HP Compaq d538 MT Operating and maintenance manual

Hardware Reference Guide
HP Compaq Business Desktops
d538 Convertible Minitower
Document Part Number: 354524-001
November 2003
This guide provides basic information for upgrading this computer
model.

© Copyright 2003 Hewlett-Packard Development Company, L.P.
The information contained herein is subject to change without notice.
Microsoft, MS-DOS, Windows, and Windows NT are trademarks of Microsoft
Corporation in the U.S. and other countries.
Intel, Pentium, Intel Inside, and Celeron are trademarks of Intel Corporation in
the U.S. and other countries.
Adobe, Acrobat, and Acrobat Reader are trademarks or registered trademarks of
Adobe Systems Incorporated.
The only warranties for HP products and services are set forth in the express
warranty statements accompanying such products and services. Nothing herein
should be construed as constituting an additional warranty. HP shall not be liable
for technical or editorial errors or omissions contained herein.
This document contains proprietary information that is protected by copyright.
No part of this document may be photocopied, reproduced, or translated to
another language without the prior written consent of Hewlett-Packard
Company.
ÅWARNING: Text set off in this manner indicates that failure to follow
directions could result in bodily harm or loss of life.
ÄCAUTION: Text set off in this manner indicates that failure to follow
directions could result in damage to equipment or loss of information.
Hardware Reference Guide
HP Compaq Business Desktops
d538 Convertible Minitower
First Edition (November 2003)
Document Part Number: 354524-001

Hardware Reference Guide www.hp.com iii
Contents
1 Product Features
Standard Configuration Features. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1–1
Front Panel Components. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1–2
Rear Panel Components . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1–3
Easy Access Keyboard . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1–4
Customizing the Easy Access Buttons . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1–5
Using the Windows Logo Key . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1–5
Special Mouse Functions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1–6
Serial Number Location . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1–6
Changing from a Minitower to a Desktop Configuration . . . . . . . . . . . . . . . . . . . . . . . 1–7
Changing from a Desktop to a Minitower Configuration . . . . . . . . . . . . . . . . . . . . . . 1–10
2 Hardware Upgrades
Serviceability Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2–1
Warnings and Cautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2–1
Smart Cover Lock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2–2
Using the Smart Cover FailSafe Key . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2–2
Removing the Computer Access Panel. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2–4
Removing the Front Bezel. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2–5
Removing Bezel Blanks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2–6
Installing Additional Memory. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2–7
DIMMs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2–7
DDR-SDRAM DIMMs. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2–7
DIMM Sockets . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2–8
Installing DDR-SDRAM DIMMs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2–10
Installing or Removing an Expansion Card . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2–12
Drive Positions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2–17
Installing Additional Drives . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2–18
Installing an Optical or other Removable Storage Device . . . . . . . . . . . . . . . . . . 2–19

iv www.hp.com Hardware Reference Guide
Contents
Installing a Hard Drive into a 3.5-inch Drive Bay . . . . . . . . . . . . . . . . . . . . . . . . 2–22
Removing a Drive from the Drive Bay. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2–26
Working with the MultiBay . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2–30
“Hot-Plugging” or “Hot-Swapping” MultiBay Drives. . . . . . . . . . . . . . . . . . . . . 2–30
Partitioning and Formatting a MultiBay Hard Drive . . . . . . . . . . . . . . . . . . . . . . 2–31
Uninstalling the MultiBay Security Screw. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2–32
Inserting a Drive into the MultiBay . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2–33
Removing a Drive from the MultiBay . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2–34
A Specifications
B PATA Hard Drive Installation Guidelines
Using the Cable-Select Feature with Parallel ATA (PATA) Devices. . . . . . . . . . . . . . B–1
Guidelines for Installing PATA Drives . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . B–1
C Battery Replacement
D Security Lock Provisions
Installing a Security Lock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . D–1
E Port Security Bracket
Installing the Port Security Bracket. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . E–1
Removing the Port Security Bracket. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . E–5
F Electrostatic Discharge
Preventing Electrostatic Damage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . F–1
Grounding Methods. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . F–1
G Routine Computer Care and Shipping Preparation
Routine Computer Care. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . G–1
Optical Drive Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . G–2
Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . G–2
Cleaning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . G–2
Safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . G–2
Shipping Preparation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . G–3

