Appendix C
Retrieving Data Remotely from the SpeedLane
There are two ways to access the SpeedLane Pro data remotely:
1. Call directly in to the radar via the Stats Analyzer software
2. Setup the SpeedLane Pro to call out to our TetryonTM cloud server and access the
data on the server via a browser from any computer connected to the Internet
Both options can be used with either your own external modem or the optional built-in
3G GSM modem.
1. Call in to the SpeedLane from your Windows computer
When using external modem, you need to forward incoming network connections to
allow the remote computer to connect into the SpeedLane. You also require a static IP
address in the modem so you can connect to it directly.
If the SpeedLane is connected via Ethernet to the router/modem:
1.1. Assign an unused private static IP address to the SpeedLane via the SpeedLane
Setup->Ethernet tab.
1.2. On the external modem, select any available external port number you wish to
use (e.g. 5000). In the external modem configuration forward all TCP/IP traffic
for this external port number to the SpeedLane IP address at port 23.
1.3. If you wish to use the video streaming feature, you also need to forward all
TCP/IP traffic for external port 8080 to the SpeedLane IP address at port 8080.
If the SpeedLane is connected via serial port to the external modem:
1.4. On the external modem, select any available external port number you wish to
use (e.g. 5000). In the external modem configuration forward all TCP/IP traffic
for this external port number to the local serial port on the external modem
connected to the SpeedLane.
1.5. Ensure you do not have any “terminal editing” settings enabled on this serial port
and you are using it in “raw” mode without any character translation.
1.6. Setup the modem serial port with the following parameters: 115200 baud, 8bits,
1 stop, no parity and no handshaking. The DB9 port on the radar cable is wired
as a DCD so it will require a null modem/crossover to connect to your modem.
enaLdeepSottenrehtE
enaLdeepSotlaireS
What options are installed
in the SpeedLane?
Check the label on the
back.
