Model A4268A FWD SCSI Adapter
Installation and Service Guide
Embedded Systems Operation
Part No. A4268–90601
Edition E1097

Hewlett–Packard Co. 1995, 1997
First Printing: April 1995
Last Printing: October 1997
UNIX is a registered trademark in the United States and other countries, licensed exclusively through
X/Open Company Limited.
NOTICE
The information contained in this document is subject to change without notice.
HEWLETT–PACKARD MAKES NO WARRANTY OF ANY KIND WITH REGARD TO THIS
MATERIAL INCLUDING BUT NOT LIMITED TO THE IMPLIED WARRANTIES OF
MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE. Hewlett–Packard shall
not
be liable for errors contained herein or for incidental or consequential damages in connection with
the furnishing, performance or use of this material.
Hewlett–Packard
assumes no responsibility for the use or reliability of its software on equipment that is
not furnished by Hewlett–Packard.
This
document contains proprietary information which is protected by copyright. All rights reserved.
No part of this document may be photocopied, reproduced or translated to another language without the
prior written consent of Hewlett–Packard Company.
RESTRICTED RIGHTS LEGEND. Use, duplication, or disclosure by government is subject to
restrictions
as set forth in subdivision (c) (1) (ii) of the Rights in T echnical Data and Computer Software
Clause at DFARS 252.227.7013. Hewlett–Packard Co., 3000 Hanover St., Palo Alto, CA 94304
10 9 8 7 6 5 4 3 2 1

iii
Contents
Preface
Chapter 1 Preparing for the Installation
Product Description 1–2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Features 1–2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Physical and Environmental Specifications 1–2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Check That You Have the Necessary Equipment 1–3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
System Prerequisites 1–4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Hardware Prerequisites 1–4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Firmware Prerequisites 1–4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Software Prerequisites 1–4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Record Adapter Information 1–5. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Check the Switch Settings 1–6. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Chapter 2 Installing the FWD SCSI Adapter
Remove SBC from the Card Cage. 2–2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Remove blank plate from front panel. 2–4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
For Model 743 only, install new Boot ROM if required. 2–5. . . . . . . . . . . . . . . . . . . . . . . .
Install FWD SCSI Adapter card. 2–6. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Replace the SBC in the Card Cage. 2–8. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Connect the disk drives. 2–9. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Verify the operation of the FWD SCSI adapter. 2–10. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Contents
iv
Chapter 3 Troubleshooting
Diagnostic Information 3–2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Term Power LED 3–2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Off–Line Diagnostics 3–3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
MAPPER 3–3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
IOTEST 3–3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Field Replaceable Units 3–4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Removing and Replacing the Term Power Fuse 3–4. . . . . . . . . . . . . . . . . . . . . . . . . . .

v
Preface
This guide describes how to install and configure the Fast–Wide–Differential (FWD)
SCSI adapter on your Model 743 or 744 Single Board Computer or Model 748 Industrial
System.
We’ve organized this guide as follows:
Chapter 1 This chapter describes how to prepare your computer for the installation.
It lists the contents of the kit, and system prerequisites.
Chapter 2 This chapter describes the step–by–step procedure for installing the FWD
SCSI adapter.
Chapter 3 This chapter tells you what to do if you experience problems after
installing the new adapter.
Audience
This guide is intended for use by anyone familiar with the Model 743 or 744 Single
Board Computer or Model 748Industrial System who wants to install a FWD SCSI
adapter.

Preface
vi
Installation Notice
Products designated in the applicable Hewlett–Packard price list as customer installable
can be installed by computer–knowledgeable customers who carefully read and follow
the instructions provided. Customers who elect to have the product installed by our field
personnel are charged the applicable field installation charge, as covered under the
standard terms and conditions. For more information, please contact your local sales
representative.
Related Manuals
For more information, refer to the following documents:
•Model 744 Owner’s Guide (A4511–90602)
•Model 743 Owner’ s Guide (A2636–90606)
•Model 748 Owner’s Guide (A4511–90604)
•HP–RT Operating System 3.01 Release Notes (B5487–90013)
•HP–RT System Administration T asks (B5487–90002)

Preface
vii
Revision History
The revision history for each edition of the manual is listed below:
Edition Revision History
E0495 First edition.
E1097 Second edition, revised to include information relating to the
Model 744.

