Honeywell TE529ELW User manual

11
Weather Forecaster
with Indoor/Outdoor
Temperature and
Humidity
USER MANUAL
(TE529ELW)

21
INTRODUCTION
Thank you for selecting the Honeywell Weather
Forecaster. This device includes weather forecast with
pressure trend, precise time keeping and
temperature and humidity monitoring features
that you can use from the comfort of your home.
In this package you will find:
• Main unit (receiver)
• Remote sensor (transmitter) TS33
Please keep this manual handy as you use your
new item. It contains practical step-by-step instructions,
as well as technical specifications and precautions
you should know.
PRODUCT OVERVIEW
MAIN UNIT
FEATURES
• Wireless sensor transmits temperature and humidity to the
 main unit from up to 100 feet away
• Multi-channel capability to monitor temperature and
 humidity in up to 3 remote locations
• Indoor/Outdoor temperature with trends
• Indoor/Outdoor humidity with comfort level indicators
• Weather forecast in 5 large graphic icons:
 Sunny, Partly Cloudy, Cloudy, Rainy and Snowy
• Barometric pressure indication
• Precise time and date set via RF signal from the
 US Atomic Clock
• Calendar displays date with month and weekday in
 English, Spanish, French, German or Italian
• Dual crescendo alarm with snooze
• Programmable low-temperature alarm warning about icy
 or inclement weather conditions
• Blue backlight

43
MEM CHANNEL
ALARM
ON/OFF
MODE
ATOMIC CLOCK
D
A
H
E F B C G
FRONT VIEW
A WEATHER AND PRECISE TIME INFORMATION
 IN FIVE - LINE LCD DISPLAY
Views indoors and outdoors conditions along with
 precise time
B MEMORY BUTTON
 1). Recalls current, maximum or minimum temperature
  and humidity
 2). Clears all readings memory
C MODE BUTTON
 Changes clock display modes, activates and confirms settings
D ALARM ON/OFF BUTTON
 Sets weekday, single and pre-alarm and allows displaying
 alarm status
E UP BUTTON
 1). Increases settings
 2). Activates all alarms
 3). Activates atomic clock receiver
F DOWN BUTTON
 1). Decreases setting
 2). Disables all alarms
 3). Enforces remote sensor channel signal search
G CHANNEL BUTTON
 1). Recalls the different remote sensor reading
 2). Enables auto-scan feature
H SNOOZE/LIGHT BUTTON
 1). Stops alarm temporarily
 2). Activates LCD backlight

65
THERMO – HYGRO SENSOR
MADE IN CHINA
TM
1
2
3A
C
B
D
F
E
MADE IN CHINA
I
J
K
REAR VIEW
I WALL MOUNT RESESSED HOLE
Keeps unit on the wall
J BATTERY COMPARTMENT
 Accommodates 2 (two) UM-3 or AA 1.5V alkaline batteries
K REMOVABLE TABLE STAND
 Keeps unit in upright position
REMOTE SENSOR
A LED INDICATOR
 Flashes once when the remote sensor transmits the reading
 to the main unit.
 Flashes twice indicating low battery
B BATTERY COMPARTMENT
 Holds two AA-size batteries
C RESET
 Resets all previous settings
D CHANNEL SWITCH
 Selects the desired channel
FEATURES
• Remote temperature transmission to the main unit via
 433 MHz signal
• Case can be wall mounted using built-in hanger
• 100 feet transmission range without interference
• LCD display of measured temperature and humidity
• Temperature display type (C°or F°) selection
• Transmission channel selection

