Hoover TS2065 001 User manual

CANISTERS
39000711 TS2065 001
Service Manual

39000711 TS2065 001 1019 (03/05/2010)
Ref. Descrizione - Description - Beschreibung - Descripcion
Fine
Ending
Fin
End
Fin
Inizio
Beginning
Debut
Begin
Inicio
Ricambio
Part No.
Piece
E-Teil
Pieza
Copyright 2011 Gias S.r.L.
1 Motor mount - fan end 48000582
2b Motor Kit 49019890
3 Motor mount - commutator end 48000593
4 Screw 02105005
15 Chassis 48000863
17 Rear wheel 48000864
21 Castor wheel 04320016
21a Castor support 48000865
38 Top cover 48002405
45 Plug and cord assembly 04635018
47 Hose assembly 35600361
48d Telescopic extension tube 48000880
61d Hepa filter 04365062
63 Motor cover 03726030
66 Bag door seal 03875063
69 Bag full indicator 03935011
70 Pre-motor filter 03875166
70a Filter kit 09205469
71 Disposal bag 35600392
85 Pressure switch tube 06605089
88 Electronic module 48000580
90 Module housing (protection) 03645010
92 Spring clip 03835008
96 Spring 03835006
101 Bag holder 03645055
102 Seal 03870606
105 Motor support 03715024
120 Floor nozzle 04845090
157 Handle tube upper (curved hose end) 48000874
165 Valve 04350201
184 Noise reducer 03945048

39000711 TS2065 001 1019 (03/05/2010)
Ref. Descrizione - Description - Beschreibung - Descripcion
Fine
Ending
Fin
End
Fin
Inizio
Beginning
Debut
Begin
Inicio
Ricambio
Part No.
Piece
E-Teil
Pieza
Copyright 2011 Gias S.r.L.
186 Noise reducer 03945026
193 Cord clamp 03610367
202 Silencer 03945049
248 On/Off pedal 48000867
249 Cord reel pedal 48000866
251a Motor housing seal 03875167
257 Roundel (Hoover emblem) 05165002
263 Flexible hose without edges 35600360
280 Cord reel complete 04685037
282 Potentiometer spindle 03275004
285 Button spring 03835005
368 Litter picker 03955000
400 Seal for partition 03875168
701 Bulkhead gasket 03115004
720 Spring 03835024
802 Seal 03875052
1075 Frame 03726033
1114 Multi function tool 04865025

SENSORY Suction Cleaners
SENSORY Fitting Notes (Base Models)
Access to Main components
Open fully the Bag cover using the moulded handle at the rear of the cleaner, if
required to remove fully unclip at the front of Bag cover by prising the 2 lugs on front
handle from the Lower body and remove.
Remove the Exhaust filter assy from the Motor cover, remove the 4 screws at each
corner of the Motor cover and lift up.
Motor Removal
Procede as above Access to Main components
Remove the Motor Mount upper you now have access to the Motor.
Make a note of the 2 wires attached to the Motor and remove, lift out the Motor along
with the rubber mount and plastic motor support , unless damaged you can leave the
Motor mount lower in place.
Cord Reel /Module (On/Off Switch) Removal
Procede as above Access to Main components
Module Removal
You now have access to the Cord reel and Module (Includes On/Off Switch), to
remove the Module and On/Off Switch unclip the module from its housing and unclip
the Bag check indicator tube.
Lift up the Module assy and the Cord reel enough to gain access to the leads on the
Cord reel, next taking note of the connections remove the 2 leads to the Cord reel
assy then remove the 2 leads at the motor and pull the leads through the aperture in
the Lower body, replace the Module(On/Off Switch).
Cord Reel Removal
Procede as above Access to Main components
Lift up the Module assy along with the Cord reel assy, disconect the 2 leads to the
module and unclip the Bag check indicator tube you can now remove the Cord reel.
When replacing the Cord reel refit in the aperture of the lower body, care needs to be
taken that the Cord reel brake button is in place to engage when the Cord reel pedal
is pressed.

SENSORY Suction Cleaners
Cord Reel /On Off Pedals Removal
Open fully the Bag cover using the moulded handle at the rear of the cleaner, if
required to remove fully unclip at the front of Bag cover by prising the 2 lugs on front
handle from the Lower body and remove.
You now have access to the Motor cover, remove the 4 screws at each corner and lift
away, turn the Motor cover upside down the pedals are each located by 3 lugs using
a Terminal screwdriver prise away one lug at a time and push down the Pedal and
remove.
Rear Wheel Removal
Turn the cleaner upside down, using a flat bladed screwdiver feel for one of the 3
lugs holding the Rear wheel in position and push in, using your other hand push the
wheel away from you and gently ease away.
Castor Wheel Removal
Turn the cleaner upside down, using a Terminal screwdriver gently ease away and
pull away from cleaner.
Electrical Checks
Check condition of plug--------- if the pins are burnt or body cracked take
appropriate action.
Check condition of the mains lead ---------------if chipped or burnt,take
appropriate action.
Insulation test
Open fully the Bag coverr
Remove the pre - motor filter.
Use a Metrohm.
Bond the Live and Neutral pins with one of the meter clips and connect the other
meter clip to a terminal screwdriver.
Insert the screwdriver through the grill onto the fan casing.
Select- The MEGOHMS SCALE =MINIMUM READING 1 MEGOHM

SENSORY
Sensory
FILTERS
PREMOTOR FILTERS EXHAUST FILTERS
S76 T57
Product code: 03875166 Product code: 04365030
EAN code: 8016361900639 EAN code: 5010418160932
Chinese production Washable microfilter
BAGS
PUREHEPA BAGS
H60
Product code: 35600392
EAN code: 8016361737204
N° of layers: HEPA Anti-
odour filtration
N° of bags in pack: 4
H52 replacement
PUREFILT BAGS
H30S
Product code: 09178278
EAN code: 5010418137415
N° of layers: 3
N° of bags in pack: 5
ALLERGY DEFENDER SPRAY
A30S
Product code: 35600450
EAN code: 8016361739758
10 bottles per display
ALLERGY DEFENDER GRANULES
A31G
Product code: 35600451
EAN code: 8016361739765
15 boxes per display

S58 T70
Product code: 03875043 Product code: 04365062
EAN code: 5010418159455 EAN code: 8032767162198
Double layer premotor filter
European production Washable HEPA filter
FILTER KITS
U27
Product code: 09205469
EAN code: 5010418169904
HEPA exhaust filter+ both new
and old premotor filter version
to satisfy all customer
U28
Product code: 09205451
EAN code: 5010418169898
Washable exhaust microfilter+
both new and old premotor
filter version to satisfy all
customer
Sensory
HOSES
HOSE COMPLETE HOSE
E32 D79
Product code: 35600360 Product code: 35600361
EAN code: 8016361734104 EAN code: 8016361734111
COMPLETE ZOOM TUBE
D92
Product code: 35600526
EAN code: 8016361743434