Hardware Reference Guide www.hp.com v
Contents
Index

vi www.hp.com Hardware Reference Guide
Contents

Hardware Reference Guide www.hp.com 1–1
1
Product Features
Standard Configuration Features
The HP Compaq Convertible Minitower computer can be easily
converted to a desktop. Features may vary depending on the model.
For a complete listing of the hardware and software installed in the
computer, run Diagnostics for Windows. Instructions for using this
utility are provided in the Troubleshooting Guide on the
Documentation Library CD.
Compaq Convertible Minitower Configuration

1–2 www.hp.com Hardware Reference Guide
Product Features
Front Panel Components
Drive configuration may vary by model.
Front Panel Components
1Optical Drives 7Optical Drive Eject Buttons
2Optical Drive Activity Lights 8Power Button
3Diskette Drive (optional) 9Power On Light
4Diskette Drive Activity Light (optional) -USB (Universal Serial Bus) Ports
5Diskette Eject Button (optional) ;Headphone Jack
6Hard Drive Activity Light <Microphone Connector
✎An optical drive is a CD-ROM, CD-R/RW, DVD-ROM, DVD-R/RW, or
CD-RW/DVD Combo drive.

Hardware Reference Guide www.hp.com 1–3
Product Features
Rear Panel Components
Rear Panel Components
1Power Cord Connector 7nRJ-45 Network Connector
2Voltage Select Switch 8lParallel Connector
3bPS/2 Mouse Connector 9cMonitor Connector
4aPS/2 Keyboard Connector -hHeadphone/Line-Out Connector
5oUniversal Serial Bus (USB) qjLine-In Audio Connector
6mSerial Connector wgMicrophone Connector
✎Arrangement and number of connectors may vary by model.
The monitor connector on the system board is inactive when an AGP expansion card is installed in
the computer, or when both an AGP and PCI graphics card are installed.
If only a PCI graphics card is installed, the connectors on the card and the system board may be
used at the same time. Some settings may need to be changed in F10 setup to use both connectors.
For more information about Boot Order, refer to the Computer Setup (F10) Utility Guide on the
Documentation Library CD.
If you have installed an AGP and PCI graphics card, the connectors on both cards are active and
can be used at the same time.

1–4 www.hp.com Hardware Reference Guide
Product Features
Easy Access Keyboard
Easy Access Keyboard Components
1Function Keys Perform special functions, depending on the software application
being used.
2Easy Access Buttons Provide quick access to specific Internet destinations.
3Editing Keys Includes the following: Insert, Home, Page Up, Delete, End, and
Page Down.
4Status Lights Indicate the status of the computer and keyboard settings
(Num Lock, Caps Lock, and Scroll Lock).
5Numeric Keys Work like a calculator keypad.
6Arrow Keys Used to navigate through a document or Web site. These keys
allow you to move left, right, up, and down, using the keyboard
instead of the mouse.
7Application Key* Used (like the right mouse button) to open pop-up menus in a
Microsoft Office application. May perform other functions in
other software applications.
8Windows Logo Keys* Used to open the Start menu in Microsoft Windows. Used in
combination with other keys to perform other functions.
9Ctrl Key Used in combination with another key; its effect depends on the
application software you are using.
*Keys available in select geographic regions.

Hardware Reference Guide www.hp.com 1–5
Product Features
Customizing the Easy Access Buttons
All Easy Access buttons can be reprogrammed to open any software
application or data file on the hard drive, or any Internet address.
To reprogram the Easy Access buttons, complete the following steps:
1. Double-click the keyboard icon in the notification area (lower
right corner) of the Windows taskbar. The Keyboard Properties
dialog box is displayed.
2. Click the Help button on the Keyboard Properties dialog box for
instructions.
Using the Windows Logo Key
Use the Windows Logo key in combination with other keys to
perform certain functions available in the Windows operating system.
Refer to the “Easy Access Keyboard” section to identify the Windows
Logo key.
Windows Logo Key Displays or hides the Start menu
Windows Logo Key + dDisplays the Desktop
Windows Logo Key + mMinimizes all open applications
Shift + Windows Logo Key + m Undoes Minimize All
Windows Logo Key + eLaunches My Computer
Windows Logo Key + fLaunches Find Document
Windows Logo Key + Ctrl + f Launches Find Computer
Windows Logo Key + F1 Launches Windows Help
Windows Logo Key + lLocks the computer if you are connected to a
network domain, or allows you to switch users if you
are not connected to a network domain
Windows Logo Key + rLaunches the Run dialog box
Windows Logo Key + uLaunches the Utility Manager
Windows Logo Key + Tab Activates the next Taskbar button

