HP 8000 - Elite Convertible Minitower PC User instructions

Ultra-slim Desktop
1. Optical Disc Drive (slimline)
2. Secure Digital (SD) Card Reader
3. Rear I/O includes (6) USB 2.0 ports, DisplayPort and VGA
video interfaces, PS/2 mouse and keyboard ports, RJ-45
network interface, audio in/out jacks
4. Front I/O includes (4) USB 2.0 ports, dedicated headphone
output, and a microphone/headphone jack
5. 2.5” internal hard disk drive bay
6. 135W 87% efficient external Power Adapter
7. HP USDT Tower Stand (sold separately)
8. HP Optical Mouse
9. HP Keyboard
10. HP Monitor (sold separately)
QuickSpecs
HP Compaq 8000 Elite PC
Overview
DA - 13424 Worldwide QuickSpecs — Version 17 — 6/25/2010 Page 1

Small Form Factor
1. Rear I/O includes (6) USB 2.0 ports, serial port, PS/2
mouse and keyboard ports, RJ-45 network interface,
DisplayPort and VGA video interfaces, and audio in/out jacks
2. Low profile expansion slots include (1) PCI slot, (2) PCI
Express x1 slots and (1) PCI Express x16 graphics slot
3. Front I/O includes (4) USB 2.0 ports, dedicated headphone
output, and a microphone/headphone jack
4. HP Optical Mouse
5. HP Keyboard
6. 3.5” external drive bay supporting a media card reader or a
secondary hard disk drive
7. 5.25” external drive bay supporting an optical disk drive
8. 3.5” internal drive bay supporting primary hard disk drive
9. 240W standard or 89% high efficiency Power Supply
10. HP Monitor (sold separately)
QuickSpecs
HP Compaq 8000 Elite PC
Overview
DA - 13424 Worldwide QuickSpecs — Version 17 — 6/25/2010 Page 2

Convertible Minitower
1. (3) 5.25” external drive bays supporting optical disk drives,
removable hard disk drives, or the HP Media Card Reader
2. 320W standard or 89% high efficiency Power Supply
3. Rear I/O includes (6) USB 2.0 ports, serial port, PS/2
mouse and keyboard ports, RJ-45 network interface,
DisplayPort and VGA video interfaces, and audio in/out jacks
4. Front I/O includes (4) USB 2.0 ports, dedicated headphone
output, and an auto detecting microphone/headphone jack
5. (3) 3.5” internal drive bays supporting multiple hard disk
drives
6. Full height expansion slots include (3) full-length PCI slots,
(1) PCI Express x1 slot, and (2) full-length PCI Express x16
graphics slots
NOTE: 2nd PCIe x16 slot has x4 connectivity.
7. HP Optical Mouse
8. HP Keyboard
9. HP Monitor (sold separately)
QuickSpecs
HP Compaq 8000 Elite PC
Overview
DA - 13424 Worldwide QuickSpecs — Version 17 — 6/25/2010 Page 3

At A Glance
Designed for long-term deployment within corporate, enterprise, public sector and mid-market commercial
organizations
Choice of three professional chassis form factors to accommodate any desired mix between expandability and size
BIOS developed and engineered by HP for better security, manageability and software image stability
Intel® Q45 Express chipset featuring integrated GMA 4500 integrated graphics
DDR3 Synchronous Dynamic Random Access Memory (SDRAM)
Intel® Core 2 Processor with vPro Technology (requires select processors)
Supports industry standard management protocols including Intel Standard Manageability and DASH 1.1 (via optional
Broadcom NIC card)
Integrated dual independent monitor support via both a VGA and DisplayPort video interface
Standard efficiency or 89% high efficiency energy saving power supplies available on the CMT and SFF models
87% efficient energy saving external power adapter standard with USDT models
ENERGY STAR qualified models available (dependent upon the desired configuration)
CMT and SFF models can be configured with multiple hard disk drives in a RAID array
Guaranteed lengthy purchase lifecycles and image stability
Software image fully compatible across all models and form factors
Created using industry leading Design for Environment standards
Selected configurations with global availability easily set up and ordered through HP.com Business to Business
portals ( http://h10019.www1.hp.com/business-site/index.html )
Tailored HP Factory Express deployment and lifecycle services available
( http://h71028.www7.hp.com/enterprise/cache/97688-0-0-225-121.aspx )
Protected by HP Services, including standard warranties up to 5-5-5 (terms and conditions vary by country; certain
restrictions and exclusions apply)
Tool-less serviceability features for easier upgrades and repairs
QuickSpecs
HP Compaq 8000 Elite PC
Overview
DA - 13424 Worldwide QuickSpecs — Version 17 — 6/25/2010 Page 4

