RYOBI
18 VOLT CANISTER VAC
MODEL NO. P3200
REPAIR SHEET

2
20
20
23
4
6
13
12
18
28
14 17
27
15
16
5
19
1
8
7
7
22
21
3
11
9
6
10
24
25
26
RYOBI 18 VOLT CANISTER VAC – MODEL NUMBER P3200
2

RYOBI 18 VOLT CANISTER VAC – MODEL NUMBER P3200
3
KEY PART
NO. NUMBER DESCRIPTION QTY.
PARTS LIST
1 901556001 DIRT TANK FOAM GASKET
1 901556001 DIRT TANK FOAM GASKET
....................................................
1
2 514763001 DRAIN PLUG
2 514763001 DRAIN PLUG
...........................................................................
1
3 560069001 RETAINER BAND
3 560069001 RETAINER BAND
.....................................................................
1
4 900312004 DRY USE FILTER
4 900312004 DRY USE FILTER
.....................................................................
1
5 660206025 * SCREW (M3.5 X 10 mm)
5 660206025 * SCREW (M3.5 X 10 mm)
.........................................................
8
6 001222001 HOUSING ASSEMBLY (INC. KEY NOS. 7, 9, 21 AND 22)
6 001222001 HOUSING ASSEMBLY (INC. KEY NOS. 7, 9, 21 AND 22)
............
1
7 561542001 MOTOR CUSHION
7 561542001 MOTOR CUSHION
..................................................................
2
8 760665002 SWITCH
8 760665002 SWITCH
...................................................................................
1
9 631851001 PIN (Ø 3mm)
9 631851001 PIN (Ø 3mm)
............................................................................
2
10
870234001 FUSE
........................................................................................
1
11
6620606 * SCREW (M3.5 X 16 mm)
.........................................................
7
12
540721002 WAND
......................................................................................
1
13
511760001 CAR NOZZLE
..........................................................................
1
14
590719002 NARROW CREVICE TOOL
......................................................
1
15
511303001 WIDE NOZZLE
.........................................................................
1
16
511274001 SQUEEGEE
..............................................................................
1
17
300840002 FLOOR BRUSH
.......................................................................
1
18
300056071 HOSE ASSEMBLY
...................................................................
1
19
901520001 WET USE FOAM FILTER
.........................................................
1
20
941065003 LOGO LABEL
...........................................................................
2
21
941065002 LOGO LABEL
...........................................................................
1
22
940304258 DATA LABEL
............................................................................
1
23
001223001 DUST TANK ASSEMBLY (INC. KEY NOS. 1, 2 AND 20)
.........
1
24
001226001 FLOAT CAGE ASSEMBLY
.......................................................
1
25
001224001 LOWER BLOWER HOUSING
..................................................
1
26
001227001 BLOWER ASSEMBLY (INC. KEY NOS. 8 AND 10)
..................
1
27
001225001 WIDE NOZZLE W/SQUEEGEE ASSEMBLY
(INC. KEY NOS. 15 AND 16)
(INC. KEY NOS. 15 AND 16)
.........................................................
1
28
301814001 DETACHABLE TOOL BELT
.....................................................
1
983000956 OPERATOR’S MANUAL
983000956 OPERATOR’S MANUAL
08-24-06
08-24-06
(REV:00)
(REV:00)
* Standard Hardware Item – May Be Purchased Locally
The model number will be found on a plate attached to the motor housing. Always mention the model
number in all correspondence regarding your CANISTER VAC or when ordering repair parts.

RED LEAD
* NOTE: The positive side of the motor has a red marking for identification.
RYOBI 18 VOLT CANISTER VAC – MODEL NUMBER P3200
4
SWITCH
MOTOR
RED
LEAD
WIRING DIAGRAM
FUSE
BLACK
LEAD
CONTACT
PLATE HOLDER
BROWN
LEAD
PCB BOARD