Preface
viii
Problems, Questions, and Suggestions
If you have any questions or problems with our hardware, software, or documentation, please
contact your designated service representative.

Preface
ix
Documentation Conventions
Unless otherwise noted in the text, this guide uses the following symbolic conventions:
literal values Bold words or characters in formats and command descriptions
represent commands that you must use literally. Pathnames are
also in bold.
user–supplied Italic words or characters in formats and command descriptions
values represent values that you must supply. Italics are also used in
text for emphasis.
screen display Information that the system displays appears in this typeface.
Enter A rectangle with rounded corners and a key label denotes a key on
your keyboard. (In this manual we refer to the Enter key. On your
keyboard the key may be labeled either Enter or Return.)
This symbol indicates the end of a chapter or part of this guide.

Preface
x

1–1
Chapter 1
Preparing for the Installation
This chapter describes how to prepare your system for a FWD SCSI adapter installation.
Before installing your new adapter, you need to complete the following tasks:
•Check that you have the necessary equipment.
•Make sure that your system meets the prerequisites.
•Record adapter information.
• Check switch settings.

Preparing for the Installation
1–2
Product Description
The followings describes the features, physical and environmental specifications and
parts included with the installation kit.
Features
The HP A4268A FWD SCSI Adapter complies with ANSI X3T9.2 SCSI specifications
and has the following features:
•NCR 53C720 SCSI I/O processor chip.
•Differential control and data lines.
•Internal removable terminators allowing for installation anywhere on the SCSI bus.
•4 position DIP switch to set SCSI ID for the adapter.
Physical and Environmental Specifications
The HP A4268A FWD SCSI Adapter’s physical and environmental specifications are:
•Temperature
– Operating: 0 to 55 degrees C (ramp rate 10 degrees C).
– Storage: – 40 to 70 degrees C.
•Humidity: 95% relative humidity at 40 degrees C.
•Mechanical shock: compliant with IEC 654-3 and IEC-68-2 methods.
•Mechanical vibration: compliant with IEC 654-3 Class VH3 levels or better.

Preparing for the Installation
1–3
1. Check That You Have the Necessary Equipment
Verify that you have kit A4268A FWD SCSI adapter). Ensure that the kit contains the
following parts.
•HP A4268A FWD SCSI adapter card
•Screws (2)
•Boot ROM, upgrade (for use with Model 743 only)
•IC removal tool (for use with Model 743 only)
• Disposable anti–static wrist strap
Verify that you have the following tools to perform the installation:
•Small flat blade screwdriver
•#1 Pozidriv screwdriver

Preparing for the Installation
1–4
2. System Prerequisites
Your system must meet some hardware and software prerequisites to support the FWD
SCSI adapter. These prerequisites are described in the following sections.
Hardware Prerequisites
The required hardware is as follows:
•GSC Expansion Adapter (A4262A or A4219A) or HCRX/VME Graphics Board
(A4315A or A4316A)
•A minimum of 32-MB RAM if running HP-UX version 10.20, or
a minimum of 16-MB RAM if running HP-UX version 9.x, or
a minimum of 24–MB RAM if running HP–RT
Firmware Prerequisites
The required firmware is as follows:
•A Model 743 Single Board Computer (SBC) may require a firmware upgrade if the
Boot ROM included in this kit is a later version than the one in use on your SBC.
To determine if the Boot ROM of your SBC needs to be replaced, you need to
determine
the revision number , which can be done in one of two ways: use the Boot
Console Handler (BCH) interface as described in the Model 743 Owner ’ s Guide , or
you can examine the label on the Boot ROM – a revision number is printed on the
label. If the revision number on the Boot ROM installed on the Model 743 is a lower
number than the one included in this kit, you should replace the Boot ROM with the
one included in this kit. If the revision number on the Boot ROM installed on the
Model
743 is equal to or greater than the one included in this kit, DO NOT replace
the Boot ROM on the Model 743.
•A Model 744 Single Board Computer does not require a firmware upgrade
Software Prerequisites
The required software is as follows:
•For Model 743 SBC with HP-UX, software release 9.05 or later version.
•For Model 744 SBC with HP-UX, software release 10.20 or later version.
To identify which revision of HP-UX your workstation is running, enter
the following command:

Preparing for the Installation
1–5
uname –r Enter
A line similar to the following is displayed:
A.09.05
If a number less than 09.05 is displayed it means that you need to update
your software before installing your HCRX/VME graphics upgrade.
•For Model 743 and 744 SBCs with HP-R T , the operating system software revision
of the host system must be HP-UX 10.10 or later , and the HP-R T tar get system must
have at least HP-R T 3.01. For more information, refer to the HP–RT 3.01 Release
Notes.
Contact your designated service representative for information on receiving an upgrade to
the correct version of the operating system.
3. Record Adapter Information
Record the serial number of the adapter for future reference. If your adapter needs
service in the future, the serial number will be needed by HP service personnel. This
information is provided on the bar code sticker affixed to the adapter. See the following
example.

401105H009

Preparing for the Installation
1–6
4. Check the Switch Settings
Ensure the SCSI address switches are set to SCSI address 7 unless your storage
subsystem allows multiple controllers (refer to your storage subsystem documentation).
The SCSI adapter address switches are shown set to SCSI address 7 in Figure 1–1.
SCSI Address Switches
7
6
1 2 3 4
5
15
14
1 2 3 4
13
4
3
2
12
11
10
1 2 3 4
1
0
9
8
Depressed
Side of Switch
Figure 1–1. The SCSI Adapter Addr ess Switches

2–1
Chapter 2
Installing the FWD SCSI Adapter
This chapter describes how to install the FWD SCSI adapter. Before beginning the
hardware installation, you must complete the tasks in Chapter 1. The tasks for installing
the FWD SCSI adapter are as follows:
•Remove the single board computer (SBC).
•For a Model 743 SBC, install new Boot ROM, if required.
•Remove a blank cover.
•Install FWD SCSI card.
•Replace the single board computer.
•Connect the disk drive(s).
CAUTION: The FWD SCSI adapter is susceptible to electrostatic shock. When
handling your graphics option board, always wear the
static–grounding wrist strap that came in the kit. Always handle
printed circuit boards carefully.

Installing the FWD SCSI Adapter
2–2
1. Remove SBC from the Card Cage.
a. Power down your card cage.
b. Disconnect the power cord(s) from the wall outlet and the card cage.
c. Power off any external peripherals attached to your computer, and unplug their
power cables from the wall outlet.
d. Attach the anti–static grounding wrist strap to your wrist and an exposed piece of
metal on your computer, as described on the wrist strap’s packaging.

Installing the FWD SCSI Adapter
2–3
e. Loosen the SBC’s two captive screws with a small flat blade screwdriver. Depending
on your configuration, you could have four captive screws – two on the SBC, and
two on the expansion slot. If you have these four captive screws, you will need to
remove all four. See Figure 2–1.
Captive Screws
Captive Screws
Figure 2–1. Removing the Single Boar d Computer
f. Push the ejector handles to the outside of the board and remove the SBC from the
card cage, as shown in Figure 2–1.

Installing the FWD SCSI Adapter
2–4
2. Remove blank plate from front panel.
Remove the blank plate from the opening of the front panel expansion plate at the
site where you will install the FWD SCSI adapter. Save the screws for use later. See
Figure 2–2.
Figure 2–2. Removing a Blank Plate