1–6 www.hp.com Hardware Reference Guide
Product Features
Special Mouse Functions
Most software applications support the use of a mouse. The functions
assigned to each mouse button depend on the software applications
you are using.
Serial Number Location
Each computer has a unique serial number that is located on the side
access panel. Keep this number available for use when contacting
customer service for assistance.
Serial Number Location

Hardware Reference Guide www.hp.com 1–7
Product Features
Changing from a Minitower to a Desktop
Configuration
1. If you have locked the Smart Cover Lock, see the “Smart Cover
Lock” section or use Computer Setup to unlock it.
2. Turn off the computer properly through the operating system and
turn off any external devices. Disconnect the power cord from the
power outlet and disconnect any external devices.
3. Remove the computer access panel as described in the
“Removing the Computer Access Panel” section.
4. Remove the front bezel as described in the “Removing the Front
Bezel” section.
5. Disconnect all power and data cables from the back of the drives
in the 5.25-inch drive bays.
6. To release the drives from the 5.25-inch drive bay, lift the release
tab on the green latch drive bracket for the drive. While lifting the
release tab, slide the drive from its drive bay. Repeat this step for
each 5.25-inch drive.
Releasing the 5.25-inch Drives from the Drive Bays (Minitower)

1–8 www.hp.com Hardware Reference Guide
Product Features
7. Before you reinstall each drive into the chassis, turn the drive so
that it is perpendicular to the internal 3.5-inch drive. The drive
should be parallel to the green latch drive bracket.
Installing a Drive in the Desktop Configuration
8. Gently slide the drive into the uppermost available bay until it
snaps into place. When the drive is properly inserted, the
drivelock will secure it. Repeat this step for each drive.
ÄCAUTION: The bottom 5.25-inch drive bay has a shorter depth than the
upper two bays. The bottom bay supports a drive that is no more than 6.7
inches in depth, including the cables that attach to the back of the drive.
Do not try to force a larger drive, such as an optical drive or MultiBay
drive, into the bottom bay. This could cause damage to the drive and the
system board.
The use of unnecessary force when installing any drive into the drive bay
may result in damage to the drive.
9. Reconnect all power and data cables to the drives in the 5.25-inch
drive bays.
10. Remove the bezel subpanel as described in the “Removing Bezel
Blanks” section.
ÄCAUTION: Hold the subpanel straight when you pull it away from the
front bezel. Pulling the subpanel away at an angle could damage the pins
that align it within the front bezel.

Hardware Reference Guide www.hp.com 1–9
Product Features
11. Reposition the bezel blanks within the subpanel in the proper
orientation for the desktop configuration.
12. Reposition the subpanel (rotate it 180°) with the logo at the
bottom, then snap it back into the bezel.
Changing from a Minitower to a Desktop Configuration
13. Replace the front bezel and computer access panel.
14. Reconnect the external equipment.
15. If you normally lock the Smart Cover Lock, use Computer Setup
to relock the lock and enable the Smart Cover Sensor.

1–10 www.hp.com Hardware Reference Guide
Product Features
Changing from a Desktop to a Minitower
Configuration
1. If you have locked the Smart Cover Lock, see the “Smart Cover
Lock” section or use Computer Setup to unlock it.
2. Turn off the computer properly through the operating system and
turn off any external devices. Disconnect the power cord from the
power outlet and disconnect any external devices.
3. Remove the computer access panel as described in the
“Removing the Computer Access Panel” section.
4. Remove the front bezel as described in the “Removing the Front
Bezel” section.
5. Disconnect all power and data cables from the back of the drives
in the 5.25-inch drive bays.
6. To release the drives from the 5.25-inch drive bay, press down
on the short yellow drivelock as shown. While pressing the
drivelock, pull the drives out of the drive bay.
Releasing the 5.25-inch Drives from the Drive Bays (Desktop)