87
E WALL-MOUNT RECESSED HOLE
 Keeps the remote sensor on the wall
F °C/ °F SWITCH
 Selects the temperature display unit in Celsius or Fahrenheit
BEFORE YOU BEGIN
1. We recommend using alkaline batteries for the main unit
 and remote sensor.
2. Avoid using rechargeable batteries.
3. Insert batteries before first use, matching the polarity as
 shown in the battery compartment.
4. Always install batteries in the remote sensor before the
 main unit.
5. Press RESET after each battery change, using a paper clip
 or similar tool.
6. During an initial setup, place the main unit as close as
 possible to the remote sensor.
7. After reception is established (remote temperature will
 appear on the receiver’s display), position the remote sensor
 and main unit within the effective transmission range of
 100 feet.
NOTE:
1. Avoid setting the time and date on the main unit before the
 outdoor temperature is displayed.
2. The effective operating range may be influenced by the
 surrounding building materials and how the receiver and
 transmitter are positioned.
3. Position the remote sensor so that it faces the main unit
 (receiver), minimizing obstructions such as doors, walls,
 and furniture.
4. Though the remote sensors are weather-resistant, they
 should be placed away from direct sunlight, rain or snow.
 only one remote sensor is being used.
3. If you are using more than one sensor, select a different
 channel for each sensor.
4. Install two “AA” size alkaline batteries (not included)
 matching to the polarities shown in the battery compartment.
5. Replace the battery compartment door and secure the screws.
6. Secure the remote sensor in the desired location.
BATTERY INSTALLATION
REMOTE SENSOR
NOTE: Install the batteries; select the channel and type of
temperature (ºC/ºF) before you mount the sensor.
1. Remove the screws from the battery compartment with a
 small Phillips screwdriver.
2. Set the channel. The switch is located in the battery
 compartment. Channel 1 is typically selected if
BATTERY INSTALLATION
MAIN UNIT
1. Open the battery compartment door.
2. Install two batteries (UM-3 or “AA” size 1.5V) matching
 the polarity as shown in the battery compartment.
3. Replace the battery compartment door.
LOW BATTERY WARNING
A low-battery indicator [ ] will appear on the indoor or
remote temperature reading line of the main unit warning that
the corresponding batteries need replacement.
HOW TO USE THE TABLE STAND
The main unit has a removable table stand, which supports
the unit on the flat surface. The main unit can also be
mounted on the wall using the recessed screw hole.
The stand must be removed prior to mounting. The remote
sensor can be similarly mounted or placed on a flat surface.
GETTING STARTED
After batteries are installed, remote sensors will transmit
temperature readings at 45 second intervals. The main unit
may take up to 2 (two) minutes to receive the initial readings.
Upon successful reception, remote temperature will be
displayed. Then the main unit will automatically update
readings at 45-second intervals.
If no signals are received from the remote sensor(s) within
(2) two minutes, dashes “ ” will be displayed.
Press and hold [ ] button on the main unit for 2 seconds
to initiate another signal search.

109
READING THE KINETIC WAVE DISPLAY
The kinetic wave display shows the main unit (receiver)
signal reception strength.
MAXIMUM AND MINIMUM
TEMPERATURE & HUMIDITY
The maximum and minimum records of the indoor/outdoor
temperature and humidity will be automatically stored
in the memory of the main unit (receiver). Main unit
will display the minimum, maximum and the current reading
upon each press of MEM button. The unit will return to the
current temperature display in 15 seconds.
To clear the memory, press and hold MEM button and
stored readings will be erased.
TEMPERATURE TRENDS
The temperature trend indicator shows the trend of
temperatures collected at particular remote sight. There are
three trends will be shown: rising, steady, and falling.
COMFORT LEVEL INDICATORS
The comfort level indicators COM, WET or DRY will tell
you if the current environment is comfortable, too wet or
too dry. The comfort indicators will appear on the display
of the main unit when the following conditions are satisfied:
The unit is in searching mode.
Temperature readings
securely registered.
No signals. ˚F
TREND
TREND
Arrow
indicator
Temperature
Trend Steady FallingRising
TREND
CHECKING REMOTE AND INDOOR TEMPERATURES
The wave icon on the main unit's display located near the
remote sensor reading line, indicates a good reception from
the remote sensor. If the temperature goes above or below the
temperature operating range stated in specifications, the
display will show dashes “ ”
WWVB RADIO CONTROLLED TIME
The NIST (National Institute of Standards and Technology)
radio station is located in Ft. Collins Colorado. It transmits
an exact time signal continuously throughout the continental
United States at 60 KHz frequency. The Weather Forecaster
can receive this WWVB signal through its internal antenna
from up to 2,000 miles away. Due to the nature of the Earth’s
ionosphere, reception can be limited during the daylight hours.
The radio controlled clock will search for an alternate station
that derives its signal from the NIST Atomic clock in Boulder,
Colorado.
* Make sure the main unit is positioned at 8 feet minimum
 distance from any interference source such as a TV,
 computer monitor, microwave, etc. The successful reception
 of the atomic time signal depends on the positioning and
 location of the clock. Always place the main unit by the
 window for better reception.
* Within concrete wall rooms such as basements or office
 buildings, the received signal may be weakened.
 Always place the unit near the window.
The WWVB tower icon on the main unit’s display will flash
indicating radio signal reception from the WWVB station.
If the tower icon is not fully lit, or if the time is not set
automatically, please consider the following:
* During night-time hours, atmospheric disturbances are
 typically less severe and reception may improve.
 A single daily reception is sufficient enough to keep
 the accuracy reading within 1 second.

