QuickSpecs
HPE Ethernet 10Gb 2-port 570M Adapter
Overview
Page 1
HPE Ethernet 10Gb 2-port 570M Adapter
The HPE 570FLR-SFP dual-port 10Gb Ethernet SFP+ Onload server adapter is based on the Solarflare next generation 10GbE
controller, Solarflare™ SFC9120, and delivers unmatched message rates with low latency and jitter over standard Ethernet along with
the lowest CPU utilization and power consumption, enabling the industry's best performance and scalability for financial serv
ices and
other enterprise data centers.The HPE 570M supports high performance networking features such as VLAN tagging, low latency
interrupts, TCP and UDP checksum offloading, MSI-X, NIC teaming (bonding), Receive Side Scaling (RSS), jumbo frames, and PXE
boot.
HPE Ethernet 10Gb 2-port 570M Adapter
Models
HP Ethernet 10Gb 2-port 570M Adapter
718935-B21
NOTE:
The HPE 570M on each server blade connects to a 10Gb interconnect in bays 3-8 (HPE BladeSystem
c7000 Enclosure) or bays 2
-4 (HPE BladeSystem c3000 Enclosure).
NOTE: The HPE 570M adapter requires a minimum of 2 GB of server memory.

QuickSpecs
HPE Ethernet 10Gb 2-
port 570M Adapter
Overview
Page 2
Kit contents
•HPE Ethernet 10Gb 2-port 570M Adapter
•Quick install card
•Product warranty statement
•Drivers, user guide, and utilities via: http://www.hp.com

QuickSpecs
HPE Ethernet 10Gb 2-
port 570M Adapter
Compatibility
Page
3
HPE ProLiant
Server Support
HPE ProLiant BL460c Gen8
Supported
Interconnect
Modules
•HPE 6120XG Blade Switch
•HPE 6120G/XG Blade Switch
•HPE 6125XLG Ethernet Blade Switch
•HPE 6127XLG Ethernet Blade Switch
•HPE 1:10Gb Ethernet BL-c Switch
•Cisco Catalyst 3120G Blade Switch for HPE
•Cisco Catalyst 3120X Blade Switch for HPE
•Cisco Catalyst 3020 Blade Switch
•Cisco Fabric Extender B22HP for HPE
•HPE GbE2c Layer 2/3 Ethernet Blade Switch
•HPE 1GbE Pass Thru Module
•10GbE Ethernet Pass-Thru Module
•HPE 6125G Ethernet Blade Switch
•HPE 6125G/XG Ethernet Blade Switch
NOTE: 10GbE converged connectivity is supported in all HPE 6120XG, HPE
6125XG series switches, Cisco
B22 Fabric Extender and HPE 10GbE Pass-Thru modules. All other supported interconnects and
switches are limited to 16GbE per connection for Ethernet-only traffic.

QuickSpecs
HPE Ethernet 10Gb 2-
port 570M Adapter
Standard Features
Page
4
Product Features •Supports Open-Onload® high-performance user-level network stack for Linux
•Industry-leading throughput and latency performance
•Up to 40Gb/s bi-directional near line rate throughput
•Hardware acceleration TCP/IP/UDP stateless intelligent offloads
•SR-IOV capable in hardware (requires server FW, SW and OS support)
•PXE, Jumbo Frames, Checksum & Segmentation Offload, IPv6 and RSS
•On board temperature monitor
•Standard server operating system support
•Standard NC series option kit warranty, support, services
•Field replaceable and upgradeable
•Preboot eXecution Environment (PXE) enabled
•Integrated PHY and MAC
Dual-
port 10 Gigabit
Ethernet
Throughput
(theoretical
bandwidth)
The 20 Gbps full duplex Ethernet transfer rate per port (40 Gbps aggregate full duplex) delivers outstanding
network performance that improves response time and removes bottlenecks.
Jumbo Frames The HPE 570M adapter supports jumbo frames (also known as extended frames) with a maximum
transmission unit (MTU) of up to 9.5K bytes when running Ethernet and/or, which is over five times the size
of standard 1500-byte Ethernet frame. Jumbo frames can help achieve higher throughput and better CPU
utilization. Jumbo frames are particularly useful for database transfers.
MSI and MSI-X Message Signaled Interrupt (Extended) provides performance benefits for multi-core servers by load
balancing interrupts between CPUs/cores
Interrupt
Coalescence
Interrupt coalescing (interrupt moderation) groups multiple packets, thereby reducing the number of
interrupts sent to the host. This process optimizes host efficiency, leaving the CPU available for other duties.
802.1p QoS Tagging
IEEE quality of service (QoS) 802.1p tagging allows the adapter to mark or tag frames with a priority level
across a QoS-aware network for improved traffic flow.
802.1Q VLANs The HPE 570M adapter supports the IEEE 802.1Q virtual local area network (VLAN) protocol that allows each
physical port to be assigned to a VLAN for added network segmentation and enhanced security and
performance. VLANs increase security by isolating traffic between users. Limiting the broadcast traffic to
within the same VLAN domain also improves performance.
TCP/IP Stateless
Offloading
For overall improved system response, the HPE 560M adapter supports standard TCP/IP stateless offloading
techniques including:
•TCP/IP checksum offload (TCO) moves the TCP and IP checksum offloading from the CPU to the