Hardware Reference Guide www.hp.com 1–11
Product Features
7. Before you reinstall each drive into the chassis, turn it so that it is
in the same orientation as the internal 3.5-inch drive. The bottom
of the drive should be parallel to the yellow drivelock.
Installing a Drive in the Minitower Configuration
8. Gently slide the drive into the uppermost available bay until it
snaps into place. When the drive is properly inserted, the
drivelock will secure it. Repeat this step for each drive.
ÄCAUTION: The bottom 5.25-inch drive bay has a shorter depth than the
upper two bays. The bottom bay supports a drive that is no more than 6.7
inches in depth, including the cables that attach to the back of the drive.
Do not try to force a larger drive, such as an optical drive or MultiBay
drive, into the bottom bay. This could cause damage to the drive and the
system board.
The use of unnecessary force when installing any drive into the drive bay
may result in damage to the drive.
9. Reconnect all power and data cables to the drives in the 5.25-inch
drive bays.

1–12 www.hp.com Hardware Reference Guide
Product Features
10. Remove the bezel subpanel as described in the “Removing Bezel
Blanks” section.
ÄCAUTION: Hold the subpanel straight when you pull it away from the
front bezel. Pulling the subpanel away at an angle could damage the pins
that align it within the front bezel.
11. Reposition the bezel blanks within the subpanel in the proper
orientation for the desktop configuration.
12. Reposition the subpanel (rotate it 180°) with the logo at the
bottom, then snap it back into the bezel.
Changing from a Desktop to a Minitower Configuration
13. Replace the front bezel and computer access panel.
14. Reconnect the external equipment.
15. If you normally lock the Smart Cover Lock, use Computer Setup
to relock the lock and enable the Smart Cover Sensor.

Hardware Reference Guide www.hp.com 2–1
2
Hardware Upgrades
Serviceability Features
The computer includes features that make it easy to upgrade and
service. No tools are needed for most of the installation procedures
described in this chapter.
Warnings and Cautions
Before performing upgrades be sure to carefully read all of the
applicable instructions, cautions, and warnings in this guide.
ÅWARNING: To reduce the risk of personal injury from electrical shock
and/or hot surfaces, be sure to disconnect the power cord from the wall
outlet and allow the internal system components to cool before touching.
ÅWARNING: To reduce the risk of electrical shock, fire, or damage to the
equipment, do not plug telecommunications/telephone connectors into the
network interface controller (NIC) receptacles.
ÄCAUTION: Static electricity can damage the electrical components of the
computer or optional equipment. Before beginning these procedures,
ensure that you are discharged of static electricity by briefly touching a
grounded metal object. See Appendix F, “Electrostatic Discharge” for
more information.
ÄCAUTION: Before removing the computer cover, ensure that the
computer is turned off and that the power cord is disconnected from the
electrical outlet.

2–2 www.hp.com Hardware Reference Guide
Hardware Upgrades
Smart Cover Lock
✎The Smart Cover Lock is an optional feature included on select
models only.
The Smart Cover Lock is a software-controllable cover lock,
controlled by the setup password. This lock prevents unauthorized
access to the internal components. The computer ships with the
Smart Cover Lock in the unlocked position. For more information
about locking the Smart Cover Lock, refer to the Desktop
Management Guide on the Documentation Library CD.
Using the Smart Cover FailSafe Key
If you enable the Smart Cover Lock and cannot enter your password
to disable the lock, you will need a Smart Cover FailSafe Key to open
the computer cover. You will need the key to access the internal
computer components in any of the following circumstances:
■Power outage
■Startup failure
■PC component (for example, processor or power supply) failure
■Forgotten password
ÄCAUTION: The Smart Cover FailSafe Key is a specialized tool available
from HP. Be prepared; order this key before you need one.
To obtain a FailSafe Key:
■Contact an authorized HP reseller or service provider. Order PN
166527-001 for the wrench-style key or PN 166527-002 for the
screwdriver bit key.
■Refer to the HP Web site (www.hp.com) for ordering information.
■Call the appropriate number listed in the warranty.