1211
TEMPERATURE AND HUMIDITY SCANNING
Press and hold CHANNEL button for 2 seconds
– the indoor, channel 1, channel 2 and 3 readings will be
displayed in sequence automatically.
LOST COMMUNICATIONS
If the main unit display for the remote sensor goes blank,
press and hold [ ] button for 2 seconds to begin a new signal
search. If the signal still isn’t received, please make sure that:
1. The remote sensor is in its proper location.
2. The distance between main and remote units is not
 over 100 feet.
3. The path between the units is clear of obstacles. Shorten the
 distance between units if necessary.
4. Fresh batteries are installed correctly in both remote and
 main units.
Note: When the temperature falls below freezing, the batteries
in outdoor remote sensors may have reduced voltage supply
and a shorter effective range. We recommend to
Use lithium-ion batteries at the temperatures below 32°F
If everything listed above is in order and there is no reception
anyway, please perform the following steps:
1. Bring main unit and remote sensor close together.
2. Remove 4 small screws from the back of the remote sensor
 and open the battery compartment.
3. Remove the batteries from the battery compartment and
 reinstall them in the same manner. Remote sensor
 LED indicator will flash showing transmission of the signal.
4. Remove the batteries from the main unit and reinstall
 them in the same manner.
5. On the main unit select the same channel number as
 set on the remote sensor. Outdoor temperature
 on the display will show that transmission is being
 received successfully .
WEATHER FORECAST
The weather station is capable of detecting atmospheric
pressure changes. Based on collected data, it forecasts the
weather for the next 12 to 24 hours.
NOTE:
1. The weather forecast accuracy is approximately 70%.
2. Display shows forecasted, not current conditions.
3. The “Sunny” icon indicates clear weather, even when
 displayed during night-time.
Forecast is...
Sunny Partly
Cloudy Cloudy SnowyRainy
When the
display
shows...
Indicator
displayed
on the unit
Temperature
Range
Humidity
Range
Shows
Current
Environment
COM
WET
DRY
No
Indicator
40%RH-
70%RH
OVER
70%RH
Below
40%RH
40%RH
to
70%RH
Ideal range for
both relative
humidity and
temperature
Contains excess
moisture
Contains
inadequate
moisture
No comment
20˚C to 25˚C
(68˚F to 77˚F)
-5˚C -+ 50˚C
(23˚F - 122˚F)
-5˚C -+ 50˚C
(23˚F - 122˚F)
Less than
20˚C (68˚F) or
More than
25˚C (77˚F)

