Honeywell B/Q682 User manual

Heating/Cooling
Thermostat and Subbase or
Heating or Cooling Thermostat
and Wallplate
T8195A,B/Q682
OWNER’S MANUAL
69-0563-2

269-0563—2
Welcome to the world of energy savings with your new Honeywell thermostat. The Honeywell
name is your assurance of accurate control and reliable operation for years to come.
This thermostat meets California Title 24 requirements—mandatory installation of automatic
setback thermostats in new heating and cooling systems. During heating and cooling, this
thermostat will automatically lower and raise the temperature in your home one or more times
every 24 hours. This allows you to significantly lower your fuel costs, while awakening (or
returning home) to a comfortable temperature.
Read this manual to learn how to use your new thermostat.
Recycling Notice
This control contains mercury in a sealed tube. Do not place control in the trash at the end of
its useful life.
If this control is replacing a control that contains mercury in a sealed tube, do
not place your
old control in the trash.
Contact your local waste management authority for instructions regarding recycling and the
proper disposal of this control, or an old control containing mercury in a sealed tube.
If you have questions, call Honeywell Inc. at 1-800-468-1502.
M3375

369-0563—2
Table Of Contents
PAGE
Features Of Your Thermostat........................................................................................................... 4
Setting The Temperature ................................................................................................................. 7
Setting Subbase Switches................................................................................................................ 8
Inserting Timer Backup Batteries ..................................................................................................... 9
Setting The Timer ........................................................................................................................... 10
Programming .................................................................................................................................. 11
Troubleshooting .............................................................................................................................. 14
Servicing The Thermostat .............................................................................................................. 21
Warranty ......................................................................................................................................... 23

469-0563—2
8PROGRAM INDEX WHEEL. Controls high
and low temperature at specific time of
day as set by program pins.
9PROGRAM PINS. Must be inserted into
24-hour timer dial slots to control program
index wheel.
2
4
1
3M8723
Features Of Your Thermostat
1FLIP-UP COVER. Lift it up to set timer for
energy savings and comfort temperature
periods.
2THERMOSTAT COVER. Lift up to adjust
timer.
3THERMOMETER. Provides accurate room
temperature reading.
4TEMPERATURE SETTING LEVERS. Left
(blue mark) controls the low temperature, right
(red mark) controls the high temperature.
5TIMER. This timer provides a 24-hour
slotted dial to hold the programming pins.
6TIMER SETTING KNOB. Turn clockwise
to match the correct a.m. or p.m. time to
the time indicator.
7TIME INDICATOR. Arrow head indicates
time for 24-hour dial.

569-0563—2
M8744
12
6911 5
10 87M8745
10 PIN SLOTS. Located on 24-hour dial at
10-minute intervals for program pin
insertion.
11 MERCURY BULB AND BIMETAL ELEMENT
(2). Provide automatic temperature control
by switching the heating or cooling system
on and off.
12 WALLPLATE. Provides mounting base
and wiring connections for heating or
cooling thermostat without system or fan
switching.

669-0563—2
13 Q682 SUBBASE. Provides mounting base,
wiring connections and manual switching
control for heating/cooling thermostat.
AUTO OFF COOL HEATON
FAN
B
O
W
Y
R
G
M1551
13

769-0563—2
Setting The Temperature
For Heating
Set the left lever (blue mark) to the energy
savings temperature you want when you are
sleeping or your home is unoccupied.
Set the right lever (red mark) to the tem-
perature you want for normal comfort periods.
NOTE: You may override the time program by
setting both the red and blue levers to the
same temperature setpoint.
For Cooling
Set the left lever (blue mark) to the tempera-
ture you want for normal comfort periods.
Set the right lever (red mark) to the energy
savings temperature you want when you are
sleeping or your home is unoccupied. Fig. 1—Setting high and low temperature levers.
50 60 70 80
50 60 70 80
HIGH
TEMPERATURE
SETTING
LEVER
LOW TEMPERATURE
SETTING LEVER
M8586

869-0563—2
Setting Subbase Switches
(if applicable)
The subbase system switch controls system
operation as follows:
HEAT—Heating system is controlled by the
thermostat. Cooling system is Off.
COOL—Cooling system is controlled by the
thermostat. Heating system is Off.
OFF— Both the heating and cooling systems
are Off. If the fan switch is at the AUTO
position, the fan is also off.
ON—In a cooling only application, only cooling
operates. In a heating only application, only
heating operates.
The subbase fan switch controls fan
operation as follows:
ON—Fan operates continuously.
AUTO—Fan operates with cooling equipment
as contolled by the thermostat or with the
heating equipment as controlled by the
thermostat in heating and cooling.
To switch positions, use thumb or index
finger to slide lever to desired position. Switch
lever must stop in the detent over desired
function indicator mark for proper circuit
operation.

