HP StorageWorks 30ux User manual

Getting Connected
7.5 cm (3 in)
1
Note the
environmental
considerations. Sufficient clearance
is necessary to ensure adequate air circulation.
hp
StorageWorks
Optical 30ux
Getting
Started
4
2
1
Removal
3
Accessories:
A. Power cord (U.S.)
B. Terminator
C. UDO media
D. Driver CD
E. Documentation CD
F. Getting Started poster
G. Setup Guide
H. Warranty information
I. Safety Guide
Not Included:
J. LVD SCSI adapter
for host system
K. LVD SCSI cable
L. Non-U.S. power cord
A
B
C
J K L
HI
E
F
G
D
FRONT VIEW:
A. Disk slot
B. Activity indicator
C. Power indicator
D. Eject tool
access hole
E. Eject button
A
D
C
BACK VIEW:
A. SCSI ID switch
B. Power connector
C. On/Off switch
D. SCSI port with
terminator
E. SCSI port with
SCSI cable
Note: See the HP StorageWorks
Optical 30ux User’s Guide for detailed
information regarding these features.
A
BC
D
E
B
E
Caution: Components can be
damaged by electrostatic discharge.
Make sure you are properly grounded
when touching static-sensitive
components.
Note: The following is an overview
of the installation procedure.
For detailed information, refer to the
setup guide that shipped with this
product.

1
2
3
6
23
4
5
Set the drive’s SCSI
ID by pushing the
button. Ensure
that there are no SCSI
ID conflicts with existing
devices. The drive
default setting is “4”.
Note: The SCSI ID can be inadvertantly
changed during handling.
Connect the drive to your host computer and
terminate the last device in the SCSI chain.
Warning: This product can only be used
with an HP approved power cord for your
specific geographic region. Use of a non-
HP approved power cord may result in:
1) noncompliance with individual, country-
specific safety requirements; 2) insufficient
conductor ampacity that could result in
overheating with potential personal injury
and/or property damage; and 3) a
fractured power cord, which could cause
the internal contacts to be exposed, which
potentially could subject the user to a shock
hazard. HP disclaims all liability when HP-
approved power cords are not used. Connect power to the drive. Power on the drive
and then power on the host system.
Configure the drive for your host operating system.
Refer to the setup guide for detailed procedures.
Load a disk into the drive by inserting it gently but
firmly into the opening on the front panel, shutter
end first, with the side you want to access facing
up (A or B).

Using HP StorageWorks
Library and Tape Tools
HP StorageWorks Library and Tape Tools (L&TT) is
a robust diagnostic tool for tape mechanisms, tape
automation, magneto-optical and UDO products.
L&TT provides functionality for firmware downloads,
verification of device operation, maintenance
procedures, failure analysis, corrective service
actions and some utility functions.
Seamless integration is provided with HP’s
hardware support organization by generating and
emailing support tickets. The support ticket delivers
a snapshot, or an in-depth view, of the storage
system.
L&TT is a free download from the web and
deploys in less than five minutes. It is ideal for
customers who want ensured product reliability,
self-diagnostics and faster resolution of device
issues.
For more information, visit
http://www.hp.com/support/tapetools.
Getting Help
•HP product information:
http://www.hp.com/go/udo
•HP technical support and phone numbers:
http://www.hp.com/support
•HP StorageWorks Library and Tape Tools
(L&TT) diagnostic software:
http://www.hp.com/support/tapetools
Using UDO Media
HP UDO media meets HIPPA and federal
archival regulations and offers customers both
WORM and ReWritable formats. By using
HP UDO media in your HP StorageWorks
UDO jukeboxes and drives, you safeguard
your investment by preserving the integrity of
your data. HP develops, designs, qualifies and
exhaustively tests both hardware and media
together to ensure the highest level of media
quality and reliability.
To order HP UDO media, contact your local
area HP Authorized Reseller or buy online from
http://www.hp.com/go/storagemedia.
For HP UDO 30GB Write Once media, order
part number Q2030A. For HP UDO 30GB
ReWritable media, order part number Q2031A.

© 2004 Hewlett-Packard Development Company, L.P.
First Edition (May 2004)
Part Number: AA961-96001
*AA961-96001*
AA961-96001
