HP 652497-B21 User manual

The HP 361T offers two high-performing 1GbE PCIe Gen 2.1 connections in a low cost, low power, halogen-free design. Based on the
new fully integrated (bridgeless) Intel® Ethernet I350 Controller, it introduces new levels of performance and power management
technologies for HP ProLiant Gen8 DL/ML/SL servers and select G7 servers.
It can be used with a full height or low profile bracket, and can operate at three different data rates (10/100/1000 Mbps).
The HP 361T is positioned as the follow-on to the HP NC360T.
Models
HP Ethernet 1Gb 2-port 361T Adapter 652497-B21
Kit Contents HP Ethernet 1Gb 2-port 361T Adapter PCA with a standard height bracket attached to it (the low
profile bracket is included in the clamshell that the PCA ships in)
Product Warranty statement and the Quick Install Card (QIC).
QuickSpecs
HP Ethernet 1Gb 2-port 361T Adapter
Overview
DA - 14334 North America — Version 8 — October 11, 2013 Page 1

Server Support ProLiant DL (rack-optimized) :
HP ProLiant DL160 Gen8
HP ProLiant DL165 G7
HP ProLiant DL320e Gen8
HP ProLiant DL320e Gen8 v2
HP ProLiant DL360e Gen8
HP ProLiant DL360p Gen8
HP ProLiant DL380e Gen8
HP ProLiant DL380p Gen8
HP ProLiant DL385p Gen8
HP ProLiant DL560 Gen8
HP ProLiant DL580 G7
HP ProLiant DL585 G7
HP ProLiant DL980 G7
ProLiant ML (expansion-optimized) :
HP ProLiant ML310e Gen8
HP ProLiant ML310e Gen8 v2
HP ProLiant ML350e Gen8
HP ProLiant ML350e Gen8 v2
HP ProLiant ML350p Gen8
ProLiant SL (scalable line) :
HP ProLiant SL210t Gen8
HP ProLiant SL230s Gen8
HP ProLiant SL250s Gen8
HP ProLiant SL270s Gen8
NOTE: This is a list of supported servers. Some may be discontinued.
QuickSpecs
HP Ethernet 1Gb 2-port 361T Adapter
Compatibility
DA - 14334 North America — Version 8 — October 11, 2013 Page 2

Features
Product Highlights Two Gigabit Ethernet Ports
Supported on HP ProLiant Gen8 & Select G7 Rack & Tower servers
Intel® Ethernet I350 controller
Designed with server needs in mind:
IEEE 802.1p, 802.1Q, 802.3, 802.3ad, and 802.3x
EEE, EFI/uEFI support
ProLiant Teaming including Network Fault Tolerance, Transmit Load Balancing, and Switch-
Assisted Load Balancing
9.5K Jumbo frames
DMA Coalescing
IEEE 1588 (Precision Time Stamping) & 802.1AS (Hardware enabled Time Synchronization)
TCP/IP checksum offload (TCO) and large send offload (LSO)
PXE
Intel® Integrated I/O and Data Direct I/O for increased performance and reduced latency
Virtualization with VMDq
IPv6 packet transmit and receive (excluding all offload capabilities); IPv6 aware SNMPv1
agent for Windows
Performance
Gigabit Throughput
Combined with Legacy
Ethernet Support
10/100/1000 Mbps Ethernet transfer rate delivers outstanding network performance that improves
response time and removes bottlenecks. Because the HP 361T supports both 10Mbps Ethernet and
100Mbps Fast Ethernet in addition to Gigabit Ethernet, users are guaranteed end-to-end protocol support
across their enterprise.
PCI Express Interface HP was an early champion of PCI Express bus technology and has played a key role in the development and
industry adoption of the PCI Express specification. The HP 361T features a high performance Intel®
Ethernet Controller I350 and offers a four lane (x4) PCI Express bus based on the PCIe v2.1 standard,
yielding faster transmissions with lower CPU utilization than earlier solutions.
Load Balancing Transmit Load Balancing (TLB) and Switch-assisted Load Balancing (SLB) are two advanced features that
customers can use to build a bigger pipe for improved networking bandwidth. These port bonding
techniques enable users to install up to four dual-port HP 361T adapters (total of 8 ports) in a HP ProLiant
server and aggregate their throughput up to a theoretical maximum of 16 Gigabits per second full-duplex
transmissions.
Jumbo Frames Jumbo Frames (also known as Extended Frames) offer a 9.5K byte Maximum Transmission Unit (MTU),
which is approximately six times the size of traditional Ethernet frames. Like all HP ProLiant server
adapters, the HP 361Tsupports jumbo frames as a way to achieve higher throughput and better CPU
utilization when deployed in a network infrastructure that supports them. Jumbo frames are particularly
useful for database transfers and tape backups.
QuickSpecs
HP Ethernet 1Gb 2-port 361T Adapter
Standard Features
DA - 14334 North America — Version 8 — October 11, 2013 Page 3

