House of lithium 50/50 User manual

house of lithium
E
l
e
c
t
r
i
c
M
o
t
o
r
S
p
o
r
t
s
USER MANUAL
50/50

house of lithium

house of lithium
CONTENTS
Part 1 - Unboxing Pg. 1-5
Part 2 - Display Instructions Pg. 6-12
Part 3 - Common Problems and Solutions Pg. 13-15
Part 4 - Use and Maintenance Pg. 16-19
Part 5 - After Sales and Warrenty Pg. 20-24
E
l
e
c
t
r
i
c
M
o
t
o
r
S
p
o
r
t
s

Push the clamp to lock the frame solidly and make sure it is tight.
house of lithium 01
(1)Frame Unfolding
Part 1 Unboxing
The 50/50 ebike comes 95% assembled.
Only three steps to Fold/Unfold:

house of lithium 02
(2)Handlebar
Attach handlebars to the stem using a the 6mm allen key provided.

Unfold
Rotate the pedal up until the pedal is fully engaged.
Fold
To fold the pedal, push it from the front first, and then rotate it downward.
house of lithium 03
(3)Pedal

house of lithium 04
(4)Battery Removal and Charging
When the charger light turns red, it means the battery is being charged;
When the light turns green, it means the battery is fully charged.
*Two ways to charge:
1. Remove the battery and charge.
Insert the key and rotate until the battery is released, then pull the key out to remove the battery .
2. There is a charging access port behind the back of the bicycle's frame hinge. You can charge
directly through this charging port without having to remove the battery.
(5) Pedal Assit Switch
When set the level "1" ~ "5", press the red button to turn pedel assit on / off.

1.This function can only be adjusted while pedaling.
2. Depress this lever to shift to a higher gear.
3.Depress this lever to shift to a lower gear.
house of lithium 05
(6) Transmission System

house of lithium 06
(I)Display Interface
Part 2 Display Instruction

1.Miles traveled 2. Total miles traveled 3. Maximum speed
4.Average speed 5.Total traveled time
(1) Press the “i” buton to display different information.
house of lithium 07

(2) Driving Mode Switching
3.Sport Mode
Activates at a high speeds
providing high acceleration
(Higher energy consumption).
2.Normal Mode
Activates at a normal speeds
providing normal
acceleration (Normal energy
consumption).
1. Eco Mode
Activates at a slow speeds
providing low acceleration
(Low energy consumption).
house of lithium 08

1.Walk-assistance function may only be used when you
walking the ebike
2.To activate the walk-assistance function, press the
“-” button for 2 s.
3.The walk-assistance function will be switched off as
soon as you release the button.
1.Press "+" or "-" button to switch the ebike system assistance level to
change the motor output power.
2.The default assistance level ranges from level“0”to level“5”.
3.The output power is zero on Level “0”. Level “1” is the minimum power.
Level “5” is the maximum power.
4.The default value is level “0”.
house of lithium 09
(3) Switching Walk-Assistance Mode On-Off
(4) Assistance Level Selection

house of lithium 10
T he f ollo w ing f unc t io ns mu s t r e s t a r t t h e dis pla y
a f t er s et t ing t he ins t r u men t t o ma k e ef f ec t .
II INTRODUCTION OF COMMON FUNCTIONS
(1) Setting Access
1. press both the “+” button and the “-” button for 2s to access general
settings menu.
2. All the Settings are operated in this page.

In case of the rider
change the settings and
then don`t remember
the default settings,
here are two images
for reference.
1.This setting means power-on password setting when you turn on the
display.
2 . After accessing the password settings, press the“+”or the“-”button to
adjust the number and then press the“i”button to confirm digit one by one
until the correct 4-digit password is completed.
(3) Password Setting
house of lithium 11
(2) Default Settings
the energy consumption of the motor.

