Hover-1 FALCON-1 User manual

ELECTRIC SCOOTER ACCESSORY
FA LCO N
-
1

For warranty information, Please visit us at:
www.hover-1.com
WARRANTY
Please visit
www.hover-1.com/troubleshoot
to request missing
or defective parts
20

Operation Manual H1-F1-BGY Falcon-1
*Images used in this manual may vary slightly from
the product and are for reference purposes only.
IMPORTANT: KEEP FOR FUTURE REFERENCE
Even if you have ridden a scooter for years, it is important for you
and every rider to read this manual before using this product.
ELECTRIC SCOOTER ACCESSORY
FALCON
-
1
1

HELMETS SAVE LIVES!
Always wear a properly fitted helmet that complies with CPSC or CE safety standards when you
ride your scooter.
WARNING
Correct Fitting:
Make sure your helmet
covers your forehead.
Incorrect Fitting:
Forehead is exposed and
vulnerable to serious injury.
2

This manual is designed to give you the information you need for the safe operation and maintenance of
your new Hover-1 Falcon-1. Please read it thoroughly before riding your Hover-1 Falcon-1.
• Section One of this manual involves safety and Hover-1 Falcon-1 care. Understanding and following this
Information will help you and your Hover-1 Falcon-1 avoid injury or damage.
• Section Two of this manual gives assembly and installation instructions for your Hover-1 Falcon-1.
• Section Three of this manual covers specific safety and operating instructions for your Hover-1 Falcon-1.
Even if you are an experienced rider, you should review this section before your first ride.
• Section Four of this manual covers warranty specifications of your Hover-1 Falcon-1.
INTRODUCTION
WARNING
Make sure you read this complete manual before riding
your Hover-1 Falcon-1. Failure to do so, or failure to follow
its guidelines could lead to serious injury or death.
3

HOVER-1 FALCON-1 DIAGRAM
SPECIFICATIONS
1. Bucket Seat
2. Fog Blaster & Mount
3. Handle Bar (R)
4. Pedal Mounts
5. Hook and Loop Strap
6. Handle Bar (L)
7. Frame Base
8. Twist Knob
9. Frame Extension
10. Foot Rests
11. Caster Wheel
Compatibility: Most 6.5” scooters
Max Load: See max load of your scooter
Tire Size: 4” swivel caster
Seat Material: PP
1
5
4
7
6
3
8
9
10
11
2
Please visit
www.hover-1.com/troubleshoot
to request missing
or defective parts
4

PARTS LIST
(1) Bucket Seat
(1) Frame Base
(1) Frame Extension
(1) Fog Blaster Mount
(1) Left Handle Bar
(1) Right Handle Bar
Please visit www.hover-1.com/troubleshoot to request missing
or defective parts
(1) Fog Blaster
(1) Charge Cable
(1) Twist Knob
Tool Set:
(4) M8 Long Screw
(4) Short Screw
(4) M8 Short Screw
(8) Anti-Slip M8 Nuts
ABCLarge Wrench Flathead
Screwdriver
Large Hex Key
A
B
C
1 Set Hook & Loop Straps
with Rubber Protectors
Preassembled
1 Set Spare Hook &
Loop Straps
5

ASSEMBLING YOUR HOVER-1 FALCON-1
If you have any questions or concerns about any of these steps, please feel free to contact our Customer
Service Team at www.hover-1.com. A representative will be in touch to walk you through these steps.
Carefully follow the steps shown in the following pages for assembling the Hover-1 Falcon-1.
Remove all Hover-1 Falcon-1 contents from the box. Ensure all contents from the “Parts List” section are
accounted for.
1. Locate the Frame Base as shown below. This is the main section to which other components including your
hoverboard will be mounted.
Please visit
www.hover-1.com/troubleshoot
to request missing
or defective parts
6

Please visit
www.hover-1.com/troubleshoot
to request missing
or defective parts
3. Insert the Frame Extension into the Frame Base. Adjust the Frame Extension to your desired length. Secure in place
using the Twist Knob as shown below.
2. Locate the included Large Hex Key and M8 Long Screws then attach the Left and Right Handle Bars to the
Frame Base. Locate 4 of the Anti-Slip M8 Nuts and the Large Wrench. Tightly fasten the nuts onto the M8 Long
Screws as shown below.
x 2 x 2
AB
Tools
needed
7

2. Attach the Fog Blaster to the Fog Blaster Mount and secure in place using the athead screwdriver and the
included Short Screws as shown below.
3. Align the holes of the Fog Blaster Mount to the holes of the Frame Base as shown below.
Please visit
www.hover-1.com/troubleshoot
to request missing
or defective parts
X 4
Tools
needed
C
8

4. Align the holes of the Bucket Seat with the holes of the Frame Base and Fog Blaster Mount. Use the Large Hex
Key to fasten four of the M8 Short Screws. Secure the Bucket Seat to the frame using the 2 wrenches with four
Anti-Slip M8 nuts and four nuts as shown below.
5. Your Hover-1 Falcon-1 is now assembled!
Please visit
www.hover-1.com/troubleshoot
to request missing
or defective parts
x 4 x 4
B
Tools
needed
A
9