969-0563—2
Inserting Timer Batteries
(Optional)
Power is supplied to the timer by the 24 Vac
transformer. Two AAA alkaline backup batter-
ies (not included) may be installed to supply
power to the timer if power is interrupted due to
power failure. Install the batteries in the
thermostat as shown in Fig. 2. Once a year or
when batteries are dead, replace with two new
AAA alkaline batteries. We recommend
Energizer® batteries.
BATTERY LOCATION FOR
(2) AAA BATTERIES;
INSTALL WITH POSITIVE
ENDS UP
M8585
Fig. 2—Inserting timer backup batteries.

10 69-0563—2
Setting The Timer
Lift thermostat flip-up cover and you will find
the 24-hour program dial, slotted in 10-minute
increments. Adjust the timer to the current time
by carefully turning the knob clockwise Do
not reverse the knob.
When time is correctly set, the Time
Indicator Arrow (See Fig. 3) will point to the
correct time and corresponding daytime (light)
or nighttime (dark) band of the program dial.
EXAMPLE: For 11 p.m., time indicator arrow will
point directly to dark band on dial. For 11 a.m.,
the arrow will point to light band on dial.
Daylight Savings Time
When Daylight Savings Time starts, carefully move the knob clockwise one hour. When
Daylight Savings Time ends, carefully move the knob clockwise 23 hours. Do
not reverse
the knob or damage to the timer mechanism may occur.
Fig. 3—Setting the timer.
TIMER
SETTING
KNOB
TIME
INDICATOR
ARROW
M821A
PROGRAM DIAL
PROGRAM
PIN (6)

11 69-0563—2
Programming
You can program your thermostat to
automatically lower and raise the temperature
one or more times every 24 hours.
Before Setting Your Program
Lift thermostat flip-up cover and you’ll find
the 24-hour program dial. The slots on the
program dial (Fig. 4) are for the program pins
which can be inserted at ten-minute intervals.
Three red and three blue program pins are
included with your thermostat. The red pins start
the high-temperature period; the blue pins start
the low-temperature period. A heating program
has been preprogrammed. A red pin is inserted
at 6:00 a.m. for high temperature (comfort
period); a blue pin is inserted at 10:00 p.m. for
low temperature (energy saving period). Two
additional sets of pins are located in the program
pin storage area. You can set up to six tempera-
ture changes with the pins supplied. We
recommend at least five hours for each energy
savings period.
Fig. 4—Program components.
24-HOUR PROGRAM DIAL
(GRAY AREA FOR NIGHT SETTINGS)
FLIP-UP
COVER
PROGRAM
PINS
THERMOSTAT
COVER
PROGRAM
PIN SLOT
PROGRAM INDEX WHEEL
TIME INDICATOR ARROW
PROGRAM
PIN STORAGE
M7348

12 69-0563—2
To change the pins or add a new energy
savings period—
•To insert a pin, push it straight into the
selected notch on the program dial until it’s
completely seated.
•To remove a pin, press against program dial
and pull the pin straight out. Do
not attempt
to change a pin if it is engaged with the
program index wheel.
•On heating-cooling systems, you must
remove the program pins from the heating
program to set new times for your cooling
program. Write down your colors and time
for reprogramming at the next heating
season. Also, you may want to change the
temperature setting lever positions.
Setting the Heating Program
Decide when you want the temperature to
reach the comfort level. Find the notch on the
program dial that’s one-half hour before this
time and insert a r
ed pin. The half-hour head
start gives the furnace time to heat the house
before you wake up or arrive home.
Fig. 5—Program examples.
WINTER SUMMER
TEMPERATURE PROGRAM
PIN IN
CONTROL
NIGHT
ENERGY
SAVING
PERIOD
DAY
ENERGY
SAVING
PERIOD
BEGINS
10:00 PM
ENDS
6:00 AM
BEGINS
7:30 AM
ENDS
4:00 PM
TEMPERATURE PROGRAM
PIN IN
CONTROL
°C
27
24
27
24
RED
BLUE
RED
BLUE
°F
58
68
58
68
°C
14
20
14
20
°F
80
75
80
75
BLUE
RED
BLUE
RED
M8677
1
1 NOT APPLICABLE ON HEATING-ONLY MODEL.

13 69-0563—2
Decide when you want the energy savings
period to start and insert a
blue pin at the notch
that corresponds to this time. After the blue pin
engages, the furnace will be off until room
temperature drops to the energy savings
setpoint.
You can set both a day and night program.
See Fig. 5. for program examples.
Setting the Cooling Program
Decide when you want the temperature to
reach the comfort level. Find the notch on the
program dial that’s one-half hour before this
time and insert a
blue pin. The half-hour head
start gives the air conditioner time to cool the
house before you wake up or arrive home.
Decide when you want the energy savings
period to start and insert a red pin at the notch
that corresponds to this time. After the red pin
engages, the air conditioner will be off until
room temperature rises to the energy savings
setpoint.