QuickSpecs
HPE Ethernet 10Gb 2-
port 570M Adapter
Standard Features
Page 5
network adapter.
•Large send offload (LSO), also known as TCP segmentation offload (TSO), allows TCP segmentation
to be handled by the adapter rather than the CPU.
Optimized for
Virtualization
Intel Virtualization Technology for Connectivity (VT-c) with VMDq and SR-IOV provides I/O Virtualization
support for VMware NetQueue, Microsoft VMQ to help meet the performance demands of consolidated
virtual workloads.
Compliant with Single-Root I/O Virtualization (SR-IOV), accommodating multiple Virtual Machines (VMs) to
share single PCIe resources. The device is capable of SR-IOV, and requires Software and OS support.
IEEE 1588 & 802.1AS
Support hardware-enabled IEEE 1588, a standard that defines PTP (Precision Time Protocol), a high-
precision
time protocol for clock synchronization used in measurement and control systems.
PXE Boot Support
Supports the Preboot eXecution Environment (PXE) allows the server to boot over the network and
download software residing in the network.
Network Adapter
Teaming
The HPE 560M adapter support for NIC teaming helps IT administrators increase network fault tolerance and
improve workload balance. These capabilities optimize availability, improve performance and help reduce
costs.
Management
Support
The HPE 570M adapter can be administered from HPE Systems Insight Manager (SIM). The adapters can be
managed individually or in teams, providing SNMP based statistics for reporting purposes. The 560M adapter
can also be managed by other applications with SNMP support.
HPE Sea of Sensors
3D
Support for HPE's Sea of Sensors which is a collection of 32 sensors that automatically track thermal activity -
heat - across the server. When temperatures get too high, sensors can kick on fans and make other
adjustments to reduce energy usage. What makes it better is the upgrade from all six fans kicking on at one
time to a new system where only one kicks on - the one in proximity of the area that started heating up - thus
reducing the amount of energy used for cooling.
HPE Active Health
System
Supports HPE Active Health System monitors and records changes in the server hardware and configuration
enabling customers to have accurate information that will assist in diagnosing problems and delivering rapid
resolution when server failures occur.
RDMA
The HPE 570M does not support RDMA
iSCSI The HPE 570M does not support iSCSI
Warranty
Hewlett Packard Enterprise branded hardware options qualified for BladeSystem c-Class and p-Class servers

QuickSpecs
HPE Ethernet 10Gb 2-
port 570M Adapter
Standard Features
Page 6
are covered by a global limited warranty and supported by HPE Services and a worldwide network of Hewlett
Packard Enterprise Authorized Channel Partners. The Hewlett Packard Enterprise branded hardware option
diagnostic support and repair is available for one year from date of purchase, or the length of the server they
are attached to, whichever is greater. Support for software and initial setup is available for 90 days from date
of purchase. Additional support may be covered under the warranty or available for an additional fee.
Enhancements to warranty services are available through HPE Care Pack services or customized service
agreements.
Additional information regarding worldwide limited warranty and technical support is available at:
http://h18004.www1.hp.com/products/servers/platforms/warranty/index.html