Operating Systems
Preinstalled Genuine Windows Vista Business (32-bit)
1
Genuine Windows Vista Home Basic1
Genuine Windows 7 Home Basic Edition (32-bit)
2
Genuine Windows 7 Home Premium Edition (32-bit or 64-bit)
2
Genuine Windows 7 Professional Edition (32-bit or 64-bit)
2
Genuine Windows 7 Professional Edition with a custom downgrade to Genuine
Windows XP Professional
2,3
FreeDOS
Supported Genuine Windows Vista Enterprise Edition
1
Genuine Windows 7 Enterprise Edition
2
Genuine Windows 7 Ultimate Edition
2
Certified Novell SUSE Linux Enterprise Desktop 11
4
Red Hat Enterprise Linux 64
4
1
Certain Windows Vista product features require advanced or additional hardware. See
www.microsoft.com/windowsvista/getready/hardwarereqs.mspx and
www.microsoft.com/windowsvista/getready/capable.mspx for details. Windows Vista Upgrade Advisor can help you
determine which features of Windows Vista will run on your computer. To download the tool, visit:
www.windowsvista.com/upgradeadvisor
2
System may require upgraded and/or separately purchased hardware and/or a DVD drive to install the Windows 7
software and take full advantage of Windows 7 functionality. See http://www.microsoft.com/windows/windows-7/ for details.
3
Windows 7 Professional disk may be included for future upgrade if desired. To qualify for this downgrade an end user
must be a business (including governmental or educational institutions) and is expected to order at least 25 customer
systems with the same custom image.
4
The following features are not supported on Linux certified systems:
HP 22-in-1 media card reader
Trusted Platform Module (TPM) 1.2 Security Chip
Intel Gigabit CT Desktop NIC Card
Broadcom NetXtreme GbE Ethernet Plus NIC
HP 802.11b/g/n wireless NIC (SFF and MT)
Intel WiFi Link 5100 a/b/g/n wireless NIC (USDT)
LSI 56K Int'l SoftModem
HP USB Smartcard keyboard
HP Serial port adapter
HP Parallel port adapter
HP eSATA port adapter
HP FireWire/IEEE 1394 I/O card
SATA Blu-Ray Writer Drive
ATI Radeon HD 4550 Graphics Card
ATI Radeon HD 4650 DP (1GB) PCIe x16 Graphics Card
Nvidia GeForce 310 DP PCIe x16 Graphics Card
Nvidia Quadro NVS 290 Graphics Card
Nvidia Quadro NVS 295 Graphics Card
QuickSpecs
HP Compaq 8000 Elite PC
Standard Features and Configurable Components (availability may vary by country)
DA - 13424 Worldwide QuickSpecs — Version 17 — 6/25/2010 Page 5

Value Added Software
(included with all models; not included when configured with FreeDOS)
HP ProtectTools Security Suite
HP Software Management Agent
Computrace for Desktops agent (optional)
HP Insight Diagnostics
PDF Complete
Value Added Software
(included with select models; not included when configured with FreeDOS)
Computer Setup Utility
McAfee Total Protection Anti-Virus*
Roxio Creator Business
HP Power Manager
HP Total Care Advisor
Microsoft Office Trial Version
Firefox HP Virtual Browser
Corel WinDVD
* 60 day trial period for McAfee Total Protection for Small Business software. Internet access required to receive updates.
First update included. Subscription required for updates thereafter.
HP Client Management Solutions
(available for free download from the Internet)
http://www.hp.com/go/easydeploy )
HP Client Automation Starter *
HP SoftPaq Download Manager
HP Client Catalog for Microsoft SMS
HP Systems Software Manag
* Available from your HP Sales Representative or HP Channel Partner
Value Added Services and Features
HP Stable Platform Program
Intel Stable Platform Program
Business-to-Business Portals
HP Global Series Services
Factory Express Deployment and Lifecycle Services
Intel Standard Manageability
Intel Core 2 Processor with vPro Technology
Trusted Platform Module (TPM) v1.2 *
* TPM module disabled where restricted by law, i.e. Russia.
Service and Support
On-site warranty and service¹: three year (3/3/3) limited warranty and service offering delivers three years of parts, labor
and on-site repair. Response time is next business day² and includes free telephone support³ 24 x 7. Global coverage²
ensures any product purchased in one country and transferred to another non-restricted country will remain fully covered
under the original warranty and service offering. Some countries/regions do not offer one year onsite and labor.
1
Terms and conditions may vary by country. Certain restrictions and exclusions apply.
2
On-site services may be provided pursuant to a service contract between HP and an authorized HP third party provider,
and is not available in certain countries. Global service response times are based on commercially reasonable best effort
and may vary by country.
3
Technical telephone support applies only to HP configured, HP and HP qualified third party hardware and software. Toll-
free calling and 24 x 7 support may not be available in some countries.
Chipset
USDT SFF CMT
Intel Q45 Express XXX
Processor
USDT SFF CMT
Intel Celeron Processors (dual core):
Intel Celeron E3200 Processor
2.40 GHz, 1M L2 cache, 800 MHz FSB
XXX
QuickSpecs
HP Compaq 8000 Elite PC
Standard Features and Configurable Components (availability may vary by country)
DA - 13424 Worldwide QuickSpecs — Version 17 — 6/25/2010 Page 6