FOG BLASTER DIAGRAM
USING & MAINTAINING YOUR FOG BLASTER
1. Charging Port
2. Water Tank Fill Port
3. Power Button
4. LED & Sound Effects Button
5. Fog Vent & LED Lights
2
5
3
4
1
Before using the Fog Blaster, charge it by connecting the included Charge Cable to the Charging Port and
a USB outlet (fig 1.). The red light will be on while charging. When the light turns off, your Fog Blaster is fully
charged. Charge for up to 3 hours. Remove the USB plug from its outlet. Next, push and hold down the Water
Tank buttons while pouring water into the fill port (fig 2.). Release when filled. Do not overfill!
Hold down to open
the tank while pouring
water into the fill port
Please visit
www.hover-1.com/troubleshoot
to request missing
or defective parts
(fig. 1) (fig. 2)
13

If you have questions or concerns about any of these steps, please feel free to contact our Customer Service
Team at www.hover-1.com. A representative will be in touch to walk you through these steps.
Carefully follow the steps shown on the following pages for installing the Hover-1 Falcon-1 onto your electric
scooter. Read this entire manual before riding your Hover-1 Falcon-1.
Your Hover-1 Falcon-1 must be completely assembled before installing it onto your electric scooter. Please
refer to the “Assembling your Hover-1 Falcon-1” section for assembling procedures.
1. Place the pedal mounts onto the footpad sensors of your self-balancing scooter with the front wheel
facing forward. Ensure the pedal mounts are centered on the footpad sensors of your scooter as much
as possible.
INSTALLING YOUR HOVER-1 FALCON-1
Please visit www.hover-1.com/troubleshoot to request missing
or defective parts
SPACE EVENLY
10

Please visit
www.hover-1.com/troubleshoot
to request missing
or defective parts
RUBBER PROTECTORS HOOK & LOOP STRAP
ASSEMBLY DIRECTIONS
LOCATION OF RUBBER
PROTECTORS
2. Using two Hook and Loop straps, attach one end of each Hook and Loop strap to the holes on the front of
each pedal mount as shown below.
3. Wrap both hook and loop straps under your self-balancing scooter and attach the ends to the hooks on
the back of each pedal mount. The rubber protective straps should be centered underneath the
hoverboard, with side B facing the ground. One set of rubber protective straps should come pre-assembled
with the hook and loop straps.
A
B
11

Please visit
www.hover-1.com/troubleshoot
to request missing
or defective parts
4. WARNING: Do not over tighten straps when you are assembling your Falcon-1 to your scooter. Ensure that
the Falcon-1 is securely attached to the scooter. See below diagram for correct fitting.
5. When fully installed, your Hover-1 Falcon-1 should look like the diagram below.
12

HOVER-1 FALCON-1 OPERATION
It is important that you fully understand all elements of your Hover-1 Falcon-1. If these elements are not used
correctly, you will not have full control of your Hover-1 Falcon-1. Before you ride fast, or outside of a controlled
environment, learn the functions of the various mechanisms on your Hover-1 Falcon-1.
Practice using the elements of your Hover-1 Falcon-1 at slower speeds in a flat, open area before taking the
Hover-1 Falcon-1 to unfamiliar areas.
BEFORE RIDING
WARNING
Any scooter that does not work properly can cause you
to lose control and fall. Inspect the entire device
thoroughly before every ride, and do not ride it until any
problems have been corrected.
WARNING
Do not ride a Hover-1 Falcon-1 with a part that is
damaged; replace the damaged part before riding.
14

Ensure that your Hover-1 Falcon-1 and scooter are in proper working order each and every time you ride. If
a part of the Hover-1 Falcon-1 does not function correctly, please contact our Customer Support Center.
• Ensure the battery of your scooter is fully charged before riding your Hover-1 Falcon-1.
• Ensure that the screws and nuts on the Hover-1 Falcon-1 are tightly secured before each ride.
• Check to ensure the tires of your scooter are not worn.
• Check to ensure all connections are maintained on your scooter.
• Make sure your hoverboard is calibrated and running properly.
PRE-RIDE HOVER-1 FALCON-1 CHECKLIST
15

