Honeywell TM001 User manual

HONEYWELL TM001 MANUAL (ENG)
SIZE: W65 X H105 (mm)
BY EMILY TSOI 26/01/06
2 3
1
In/Out Thermometer
with Probe
(TM001)
USER MANUAL
 TABLE OF CONTENTS
INTRODUCTION  3
PRODUCT OVERVIEW  3
GETTING STARTED  6
GENERAL OPERATION  6
MAXIMUM AND MINIMUM READINGS  6
SELECTION TEMPERATURE DISPLAY 7
IN CELSIUS OR FAHRENHEIT
LOW BATTERY WARNING  7
THERMOMETER PLACEMENT  7
SECURING TEMPERATURE 7
PROBE OUTDOORS
PRECAUTIONS  8
SPECIFICATIONS  9
STANDARD WARRANTY INFORMATION 10
INTRODUCTION
Thank you for selecting the Honeywell In/Out
Thermometer with Probe. This device monitors and
displays the indoor and outdoor temperature.
In this package you will find:
•One Thermometer with LCD display
•One removable temperature probe with 10 feet cable
•One User Manual
Please keep this manual handy as you use your new
item. It contains practical step-by-step instructions,
as well as technical specifications and precautions
you should know.
PRODUCT OVERVIEW
MAIN UNIT
FEATURES
•Displays indoor and outdoor temperatures at the
 same time
• User-selectable temperature display in Celsius or
 Fahrenheit
•Memory for minimum and maximum indoor and
 outdoor temperature.
• Wall mount or desktop option
• Low battery indicator

54
D. BATTERY COMPARTMENT
 •Accommodates 2 (two) UM-3 or AA 1.5V
  alkaline batteries.
E. WALL-MOUNT RECESSED HOLE
•Keeps the main unit on the wall
F. REMOVABLE TEMPERATURE PROBE
 WITH 10 FEET CABLE
•Registers outdoor temperature
FRONT VIEW
A. TEMPERATURE INFORMATION IN A
 TWO – SECTION LCD DISPLAY
B. MEMORY BUTTON
 •Toggles between current, minimum and maximum
  readings of the indoor and outdoor temperature
 •Clears the maximum and minimum temperature
  memory
C. C°/F°BUTTON
• Selects temperature display in Celsius or
  Fahrenheit
REAR VIEW
B
A
C
MEMORY
°C/°F
IN/OUT THERMOMETER
Outdoor
temperature
Indoor
temperature
E
D
F
76
GETTING STARTED
• The temperature probe can be placed indoors or
 outdoors, the thermometer must be placed indoors
 (refer to SECURING TEMPERATURE PROBE
 OUTDOORS section).
• We recommend using alkaline batteries.
• Avoid using rechargeable batteries. (Rechargeable
batteries cannot maintain correct power requirements).
• Open the battery compartment door.
• Install 2 batteries (UM-3 or “AA” size 1.5V)
 matching the polarity as shown in the battery
 compartment.
• Replace the battery compartment door.
GENERAL OPERATION
After batteries are installed; the
indoor and outdoor temperature
readings will be displayed at the
same time. The outdoor
temperature will appear on the
larger section of the unit’s display with the icon
OUT and indoor temperature will appear in the
smaller section with the icon IN.
MAXIMUM AND MINIMUM READINGS
The maximum and minimum record of the indoor and
outdoor temperatures will be automatically stored in
the unit’s memory.
To display the minimum,
maximum or the current
temperature readings press the
MEMORY button.
To clear the temperature
memory, press and hold the
MEMORY button for two
seconds and all previously stored readings will be
erased (current, minimum and maximum temperature
readings will be the same).
SELECT TEMPERATURE DISPLAY IN
CELSIUS OR FAHRENHEIT
Press C°/F°button to select the temperature in Celsius
or Fahrenheit.
LOW BATTERY WARNING
A low-battery indicator [ ] will appear on the display
warning that the batteries need replacement.
THERMOMETER PLACEMENT
Thermometer can be placed on the flat surface, such as
desk etc. as well as wall-mounted.
For wall mounting, drive the screw (not included) into
the wall until the screw head extending about 0.14 inch.
For accurate temperature measurement, mount the
thermometer in an area with free air flow.
SECURING TEMPERATURE
PROBE OUTDOORS
• Drive a small screw (not included) into the wall at the
 location selected for the temperature measurement
• Hang the temperature probe wire attachment loop
 onto the screw
• Route the temperature probe 10 feet cable through
 the window or pre-drilled hole.
• Locate the temperature probe away from direct
 sunlight and heavy precipitation

1310
8 9
SPECIFICATIONS
In/Out Thermometer
Indoor Temperature
Proposed operating range:
-5.0°C to +50.0°C/23.0°F to 122.0°F
Temperature resolution: 0.2°C/0.2°F
User-selectable (F°or C°) temperature display
Indoor and outdoor temperature memory
Low battery indicator
Wall Mount or Desktop option
Removable Temperature Probe with 10 feet cable
Outdoor Temperature
Proposed operating range:
-50.0°C to + 70.0°C/-58.0°F to + 158°F
Temperature resolution: 0.2°C/0.2°F
Power
2 AA size (UM-3) 1.5V batteries (not included)
Dimensions
2.89(L) x 3.64(H) x 1.47(D) inches
PRECAUTIONS
This product is engineered to give you years of
satisfactory service if handled carefully. Here are a few
precautions:
• Do not immerse the units in water.
• Do not clean the units with abrasive or corrosive
 materials. They may scratch the plastic parts and
 corrode the electronic circuits.
• Do not subject the product to excessive force, shock,
 dust, temperature, or humidity, which may result in
 malfunctions, shorter lifespan, damaged batteries, and
 damaged parts.
• Do not tamper with the units internal components.
 Doing so will invalidate the warranty and may cause
 damage. These units contain no user-serviceable parts.
• Use only fresh batteries. Do not mix new and old
 batteries.
• Read the user's manual thoroughly before operating
 the product.
STANDARD WARRANTY INFORMATION
This product is warranted from manufacturing defects for
one year from date of retail purchase. It does not cover
damages or wear resulting from accident, misuse, abuse,
commercial use, or unauthorized adjustment and repair.
Note that online product registration is required to ensure
valid warranty protection.
To register your product, go to our Company website at:
www.honeywellweatherstations.com. Click Online
Product Registration under the Customer Service menu.
Should you require assistance with this product and its
operation, please contact our
Customer Service Hotline [phone]
Please direct all returns to the place of the original
purchase. Should this not be possible, contact Customer
Service Hotline for assistance and to obtain a Return
Merchandise Authorization (RMA). Returns without a
return authorization will be refused. Please retain your
original receipt as you may be asked to provide a copy
for proof of purchase.
Hideki Electronics, Inc. reserves the right to repair or
replace the product at our option.
Copyright (2005) Hideki Electronics Inc. All Rights
Reserved. The Honeywell Trademark is used under
license from Honeywell Intellectual Properties Inc.
Honeywell International Inc. makes no representations
or warranties with respect to this product.