Intel Celeron E3300 Processor
2.50 GHz, 1M L2 cache, 800 MHz FSB
XXX
Intel Pentium Processors:
Intel Pentium E5300 Processor
2.60 GHz, 2M L2 cache, 800 MHz FSB
XXX
Intel Pentium E5400 Processor
2.70 GHz, 2M L2 cache, 800 MHz FSB
XXX
Intel Pentium E6300 Processor
2.80 GHz, 2M L2 cache, 1066 MHz FSB
XXX
Intel Pentium E6500 Processor
2.93 GHz, 2M L2 cache, 1066 MHz FSB
XXX
Intel Core 2 Duo Processors:
Intel Core 2 Duo E7500 Processor
2.93 GHz, 3M L2 cache, 1066 MHz FSB
XXX
Intel Core 2 Duo E7600 Processor
3.06 GHz, 3M L2 cache, 1066 MHz FSB
XXX
Intel Core 2 Duo E8400 Processor
3.0 GHz, 6M L2 cache, 1333 MHz FSB with vPro Technology
XXX
Intel Core 2 Duo E8500 Processor
3.16 GHz, 6M L2 cache, 1333 MHz FSB with vPro Technology
XXX
Intel Core 2 Duo E8600 Processor
3.33 GHz, 6M L2 cache, 1333 MHz FSB with vPro Technology
XXX
Intel Core 2 Quad Processors:
Intel Core 2 Quad Q8400 Processor
2.66 GHz, 4M L2 cache, 1333 MHz FSB
X X
Intel Core 2 Quad Q8400s Processor (low power)
2.66 GHz, 4M L2 cache, 1333 MHz FSB
X
Intel Core 2 Quad Q9500 Processor
2.83 GHz, 6M L2 cache, 1333 MHz FSB
X X
Intel Core 2 Quad Q9505 Processor
2.83 GHz, 6M L2 cache, 1333 MHz FSB with vPro Technology
X X
Intel Core 2 Quad Q9505s Processor (low power)
2.83 GHz, 6M L2 cache, 1333 MHz FSB with vPro Technology
X
Intel Core 2 Quad Q9550 Processor
2.83 GHz, 12M L2 cache, 1333 MHz FSB with vPro Technology
X X
Intel Core 2 Quad Q9550s Processor (low power)
2.83 GHz, 12M L2 cache, 1333 MHz FSB with vPro Technology
X
Intel Core 2 Quad Q9650 Processor
3.0 GHz, 12M L2 cache, 1333 MHz FSB with vPro Technology
X X
Intel Core 2 Processor with vPro Technology
All HP Compaq 8000 Elite Series models featuring this technology include processors which are part of the Intel 2010
Stable Image Platform Program (SIPP) designed to ensure the stability promise inherent in the value proposition of the HP
Compaq 8000 Elite Series Business PC, thus making these models the most stable, secure, and manageable platforms
available to enterprises today.
The 2010 SIPP processors are:
Core 2 Duo E8400, E8500, E8600
Core 2 Quad Q9505, Q9505s, Q9550, Q9550s, Q9650
Intel's Core 2 Processor with vPro Technology suite of features includes:
QuickSpecs
HP Compaq 8000 Elite PC
Standard Features and Configurable Components (availability may vary by country)
DA - 13424 Worldwide QuickSpecs — Version 17 — 6/25/2010 Page 7

Intel Advanced Management Technology (AMT) v5.0 – An advanced set of remote management features and
functionality which provides network administrators the latest and most effective tools to remotely discover, heal, and
protect networked client systems regardless of the system's health or power state. AMT 5.0 includes all features described
as part of Intel Standard Manageability plus the following advanced management functions:
Fast Call for Help – a client inside or outside the firewall may initiate a call for help via BIOS screen, periodic
connections, or alert triggered connection
Remote Scheduled Maintenance – pre-schedule when the PC connects to the IT or service provider console for
maintenance. Remote PCs can get required patches, be inventoried, etc by connecting to their IT console or Service
Provider when it's convenient
Remote Alerts – automatically alert IT or service provider if issues arise
Access Monitor – Provides oversight into Intel® AMT actions to support security requirements
Microsoft NAP Support – Allows AMT 5.0 to gain access to a Microsoft NAP enabled 802.1x network OOB to enable OOB
SW updates, inventories, remote diagnostics, etc. NAP is a new platform and solution that controls access to network
resources based on a client computer's identity and compliance with corporate governance policy. NAP allows network
administrators to define granular levels of network access based on who a client is, the groups to which the client belongs,
and the degree to which that client is compliant with corporate governance policy. If a client is not compliant, NAP provides
a mechanism to automatically bring the client back into compliance and then dynamically increase its level of network
access.
When a client attempts to access the network or communicate on the network, it must present its system health state or
proof of health compliance. If a client cannot prove it is compliant with system health requirements (for example, that it has
the latest operating system and antivirus updates installed), its access to the network or communication on the network can
be limited to a restricted network containing server resources so that health compliance issues can be remedied. After the
updates are installed, the client requests access to the network or attempts the communication again. If compliant, the
client is granted unlimited access to the network or the communication is allowed.
Redundant Array of Independent Drives (RAID)
Flexible implementation :
DriveLock is supported while in RAID mode. Users can manage the DriveLock password from within F10 Setup.
Locked drives will be displayed as such in the RAID option ROM interface.
Hard drive information can be viewed within F10 Setup while in RAID mode. Previously, the hard drives will not
appear in Drive Configuration when switching to RAID mode.
DPS Self Test can be executed on physical hard drives while in RAID mode.
The RAID Setup Utility (accessed through CTRL-I) can be protected by the F10 Setup password.
NOTE: RAID 1 is the only RAID configuration offered via factory configurations. The pre-configured systems:
Are only available on the CMT and SFF form factors. The USDT does not support RAID as it does not allow for more
than one hard disk drive.
Are complete RAID systems and have both drives installed. If the CMT is configured with three hard disk drives, the
third drive is would be unpartitioned and not part of the RAID array
Have the necessary Option ROM configuration.
Are pre-loaded and pre-installed with all required Intel software.
Include a preinstalled operating system that is mirrored mode out of the box.
Please refer to the HP White Paper titled “Advanced Host Controller Interface (AHCI) and Redundant Array of Independent
Disks (RAID) on HP Compaq 8000 Elite Series PCs” at: http://www.hp.com for more information and instructions.
QuickSpecs
HP Compaq 8000 Elite PC
Standard Features and Configurable Components (availability may vary by country)
DA - 13424 Worldwide QuickSpecs — Version 17 — 6/25/2010 Page 8

