HONTECH HT-B01 User manual

HT-B01
1
2
Specification
UNIT mm：
Max. Load:50kg
Net Weight:2.7kg
(Front View)
()Back View
()Top View
Product Spec
(Lateral View)
Parts Name
Please check out all parts.
12 x 1 ½
#Wood Screw x 6 5/16x2 Wall Anchor x4¼
G
H
10x56 Plastic Sleeve x6
TV Bracket x1
Wall Bracket x1
M4x15 Screw x 6 M4x15 Anti-thief Screw X6
4 Sleeve x6
Registered design and patent pending All rights reserved.

HT-B01
1
2
3
4
Installation
The wall must be at least 5cm
thick.
For a wooden wall,please choose
wood screws 6pcs mm( )
12 x1½ E F
#
,
For a concrete wall,please choose
wall anchors 4pcs mm(C)
5/16x2¼
At the time of installation,make
sure that 2 people hold the LCD TV.
Step 1
Step 2
Step 3
Make sure the two brackets are
locked and secure.
Step 4
Tighten the fixed screw to
lock the TV in place.
Make sure the LCD TV is turn off
before installing.
Use 6 pcs screws and
6 pcs 4(H) sleeve to assemble
the TV bracket to the LCD TV.
M4x15(G)
Registered design and patent pending All rights reserved.
BE
F
C
AH
G
D
