Hoover BH52210 User manual

IMPORTANT: Read carefully before assembly and use.
This product is intended for household use only. If used commercially the warranty is void.
©2016 Techtronic Floor Care Technology Limited. All Rights Reserved. Distributed by Royal Appliance Mfg. Co. Glenwillow, Oh 44139 #961152025 • ID117827 R0
BH52210, BH52200
BH52212
User manual.
CRUISE CORDLESS VACUUM

Welcome to
Hoover®ownership.
It’s Guaranteed.
Hoover will replace your batteries under our 2 year
limited warranty. See Warranty for complete details.
Hoover.com [phone]
Make it official.

Safety Instructions
Getting started with your Cruise Cordless Vacuum
Assembly
Attach the wall bracket
How to use
Accessories
Before you begin cleaning
Using your machine
Using your machine as a handheld
Using your machine to clean up high
Maintenance
How to order accessories
Need Help?
Service & Warranty
1
3
4
5
6
7
8
10
11
13
15
22
23
24
Your Guide:

1
IMPORTANT SAFETY INSTRUCTIONS
SAVE THESE INSTRUCTIONS
When using an electrical appliance, basic precautions should always be
followed, including the following:
READ ALL INSTRUCTIONS BEFORE USING THIS APPLIANCE.
THIS PRODUCT IS INTENDED FOR HOUSEHOLD USE ONLY.
IF USED COMMERCIALLY WARRANTY IS VOID.
WARNING: TO REDUCE THE RISK OF FIRE,
ELECTRIC SHOCK, DAMAGE OR INJURY:
•Fully assemble before operating.
• Do not use appliance on wet surfaces. Do not expose appliances to rain.
Store appliances indoors.
• The charger is for indoor use only. Be sure to always keep the battery and
charger indoors in a dry place.
• Do not allow to be used as a toy. Not intended for use by children age
12 and under. Close supervision is necessary when used near children.
To avoid injury or damage, keep children away from product, and do not
allow children to place fingers or other objects into any openings.
• Use only as described in this manual. Use only Hoover® recommended
attachments and products.
• Do not use charger with damaged cord or plug. If appliance or charger
is not working as it should, has been dropped, damaged, left outdoors,
or dropped into water, take it to a service center prior to continuing use.
• Do not pull or carry charger by cord, use cord as a handle, close a door
on cord, or pull cord around sharp edges or corners. Do not place product on
cord. Do not run appliance over cord. Keep cord away from heated surfaces.
• Do not unplug charger by pulling on cord. To unplug charger, grasp the plug,
not the cord.
• Do not handle charger including charger plug and charger terminals, or
appliance with wet hands.
• Do not put any object into openings. Do not use with any opening blocked;
keep free of dust, lint, hair, and anything that may reduce air flow.
• Keep hair, loose clothing, fingers, and all parts of body away from openings
and moving parts.
• Use extra care when cleaning on stairs. To avoid personal injury or damage,
and to prevent the cleaner from falling, always place cleaner at bottom of
stairs on floor. Do not place cleaner on stairs or furniture, as it may result in
injury or damage.
• Do not use to pick up flammable or combustible liquids, such as gasoline, or
fine wood shavings, or use in areas where they may be present.
• Do not pick up anything that is burning or smoking, such as cigarettes,
matches, or hot ashes.

2
•Do not use without Dirt Cup and/or Filters in place.
• Turn power switch off and remove battery before removing or installing
brush roll.
• Always turn off this appliance before connecting or disconnecting
Motorized Turbo Tool or tools.
• Do not incinerate the charger, battery, or appliance even if it is severely
damaged. The batteries can explode in a fire.
• This product includes rechargeable lithium-ion batteries. Do not expose
batteries to high temperatures, as they may catch fire and/or explode.
•Do not expose battery to crushing, incineration or similar actions.
• Do not dispose of battery in a fire or trash compactor. See battery disposal
section for directions.
•Do not attempt to disassemble battery.
• Unplug the charger from the outlet before any routine cleaning or
maintenance.
• Leaks from battery cells can occur under extreme conditions. If any liquid
gets on the skin wash quickly with soap and water. If any liquid gets into the
eyes, do not rub eyes, immediately flush them with clean water continuously
for a minimum of 15 minutes. Seek medical attention immediately.
• Use only the charger (Hoover Part #440009553) supplied by Hoover®
to recharge.
• Use only the battery (Hoover Part # 440009633) supplied
by Hoover®. Other batteries may burst causing serious personal injury
or damage.
• Do not touch or insert objects into battery pack or charger terminals.
•Do not attempt to short circuit the battery or charger terminals.
WARNING: This product contains chemicals known to
the State of California to cause cancer, birth defects or reproductive harm.
WASH HANDS AFTER HANDLING.
WARNING: TO REDUCE THE RISK OF ELECTRIC
SHOCK, THE CHARGER HAS A POLARIZED PLUG (ONE
BLADE IS WIDER THAN THE OTHER). THIS PLUG WILL FIT
IN A POLARIZED OUTLET ONLY ONE WAY. IF THE PLUG
DOES NOT FIT FULLY IN THE OUTLET, REVERSE THE PLUG.
IF IT STILL DOES NOT FIT, CONTACT A QUALIFIED ELECTRI-
CIAN TO INSTALL THE PROPER OUTLET. DO NOT CHANGE
THE PLUG IN ANY WAY.