DDR3 Synchronous DRAM NON-ECC System Memory
Memory upgrades are accomplished by adding single or multiple DIMMs of the same or varied sizes. This chart does not
represent all possible memory configurations. The HP Compaq 8000 Elite Series PC supports non-ECC DDR3 PC3-10600
(1333 MHz) and PC3-8500 (1066 MHz) memory.
CAUTION: You must shut down the computer and disconnect the power cord before adding or removing memory modules.
Regardless of the power-on state, voltage is always supplied to the memory modules as long as the computer is plugged in
to an active AC outlet. Adding or removing memory modules while voltage is present may cause irreparable damage to the
memory modules or system board.
Ultra-slim Desktop
Maximum Memory * Supports up to 8 GB of DDR3 SDRAM using SO-DIMM modules. Slot 1 is black and must always
be populated. Not all memory configurations possible are represented below.
NOTE: For systems configured with more than 3 GB of memory and a 32-bit operating system, all
memory may not be available due to system resource requirements.
SO-DIMM Size Slot
Channel A (black) Channel B (white)
1 GB 1 GB
2 GB
(dual channel symmetric)
1 GB 1 GB
4 GB
(dual channel symmetric)
2 GB 2 GB
8 GB
(dual channel symmetric)
4 GB 4 GB
* The Intel Q45 Express chipset includes a built-in Management Engine (ME), which allocates memory for manageability
functions. Management Engine memory is shared with system memory. If the PC contains a single SO-DIMM, 16 MB of
memory is pre-allocated for it at system startup. If the PC contains two SO-DIMMs, 32 MB of memory is pre-allocated. This
memory is not made available to the operating system, just as pre-allocated video memory is not available.
Small Form Factor and Convertible Minitower
Maximum Memory * Supports up to 16 GB of DDR3 SDRAM using DIMM modules. Slot 1 is black and must
always be populated. Not all memory configurations possible are represented below.
NOTE: For systems configured with more than 3 GB of memory and a 32-bit operating
system, all memory may not be available due to system resource requirements. Addressing
memory above 4 GB requires a 64-bit operating system.
QuickSpecs
HP Compaq 8000 Elite PC
Standard Features and Configurable Components (availability may vary by country)
DA - 13424 Worldwide QuickSpecs — Version 17 — 6/25/2010 Page 9

DIMM Size Slot
Channel A Channel B
1 (black) 2 (white) 3 (white) 4 (white)
1 GB 1 GB
2 GB
(dual channel
symmetric)
1 GB 1 GB
4 GB
(dual channel
symmetric)
1 GB 1 GB 1 GB 1 GB
8 GB
(dual channel
symmetric)
2 GB 2 GB 2 GB 2 GB
16 GB
(dual channel
symmetric)
4 GB 4 GB 4 GB 4 GB
* The Intel Q45 Express chipset includes a built-in Management Engine (ME), which allocates memory for manageability
functions. Management Engine memory is shared with system memory. If the PC contains a single DIMM, 16 MB of memory
is pre-allocated for it at system startup. If the PC contains two DIMMs, 32 MB of memory is pre-allocated. This memory is not
made available to the operating system, just as pre-allocated video memory is not available.
Memory Configurations
USDT SFF CMT
1-GB DDR3 SDRAM PC3-10600 (1,333MHz) Non ECC (1 x 1GB) XXX
2-GB DDR3 SDRAM PC3-10600 (1,333MHz) Non ECC (1 x 2GB) XXX
2-GB DDR3 SDRAM PC3-10600 (1,333MHz) Non ECC (2 x 1GB) XXX
3-GB DDR3 SDRAM PC3-10600 (1,333MHz) Non ECC (1GB + 2GB) XXX
4-GB DDR3 SDRAM PC3-10600 (1,333MHz) Non ECC (4 x 1GB) X X
4-GB DDR3 SDRAM PC3-10600 (1,333MHz) Non ECC (1 x 4GB) XXX
4-GB DDR3 SDRAM PC3-10600 (1,333MHz) Non ECC (2 x 2GB) XXX
8-GB DDR3 SDRAM PC3-10600 (1,333MHz) Non ECC (2 x 4GB) XXX
8-GB DDR3 SDRAM PC3-10600 (1,333MHz) Non ECC (4 x 2GB) X X
16-GB DDR3 SDRAM PC3-10600 (1,333MHz) Non ECC (4 x 4GB) X X
Ultra-slim Desktop Small Form Factor Convertible Minitower
QuickSpecs
HP Compaq 8000 Elite PC
Standard Features and Configurable Components (availability may vary by country)
DA - 13424 Worldwide QuickSpecs — Version 17 — 6/25/2010 Page 10