1413
ATOMIC CLOCK
1. After the main unit receives readings from the remote
 sensor(s), the atomic time signal receiver will automatically
 search for the time signal. This takes about 5-8 minutes.
2. When the radio signal is received, the date and time will
 be set automatically, and the [ ] icon will appear.
3. If in 8 minutes the time signal has not been received,
 press “MODE” button to set the time manually. Always
 place the main unit by the window for better reception.
4. The clock will continue to search for the WWVB time
 signal daily for every hour between 1:00 am and 4:30 am.
 After the signal has been successfully obtained, the time
 and date will be updated automatically.
CALENDAR AND CLOCK DISPLAY MODES
Date is displayed in month-date format. Each press of the
MODE button will change the clock display setting between
the time with seconds and time with weekday.
SETTING CLOCK MANUALLY
TIME ZONE
1). Press MODE to select HOUR/MINUTE/WEEKDAY
 display.
2). Press and hold “UP” button for 3 seconds to enter into
TIME ZONE display mode.
3). Keep holding “UP” button to select the desired
TIME ZONE.
CLOCK
1). Press and hold MODE for 3 seconds: the year will flash.
2). Press “ ” or “ ” to change the flashing digits.
 After the first value is set, press MODE again. Continue
 setting month, day, 12/24 hour time display, minutes,
 day of week, and Fahrenheit or Celsius display.
 When you’ve set the last value, press MODE for
 the last time to return to regular mode.
ALARM
To set any alarm,
1. Press [ALARM ON/OFF] once to display alarm time.
 If the alarm is off,
 “OFF” will be displayed.
2. Press and hold [ALARM ON/OFF] for two seconds.
 The hour digit will flash.
3. Enter the hour using [ ] or [ ].
4. Press [ALARM ON/OFF] again. The minute digits will
 flash.
5. Enter the minutes using [ ] or [ ].
6. Press [ALARM ON/OFF] again to exit.
7. Repeat the same procedure to set a Single and Pre-Alarm.
TRANSMISSION COLLISION
Signals from other household devices, such as doorbells,
home security systems, and entry controls, may interfere
with this product and may cause temporary reception
failure. This is normal and will not affect the general
performance of the product. The transmission and reception
of temperature readings will resume once the interference
subsides.

1615
SPECIFICATIONS
Temperature and Humidity Measurement
Main unit
Indoor Temperature
Proposed operating range : -5°C to +50°C /
     23°F to 122°F
Temperature resolution : 0.1°C/ 0.2°F
Indoor Humidity
Proposed operating range : 25% RH to 90% RH
Resolution: 1%
Comfort indicators – COMFORT, WET & DRY
User- Selectable F°or C°temperature display format
SNOOZE
When the alarm sounds, press the SNOOZE/LIGHT button
to temporarily stop the alarm. After depressing
SNOOZE/LIGHT button, the alarm sound will resume in
5 minutes. If the alarm is not disabled after that, it will sound
for 4 more minutes and then will stop by itself.
DISABLING ALARM
Press [ALARM] button on the main unit to disable an alarm.
ALARMS
* Weekday Alarm
The alarm will sound and the alarm icon will flash at the
set time Mondays through Fridays.
* Single Day Alarm
The alarm will sound and the alarm icon will flash at the
set time, but will not activate on subsequent days.
* Low Temperature Pre-Alarm
If an outdoor temperature is 32º F / 0º C or below, the
pre-alarm feature will be activated. The pre-alarm time
interval can be set for 15, 30, 45, 60, 75 or 90 minutes before
the weekday or single alarm time. Press and hold
[ALARM ON/OFF] button for two seconds in Pre-Alarm mode
to set the pre-alarm interval.
“ ” (Weekday alarm), “ ” (Single day alarm), and
“Pre-AL” (Pre-alarm) icons will indicate which alarm mode
is armed. You can enable or disable an alarm by pressing
the [ ], [ ] buttons in alarm display mode. Press
ALARM ON/OFF to toggle between alarm modes or to
return to the default display.
WS
PRECAUTIONS
This product is engineered to give you years of satisfactory
service if handled carefully. Here are a few precautions:
1. Do not immerse the units in water.
2. Do not clean the units with abrasive or corrosive materials.
 They may scratch the plastic parts and corrode the
 electronic circuits.
3. Do not subject the product to excessive force, shock, dust,
 temperature, or humidity, which may result in malfunctions,
 shorter lifespan, damaged batteries, and damaged parts.
4. Do not tamper with the units' internal components. Doing
 so will invalidate the warranty and may cause damage.
 These units contain no user-serviceable parts.
5. Use only fresh batteries. Do not mix new and old batteries.
6. Read the user's manual thoroughly before operating the units.