3
Getting started with your Cruise cordless:
CARTON CONTENTS
A. Handheld
B. Powered Head
C. Reach Wand
D. Dusting Brush
E. Crevice Tool
F. Pet/Stair Tool
G. Articulating Dusting
Brush
B
AC
ED F
All models come with a
charger, battery, wall
mount, 2 screws and
user manual.
Contents vary dependant
on the model purchased.
G

Important
This vacuum cleaner is not free standing. In
between uses or when carrying out any
maintenance always lie flat on the floor in a
suitable location so it does not become a trip
hazard or can be stepped on.
4
Assembly:
Line up the connector on
the Reach Wand with the
Powered Head. Push the
Reach Wand down onto the
Powered Head until it clicks
into place.
Push the Handheld down
onto the Reach Wand until
it clicks into place.
The vacuum cleaner is not free
standing and in between uses
must always be placed in the wall
bracket or laid flat on the floor, in
a suitable location so it does not
become a trip hazard or can be
stepped on.
2 3
WARNING
To reduce the risk of personal injury, remove
battery before cleaning or servicing.
!! !!

5
Attach the wall bracket:
First, fully assemble the vacuum but do not attach the battery.
Use both screws
and wall plugs to
secure the wall
bracket to the wall.
Place covers over
the screws.
Attach the wall
bracket to
the handle.
Firmly press the
vacuum handle
into the wall
bracket to secure.
With the wall bracket
attached, stand the
vacuum close to the
wall, in the upright
position with the
Powered Head
flat on the floor.
The tools can
be stored on the
wall bracket.
Holding the wall
bracket firmly in
place, carefully
remove the
vacuum. Using
a pencil
make a small
mark for
each screw.
3
2
45 6

6
How to use:
1. Brushbar On/Off button
2. On/Off & charging light
3. Handheld release button
4. Reach Wand
5. Power head/accessory release clip
6. Powered Head
7. Brushbar
8. Filter cover release buttons
9. Handle
10. Battery charger inlet
11. Battery release button
12. Dirt container release button (hidden)
13. Dirt release button
14. On/Off trigger
15. Continuous power latch (hidden)
16. Battery
17. Dirt container
1
4
5
6
9
10
12
14
2
7
3
8
11
13
15
16
17

7
Accessories:
All models come with a charger, battery,
wall mount, 2 screws and user manual.
Contents vary dependant on the
model purchased.
Dusting Brush Pet/Stair Tool
Crevice Tool Articulating Dusting
Brush

8
Before you begin cleaning:
WARNING
To reduce the risk of personal injury,
remove battery before cleaning
or servicing.
• IMPORTANT •
For best cleaning results, filters require cleaning at least
every 3 months and should be replaced every 12 months
depending upon use. If the vacuum cleaner is blocked,
remove the battery before removing the blockage.
!!
Slide the battery into
the back of the handheld.
The battery will click
into position when
correctly fitted.
To charge the machine,
detach the reach wand
and lie the handheld on
its side on a flat stable
surface. You can also
charge the machine
while attached to the
wall mount. Make sure
the floorhead and wand
are attached together.
Insert the charger lead
into the charger inlet
located on the back of
the handle.
Plug the charger plug
into the outlet.
234
see next page

9
Before you begin cleaning:
WARNING
Do not use the vacuum cleaner when the
machine is plugged in and charging.
!!
The On/Off and charging light will
illuminate continuously while the
charger is connected.
Red light – The battery is charging.
Green light – The battery is charged
(after 5 hours).
If charging for the first time the initial
charge time is 8 hours.
5
WARNING
For best performance the terminals
on the battery and vacuum cleaner must
be clean and free from dust and dirt.
The life expectancy of the battery will
vary depending on the usage of the
vacuum cleaner.
!!