Storage - Drive Support
USDT SFF CMT
SDR ODD HDD
SSD
MCR ODD HDD
SSD
MCR ODD HDD
SSD
Quantity
Supported
111112123
Position 1 2 3 1 3 2,1 3 1,2 4,5,6
Hard Disk Drives
USDT SFF CMT
160GB 2.5” Hard Disk Drive
7,200 rpm, 8MB cache, 3.0 GB/s, NCQ, Smart IV
X
160GB 3.5” Hard Disk Drive
7,200 rpm, 8MB cache, 3.0 GB/s, NCQ, Smart IV
X X
160GB 2.5” Hard Disk Drive
10,000 rpm, 16MB cache, 3.0 GB/s, NCQ, Smart III
X X
160GB Removable Hard Disk Drive
7,200 rpm, 8MB cache, 3.0 GB/s, NCQ, Smart IV
X X
250GB 2.5” Hard Disk Drive
7,200 rpm, 8MB cache, 3.0 GB/s, NCQ, Smart IV
X
250GB 3.5” Hard Disk Drive
7,200 rpm, 8MB cache, 3.0 GB/s, NCQ, Smart IV
X X
250GB Removable Hard Disk Drive
7,200 rpm, 8MB cache, 3.0 GB/s, NCQ, Smart IV
X X
320GB 3.5 ” Hard Disk Drive
7,200 rpm, 8MB cache, 3.0 GB/s, NCQ, Smart IV
X X
320GB Removable Hard Disk Drive
7,200 rpm, 8MB cache, 3.0 GB/s, NCQ, Smart IV
X X
500GB 3.5” Hard Disk Drive
7,200 rpm, 16MB cache, 3.0 GB/s, NCQ, Smart IV
X X
500GB Removable Hard Disk Drive
7,200 rpm, 16MB cache, 3.0 GB/s, NCQ, Smart IV
X X
1 TB 3.5” Hard Disk Drive
7,200 rpm, 16MB cache, 3.0 GB/s, NCQ, Smart IV
X X
Solid State Drives
USDT SFF CMT
64GB 2.5” Solid State Drive X
5.25-inch Optical Drives
USDT SFF CMT
DVD-ROM Drive
1
X X
SuperMulti LightScribe DVD Writer Drive
1,2,3
X X
Blu-Ray Writer Drive X X
QuickSpecs
HP Compaq 8000 Elite PC
Standard Features and Configurable Components (availability may vary by country)
DA - 13424 Worldwide QuickSpecs — Version 17 — 6/25/2010 Page 11

Slimline Optical Drives
USDT SFF CMT
DVD-ROM Drive
1
X
SuperMulti LightScribe DVD Writer Drive
1,2,3
X
1
For playing DVDs, Corel WinDVD 8
2
For writing CDs, choice of Sonic/Roxio Easy Media Creator 9 orRoxio Business Creator 10
3
For writing CDs and DVDs, video editing and authoring DVDs, choice of Sonic/Roxio Easy Media Creator 9 or Roxio
Business Creator 10
Media Card Readers
USDT SFF CMT
Media Card Reader (22-in-1) X X
Media Card Reader (22-in-1) with 1394 port X X
Secure Digital (SD) HC Reader X
Security
USDT SFF CMT
Trusted Platform Module (TPM) 1.2
1
XXX
Stringent Security (via BIOS)
2
XXX
SATA Port Disablement (via BIOS) XXX
Drive Lock XXX
RAID Configurations X X
HP ProtectTools Embedded Security Software XXX
Serial, Parallel, USB enable/disable (via BIOS) XXX
Optional USB Port Disable at factory (user configurable via BIOS) XXX
Removable Media Write/Boot Control XXX
Power-On Password (via BIOS) XXX
Setup Password (via BIOS) XXX
Solenoid Hood Lock / Sensor X X
Hood Sensor X
Support for chassis padlocks and cable lock devices XXX
1
TPM module disabled where use is restricted by law; for example, Russia.
2
This setting is defaulted to disable, but when enabled, the PW jumper will not clear the BIOS pre-boot authentication
passwords.
Network Interface Connection
USDT SFF CMT
Intel 82567LM GbE Network Connection (integrated) XXX
Intel Gigabit CT Desktop NIC Card X X
Broadcom NetXtreme GbE Ethernet Plus NIC (PCIe x1) X X
NOTE: The integrated network connection is required to support the vPro Technology features.
HP 802.11 b/g/n Wireless NIC (PCIe x1) X X
Intel Wi-Fi Link 5100 a/b/g/n Wireless NIC (mini PCI) X
NOTE: These wireless network interface solutions will disable the vPro Technology features.
Modem
USDT SFF CMT
QuickSpecs
HP Compaq 8000 Elite PC
Standard Features and Configurable Components (availability may vary by country)
DA - 13424 Worldwide QuickSpecs — Version 17 — 6/25/2010 Page 12

LSI Hi-Speed 56K International Soft Modem (PCIe x1) X X
Graphics
USDT SFF CMT
Intel Graphics Media Accelerator 4500 (integrated) XXX
Nvidia GeForce 310 DP PCIe x16 Graphics Card X X
Nvidia Quadro NVS 290 Graphics Card X X
Nvidia Quadro NVS 295 Graphics Card X X
ATI Radeon HD 4550 Graphics Card* X X
ATI Radeon HD 4650 DP (1GB) PCIe x16 Graphics Card X X
HP ADD2 SDVO + DVI-D Video Adapter X X
* Not available until January 2010.
HP DisplayPort to DVI-D Adapter XXX
HP DisplayPort to VGA Adapter XXX
Audio/Visual
USDT SFF CMT
High Definition Audio with Realtek ALC261 codec (all ports are stereo) XXX
Microphone/Headphone * and dedicated headphone front ports XXX
Line-out and Line-In rear Ports * XXX
Multi-streaming capable * XXX
Internal Speaker (standard) XXX
HP Thin USB Powered Speakers XXX
HP TV Tuner Mini PCIe Card X
HP TV Tuner PCIe x1 Card X X
* The front microphone port is re-taskable as a Line-in, Microphone-in or Headphone . Rear audio input ports are re-
taskable as Line-in or Microphone-in. External speakers must be powered externally. Multistreaming can be enabled in
the Realtek control panel to allow independent audio streams to be sent to/from the front and rear jacks. This allows
for different audio applications to use separate audio ports on the system. For example, the front jacks could be used
with a headset for a communications application while the rear jacks are being used with external speakers and a
multimedia application.
Input Devices
USDT SFF CMT
PS/2 Standard Keyboard XXX
USB Standard Keyboard XXX
USB SmartCard Keyboard XXX
USB Mini Keyboard XXX
USB & PS/2 Washable Keyboard XXX
PS/2 Optical Scroll Mouse XXX
USB Optical Scroll Mouse XXX
USB Laser Scroll Mouse XXX
Miscellaneous
USDT SFF CMT
FireWire (IEEE 1394) Card X X
QuickSpecs
HP Compaq 8000 Elite PC
Standard Features and Configurable Components (availability may vary by country)
DA - 13424 Worldwide QuickSpecs — Version 17 — 6/25/2010 Page 13