1817
Remote Sensor
Temperature
Proposed operating range
with alkaline batteries : -20°C to + 70°C /
     -4°F to 158°F
Proposed operating range
with lithium batteries : - 38°F to 158°F
    ( -38.8 C°to 70°C)
Temperature resolution : 0.1°C/ 0.2°F
Humidity
Proposed operating range : 25% to 90%
Resolution  : 1%
RF Transmission Frequency : 433 MHz
Maximum number of Remote sensors : 3
RF Transmission Range : Maximum 100 feet
Temperature sampling cycle : approximately
     45 seconds
Calendar and Clock
12 hour display in hh : mm format
Date Format: Month – Day format
Day of week: User- selectable in 5 languages
   (English, Spanish, French, German, Italian)
Dual 4-minute crescendo alarm with snooze
Pre-alarm for ice alert with programmable time intervals
Blue Backlight
Wall Mount or Table Stand
Power
Main unit : 2 AA batteries
   – alkaline are suggested (not included)
Remote Sensor : 2 AA batteries
   – alkaline are suggested (not included)
Dimensions
Main unit : 3.68”(L) x 7.31”(H) x 1.31”(D)
Remote sensor : 2.37”(L) x 4”(H) x 1”(D)
FCC STATEMENT
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and
(2) This device must accept any interference received,
including interference that may cause undesired operation.
Warning: Changes or modification to this unit not expressly
approved by the party responsible for compliance could void
the user’s authority to operate the equipment.
NOTE: This equipment had been tested and found to comply
with the limits for a Class B Digital device, pursuant to
Part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference
in a residential installation. This equipment generates, uses
and can radiate radio frequency energy and, if not installed and
used in accordance with the instructions, may cause harmful
interference to radio communications.
However, there is no guarantee that interference will not
occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which
can be determined by turning the equipment off and on, the
user is encouraged to try to correct the interference by one
or more of the following measures:
1. Reorient or relocate the receiving antenna.
2. Increase the separation between the equipment and receiver.
3. Connect the equipment to an outlet on a circuit different
 from that to which the receiver is connected.
4. Consult the dealer or an experienced radio / TV
 technician for help.

2019
DECLARATION OF CONFORMITY
We
Name: Hideki Electronics, Inc.
Address: 7865 SW Mohawk, Tualatin, OR 97062
Telephone No.: 1-503-612-8395
declare that the product
Product No.: TE529ELW
Product Name: Weather Forecaster with
   Indoor/Outdoor Temperature and Humidity
Manufacturer: Hideki Electronics Ltd.
Address: Unit 2304-06, 23/F Riley House, 88 Lei Muk Road,
Kwai Chung, New Territories, Hong Kong
is in conformity with Part 15 of the FCC Rules. Operation is
subject to the following two conditions:
1. This device may not cause harmful interference.
This device must accept any interference received, including
interference that may cause undesired operation.
The information above is not to be used as contact for support
or sales. Please call our customer service hotline
(refer to the warranty statement) for all inquiries instead.
STANDARD WARRANTY INFORMATION
This product is warranted from the manufacturing defects for
one year from date of retail purchase. It does not cover
damages or wear resulting from accident, misuse, abuse,
commercial use, or unauthorized adjustment and repair.
Note that online product registration is required to ensure
valid warranty protection.
To register your product, go to our Company website at:
www.hidekielectronics.us. Click Online Product Registration
under the Customer Service menu.
Should you require assistance with this product and its
operation, please contact our
Customer Service Hotline [phone]
Please direct all returns to the place of the original purchase.
Should this not be possible, contact Customer Service Hotline
for assistance and to obtain a Return Merchandise Authorization
(RMA). Returns without a return authorization will be refused.
Please retain your original receipt as you may be asked to
provide a copy for proof of purchase.
Hideki Electronics, Inc. reserves the right to repair or replace
the product at our option.
Copyright (2005) Hideki Electronics Inc. All Rights Reserved.
The Honeywell Trademark is used under license from
Honeywell Intellectual Properties Inc.
Honeywell International Inc. makes no representations or
warranties with respect to this product.
