hp pavilion home pc
Installing the Wireless Keyboard and Mouse Set

Filename: 5219urf users guide US_revised(p11).doc Title: hp pavilion home pc
Template:Normal.dot Author:pamela LastSavedBy:demi
Revision #: 2 Page: 2 of 13 Printed: 03/03/03 02:22 PM

HP Pavilion home PC 1
Filename: 5219urf users guide US_revised(p11).doc Title: hp pavilion home pc
Template:Normal.dot Author:pamela LastSavedBy:demi
Revision #: 2 Page: 1 of 13 Printed: 03/03/03 02:22 PM
Installing the Wireless
Keyboard and Mouse Set
The wireless keyboard and mouse set
consists ofa receiver (A) that plugs into the
computer, a wireless keyboard (B), and a
wireless mouse (C).
Note: This wireless set is compatible with your
HPPavilion home PC and not intended
forusewithother computers.
Note: You can replace the batteries in the mouse
andkeyboard without turning off the
computer. The computer must be on to
change the ID setting on the three units.
A
B
C

2HP Pavilion home PC
Filename: 5219urf users guide US_revised(p11).doc Title: hp pavilion home pc
Template:Normal.dot Author:pamela LastSavedBy:demi
Revision #: 2 Page: 2 of 13 Printed: 03/03/03 02:22 PM
Getting the Mouse Ready
EE1
K
EE1
K
Note: Do not use rechargeable batteries in the
mouse. Alkaline batteries are recommended.

HP Pavilion home PC 3
Filename: 5219urf users guide US_revised(p11).doc Title: hp pavilion home pc
Template:Normal.dot Author:pamela LastSavedBy:demi
Revision #: 2 Page: 3 of 13 Printed: 03/03/03 02:22 PM
Install the two AA alkaline batteries
(provided) inthe wireless mouse: Push in at
E1 and lift thebattery cover (E) from the
bottom of the mouse, and then insert the
batteries into the compartment. Note the
battery icons, and make sure batteries are
placed in the correct direction. Replace the
cover.
Note: The red LED (K) turns on indicating the
batteries are installed correctly.

4HP Pavilion home PC
Filename: 5219urf users guide US_revised(p11).doc Title: hp pavilion home pc
Template:Normal.dot Author:pamela LastSavedBy:demi
Revision #: 2 Page: 4 of 13 Printed: 03/03/03 02:22 PM
Getting the Keyboard Ready
II
G
H
G
H
J
Note: Do not use rechargeable batteries in the
keyboard. Alkaline batteries are recommended.

HP Pavilion home PC 5
Filename: 5219urf users guide US_revised(p11).doc Title: hp pavilion home pc
Template:Normal.dot Author:pamela LastSavedBy:demi
Revision #: 2 Page: 5 of 13 Printed: 03/03/03 02:22 PM
1Install the two AA alkaline batteries
(provided) in the wireless keyboard: Remove
the cover (G) from the bottom of the
keyboard, and insert the batteries into the
compartment (H). Note the battery icons,
and make sure batteries are placed in the
correct direction. Replace the cover.
2Adjust the keyboard height by lifting the
adjustment bar (JI).
Getting the Receiver Ready
The receiver (A) must be placed upright and
positioned properly to avoid interference
from other electrical equipment.
1Turn off your computer, and disconnect the
power cord and modem/phone cable.
2Connect the receiver cable (L) to the USB
connector on the back of the computer.

6HP Pavilion home PC
Filename: 5219urf users guide US_revised(p11).doc Title: hp pavilion home pc
Template:Normal.dot Author:pamela LastSavedBy:demi
Revision #: 2 Page: 6 of 13 Printed: 03/03/03 02:22 PM
A
L
M
A
3Set the receiver upright and follow these
guidelines.
nA: Minimum 20 cm (8 inches) clearance
between the receiver and other
electronic devices.
nB: Maximum 1.5 m (59 inches) working
distance between the receiver and
wireless mouse or wireless keyboard.
L

HP Pavilion home PC 7
Filename: 5219urf users guide US_revised(p11).doc Title: hp pavilion home pc
Template:Normal.dot Author:pamela LastSavedBy:demi
Revision #: 2 Page: 7 of 13 Printed: 03/03/03 02:22 PM
nC: Minimum 20 cm (8 inches) clearance between the receiver and the monitor.
nPlace no electronic device between the receiver and wireless mouse or wireless keyboard.
Note: This is one example of the setup. Other setup positions are also possible.
Warning: To avoid causing interference, keep the receiver at least 20 cm (8 inches) away from the
monitor.

8HP Pavilion home PC
Filename: 5219urf users guide US_revised(p11).doc Title: hp pavilion home pc
Template:Normal.dot Author:pamela LastSavedBy:demi
Revision #: 2 Page: 8 of 13 Printed: 03/03/03 02:22 PM
Setting Up the Wireless Set
The mouse and keyboard have 255 IDs that
are randomly selected when you press the
ID button. This helps protect against
interference from other wireless devices in
the same area.
Important: The word CONNECT labels the ID button
on the bottom of each unit. To press the ID
button, use a blunt pointed object, like the tip
of a ball point pen.
1Connect the power cord and
modem/telephone cable to the
computer. Turnon the computer.
Receiver
2On the bottom of the receiver, press the
IDbutton (D) once with a blunt pointed
object.
The top activity LED (N, a blue light) on the
receiver will start flashing and will continue
flashing until the next step are completed
or until 30 seconds pass.
D
Important: If 30 seconds pass before you complete
steps 3, you must repeat steps 2, 3 to set the
IDs.
