pgm + Prst will store current viewas preset No. 101. In this case, focus
and Iris mode will be programmed as Auto, dwell time will be set to 3 sec.
3.7 Tour (THIRD ITEM OF THE MAIN MENU / SHORTCUT: Tour)
There are 8programmable Tours. EachTour consists of upto42 Preset positions, Patterns,
Scans or other Tours(second-level). Using second-level Tours, it canbe expanded to over 300
functionsin a single Tour. However Tours in second level Tour will be ignored when called bya
Tours. The followingexample illustrates this concept:
If Tour1 hasPreset1èPreset2èTour2èTour3 and
Tour2 hasPreset3èPreset4èTour4èPreset5 and
Tour3 hasPreset6èPattern and
Tour4 hasPreset7.
Tour1 executesas follows:
Preset1 èPreset2 èPreset3 èPreset4 èPreset5 èPreset6 èPattern1 è
Preset1 è... (Repeat)
Tour2 executesas follows:
Preset3 èPreset4 èPreset7 èPreset5 èPreset1 “Repeat
(Tour4is still valid ifcalled directlyfrom Tour2.)