Optimized for
Virtualization
I/O Virtualization support for Intel's Virtual Machine Device Queues (VMDq), VMware NetQueue and
Microsoft VMQ help meet the performance demands of consolidated virtual workloads.
Compliant with Single-Root I/O Virtualization (SR-IOV), accommodating multiple Virtual Machines (VMs) to
share single PCIe resources. The device is capable of SR-IOV, and requires Firmware, Software and OS
support
IEEE 1588 & 802.1AS Hardware assist for IEEE 1588 and IEEE 802.1AS time synchronization implementations for time sensitive
applications.
Power Management
Technologies
The 361T supports latest power management technologies such as Energy Efficient Ethernet & DMA
coalescing:
Energy Efficient Ethernet : Compliant with IEEE 802.3az, featuring advanced power savings
features throttles power usage with network load activity.
DMA Coalescing : Supports DMA Coalescing, the incoming data packets and interrupts associated
with these DMA calls are intelligently batched to keep the system devices in lower power states.
Intel® Integrated I/O with
Data Direct I/O
New on HP ProLiant Gen8 servers, Intel® Integrated I/O features reduces memory access from I/O on local
socket which speeds up CPU data transfer and accelerates inbound and outbound traffic flows. Together,
Integrated I/O and Data Direct I/O technologies reduce system power, increases I/O performance and
reduced I/O latency.
PXE Boot Support for pre-boot execution environment (PXE) enables automatic deployment of computing resources
remotely from anywhere. It allows a new or existing server to boot over the network and download
software, including the operating system, from a management/ deployment server at another location on
the network. Additionally, PXE enables decentralized software distribution and remote troubleshooting
and repairs.
Linux boot via PXE or BOOTP, Windows Deployment Services, or UEFI which allows networked computer to
boot using a program code image supplied by a remote server. It complies with the Pre-boot eXecution
Environment (PXE) Version 2.1 specification.
HP Sea of Sensors 3D Support for HP Sea of Sensors 3D Technology which is a collection of 32 sensors that automatically track
thermal activity - heat - across the server. When temperatures get too high, sensors can kick on fans and
make other adjustments to reduce energy usage. What makes it better is the upgrade from all six fans
kicking on at one time to a new system where only one kicks on - the one in proximity of the area that
started heating up - thus reducing the amount of energy used for cooling.
QuickSpecs
HP Ethernet 1Gb 2-port 361T Adapter
Standard Features
DA - 14334 North America — Version 8 — October 11, 2013 Page 4