QuickSpecs
HPE Ethernet 10Gb 2-
port 570M Adapter
Service and Support
Page
7
Service and Support
HPE Technology Services
HPE Technology Services offers you consultants and support experts to solve your most complex
infrastructure problems. We help keep your business running, boost availability and avoid downtime.
Protect your business beyond warranty with HPE Care Pack Services
When you buy HPE Options, it's also a good time to think about what level of service you may need. HPE
Care
Pack services provide total care and support expertise with committed response choices designed to meet
your IT and business need.
HPE Foundation Care services deliver scalable support-packages for Hewlett Packard Enterprise industry-
standard servers and software. You can choose the type and level of service that is most suitable for your
business needs. New to this portfolio is HPE Collaborative Support. If you are running business critical
environments, Hewlett Packard Enterprise offers Proactive Care or Critical Advantage. These services help
you deliver high levels of application availability through proactive service management and advanced
technical response.
Here is the support service recommendation from the Foundation Care and Proactive Care portfolio. For
customized support service solution, Hewlett Packard Enterprise can work with you to tailor a service solution
for your unique support requirements using broader services portfolio of Foundation Care and Proactive Care.
Recommended
Services
Recommended HPE Care Pack Services for optimal satisfaction with your HPE product
3-Year HPE 24x7 4 hour Response, Hardware Support Onsite Service
Provides you with rapid remote support and if required an Hewlett Packard Enterprise authorized
representative who will arrive on site any time and day of the year to begin hardware maintenance service
within 4 hours of the service request being logged.
http://h20195.www2.hp.com/V2/GetPDF.aspx/5982-6547EEE.pdf
OR
3-Year HPE 24x7 4 hour Response, HPE Collaborative Support
Offers customers a single point of contact for server problem diagnosis, hardware problem resolution, and
basic software problem diagnosis, fault isolation, and resolution if available to Hewlett Packard Enterprise. If
the problem is with HPE HW, the representative will arrive on site any time and day of the year to begin
hardware maintenance service within 4 hours of the service request being logged. In case, the issue is with
Hewlett Packard Enterprise or supported third-party software product and cannot be resolved by applying
known fixes, Hewlett Packard Enterprise will contact the third-party vendor and create a problem incident on
your behalf.
HPE ProLiant Server Hardware Installation
Provides for the basic hardware installation of Hewlett Packard Enterprise branded servers, storage devices
and networking options to assist you in bringing your new hardware into operation in a timely and
professional manner.
http://h20195.www2.hp.com/V2/GetPDF.aspx/5981-9356EN.pdf
Related Services
Related HPE Care Pack Services to enhance your HPE product experience