14 69-0563—2
Troubleshooting
Your Honeywell thermostat requires little or no attention. Most problems can generally be
traced to the following:
(continued)
1
Problem Check Action
No heat. — system switch. May be in OFF
or COOL position. Move system switch to HEAT position.
— fuse or circuit breaker. If blown or tripped, replace fuse or reset
breaker.
— furnace power switch. May be
Off. Move switch to ON.
— pilot flame. May be out. Relight pilot flame per furnace manufacturers
instructions.
—Rand W thermostat
connections. Turn Off power to furnace. Check for correct terminal hookups. Repair any frayed or broken
wires. Firmly tighten all terminal screws. Turn
On power.

15 69-0563—2
Troubleshooting (continued)
(continued)
2
Problem Check Action
No heat (continued). — other problem. Contact a qualified service technician for
assistance.
Energy savings
temperature program
12 hours off.
— program dial for proper day or
night phase. Turn timer ahead 12 hours. Move setting knob clockwise only.
Rooms do not warm
up at programmed
time.
— timer program for heating
system. May need more time to
warm up rooms.
Move red pin one-half hour earlier on the
program dial.
Temperature change
occurs at the wrong
time.
— programs pins for correct time
locations. Relocate pins to desired settings.
Room temperatures
are not correct. — positions of thermostat setpoint levers. Reset to desired temperatures.
— position of subbase system
switch (heating-cooling model). Move to desired operating position.

16 69-0563—2
Troubleshooting (continued)
(continued)
Problem Check Action
Room temperatures
are not correct
(continued).
— thermostat circuits. HEATING-ONLY SYSTEM—Move temp-
erature setting levers 5°F (3°C) above room
temperature. Heating system should start. If
the system does not operate, call a
qualified service technician.
COOLING-ONLY SYSTEM—Move temp-
erature setting levers 5°F (3°C) below room
temperature. Cooling system should start. If
the system does not operate, call a
qualified service technician.
HEATING/COOLING SYSTEM—With system
switch at HEAT, move temperature setting
levers 5°F (3°C) above room temperature.
Heating system should start. With system
switch at COOL, move temperature setting
levers 5°F (3°C) below room temperature.
Cooling system should start. If the systems
do not operate, call a qualified technician.

17 69-0563—2
Troubleshooting (continued)
(continued)
Problem Check Action
No cooling. — system switch. May be in OFF
or HEAT position. Move switch to COOL position.
— fuse or circuit breaker. If fuse is blown or breaker tripped, replace or
reset.
— condenser switch position.
Located outdoors and may be
turned OFF.
Move to ON position.
—Yand R thermostat
connections. Turn Off power to cooling system. Check for correct terminal hookups. Repair any frayed or
broken wires. Firmly tighten all terminal
screws.
— other Contact a qualified service technician for
assistance.
Timer is losing time. — Power. May be interrupted.
Make sure power is On. Make sure power is Off. Reset clock.
1

18 69-0563—2
Troubleshooting (continued)
(continued)
Problem Check Action
Timer is losing time
(continued).
— high limit control. If clock
powered through system trans-
former, power to clock and
equipment may be Off on
safety.
Wire separate transformer to power clock.
— filter. May be clogged. Safety
limit on equipment may cut off
power to system.
Replace filter and reset clock.
Timer does not run. — voltage across the C and R
terminals.
Remove the thermostat from the wallplate or
subbase, and measure the voltage. Refer to
page 19 for cause and action.

19 69-0563—2
Troubleshooting (continued)
Problem Check Action
Thermostat setting
and thermometer.
— level position of thermostat. Reinstall thermostat subbase. Use a spirit
level.
reading disagree. — area around thermostat for
drafts or radiant heat.
Thermostat should be about 5 ft (1.5m) above
floor on an inside wall. Contact qualified
service technician for change of location.
1Not applicable on model used in heating-only system.
2Not applicable on model used in cooling-only system.
If this Troubleshooting section has not solved the problem, call a qualified service technician or
Honeywell Customer Assistance Center, Honeywell Inc., P.O., Box 524, Minneapolis, MN 55440-0524
or call 1-800-468-1502, Monday-Friday, 7:00 a.m. to 5:30 p.m., Central time.

20 69-0563—2
Voltage at Timer Terminals
Ac Voltage at
C-R Terminals Possible Cause Check Action
0 Vac 1. System power is Off. 1. Restore power.
2. Short in timer power supply wiring. 2. Replace wiring.
3. Limit switch contacts stuck open. 3. Free or replace limit switch.
4. Transformer supplying power is
burned out. 4. Replace transformer.
Up to 15 Vac. 1. System transformer used to power
the timer is inadequate. 1. Use additional (separate) transformer.
2. Additional (separate) transformer
used to power the timer has
inadequate voltage.
2. Install transformer with proper
secondary voltage.
15 to 30 Vac. 1. Spring fingers on thermostat not
making proper contact with
subbase terminals.
1. Rebend spring fingers to a
45 degree angle to ensure
proper contact.
2. Timer has failed. 2. Replace thermostat.