Scalability and Reliability
Dual Ports Two Gigabit ports allow users to save slots in situations where their servers are slot-constrained. HP has
long been an advocate of dual port adapters for servers; the HP 361T is the latest best-of-breed dual port
devices for HP ProLiant servers.
NOTE: Port enumeration on the HP 361T is from the top down, i.e. the port near the top of the adapter is
port #1 and the port closest to the gold teeth is port #2
Network Fault Tolerance
(NFT)
Network Fault Tolerance, sometimes called "failover" or "NIC Redundancy," allows for the installation of
multiple server adapters so that the active device can be backed up by a redundant adapter to improve
availability. HP's teaming utility also allows users to specify that when a failed adapter is fixed and
replaced, the original adapter resumes its function as the primary network connection.
Distance capabilities The HP 361T supports cable runs up to 100 meters (328 feet).
Network Management
Auto-negotiation The HP 361T automatically senses and configures itself to the speed of the device to which it is attached. It
also automatically configures for half or full duplex, depending on the duplex mode of the switch, hub, or
router at the other end of the cable.
Wake-on-LAN The HP 361T provides Wake-on-LAN (WOL) support through the PCI Express bus. A system that supports
Wake on LAN can remain available to a systems administrator during its normal downtime. Once the
machine is awakened, the systems administrator can remotely control, audit, debug, or manage the
machine.
Management Support Like all HP ProLiant server adapters, the HP 361T ships with drivers and agents that can be managed from
all versions of Systems Insight Manager. Additionally, it supports any management application that
supports SNMP.
Server Integration The SmartStart configuration utility includes setup support for the HP 361T so that the adapter can be
configured as part of the SmartStart configuration process. Insight Manager can recognize the 361T
individually or in a port-bonded team, and it can collect and report SNMP statistics on the adapter events.
Integrated Management Log (IML) support is provided by the 361T for critical event logging on HP ProLiant
servers.
Configuration Utilities Each HP 361T ships with a suite of operating system-tailored configuration utilities that allow the user to
enable initial diagnostics and configure adapter teaming. This includes a patented teaming GUI for
Microsoft Windows operating systems. Additionally, support for scripted installations of teams in a
Microsoft Windows environment allow for unattended OS installations
LED Indicators Bracket LED indicators show link integrity, network activity, and speed on each port for easy
troubleshooting.
QuickSpecs
HP Ethernet 1Gb 2-port 361T Adapter
Standard Features
DA - 14334 North America — Version 8 — October 11, 2013 Page 5

Warranty Maximum : The remaining warranty of the HP product in which it is installed (to a maximum three-year,
limited warranty).
Minimum : One year limited warranty.
See Internet address http://www.hp.com for overall information on HP.
QuickSpecs
HP Ethernet 1Gb 2-port 361T Adapter
Standard Features
DA - 14334 North America — Version 8 — October 11, 2013 Page 6

Service and Support HP Technology Services
HP Technology Services offers you technical consultants and support expertise to solve your most
complex infrastructure problems. We help keep your business running, boost availability, and avoid
downtime.
Protect your business beyond warranty with HP Care Pack Services
When you buy HP Options, it's also a good time to think about what level of service you may need. HP Care
Pack services provide total care and support expertise with committed response choices designed to meet
your IT and business need.
HP Foundation Care services deliver scalable support-packages for HP industry-standard servers and
software. You can choose the type and level of service that is most suitable for your business needs. New
to this portfolio is HP Collaborative Support. If you are running business critical environments, HP offers
Proactive Care or Critical Advantage. These services help you deliver high levels of application availability
through proactive service management and advanced technical response.
Here is the support service recommendation from the Foundation Care and Proactive Care portfolio. For
customized support service solution, HP can work with you to tailor a service solution for your unique
support requirements using broader services portfolio of Foundation Care and Proactive Care.
Recommended HP Care Pack Services for optimal satisfaction with your HP product
Recommended Services 3-Year HP 24x7 4 hour Response, Proactive Care
Helps optimize your systems and delivers high levels of application availability through proactive service
management and advanced technical response. A skilled Technical Manager will own your query or issue
end to end until resolved, delivering a single point of contact for you
OR
3-Year HP 24x7 4 hour Response, HP Collaborative Support
Provides problem resolution support across the stack of HW, firmware, and HP and 3rd party SW. In case
the issue is with 3rd party SW, HP does known issue resolution. If HP cannot solve the issue, it will contact
the third-party vendor and create a problem incident on your behalf
http://h20195.www2.hp.com/V2/GetPDF.aspx/4AA3-8232ENW.pdf
HP Installation of ProLiant Add On Options Service
This easy-to-buy, easy-to-use HP Care Pack service helps ensure that your new HP hardware or software is
installed smoothly, efficiently, and with minimal disruption of your IT and business operations
QuickSpecs
HP Ethernet 1Gb 2-port 361T Adapter
Service and Support
DA - 14334 North America — Version 8 — October 11, 2013 Page 7