QuickSpecs
HPE Ethernet 10Gb 2-
port 570M Adapter
Service and Support
Page 8
3-Year HPE 24x7 4 hour Response, Proactive Care or Critical Advantage
Helps optimize your systems and delivers high levels of application availability through proactive service
management and advanced technical response. A skilled Technical Manager will own your query or issue end
to end until resolved, delivering a single point of contact for you.
http://h20195.www2.hp.com/V2/GetPDF.aspx/4AA3-2140ENW.pdf
OR
3-Year HPE 6-hour Onsite Call-to-Repair, HPE Collaborative Support
Offers customers a single point of contact for server problem diagnosis, hardware problem resolution to
return the hardware in operating condition within 6 hours of the initial service request to the HPE Global
Solution Center, and basic software problem diagnosis, fault isolation, and resolution if available to Hewlett
Packard Enterprise. In case, the issue is with Hewlett Packard Enterprise or supported third-party software
product and cannot be resolved by applying known fixes, Hewlett Packard Enterprise will contact the third-
party vendor and create a problem incident on your behalf.
HPE Proactive Select Service
Provides a flexible way to purchase Hewlett Packard Enterprise best-in-class consultancy and technical
services. You can buy Proactive Select Service Credits when you purchase your hardware and then use the
credits over the next 12 months.
http://h20195.www2.hp.com/V2/GetPDF.aspx/4AA2-3842ENN.pdf
Insight Remote
Support
Provides 24 X 7 remote monitoring, proactive notifications, and problem resolution. Learn more
http://www.hp.com/go/insightremotesupport
HPE Support Center
Personalized online support portal with access to information, tools and experts to support Hewlett Packard
Enterprise business products. Submit support cases online, chat with Hewlett Packard Enterprise experts,
access support resources or collaborate with peers. Learn more http://www.hp.com/go/hpsc
The HPE Support Center Mobile App* allows you to resolve issues yourself or quickly connect to an agent for
live support. Now, you can get access to personalized IT support anywhere, anytime.
HPE Insight Remote Support and HPE Support Center are available at no additional cost with a Hewlett
Packard Enterprise warranty, HPE Care Pack or Hewlett Packard Enterprise contractual support agreement.
*The HPE Support Center Mobile App is subject to local availability.
Parts and materials Hewlett Packard Enterprise will provide HPE-supported replacement parts and materials necessary to
maintain the covered hardware product in operating condition, including parts and materials for available and
recommended engineering improvements. Supplies and consumable parts will not be provided as part of this
service; standard warranty terms and conditions apply. Parts and components that have exceeded their
maximum supported lifetime and/or the maximum usage limitations as set forth in the manufacturer's
operating manual or the technical product data sheet will not be provided, repaired or replaced as part of this
service.
Warranty / Service
For ProLiant servers and storage systems, this service covers HPE-
branded hardware options qualified for the

QuickSpecs
HPE Ethernet 10Gb 2-
port 570M Adapter
Service and Support
Page 9
Coverage server, purchased at the same time or afterward, internal to the enclosure, as well as external monitors up to
22" and tower UPS products; these items will be covered at the same service level and for the same coverage
period as the server unless the maximum supported lifetime and/or the maximum usage limitation has been
exceeded. Coverage of the UPS battery is not included; standard warranty terms and conditions apply.
The defective media retention service feature option applies only to Disk or eligible SSD/Flas
h Drives replaced
by Hewlett Packard Enterprise due to malfunction. It does not apply to any exchange of Disk or SSD/Flash
Drives that have not failed. SSD/Flash Drives that are specified by Hewlett Packard Enterprise as consumable
parts and/or that have e
xceeded maximum supported lifetime and/or the maximum usage limit as set forth in
the manufacturer's operating manual or the technical data sheet are not eligible for the defective media
retention service feature option.
For more
information
To learn more on services for HPE ESSN Options, please contact your Hewlett Packard Enterprise sales
representative or Hewlett Packard Enterprise Authorized Channel Partner. Or visit:
http://www.hp.com/services/proliant
or
http://www.hp.com/services/bladesystem

QuickSpecs
HPE Ethernet 10Gb 2-
port 570M Adapter
Related Options
Page
10
c
-
Class BladeSystem
Adapters
FlexibleLOM Adapters
HP FlexFabric 10Gb 2
-port 554FLB Adapter 647586-
B21
HP Flex-10 10Gb 2-port 530FLB Adapter
656590-B21
HP Ethernet 10Gb 2
-port 560FLB Adapter 655639-
B21
HP Ethernet 1Gb 2
-port 361FLB Adapter
652500-
B21
Mezzanine Adapters
HP Flex
-10 10Gb 2-port 530M Adapter 631884-
B21
HP Flex
-10 10Gb 2-port 552M Adapter 674764-
B21
HP FlexFabric 10Gb 2-port 554M Adapter
647590-B21
HP Ethernet 1Gb 4
-port 366M Adapter
615729-
B21
c
-
Class BladeSystem
Interconnect
Options
HP 6120XG Blade Switch
516733-B21
HP Cisco B22HP Fabric Extender for BladeSystem c
-Class 641146-
B21
HP GbE2c Ethernet Blade Switc
h for HP c-Class BladeSystem 410917-
B21
HP 1GB Ethernet Pass
-Thru Module for c-Class BladeSystem 406740-
B21
HP 1GB Ethernet Pass-Thru Module for c-Class BladeSystem
406740-B21
HP 6125G Ethernet Blade Switch
658247-
B21
HP 6125G/XG Ethernet Blade Swi
tch 658250-
B21