SAFETY PRECAUTIONS
The first rule in safe riding is to use common sense. A Hover-1 Falcon-1 is vulnerable; it cannot protect you in
a crash, against impact, or loss of control the way driving a car can. A Hover-1 Falcon-1 can tip over
sideways or pitch you over the front wheel. It moves faster than a typical scooter. It does not have bumpers
or airbags as a car does. This section is a guide of safe riding practices for operation. Make sure you are using
your Hover-1 Falcon-1 properly.
Different localities and countries have different laws governing riding on public roads, and you should check
with local officials to ensure you are complying with these laws.
Hover-1 is not liable for tickets or violations given to riders who do not follow these regulations.
• For your safety, always wear a helmet that meets CPSC or CE safety standards. In the event of an accident,
a helmet can protect you from serious injury and in some cases, even death.
• Obey all local laws, stop signs, pedestrian crosswalks, etc.
• If riding with friends and multiple Hover-1 Falcon-1’s, ride single file in a straight line.
• Have a satisfactory signaling device (bell, horn, etc.) to warn drivers and pedestrians of your approach.
• Ride defensively; expect the unexpected.
• Give pedestrians the right-of-way.
• Do not ride too close to pedestrians and alert them if you intend to pass them from behind.
• Slow down at all street intersections and look to the left and right before crossing.
•Obey all traffic signals.
• Always use proper hand signals for turning and stopping. Give signals 100ft before stopping or turning and
always return both hands to the handle bars before stopping or turning.
• Watch for cars pulling out into traffic and for the sudden opening of car doors.
• Avoid potholes, drainage grates or other hazards.
• Be careful when riding on soft road edges, gravel, sand and uneven surfaces. Ride slowly and avoid quick
turns when riding on these surfaces.
• Never hitch onto other vehicles.
• Do not “stunt” ride or race in traffic.
• Do not weave in and out of traffic or swerve from side to side.
• A crash can put extraordinary stress on Hover-1 Falcon-1 components, possibly causing them to
fatigue prematurely. Components suffering from stress fatigue can fail suddenly, causing loss of control
or serious injury.
CAUTION: RIDING IN WET WEATHER
It is recommended that you do not ride your Hover-1 Falcon-1 in wet weather as there are electronic
components of scooter that may be damaged if exposed to water and stopping distances can be greater
than in dry conditions.
1. This product is strictly forbidden to use on roads and highways unless your local laws state otherwise. You
must wear a safety helmet, knee and elbow pads and other necessary protective gear when riding your
Hover-1 Falcon-1.
2. Due to the particularity of the product, the assembly pieces are to be checked before every ride to avoid
an accident while riding.
3. Do not make a sharp turns as you may drift and overturn the Hover-1 Falcon-1 which can result in injury to
yourself and/or damage the unit.
4. Do not operate near swimming pools or other bodies of water.
16

The first rule in safe riding is to use common sense. A Hover-1 Falcon-1 is vulnerable; it cannot protect you in
a crash, against impact, or loss of control the way driving a car can. A Hover-1 Falcon-1 can tip over
sideways or pitch you over the front wheel. It moves faster than a typical scooter. It does not have bumpers
or airbags as a car does. This section is a guide of safe riding practices for operation. Make sure you are using
your Hover-1 Falcon-1 properly.
Different localities and countries have different laws governing riding on public roads, and you should check
with local officials to ensure you are complying with these laws.
Hover-1 is not liable for tickets or violations given to riders who do not follow these regulations.
• For your safety, always wear a helmet that meets CPSC or CE safety standards. In the event of an accident,
a helmet can protect you from serious injury and in some cases, even death.
• Obey all local laws, stop signs, pedestrian crosswalks, etc.
• If riding with friends and multiple Hover-1 Falcon-1’s, ride single file in a straight line.
• Have a satisfactory signaling device (bell, horn, etc.) to warn drivers and pedestrians of your approach.
• Ride defensively; expect the unexpected.
• Give pedestrians the right-of-way.
• Do not ride too close to pedestrians and alert them if you intend to pass them from behind.
• Slow down at all street intersections and look to the left and right before crossing.
•Obey all traffic signals.
• Always use proper hand signals for turning and stopping. Give signals 100ft before stopping or turning and
always return both hands to the handle bars before stopping or turning.
• Watch for cars pulling out into traffic and for the sudden opening of car doors.
• Avoid potholes, drainage grates or other hazards.
• Be careful when riding on soft road edges, gravel, sand and uneven surfaces. Ride slowly and avoid quick
turns when riding on these surfaces.
• Never hitch onto other vehicles.
• Do not “stunt” ride or race in traffic.
• Do not weave in and out of traffic or swerve from side to side.
• A crash can put extraordinary stress on Hover-1 Falcon-1 components, possibly causing them to
fatigue prematurely. Components suffering from stress fatigue can fail suddenly, causing loss of control
or serious injury.
CAUTION: RIDING IN WET WEATHER
It is recommended that you do not ride your Hover-1 Falcon-1 in wet weather as there are electronic
components of scooter that may be damaged if exposed to water and stopping distances can be greater
than in dry conditions.
1. This product is strictly forbidden to use on roads and highways unless your local laws state otherwise. You
must wear a safety helmet, knee and elbow pads and other necessary protective gear when riding your
Hover-1 Falcon-1.
2. Due to the particularity of the product, the assembly pieces are to be checked before every ride to avoid
an accident while riding.
3. Do not make a sharp turns as you may drift and overturn the Hover-1 Falcon-1 which can result in injury to
yourself and/or damage the unit.
4. Do not operate near swimming pools or other bodies of water.
17