Related HP Care Pack Services to enhance your HP product experience
Related Services 3-Year HP 24x7 4 hour Response, Proactive Care
Helps optimize your systems and delivers high levels of application availability through proactive service
management and advanced technical response. A skilled Technical Manager will own your query or issue
end to end until resolved, delivering a single point of contact for you
OR
3-Year HP 24x7 4 hour Response, Hardware Support Onsite Service
Provides you with rapid remote support and if required an HP authorized representative who will arrive on
site any time and day of the year to begin hardware maintenance service within 4 hours of the service
request being logged http://h20195.www2.hp.com/V2/GetPDF.aspx/5982-6547EEE.pdf
3-Year HP 6-hour Onsite Call-to-Repair, HP Collaborative Support
Offers customers a single point of contact for server problem diagnosis, hardware problem resolution to
return the hardware in operating condition within 6 hours of the initial service request to the HP Global
Solution Center, and basic software problem diagnosis, fault isolation, and resolution if available to HP.
http://h20195.www2.hp.com/V2/GetPDF.aspx/4AA3-8232ENW.pdf
HP Proactive Select Service
Provides a flexible way to purchase HP best-in-class consultancy and technical services. You can buy
Proactive Select Service Credits when you purchase your hardware and then use the credits over the next
12 months. http://h20195.www2.hp.com/V2/GetPDF.aspx/4AA2-3842ENN.pdf
Insight Remote Support Provides 24 X 7 remote monitoring, proactive notifications, and problem resolution. Learn more
http://www.hp.com/go/insightremotesupport
HP Support Center Personalized online support portal with access to information, tools and experts to support HP business
products. Submit support cases online, chat with HP experts, access support resources or collaborate with
peers. Learn more http://www.hp.com/go/hpsc
HP's Support Center Mobile App * allows you to resolve issues yourself or quickly connect to an agent for
live support. Now, you can get access to personalized IT support anywhere, anytime.
HP Insight Remote Support and HP Support Center are available at no additional cost with a HP warranty,
HP Care Pack or HP contractual support agreement.
*HP' Support Center Mobile App is subject to local availability
Parts and materials HP will provide HP-supported replacement parts and materials necessary to maintain the covered
hardware product in operating condition, including parts and materials for available and recommended
engineering improvements. Supplies and consumable parts will not be provided as part of this service;
standard warranty terms and conditions apply. Parts and components that have exceeded their maximum
supported lifetime and/or the maximum usage limitations as set forth in the manufacturer's operating
manual or the technical product data sheet will not be provided, repaired or replaced as part of this service.
QuickSpecs
HP Ethernet 1Gb 2-port 361T Adapter
Service and Support
DA - 14334 North America — Version 8 — October 11, 2013 Page 8

