Hoolux HLX-1 User manual

Follow these instructions to setup
your Hoolux Medical Device.
welcome
02

03
contents
HM PLAYER SETUP
10 Switching On
11 Loading the App
12 WiFi Setup
13 Pairing Key
14 Login
15 Device Registration
DEVICE SETUP
04 Check Contents
05 Attaching the Device
07 Connect to Power
08 Connect to Display
09 Connect to LAN
OTHER
20 Help & Support
21 Device Ports
22 The Remote
23 FCC Guarantee

check contents
04
Ensure that you have received
all contents. Please refer to the
Help & Support section on
page 20 if an item is missing. 1. Hoolux Device
2. Remote 3. Power Cable 4. HDMI Cable
check contents

05
attaching the device
Place the Hoolux device on top of
the TV monitor as shown in the
illustration.
Use the bottom clip to attach the
device on top of the display. Please
remove the adhesive lm from the
inside of the bottom clip.
Please ensure the device is
centered and attached securely.
The device can be tilted up and down
from the bottom clip to ensure a
better angle facing the patients in
the waiting room.

attaching the device
(continued)
It is very important that the device and
TV monitor are facing the area of your
waiting room which faces the majority
of your patients. See the illustrations
on the right to guide you.
06

Connect the device to a power
outlet as shown in the illustrations.
connect to power 07
1
2

Connect the device to the display
using the HDMI cable provided.
connect to display
through hdmi
08

We strongly advice you to use an
Ethernet cable to connect the
device to your router. While the
device can connect using WiFi,
lower speeds and connectivity
issues may compromise
performance.
connect to lan
(optional)
09

Switch On the device.
While the device powers up,
the monitor will display a loading
animation. When the device
nishes loading the monitor will
display your Home Screen with the
Hoolux Medical Icon.
switching on
10

Select the Hoolux Player App from
the Home Screen.
Press OK on the remote to launch it.
loading the app 11

12
This step is only necessary if you
are connecting through WiFi.
Use the remote (arrows and OK button)
to select the your WiFi network from
the drop-down menu.
Enter your WPA (WiFi password) in the
box provided.
Once the network is selected and
the password is entered, click
the NEXT button.
wiFi setup
(optional)

13
Please take note of your Pairing Key.
This key consists of 3 short words
inside a dark gray box which will be
required to login into your Hoolux
Medical account from your computer.
As soon as you complete your
registration the player will
automatically connect to the
Hoolux network and nish the
device setup.
pairing key

14
From your personal computer, please visit
dr.hooluxmedical.com and login to the Hoolux
Medical Portal. At this stage, you will have received
a welcome email from Hoolux Medical containing
your details for accessing the portal.
Please refer to the Help & Support section
on page 20 if you experience any problems.
On successful login please follow the instructions
in order to complete your device registration.
These steps will include entering your Pairing
Key (see page 13) and completing a form with
information about your practice.
login

15
STAGE 1
Once you have logged into the Hoolux
Medical portal, select DEVICES in the
main navigation bar.
Here you will see a large yellow button
that reads: ADD A NEW DEVICE TO
MY ACCOUNT. Click on the button to
proceed to the next stage.
device online
registr ation

16 STAGE 2
Here you will have to enter your
Pairing Key (see page 13). This unique
code is used to pair the device in your
waiting room to your Hoolux Medical
account.
Once completed, click CONTINUE.

17
STAGE 3
In order to complete your
registration process you are
required to complete all elds
in the form.
Begin by entering a Device Name
(a name chosen by you).
The Device Name will help with
identifying your device and can be
used if you require any support.
After entering a Device Name we
require you to provide us with an
Average Number of Patients that
visit the clinic per day. Please round this
gure to the nearest whole number.

18 STAGE 3 (continued)
Now we require you to provide your Medical
Specialties; areas of medicine that your
practice specializes in. Click on the button
that says “Open Specialties”, from the pop up
please check the boxes that are relevant to
your practice and when complete please click
the SAVE button.
Finally you will need to register the Address
at which the Device is housed. Once your
address is provided click the SAVE DEVICE
button and return to where the physical
device is set up in your waiting room..

19
Once the registration is completed
the device will automatically connect
to the network, and will download
and start playing the videos.
Finish

20
Should you encounter any issues
during your Setup and Registration
process please don’t hesitate to
contact our support team by email
or phone.
help & support
Support Availability:
Monday to Friday from 7.00am to 4.00pm EST
Support Email:
[e-mail]
Support Phone:
[phone]
