Howdens RKLENBUOH User manual

Important Notes:
Ensure packaging is disposed of in a safe
environmentally friendly way
Please ensure there is sufficient clearance for the drawer to open once flooring has been installed
Built Under Oven Housing
Assembly
1
RKLENBUOH
Fit legs to the inner sides of the cabinet.
2
Fit runners to the inner sides of the cabinet.
Fit cabinet into place and adjust legs as required
Note: These screws are
packed in the cabinet fittings bag
Note: These screws are
packed in the cabinet fittings bag
Leg x4
Runner x2 (LH&RH)
66mm
37mm
224mm
69mm
256mm
Screw x8
30mm csk
Screw x8
4 x 16mm csk
10mm
26mm
HD020160v3
Screw x16
13mm csk
458mm
426mm
97mm
65mm

Assembly
3
Bottom Edge
597mm
435mm
Lower Fascia
Fascia Locking
Clip x2
4
Unlock and remove the brackets from the drawer.
Cut plinth section to length. Fit brackets to lower fascia (plinth) section.
Fit clips to upper BUOH fascia (115mm).
5
Fit the fascias to the drawer box, locking into position.
Lower Fascia
Lock into place
Fully extend runners, then fit the drawer onto the runners.
Push the drawer back into the cabinet.
6
Bottom Edge
416mm
= =
Scribe the bottom edge of the plinth front
when fully extended if required.
Screw x4
3.5 x 12mm csk
Screw x4
3.5 x 16mm csk
Upper Fascia
Lock into place