Serial Port Adapter X X
Parallel Port Adapter X X
eSATA Port Adapter X X
PC Tower Stand X X
Configure CMT in desktop orientation X
Rear Port/Cable Control Cover X
QuickSpecs
HP Compaq 8000 Elite PC
Standard Features and Configurable Components (availability may vary by country)
DA - 13424 Worldwide QuickSpecs — Version 17 — 6/25/2010 Page 14

Communications
USDT SFF CMT Part Number
HP Wireless 802.11 b/g/n NIC Card X X FH971AA
Broadcom NetXtreme GbE Ethernet Plus NIC Card X X FS215AA
Intel Gigabit CT Desktop NIC Card X X FH969AA
LSI Hi-Speed 56K Int'l Soft Modem Card X X FH970AA
RJ11 Modem Adapter Kit X X DC131C
NOTE: The use of a NIC Card (wired or wireless) will disable the vPro Technology features.
Graphics
USDT SFF CMT Part Number
ATI Radeon HD 4550 Graphics Card* X X AT042AA
ATI Radeon HD 4650 DP (1GB) PCIe x16 Graphics Card X VN566AA
Nvidia Quadro NVS 290 PCIe x16 Graphics Card X X KG748AA
Nvidia Quadro NVS 290 PCIe x1 Graphics Card X KN586AA
Nvidia Quadro NVS 295 Graphics Card X X FY943AA
Nvidia GeForce 310 DP PCIe x16 Graphics Card X X VG885AA
HP ADD2 SDVO + DVI-D Video Adapter X X DY674A
* Not available until January 2010.
DMS59 DVI Dual-head Connector Cable X X DL139A
HP DVI to DVI cable X X DC198A
HP DisplayPort To DVI-D adapter XXX FH973AA
HP DisplayPort To DL DVI-D adapter XXX NR078AA
HP DisplayPort to VGA Adapter XXX AS615AA
HP DisplayPort Cable Kit XXX VN567AA
Hard Disk Drives
USDT SFF CMT Part Number
HP 160GB SATA NCQ SMART IV Hard Disk Drive X X PY277AT
HP 250GB SATA NCQ SMART IV Hard Disk Drive X X PY278AA
HP 500GB SATA NCQ SMART IV Hard Disk Drive X X KW347AA
HP eSATA Adapter X X FH966AA
HP Removable SATA Hard Drive Enclosure (frame & carrier) X X RY102AA
HP Removable SATA Hard Drive Enclosure (Carrier Only) X X RY103AA
QuickSpecs
HP Compaq 8000 Elite PC
After-Market Options (availability may vary by region)
DA - 13424 Worldwide QuickSpecs — Version 17 — 6/25/2010 Page 15

Input/Output Devices
USDT SFF CMT Part Number
HP PS/2 Standard Keyboard XXX DT527A
HP USB Standard Keyboard XXX DT528A
HP USB Gray Keyboard XXX DT529A
HP 2.4GHz Wireless Keyboard & Mouse XXX NB896AA
HP USB Mini Keyboard XXX AS601AA
HP USB Washable Keyboard XXX VF097AA
HP PS/2 Optical Scroll Mouse XXX EY703AA
HP USB Optical Scroll Mouse XXX DC172B
HP USB Laser Mouse XXX GW405AA
DDR3 SDRAM System Memory
USDT SFF CMT Part Number
1 GB DIMM X X AT023AA
1 GB SO-DIMM X TBD
2 GB DIMM X X AT024AA
2 GB SO-DIMM X VH640AA
4 GB DIMM X X TBD
4 GB SO-DIMM X VH641AA
HP Monitors
USDT SFF CMT Part Number
All HP monitors are supported that accept a graphics output provided by this PC.
Multimedia Devices
USDT SFF CMT Part Number
HP Thin USB Powered Speakers XXX KK912AA
DVD-ROM Drive X X AR629AA
DVD-ROM Drive (Slimline) X VP033AA
SuperMulti LightScribe Drive X X AR630AA
SuperMulti LightScribe Drive (Slimline) X VP034AA
Blu-Ray Writer Drive X X AR482AA
Removable Media Storage
USDT SFF CMT Part Number
HP USB External Diskette Drive XXX DC141B
HP Media Card Reader (22-in-1) X X AR941AA
HP Media Card Reader (22-in-1) with FireWire (IEEE 1394) X X AR942AA
QuickSpecs
HP Compaq 8000 Elite PC
After-Market Options (availability may vary by region)
DA - 13424 Worldwide QuickSpecs — Version 17 — 6/25/2010 Page 16