1. Cruise Control is to ride your bike at a
constant speed.
2. Press the“i” button to access the CRU
setting.
3. Press the“+”or“-”button to turn “off” into
“on” to activate the Cruise Control.
4. Press the throttle at a constant speed
you want for 5s. The bike will then
maintain this speed
5.
1. Turn on the power set, adjust to 0- 3.
2. And then turn the SHD function to 50 to start the energy recovery function.
3. When the speed reaches 15MPH going downhill, adjust the pas level to 0,
the kinetic energy can be automatically recovered, this will also happen during
braking.
house of lithium 12
(5) Kinetic Energy Recovery
(4) Cruise Control

house of lithium 13
Part 3 Common Problems
and Solutions
The battery cannot be charged, the display shows anabnormal battery
power.
Use a multimeter to check if the battery still has voltage.
Check if the charger indicator is normal. (Red light means charging,
green light means fully charged)
The battery case is damaged, stop using the battery and contact us.
The brakes make abnormal noise.
Adjust the brake pads or brake discs.
The rear wheel motor makes abnormal noise.
Lift the rear wheel off the ground and press the throttle to see if the
rear wheel runs. Then contact us with a video for further solutions.
The derailleur is pressed or the chain falls.
Try to strengthen or adjust the derailleur.
The ebike comes without keys.
The keys are hung on the wires in front of handle bar. Check the
wires in front of the handlebar and see if it falls into the box.

house of lithium 14
When an error code appears on the display.
Error Code Definition
21 Current Abnormality
22 Throttle Abnormality
23 Motor Abnormality
24 Motor Hall Signal Abnormality
25 Brake Abnormality
30 Communication Abnormality
lError code 21 and 30 indicates controller problem.
lError code 25 indicates brake problem. Do following steps to
confirm which brake is defective:
lUnplug both brake wires to see if there is any error code shows on
the display.
lOnly unplug the front brake wire to see if an error code shows on the
display.
lOnly unplug the rear brake wire to see if an error code shows on the
display.
It appears that oil is leaking from the front fork.

house of lithium 15
This is a normal phenomenon that occurs after abicycle has been
used for a period.
Can people sit on the rack?
The maximum load of the rack is 25kg. It isprohibited to sit on.
Water leaks into the display.
Do not ride in heavy rain. Add protection to the display if you must
ride in rainy conditions. Warranty will not cover the display problems
caused by water damage.
Why the ebike comes with flat tire?
The tires will not be filled with air. Ride the bike after inflating the
tires. (The pumping range is 17-18 psi)
Can I refit the bike?
The bike can be disassembled and refitted. But our warranty will not
cover any bike problems after the refit.
Can I do some upgrades on the bike?
We provide upgrade service for some accessories. Contact HOL
for more details.
I need to return the bike, what should I do?
We only accept returns with original package. Any returns without
original package will not be accepted.

Part 4 Use and Maintenance
house of lithium 16
ØBattery Maintenance
üFully charge the battery for the first use.
üDo not use the battery in low power level.
üMust use the specified charger for charging.
üDo not charge the battery at high temperature (over 212
Fahrenheit/100°C). Charge in a ventilated area.
üIf the battery is not in use for a long time, charge the battery at least
once a month to keep the battery active.
üKeep the battery away from water or any other liquid.
üTurn off the battery when it is not in use.
üFully charge the battery before each use. It will extend the battery
life.
üIf there are problems with the battery, do not charge it anymore and
contact us for further solutions.
ØFrame Maintenance
üFrame maintenance is important. Wipe the bike dry if you’ve gotten
it wet during a ride.
ØBrake Maintenance
üCheck brake pads regularly.
üCheck the brake disc regularly to prevent deform.

house of lithium 17
üIf it is a hydraulic brake, check regularly to see if there is any oil
leakage.
üClean the brake regularly.
ØMotor Maintenance
üDo not try to disassemble the motor.
üIf there are any problems with the motor, contact HOL with a
video.
ØTire Maintenance
üCheck regularly to prevent air leak.
üCheck spokes regularly.
ØDerailleur Maintenance
üCheck the rear derailleur regularly to see if it changed to every gear
(contact us for the video about how to adjust the shifter).
üCheck the rear derailleur guard to see whether it has bent to affect
the derailleur or not.
ØRiding on Rainy Days
üThe ebike should not be used in rainy days.
