Hover-1 Beast Buggy User manual

1
BEAST
BUGGY
HOVERBOARD ATTACHMENT
OPERATION MANUAL
HY-BST-BGY

HELMETS SAVE LIVES!
Always wear a properly tted helmet that complies with CPSC or CE safety standards
when you ride.
WARNING
2
Correct Fit:
Make sure your helmet
covers your forehead.
Incorrect Fit:
Forehead is exposed and
vulnerable to serious injury.

This manual provides you the information you need for the safe operation and maintenance of your Hover-1
Beast Buggy. Please read it thoroughly before riding your Hover-1 Beast Buggy.
INTRODUCTION
3
WARNING
Make sure you read this complete manual before riding
your Hover-1 Beast Buggy. Even if you are an
experienced rider, it is important that you read this
manual to ensure your safety. Failure to read the manual
or follow its guidelines could lead to serious injury or
death.
Please visit
www.hover-1.com/troubleshoot
to request replacements for
missing or defective parts

HOVER-1 BEAST BUGGY DIAGRAM
SPECIFICATIONS
1. Seat
2. Handle Bars
3. Shock Absorbing Coils
4. Pedal Mounts
5. Elastic Strap
6. Seat Frame
7. Locker
8. Frame Extension
9. Foot Rests
10. Front Wheel
Compatibility: Most hoverboards with 10” wheels
Max Supported Weight: Refer to your hoverboard’s manual
Wheel Size: 8” swivel caster
Seat Material: Polypropylene
4
1
2
4
3
5
6
7
8
10
2
5
9

PARTS LIST
5
(1) Seat
(1) Seat Frame
(1) Frame Extension
(1) Right Handlebar
(1) Wheel
(1) Left Handlebar
(2) Hook and Loop Straps (2) Spare Hook and
Loop Straps
(1) Wrench
Hex Keys:
(1) M8
(1) M6
(2) Lockers
(2) M8 X 38 Screws
(4) M8 X 40 Screws
(4) M6 X16 Screws
(4) 6 mm Nuts
(6) 8 mm Nuts
(4) 20 mm Washers

ASSEMBLING YOUR HOVER-1 BEAST BUGGY
1. Remove all of the Hover-1 Beast Buggy contents from the box. Ensure all the contents from the “PARTS LIST”
section are accounted for.
2. Insert the left and right handlebar mounts into the seat frame as shown below. Align the holes of the handlebar
mounts with the holes in the seat frame. Insert the M8 X 38 screws into the seat frame holes and attach the 8 mm
nuts to the end of the screws by twisting them on clockwise. Once the nuts are attached, hold the 8 mm nuts in
place with the wrench and turn the screws clockwise with the smaller hex key to tighten the screws. Make sure
both screws are tightly secured.
6

3. Insert the frame extension into the seat frame. The foot rests should be pointing down. Adjust the front frame to
your preferred length. Remove the black cap and the rst white washer from the end of each locker. Fully insert
the screwed section of one locker into the seat frame holes. Add the white washer and black cap back onto the
locker once it is fully inserted and twist the cap on clockwise until its is tightly secured. Close the locker clamp
tightly. Repeat these steps on the other side of the seat frame with the other locker.
7

4. Align the holes of the seat with the holes of the
seat frame as show below. Insert the M6 X16 screws.
Attach the 20 mm washers and the 6 mm nuts to
the bottom of each screw, under the seat frame.
Twist the nuts on clockwise. Hold the 6 mm nuts still
with the wrench while turning the screws clockwise
with the larger hex key to tighten the screws. Make
sure all 4 screws are tightly secured.
5. Align the holes of the wheel plate with the
holes in the frame extension. Insert the M8 X 40
screws into each hole and attach the 6 mm lug
nuts to each screw. Hold the 6 mm nuts still with
the wrench while turning the screws clockwise
with the larger hex key to tighten the screws.
Make sure all 4 screws are tightly secured.
8

9
6. Your Hover-1 Beast Buggy is now assembled and should look like the below image.

Your Hover-1 Beast Buggy should be completely assembled prior to attaching it to your hoverboard. Please
refer to the “ASSEMBLING YOUR HOVER-1 BEAST BUGGY” section for assembling procedures.
1. Place the handlebar mounts onto the foot pads of your hoverboard. Ensure the mounts are centered on
the foot pads of your hoverboard as much as possible.
ATTACHING YOUR BEAST BUGGY TO YOUR HOVERBOARD
10
