HONTECH HT-C06 User manual

HT-C06
Registered design and patent pending All rights reserved.
G
H
I
1
2
Specification
Max. Load:60kg
Net Weight:4.7kg
Product Spec
UNIT mm：
(Front View)
()Top View
(Lateral View)
TV Bracket x2
Wall Bracket x1
Parts Name
Please check out all parts.
M6 40 Anti-thief Screwxx2
Anti-thief Hookx2
4Sleeve x 4
M4x14 Screw x6
5/16x2 Wall Anchor x4¼
4x20 Wood Screw x4
M6x10 Screw x6

HT-C06
Registered design and patent pending All rights reserved.
A
C
D
D
B
E,FG
E,FG
H
I
1
2
3
4
The wall must be at least 5cm
thick.
For a wooden wall,please choose
wood screws 6pcs 4X20mm(D)
For a concrete wall,please choose
wall anchors 4pcs mm(C)
5/16 x 2¼
At the time of installation,make
sure that 2 people hold the LCD TV.
Step 1
Step 2
Step 3
Make sure the two brackets are
locked and secure.
Step 4
Tighten the fixed screw to
lock the TV in place.
Make sure the LCD TV is turn off
before installing.
Use 6 pcs screws and
6 pcs 4(F) sleeve to assemble
the TV bracket to the LCD TV.
M4x15(G)
Installation
