9
OPERATING PRINCIPALS
The Cruze uses a sensor that drives the motor that is located within the
wheel. Before riding, the user must select Standard Mode or
Acceleration Mode by pressing the Mode Button on the right side of
the skateboard as shown in FEATURES/PARTS. Next, the Cruze must first
be set in motion manually, then activate the motor by covering the
foot pad sensor with your back foot. Once the motor has been
activated, the user will be able to ride using the selected mode.
Model: HY-HSK
Net Weight: 8.38 lbs (3.8 kg)
Max Supported Weight: 198 lbs (90 kg)
Max Speed: Up to 11.18 mph (17.99 km/h)
Max Distance Range: Up to 5 miles (8 km)
Minimum Turning Radius: 0°
Battery Type: Lithium-ion
Motor Power: 150W Brushless Motor
Battery Voltage: 25.55 V
Battery Capacity: 2.15 Ah
Power Requirement: AC 100-240V, 50-60 Hz
Product Dimension: 27.56 in. x 8.66 in. x 4.53 in.
Product Weight: 8.38 lbs
Profile: High
Board Size: 27.6 in. x 8.07 in.
Axle: 8.27 in
Wheel Size: 2.5 in (70mm)
PLEASE READ THE FOLLOWING INSTRUCTIONS CAREFULLY
TURNING YOUR DEVICE ON/OFF
Power ON: Take your device out of the box and place it flat on the
floor. Press the power switch (located on the right of your device)
once. Check the LED indicator (located in the center of your device).
The battery indicator light should be lit, indicating the device is
powered on.
Power OFF: Press the power switch once in the OFF position.
SENSOR
There is one foot pad sensor on the rear of your skateboard, indicated
by the dot pattern. Once the Cruze is manually set in motion, cruise
control is activated when the user steps and holds their foot on the
sensor.
BATTERY INDICATOR
The display board is located in the middle of the Cruze.
The green LED light indicates battery levels of 20%, 50%, 75%, and
100% respectively. Please refer to the diagram below. When the
battery level is low, the LED light will flash, indicating the device should
be charged.
The Cruze is a personal transporter. Our technology and production
processes are developed with strict testing for each Cruze. Operating
the Cruze without following the contents of this manual may lead to
damage to your Cruze, or bodily injury.
This manual is designed to give you the information you need for the
safe operation and maintenance of your new Cruze. Please read it
thoroughly before riding your Cruze.
PACKAGE CONTENTS
• Hover-1 Cruze Electric Skateboard
• Charging Cable
• Operation Manual
FEATURES/PARTS
1. Foot Pad Sensor 5. Mode Button
2. Handle 6. Mode Indicator
3. Brushless Motor 7. Power Button
4. Battery Indicator 8. Wheel Truck
9. Charging Port
PLEASE READ THE USER MANUAL THOROUGHLY.
Failure to follow the basic instructions and safety precautions listed in
the user manual can lead to damage to your device, other property
damage, serious bodily injury, and even death.
Thank you for purchasing the Hover-1 Cruze Power-Assisted
Skateboard. Please read all instructions carefully before using and
retain this manual for future use and reference.
This manual applies to the Hover-1 Cruze.
• In order to avoid dangers that are caused by collisions, falls, and loss
of control, please learn how to ride the Cruze safely.
• You can learn operating skills by reading the product manual and
watching videos.
• This manual includes all operating instructions and precautions, and
users must read it carefully and follow the instructions.
• All users are responsible for any consequences caused by violating
warning contents or prompt operations. Hover-1 can not be held
liable.
ATTENTION
1. Use only the supplied charger with this skateboard.
Charger Manufacturer: Jin Xin Yu Power (Shenzhen) Supply Co., Ltd.
Model: XVE-2940100
2. The operating temperature range of the charger is -4° F-122° F
(-20-50° C).
3. The operating temperature range of the Cruze is 32-104° F (0-40° C).
4. Do not ride on icy or slippery surfaces.
5. Read the user manual and warning labels before riding.
6. Store the Cruze in a dry, ventilated environment.
7. When transporting the Cruze, avoid violent crashes or impact.
• Do not operate, or allow others to operate the Cruze, until the user
understands all instructions, warnings and safety features described in
this manual.
• Check with your doctor if you have a medical condition that could
affect your ability to use the Cruze.
• Persons with head, back or neck ailments or prior surgeries to
those areas of the body are not recommended to use this Cruze.
• Persons with any mental or physical conditions that may make
them susceptible to injury or impair their physical or mental
capabilities to recognize, understand and perform all of the
safety instructions and to be able to assume the hazards inherent
in unit use, should not use the Hover-1 Cruze.
In this manual, the above symbol with the word “NOTES” indicates
instructions or relevant facts the user should remember prior to using
the device.
In this manual, the above symbol with the word “CAUTION” indicates
a hazardous situation which, if not avoided, can cause minor or
moderate injury.
In this manual, the above symbol with the word “WARNING”
indicates a hazardous situation which, if not avoided, can cause
death or serious injury.
Please keep the serial number on file for warranty claims as well as
proof of purchase.
best enjoy your experience.
The first rule in safe riding is to use common sense.
Different localities and countries have different laws governing riding
on public roads, and you should check with local officials to ensure
you are complying with these laws.
Hover-1 is not liable for tickets or violations given to riders who do not
follow local laws and regulations.
• For your safety, always wear a helmet that meets CPSC or CE safety
standards. In the event of an accident, a helmet can protect you
from serious injury and in some cases, even death.
• Obey all local traffic laws. Obey red and green lights, one-way
streets, stop signs, pedestrian crosswalks, etc.
• Ride with traffic, not against it.
• Ride defensively; expect the unexpected.
• Give pedestrians the right-of-way.
• Do not ride too close to pedestrians and alert them if you intend to
pass them from behind.
• Slow down at all street intersections and look to the left and right
before crossing.
Your Cruze is not equipped with reflectors. It is not recommended that
you ride in conditions of low visibility.
SAFETY PRECAUTIONS
LOW TEMPERATURE WARNING
Low temperature will affect the lubrication of moving parts inside
the Cruze, increasing internal resistance. At the same time, in low
temperatures, the discharge capacity and the capacity itself of
the battery will be significantly decreased.
Use caution when riding the Cruze in cold temperatures (below 40
degrees F).
Doing so may increase the risk of mechanical failures of the
skateboard, which may lead to damage to your device, other
property damage, serious bodily injury and even death.
SAFETY INSTRUCTIONS
• Keep the device away from heat sources, direct sunlight,
humidity, water and any other liquids.
• Do not operate the device if it has been exposed to water,
moisture or any other liquids to prevent against electric shock,
explosion and/or injury to yourself and damage to the device.
• Do not use the device if it has been dropped or damaged in
any way.
• Repairs to electrical equipment should only be performed by
the manufacturer. Improper repairs voids the warranty and may
place the user at serious risk.
• Do not puncture or harm the exterior surface of the product in
any way.
• Keep the device free from dust, lint, etc.
• Do not use this device for anything other than its intended use or
purpose. Doing so may damage the device or lead to property
damage, injury or death.
• This product is not a toy. Keep out of reach of children.
• Do not expose batteries, battery pack, or batteries installed to
excessive heat, such as direct sunlight, or open flame.
• Do not allow hands, feet, hair, body parts, clothing or similar
articles to come in contact with moving parts, trucks, wheels or
drivetrain, while the engine is running.
WARNING
When you ride in low-visibility conditions
such as fog, dusk, or night, you might be
diicult to see, which could lead to a
collision. To increase your level of safety,
be sure wear bright, reective clothing
when riding in poor lighting conditions.