Warranty / Service
Coverage
For ProLiant servers and storage systems, this service covers HP-branded hardware options qualified for
the server, purchased at the same time or afterward, internal to the enclosure, as well as external
monitors up to 22" and tower UPS products; these items will be covered at the same service level and for
the same coverage period as the server unless the maximum supported lifetime and/or the maximum
usage limitation has been exceeded. Coverage of the UPS battery is not included; standard warranty terms
and conditions apply.
The defective media retention service feature option applies only to Disk or eligible SSD/Flash Drives
replaced by HP due to malfunction. It does not apply to any exchange of Disk or SSD/Flash Drives that have
not failed. SSD/Flash Drives that are specified by HP as consumable parts and/or that have exceeded
maximum supported lifetime and/or the maximum usage limit as set forth in the manufacturer's operating
manual or the technical data sheet are not eligible for the defective media retention service feature option.
For more information To learn more on services for HP ESSN Options, please contact your HP sales representative or HP
Authorized Channel Partner. Or visit: http://www.hp.com/services/proliant or
www.hp.com/services/bladesystem
QuickSpecs
HP Ethernet 1Gb 2-port 361T Adapter
Service and Support
DA - 14334 North America — Version 8 — October 11, 2013 Page 9

Gigabit Server Adapters HP NC112T PCI Express Gigabit Server Adapter 503746-B21
HP NC360T PCI-E Dual Port Gigabit Server Adapter 412648-B21
HP NC364T PCI-E Quad Port Gigabit Server Adapter 435508-B21
HP NC365T 4-port Ethernet Server Adapter 593722-B21
HP NC373F PCI-E Multifunction 1000SX Gigabit Svr Adapter 394793-B21
HP NC373T PCI-E Multifunction Gigabit Server Adapter 394791-B21
HP NC375T PCI Express Quad Port Gigabit Server Adapter 538696-B21
HP NC382T PCI Express Dual Port Multifunction Gigabit Server Adapter 458492-B21
HP Ethernet 1Gb 4-port 331T Adapter 647594-B21
HP Ethernet 1Gb 2-port 332T Adapter 615732-B21
10 Gigabit Server
Adapters
NOTE: A minimum of two Gigabytes (2 GB) of server memory is required per each
adapter.
HP NC522SFP Dual Port 10GbE Gigabit Server Adapter 468332-B21
HP NC523SFP 10Gb 2-port Server Adapter 593717-B21
HP NC524SFP Dual Port 10GbE Module
NOTE: NC524SFP is available only on DL370 G6, ML370 G6, DL580 G7, DL585 G7, and
DL980 G7.
489892-B21
HP NC550SFP Dual Port 10GbE Server Adapter 581201-B21
HP NC552SFP 10Gb 2-port Ethernet Server Adapter 614203-B21
HP Ethernet 10Gb 2-port 530SFP Adapter 652503-B21
HP Ethernet 10Gb 2-port 530T Adapter 656596-B21
HP Ethernet 10Gb 2-port 560SFP+ Adapter 665249-B21
HP Ethernet 10Gb 2-port 561T Adapter 716591-B21
HP Ethernet 10Gb 2-port 570SFP+ Adapter 718904-B21
FlexibleLOM Adapters NOTE: A minimum of two Gigabytes (2 GB) of server memory is required per each
adapter.
Ethernet Adapters
HP Ethernet 1Gb 4-port 331FLR Adapter 629135-B21
HP Ethernet 1Gb 4-port 366FLR Adapter 665240-B21
HP Ethernet 10Gb 2-port 530FLR-SFP+ Adapter 647581-B21
HP Ethernet 10Gb 2-port 560FLR-SFP+ Adapter 665243-B21
HP Ethernet 10Gb 2-port 561FLR-T Adapter 700699-B21
HP Ethernet 10Gb 2-port 570FLR-SFP+ Adapter 717491-B21
FlexFabric Adapters
HP FlexFabric 10Gb 2-port 526FLR SFP+ Adapter 629138-B21
HP FlexFabric 10Gb 2-port 533FLR-T Adapter 700759-B21
HP FlexFabric 10Gb 2-port 534FLR-SFP+ Adapter 700751-B21
HP FlexFabric 10Gb 2-port 554FLR-SFP+ Adapter 629142-B21
NOTE: Please see the QuickSpecs for Technical Specifications and additional
information: www.hp.com/go/ProLiantNICs
QuickSpecs
HP Ethernet 1Gb 2-port 361T Adapter
Related Options
DA - 14334 North America — Version 8 — October 11, 2013 Page 10