10
Using your machine:
WARNING
This vacuum cleaner has a constantly rotating brushbar when the brushbar
‘ON’ is selected. Never leave the vacuum cleaner in one spot for an
extended period of time as this may damage the floor surface.The brushbar
should be ON for carpets and OFF for hard floors.
!! WARNING
Risk of personal injury – the brush
roll may suddenly restart. Turn power
switch off and remove the battery before
cleaning of servicing the brush roll.
!!
Squeeze the trigger located
underneath the handle, the
machine will switch ‘On’. The
On/Off and charging light will
illuminate green indicating the
power is on and the machine is
charged. Release the trigger to
switch the machine ‘Off’.
Squeeze the trigger and push the
‘Continuous power latch’ towards
the trigger. This will lock it into the
‘On’ position and will continue
to power the machine without
having to hold in the trigger. Push
the latch away from the trigger to
unlock and release the trigger.
Press the brushbar’s
On/Off button to activate.
Repeat this process to
de-activate the brushbar.
The brushbar should be
switched ON for carpets
and OFF for hard floors.
When the vacuum cleaner is in use
the On/Off and charging light will
illuminate and flash red when the
battery is running low. When the
red light flashes the machine will
turn off in 20 seconds. The user
should recharge the machine.
3
2
4see next page

11
Press the handheld
release clip. Pull to
separate the handheld
from the reach wand.
The reach wand when
attached to the Powered
Head/accessory is not free
standing, place safely and
securely to one side.
Choose an accessory
(pictures illustrated
dependent upon model).
Push the chosen accessory
into the handheld until it
clicks into place.
5
7
6
8
Using your machine as a handheld vacuum:
Always take extra care when using the vacuum cleaner on the stairs. IMPORTANT
Not to be used for
grooming a pet.
!!
see next page

12
Squeeze the trigger located
underneath the handle, the
machine will switch ‘On’. The
On/Off and charging light will
illuminate green indicating the
power is on and the machine is
charged. Release the trigger to
switch the machine ‘Off’.
Squeeze the trigger and push the
‘Continuous power latch’ towards
the trigger. This will lock it into the
‘On’ position and will continue
to power the machine without
having to hold in the trigger. Push
the latch away from the trigger to
unlock and release the trigger.
All of the accessories
can be attached directly
onto the handheld.
910
Using your machine as a handheld vacuum:
Always take extra care when using the vacuum cleaner on the stairs. IMPORTANT
Not to be used for
grooming a pet.
!!

13
Choose an accessory
(pictures illustrated dependent
upon model).
Push the chosen
accessory into the
reach wand until it
clicks into place.
Squeeze the trigger located
underneath the handle, the
machine will switch ‘On’. The
On/Off and charging light will
illuminate green indicating the
power is on and the machine is
charged. Release the trigger to
switch the machine ‘Off’.
3
2
4
Using your machine to clean up high:
The reach wand can be used for hard to reach places.
Press the Power Head/
accessory release clip
and pull to remove the
Powered Head from the
reach wand.
see next page

14
Squeeze the trigger and push
the ‘Continuous power latch’
towards the trigger. This will
lock it into the ‘On’ position
and will continue to power
the machine without having
to hold in the trigger. Push the
latch away from the trigger to
unlock and release the trigger.
The Reach Wand can be used for
hard to reach places.
The Reach Wand can be
used for hard to reach
places and at different
heights for above floor
cleaning.
The vacuum cleaner is not free
standing and in between uses
must always be placed in the wall
bracket or laid flat on the floor, in
a suitable location so it does not
become a trip hazard or can be
stepped on.
5
7
6
8
Using your machine to clean up high:
The reach wand can be used for hard to reach places.

15
Slide the battery out from the back
of the handheld.
2
Maintenance:
Removing the battery.
Lie the handheld on
its side on a flat stable
surface. Press the
battery release button.
WARNING
To reduce the risk of personal injury,
remove battery before cleaning
or servicing.
!!

16
The reach wand when attached
to the Powered Head/accessory
is not free standing. Place safely
and securely to one side.
Ensure the battery has
been removed and hold
the handheld over a bin,
press the dirt release
button to allow dirt and
debris to fall out.
3
2
4
Maintenance:
Cleaning the lter and separator.
Press the handheld
release clip. Pull to
separate the handheld
from the reach wand.
Ensure the battery has
been removed and hold
the handheld over a bin,
press the dirt release
button to allow dirt and
debris to fall out.
WARNING
To reduce the risk of personal injury,
remove battery before cleaning
or servicing.

17
2
Maintenance:
Cleaning the post–motor lter.
Press the filter
cover release buttons
located on both sides
of the filter cover and
pull to remove the filter
from the machine.
Pull to separate the filter from the
filter cover/holder. Tap the filter
and filter cover/holder over a bin
to remove any dirt/debris. Wash
the filter under running water (40
degrees max).
WARNING
To reduce the risk of personal injury,
remove battery before cleaning
or servicing.
!!