QuickSpecs
HPE Ethernet 10Gb 2-
port 570M Adapter
Techn
ical Specifications
Page
11
General
Specifications
Network processor
Solarflare (SFC 9120)
Data rate
Two ports, each at 20 Gbps full duplex; 40 Gbps aggregate full duplex theoretical
bandwidth.
Bus type
PCI Express
v3.0 (Gen 3) x8
Form factor
Type A Mezzanine C
ard
IEEE Compliance
802.3, , 802.3x, 802.3ad, 802.3p/802.1q, 802.3ae
Power and
Environmental
Specifications
Operating
Temperature
5°C to 55°C / 41°F to 131°F
Humidity
10% to 90% non-condensing
Power requirement
7.5W maximum
Emissions
classification
FCC Class A
Agency Approvals
USA
FCC (CFR 47 part 15) and UL 60950
Canada
ICES-003 and CSA60950
Japan
VCCI
Korea
MIC (RRL), EMC Registration
Australia
ACA, AS/NZS3548/EN55022:1998, EN55024:1998
European Union
EN55022:1998 (CISPR 22), EN55024:1998, and
IEC60950:1999 (EN60950:2000)
RoHS Compliance
6 of 6
Safety
UL Mark (USA and Canada)
CE Mark
EN 60590
Operating System
Support
Red Hat Enterprise Linux 5. 8, 5.9, 6.2 and 6.3
SLES 10 SP4 and 11SP2
NOTE: For more Linux OS support & certification information, please visit our the ProLiant &
BladeSystem Server Linux matrix:
http://h18004.www1.hp.com/products/servers/linux/hplinuxcert.html
Environment-
friendly Products
and Approach
End-of-life
Management and
Recycling
Hewlett Packard Enterprise
offers end-of-life Hewlett Packard Enterprise product
return
, trade-in, and recycling programs in many geographic areas. For trade-in
information, please go
to: http://www.hp.com/go/green. To recycle your product,
please go to:
http://www.hp.com/go/green or contact your nearest Hewlett Packard
Enterprise sales
office. Products returned to Hewlett Packard Enterprise will be
recycled, recovered or disposed of in a responsible manner.
The EU WEEE directive (2002/95/EC) requires manufacturers to provide treatment
information for each product type for use by treatment facilities.
This information
(product disassembly instructions) is posted on the
Hewlett Packard Enterprise web
site at:
http://www.hp.com/go/green. These instructions may be used by recyclers
and other WEEE treatment facilit
ies as well as Hewlett Packard Enterprise OEM

QuickSpecs
HPE Ethernet 10Gb 2-
port 570M Adapter
Technical Specifications
Page 12
customers who integrate and re
-sell Hewlett Packard Enterprise equipment.

QuickSpecs
HPE Ethernet 10Gb 2-
port 570M Adapter
Summary of Changes
Page
13
Date
Version History
Action
Description of Change
20-May-2016 From Version 2 to 3 Changed Sections were updated in QuickSpecs.
17-Dec-2015 From Version 1 to 2
Changed
Overview and Related Options sections were updated.
Removed Obsolete SKUs were deleted:
498358-B21, 438031-B21, 451438-B21, 451439-B21, 410916-
B21.
Sign up for updates
© Copyright 201
6 Hewlett Packard Enterprise Development LP. The information contained herein is
subject to change without notice. The only warranties for Hewlett Packard Enterprise products and
services are s
et forth in the express warranty statements accompanying such products and services.
Nothing herein should be construed as constituting an additional warranty. Hewlett Packard Enterprise
shall not be liable for technical or editorial errors or omissions co
ntained herein.
Windows is a US registered trademark of Microsoft Corporation.
c04227607
- 14858 - Worldwide - V3 - 20-May-2016