Security Devices
USDT SFF CMT Part Number
HP/Kensington MicroSaver Cable Lock XXX PC766A
HP Business PC Security Lock XXX PV606AA
HP (2009) USDT Rear Port Controller Cover X VN571AA
HP 2009 (SFF) Solenoid Lock and Hood Sensor X BP428AA
HP (CMT) Solenoid Lock and Hood Sensor X DE618A
HP Wall Mount/Security Sleeve X TBD
HP ProtectTools version 5.0 (1 User) XXX TBD
HP USB SmartCard Keyboard XXX ED707AA
Software Solutions
USDT SFF CMT Part Number
HP Client Automation Standard XXX T3488AA (qty 1)
TA599AA
(qty 10)
TA600AA
(qty 100)
TA601AA
(qty 500)
T3489AA
(qty 1000)
Stands and Accessories
USDT SFF CMT Part Number
HP Integrated Work Center Stand X GN783AA
HP (2009) USDT Tower Stand X VN568AA
HP (2009) SFF Tower Stand X VN569AA
HP Serial Port Adapter X X PA716A
HP Parallel Port Adapter X X KD061AA
HP 5.25” Blank Bezel Kit (50 pack) X X DC177B
HP FireWire (IEEE 1394) Card X X PA997A
QuickSpecs
HP Compaq 8000 Elite PC
After-Market Options (availability may vary by region)
DA - 13424 Worldwide QuickSpecs — Version 17 — 6/25/2010 Page 17

Ultra-slim Desktop Small Form Factor Convertible Minitower
Dimensions
Chassis
(H x W x D)
2.6 x 9.9 x 10 in
66 x 251.5 x 254 mm
3.95 x 13.30 x 14.9 in
100 x 338 x 378.5 mm
17.63 x 7.00 x 17.5 in
447.8 x 177.8 x 444.5 mm
System Volume 257.5 cu in
4.22 L
790.26 cu in
12.95 L
2160 cu in
35.4 L
Tower Stand
(H x W x D)
1.07 x 4.92 x 6.69 in
27.2 x 124.9 x 169.9 mm
1.12 x 7.01 x 7.87 in
28.5 x 178 x 200 mm
N/A
Packaging
(H x W x D)
8.60 x 15.68 x 19.68 in
218.4 x 398.3 x 499.9 mm
9.00 x 19.68 x 23.38 in
228.6 x 499.9 x 593.85 mm
22.64 x 12.72 x 24.41 in
575.0 x 323 x 620 mm
System Weight * 6.75 lb
3.07 kg
16.72 lb
7.6 kg
24.54 lb
11.15 kg
Shipping Weight * 14.42 lb
6.54 kg
17.86 lb
8.1 kg
34.0 lb
15.42 kg
Max Supported Weight
(desktop orientation)
77 lb
35 kg
77 lb
35 kg
77 lb
35 kg
*Configured with 1 hard drive, 1 optical drive, no diskette drive, and no PCI card.
I/O Ports
Ultra-slim Desktop Small Form Factor Convertible Minitower
USB 2.0 Front – four (4) ports
Rear – six (6) ports
Serial N/A one port standard; second port available optionally
Parallel N/A one port available as an option
eSATA N/A one port available as an option
PS/2 color coded support for keyboard (purple) and mouse (green)
Video VGA and DisplayPort provide integrated dual independent monitor support
DVI output available via optional DisplayPort to DVI Adapter
Audio Front – microphone & headphone
Rear – line input (supports microphone or line input), line out
NOTE: See Audio/Visual section for information on re-taskable audio ports.
NIC Industry standard RJ-45 port accesses the integrated network interface controller
Slots
Ultra-slim Desktop Small Form Factor Convertible Minitower
Type and quantity (1) mini PCI Express (1) PCI
(2) PCI Express x1
(1) PCI Express x16
(3) PCI
(1) PCI Express x1 (half-
length)
(2) PCI Express x16
Slot specifications Low profile cards
25W cards
Full height
Primary x16 slot supports
75W or 35W card
Secondary x16 slot supports
35W card
Secondary slot functions
electrically as a x4 slot
PCI Slots N/A 1 slot
low profile – 2.5"
length – 6.6"
max. power – 25W
3 slots
full height – 4.2"
full length
max. power – 25W
QuickSpecs
HP Compaq 8000 Elite PC
Technical Specifications
DA - 13424 Worldwide QuickSpecs — Version 17 — 6/25/2010 Page 18