Compliance 802.3, 802.3u, 802.3x, 802.3ab, 802.3ad, 802.1p, 802.1Q, 802.3az, IEEE 1588
PCIe v2.0 standard
RoHS (6 of 6)
FCC (U.S. only) Class B
DOC (Canada) Class B
CE EN 55024, EN55022 Class B
VCCI Class II
UL 1950
CSA 950
EN 60950
CE
ACPI 1.1a
Microsoft WHQL (Windows Hardware Quality Labs)
General Specifications Communications
Processor
Intel® Ethernet I350 Controller
Data rate 10/100/1000 Mbps, Half- and full-duplex
Data path Four lane (x4) PCI Express compatible with x4, x8, and x16 PCI Express slots
Interrupt levels Automatically configured
Cable Connector Two RJ-45
Bus Connector PCIe
Distance and
Wiring
Up to 328 feet/100 m with Category 5 (or better) twisted-pair cabling
Card Dimensions (without
brackets)
(L x W)
5.3 x 2.5 in (13.50cm x 6.4 cm)
Power and Environmental
Specifications
Operating Temperature 32° to 131° F (0° to 55° C )
Humidity 10% to 95% non-condensing
Non-operating Temperature -40° to 185° F (-40° to 85° C)
Humidity -5% to 95%
Power requirement 4.1W idle without EEE link partner
3.2W idle with EEE link partner
4.2W maximum
Emissions Standards FCC Class B, VCCI Class B, BSMI Class A, CISPR 22 Class B,
EN 55022 Class B, EN55024-1, ICES-003 Class B, MIC Class B, ACA Class B
Safety Compliant UL, Canada UL, EN60950
Operating System
Support
Microsoft Windows Server 2008
Microsoft Windows HPC Server 2008
Red Hat Enterprise Linux 5.7, 6.1
SUSE Linux Enterprise Server
Solaris 10
ESX/ESXi 4.1 & ESXi 5.0
Citrix Xenserver 6.0
Microsoft Windows Hyper-V
NOTE: For more Linux OS support & certification information, please visit our the ProLiant & BladeSystem
QuickSpecs
HP Ethernet 1Gb 2-port 361T Adapter
Technical Specifications
DA - 14334 North America — Version 8 — October 11, 2013 Page 11

Server Linux matrix: http://h18004.www1.hp.com/products/servers/linux/hplinuxcert.html
NOTE: For more OS support & certification information, please visit the NIC driver download web pages at
this location: http://h18004.www1.hp.com/support/files/networking/us/index.html
Environment-friendly
Products and Approach
End-of-life Management
and Recycling
Hewlett-Packard offers end-of-life HP product return, trade-in, and recycling
programs in many geographic areas. For trade-in information, please go to
http://www.hp.com/go/green . To recycle your product, please go to:
http://www.hp.com/go/green or contact your nearest HP sales office.
Products returned to HP will be recycled, recovered or disposed of in a
responsible manner.
The EU WEEE directive (2002/95/EC) requires manufacturers to provide
treatment information for each product type for use by treatment facilities.
This information (product disassembly instructions) is posted on the Hewlett
Packard web site at: http://www.hp.com/go/green . These instructions may be
used by recyclers and other WEEE treatment facilities as well as HP OEM
customers who integrate and re-sell HP equipment.
© Copyright 2013 Hewlett-Packard Development Company, L.P.
The information contained herein is subject to change without notice.
Windows is a US registered trademark of Microsoft Corporation.
The only warranties for HP products and services are set forth in the express warranty statements accompanying such products and
services. Nothing herein should be construed as constituting an additional warranty. HP shall not be liable for technical or editorial
errors or omissions contained herein.
QuickSpecs
HP Ethernet 1Gb 2-port 361T Adapter
Technical Specifications
DA - 14334 North America — Version 8 — October 11, 2013 Page 12