PCI Express x16 Slot
(Supports discrete
graphics cards)
N/A 1 slot
low profile – 2.5"
length – 6.6"
max. power –25W
2 slots
full height – 4.2"
full length
max. power – 75W (primary)
max. power – 35W
(secondary)
PCI Express x1 Slot N/A 2 slots
low profile – 2.5"
length – 6.6"
max. power – 10W
1 slot
half height – 2.5"
half length
max. power – 10W
Bays
Ultra-slim Desktop Small Form Factor Convertible Minitower
3.5" external N/A 1 bay available for Media Card
Reader unless used for a
secondary hard drive
N/A
5.25" external N/A 1 bay – 8.19" depth 3 bays
Top two bays accept drives
up to 8.19" depth
Bottom bay accepts drives
up to 5.7" depth
Slimline 1 bay for ODD N/A N/A
Secure Digital (SD)
Reader
SD Reader or blank N/A N/A
Internal Drive Bays 1 bay for 2.5" drive 1 bay for 3.5" drive 3 bays for 3.5" drives
Controller
Ultra-slim Desktop Small Form Factor Convertible Minitower
Hard Drive Controller Serial ATA
Supports SATA 1.5-GB/s and 3.0-GB/s
SATA Interfaces (1) Total (4) Total:
(3) common SATA
(1) eSATA
(5) Total:
(4) common SATA
(1) eSATA
Host SATA Controller Advanced Host Controller Interface (AHCI) Revision 1.2. The specification includes a description
of the hardware/software interface between system software and the host controller hardware.
Unit Environment and Operating Conditions
General Unit Operating Guidelines
Keep the computer away from excessive moisture, direct moisture and the extremes of heat and cold, to ensure that
unit is operated within the specified operating range.
Leave a 10.2 cm (4 in) clearance on all vented sides of the computer to permit the required airflow.
Never restrict airflow into the computer by blocking any vents or air intakes.
Do not stack computers on top of each other or place computers so near each other that they are subject to each
other's re-circulated or preheated air.
Occasionally clean the air vents on the front, back, and any other vented side of the computer. Lint, dust and other
foreign matter can block the vents and limit the airflow.
If the computer is to be operated within a separate enclosure, intake and exhaust ventilation must be provided on the
enclosure, and the same operating guidelines listed above will still apply.
Temperature Range Operating: 50° to 95° F (10° to 35° C) *
Non-operating: –22° to 140° F(–30° to 60° C)
Relative Humidity Operating: 10% to 90% (non-condensing at ambient)
Non-operating: 5% to 95% (non-condensing at ambient)
Maximum Altitude
(unpressurized)
Operating: 10,000 ft (3048 m)
Non-operating: 30,000 ft (9144 m)
QuickSpecs
HP Compaq 8000 Elite PC
Technical Specifications
DA - 13424 Worldwide QuickSpecs — Version 17 — 6/25/2010 Page 19

*Operating temperature is de-rated 1.0 deg C per 300 m (1000 ft) to 3000 m (10,000 ft) above sea level, no direct
sustained sunlight. Maximum rate of change is 10 deg C/Hr. The upper limit may be limited by the type and number of
options installed.
Power Supply
Ultra Slim Desktop Small Form Factor Convertible Minitower
Standard Efficiency N/A 240W active PFC 320W active PFC
High Efficiency * 135W active PFC
87% efficient
240W active PFC
87/89/85% efficient at
20/50/100% load
320W active PFC
87/89/85% efficient at
20/50/100% load
Operating Voltage Range 90 – 264 VAC 90 – 264 VAC 90 – 264 VAC
Rated Voltage Range 100 – 240 VAC 100 – 240 VAC 100 – 240 VAC
Rated Line Frequency 50/60 Hz 50/60 Hz 50/60 Hz
Operating Line Frequency
Range
47 – 63 Hz 47 – 63 Hz 47 – 63 Hz
Rated Input Current N/A 4A 5.5A
Rated Input Current with
Energy Efficient *Power
Supply
2.4A 4A 5.5A
Current Leakage
(NFPA 99)
< 250 µA < 275 µA < 450 µA
Power Supply Fan N/A 92mm variable speed 92mm variable speed
External Power Adapter
Dimensions 6.7 x 2.6 x 1.5 in N/A N/A
Total Cord Length 12 ft 8 in N/A N/A
*High efficiency power supply is a requirement for ENERGY STAR qualification in conjunction with a select range of
processors and modules
ROM BIOS Information
Key features of the HP BIOS include:
Deployment and manageability – HP BIOS provides several technologies that help integrate the HP Elite PC into the
enterprise, such as PXE, remote configuration, remote control, and F10 Setup support for 12 languages.
Select models feature either Intel Standard Manageability or Core 2 processor with vPro Technology.
Stability – HP BIOS supports the HP stable product roadmap by releasing only critical BIOS changes to the factory
and advanced change notification.
Computrace agent – For tracking and tracing services, available in select countries, separate software and purchase
of a subscription is required.
Thermal and power management – The HP BIOS provides and enables thermal and power management
technologies so component temperatures are managed for high reliability and to assist in operating the HP Business
Desktop computer in any enterprise environment.
Acoustic performance – Industry leading acoustic emissions across the range of operating conditions.
Serviceability – HP BIOS provides diagnostic and detailed service information.
Upgrades and recovery – HP BIOS provides numerous ways to upgrade HP Business Desktop computers, including
BIOS updates from within DOS (Flashbin), BIOS updates from within Windows (HPQFlash), HP Client Manager, and
fail-safe recovery. In addition, the HP Business Desktop BIOS Utilities tool enables replicated BIOS setup throughout
the Enterprise; it is available from within the BIOS software and from the support website.
Additional HP BIOS Features
Power-On password – Helps prevent an unauthorized user from powering on the system.
Administrator password – Also known as the setup password, this helps prevent unauthorized changes to the system
configuration. If the administrator password is not known, the BIOS version cannot be changed and changes cannot
be made to BIOS settings using F10 setup or under the OS.
Advanced Configuration and Power Interface (ACPI) – Represents a significant innovation in power and configuration
management, allowing operating systems and applications to manage power based on activity and usage. HP Elite
QuickSpecs
HP Compaq 8000 Elite PC
Technical Specifications
DA - 13424 Worldwide QuickSpecs — Version 17 — 6/25/2010 Page 20
